IDS806
Owner’s Manual
South Africa’s leading manufacturer and distributor of electronic security
products

Owner’s Manual
700-624-01C
2
For Service
Central Station Information:
Account #:
Telephone
Installer Information
Account #:
Telephone
This alarm is to be installed and maintained by an IDS trained installer.

Owner’s Manual
700-624-01C
3
Contents
For Service............................................................................................................................2
Contents...............................................................................................................................3
Glossary................................................................................................................................5
Introduction to the IDS806 ..................................................................................................6
System Information .............................................................................................................9
Arming the System.............................................................................................................10
Disarming the System ........................................................................................................14
Emergency Situations.........................................................................................................15
System Memory.................................................................................................................16
System Configuration.........................................................................................................17
Remote Transmitter...........................................................................................................21
Date and Time....................................................................................................................23
Troubleshooting.................................................................................................................24
Problems when Arming the System...................................................................................25
Problems when Disarming the System ..............................................................................25
Quick Reference User Guide ..............................................................................................26
Index ..................................................................................................................................27

Owner’s Manual
700-624-01C
4
Figure 1: IDS806 Keypad
Power Icon will be on
when there is AC on and
24V DC is present
Zone numbers indicate
the status of each zone
Away Arm icon will be
on when armed in away
mode
Armed icon will be on
when the system is
armed in stay or away
mode
Ready Icon will be on
when the system is in an
arm able state
Star Key is used to
bypass zones and enter
the master user menu
Fire Key is used to
activate the Fire Alarm
Medical Key is used to
activate the Medical
Alarm
Hash Key is used to
cancel any unintended
keypresses
Panic Key is used to
activate the Panic Alarm

Owner’s Manual
700-624-01C
5
Glossary
Alarm Memory
This is the history of the most recent violations that occurred the last time the system was
armed. (See pg. 16)
Arm
To set the system into the ARMED mode. In this mode, violating a zone will activate an
alarm condition. If the system is programmed accordingly, it will cause a reporting code
to be sent to the monitoring company. (See pg. 10)
Bypass
To deactivate a zone. When the panel is ARMED, violation of a bypassed zone will be
ignored. (See pg. 14)
Disarm
To deactivate the system. Fire, medical and panic functions remain active while the
system is disarmed. (See pg. 14)
Entry/Exit Zone
A zone with a programmable time delay, which allows the user to exit the premises after
arming the system and time to get to the keypad after entering the armed premises. This
zone is generally the last exit point of the building and the first entry point i.e. the front
door of a home.
Follower Zone
A zone that may be temporarily violated during the exit delay period or after violation of
an Entry/Exit zone. This allows the user access to disarm the system. A Follower zone will
behave as per an Instant zone if violated prior to the violation of an Entry/Exit zone.
Instant Zone
When the system is armed, violation of an Instant zone will immediately cause an alarm
condition to be registered.
Stay Arm
Arming that allows for certain preprogramed, STAY zones to be violated while the system
is armed. (See pg. 11)
Stay Arm and Go
Arming that allows the user to STAY ARM and leave the premises. (See pg. 12)
Stay Zone
Zones which are bypassed automatically when the system is STAY ARMED. (See pg. 11)
Zone
A specific area of your premises guarded by sensors which detect violations of that area.

Owner’s Manual
700-624-01C
6
Introduction to the IDS806
The IDS806 Control Panel is manufactured to the highest specification and will provide
many years of service if correctly installed and maintained. The unit is designed for
simple operation yet provides the maximum protection for you, your family, or business.
For trouble free operation, please follow the instructions contained in this User Manual.
Your security system consists of a control panel, one or more keypads and various
sensors and detectors. An enclosure will contain the control panel which includes the
system electronics and standby battery. There is normally no reason for anyone other
than the installer or service professional to have access to the control panel.
Notes
1. This alarm is to be installed and maintained by an IDS trained installer.
2. Read the entire manual carefully and keep it in an accessible place.
3. Your security system should be installed and serviced by a qualified security
professional who should instruct you regarding the level of protection provided
and the operation of the system.
4. Should you have any questions regarding the operation of the system, contact
your security company representative.
5. Your system should be tested on a regular basis. Before testing the system, please
notify your security company of your intention to do so.
6. NEVER disconnect the mains power, as the back-up battery will eventually
discharge thereby causing the control panel to shutdown.
7. A security system cannot prevent emergencies. It is only intended to alert you and
- if included - your security company of an emergency situation.
8. Smoke and heat detectors may not detect all fire situations.

Owner’s Manual
700-624-01C
7
Understanding the Keypad Indicators
Refer to the labelled pictures of the keypads.
Table 1: Icon Display Information
Icons
Description
System Disarmed
System Away Armed
Alarm Condition
(Check Alarm Memory zone details BEFORE re-arming)
System Stay Armed
Stay Alarm Condition
Mains Power is Present
Trouble Condition
System Ready to be armed
Zone Bypassed
Zone Clear
Zone Violated or Tampered
Icon representation explanation
= On
= Off
= Flashing

Owner’s Manual
700-624-01C
8
Operation of the Keypad
To ensure correct operation of your security system it is essential to familiarize yourself
with the use of the keypad.
The keypad has a buzzer, command entry keys, zone and system status LED's.
The keypad is used to send commands to the system and to display the current
system status.
The keypad(s) should be mounted in a convenient location within the protected
premises generally close to the Entry/Exit zones.
After a preprogramed period of inactivity, the keypad will automatically enter into
a power-save mode by turning off all the indicators. The keypad "wakes up" or
comes on when any key is pressed or any zones are violated. The power save
feature is programmable and may be disabled.
A sensor which has registered an alarm condition will be indicated on the keypad
by the corresponding zone light flashing.
The keypad buzzer will sound under the following conditions.
oWhen any key is pressed during the entry of codes.
oThree times if one or more of the zones are violated when attempting
to arm the system.
oTo indicate a trouble condition if enabled in programming.
oDuring the entry/exit delay.
oWill sound 5 times when a chime zone is violated.

Owner’s Manual
700-624-01C
9
System Information
Programmed Functions
Check with your installer which of the following functions have been enabled.
Quick Away Arm
Quick Stay Arm
Arm with Entry/Exit or Follower Zones Violated
Stay Arm
Stay Arm and Go
Forced Arming
Siren Sound on Arm/Disarm (single toot - arm/ double2 toot - disarm)
Panic Alarm
Fire Alarm
Chime Zones
Buzz Zones
Zone Tamper Monitoring
Arm with Key-switch or Remote Control
Exit Delay with Key-switch or Remote Control
User Codes
User No.
User Name
Remote Serial Number
01 (Master)
02
03
04
05
06
07
08
09
10
11
12
13
14 (Maid’s)
15 (Duress)

Owner’s Manual
700-624-01C
10
Zone Information
Zone
Zone Type e.g. Entry/Exit
Zone Name e.g. Kitchen Door
1
2
3
4
5
6
7
8
The Primary Entry Delay is
Seconds
The Secondary Entry Delay is
Seconds
The Exit Delay Is
Seconds
Arming the System
There are various options for arming the system
Away Arming
[#]+ [USER CODE]
(Leave via Entry/Exit Zone)
1. Ensure that the Ready icon is on; if not, check that all protected doors and
windows are closed and that motion has ceased in areas with motion detectors.
2. If necessary, close the front door.
3. Press the key to cancel any unintended key entries.
4. Enter a valid 4 digit [USER CODE] . If you make a mistake,
press the key and re-enter the code.
5. The ARMED icon will come on and the keypad will beep for the duration of the
exit delay. A steadily lit zone indicator will show any bypassed zones.
6. The arming process has begun. Leave only via the Follower and Entry/Exit zones.
7. The panel will arm at the end of the exit delay.
Quick Away Arming
Hold down the key until the beep
If this function is enabled, it is possible to AWAY arm by simply holding down the
key until the keypad buzzer sounds and the arming process begins.

Owner’s Manual
700-624-01C
11
Stay Arming
This allows the user to arm the perimeter zones while disabling the interior zones so that
it is possible to remain on the premises. If zones are likely to be violated accidentally,
they should be programmed as BUZZ zones (refer to page 19). The panel can be
programmed with two different STAY PROFILES to be used as required.
Example of where this may be used:
Assume a property has perimeter sensors to secure a garden fence and a number of
internal sensors within each room of the house.
The first STAY PROFILE would function as follows: At night while you are within the
house going about your normal evening activities it may be desirable to activate the
alarm such that any violation of the perimeter sensors will cause an alarm.
Therefore, this profile would have all internal sensors programmed as STAY zones
(bypassed) and perimeter sensors would be normal alarm zones.
A second STAY PROFILE would then be utilised once the family retires to their
bedrooms. All bedrooms would therefore be STAY zones (bypassed) while unused
zones i.e. a lounge and TV room, together with perimeter zones would be normal
alarm zones.
NOTE:
Once a particular stay profile is selected, the system will use the selected profile each
time the system is armed into the STAY MODE. If the alternate profile is required, it is
necessary to select the alternate profile before the system is armed.
STAY and BUZZ zones can be programmed for each profile once the profile has been
entered.
To Select a Stay Profile
There are two stay profiles that can be configured, depending on your requirements.
There are two ways to change stay profiles.
When the system is disarmed follow these steps:
+ + + or +
1. Press the [#] key to clear any previous entries.
2. Press [MODE].
3. Press [9] then press [1] or [2] for the required profile.
4. Press [*] to enter. A long beep should be heard.
5. Program STAY and BUZZ zones for the profile or ARM the profile (See sections 12
and 13).
When armed in the stay mode follow this method:
+
1. Press [#] key to clear any previous entries.
2. Press [5] for 3 seconds and the stay profile will switch to the next stay profile.

Owner’s Manual
700-624-01C
12
To Stay Arm
+ [USER CODE]
(Do not leave premises)
1. Select the required STAY PROFILE. (To Select a Stay profile page 10.)
2. Ensure that the READY icon is on; if not, check that all protected doors and
windows are closed and that motion has ceased in the areas covered by motion
detectors.
3. If necessary, close the front door.
4. Press the [#] key to cancel any unintended entries.
5. Enter a valid [USER CODE].
6. The ARMED icon will come on and the keypad buzzer will beep for the duration of
the exit delay.
7. DO NOT open the front door. If the front door is opened, the system will arm in
AWAY mode.
8. Any STAY zones (shown by a steadily lit indicator) will be automatically bypassed.
9. Ensure that you enter only those zones that are bypassed.
Quick Stay Arming
Hold down the key until the beep
It is possible to STAY arm by holding down the [5] key until the keypad beeps. There is no
exit delay.
Stay Arm and Go
Hold down the key until the beep
This is a quick function that allows the user to STAY arm and leave the premises.
1. Hold down the [6] key until the keypad buzzer sounds. The keypad buzzer will now
beep for the duration of the exit delay
2. At the end of the exit delay, the ARMED indicator will come on and the AWAY
indicator will remain off. Any stay zones will be bypassed.
3. Be sure to leave only via the Follower and Entry/Exit zones.

Owner’s Manual
700-624-01C
13
Arming from a Key-switch or Remote Control
There are several option related to this function. Verify with your installer which of the
following have been installed:
1. Key-switch or Remote Control installed?
2. Exit Delay with Key-switch or Remote Control?
3. Toot on Arm/Disarm or Arm LED indicator?
Arming with a key-switch or remote control:
1. Ensure that the READY icon on the keypad is on before leaving.
2. Leave and close the door (remembering to lock!).
3. Twist and release the key-switch or press the remote button.
4. The alarm will arm immediately and the LED ARM indicator will come on if installed
or the siren will give a single beep if programmed.
OR
5. If an exit delay has been enabled, the exit delay will begin and arm after the delay
with either an Arm LED or siren toot to indicate arm status.
NOTE:
If a remote control is used, it is advisable to have the siren sound on arm and disarm or a
LED indicator to verify function enabled.
Auto Arming
Your system can be programmed to automatically arm itself daily at a preprogramed
time. Ask your installer to program this function if required. Should the premises be
occupied at the auto arming time, a valid [USER CODE] entered during the 3 minute
arming cycle will cancel the process.
NOTE:
For accurate timing please connect to the HYYP platform via the HYYP GSM module or
HYYP IP module.
Arming with Entry/Exit or Follower Zones Violated
The system can be programmed to arm even if the Entry/Exit or Follower zones are
violated. Check with your installer. Follow the normal arming procedures i.e. Enter a valid
[USER CODE], but it is not necessary to close the front door.
Forced Arming
If so programmed, the panel can be armed even if there are violated zones. This means
that a monitored window can be left open or other zones can be violated and the panel
will still arm. If the violated zone is then cleared, the panel will resume monitoring the
zone, hence causing an alarm condition or initiation of entry delay, as appropriate, if
violated.

Owner’s Manual
700-624-01C
14
Zone Bypassing
The term BYPASS is used to describe a zone that has been deactivated for the
armed cycle; i.e. violation of a bypassed zone will not cause an alarm.
Is used when access is needed to a protected area while the system is armed.
Zones cannot be bypassed once the system is armed.
Bypassed zones are automatically cancelled each time the system is disarmed and
must be re-bypassed before the next arming.
To Bypass a Zone
+ [ZONE NUMBER]
1. Press the [*] key (while bypassing zones, violated zones will be flashing).
2. Press the number corresponding to the zone you need to bypass e.g. the [2] key if
you wish to bypass zone 2.
3. The relevant zone indicator will come on to indicate that the zone is now bypassed.
4. Repeat steps 1 and 2 to bypass any other zones.
NOTE:
Panic/priority zones cannot be bypassed
To Un-bypass a Zone
+ [ZONE NUMBER]
1. Press the [*] key.
2. Press the number corresponding to the currently bypassed zone
3. The zone indicator will turn off - the zone is now active.
Disarming the System
Disarming with a User Code
+ [USER CODE]
To disarm the system, enter a valid [USER CODE] before the expiry of the entry delay.
Although not essential, it is recommended that the [#] key be pressed before entering a
user code as this clears any unintended key entries.
Enter the premises through a designated Entry/Exit door or an alarm will occur.
As soon as the Entry/Exit zone is violated i.e. the door has been opened, the entry
delay begins and follower zones become in-active.
The keypad buzzer will sound until a valid user code is entered or entry time runs
down. If the entry period is too short, have your installer change the entry time.
If the ARMED indicator remains lit, an error was made while entering the user
code, press the [#] key, and re-enter the code.
Once the system disarms, the ARMED indicator and the entry sound will turn off.
If no valid user code has been entered by the end of the entry delay period, an
alarm condition will be registered.

Owner’s Manual
700-624-01C
15
If four incorrect user codes are entered consecutively while either arming or
disarming the system, the keypad will be non-responsive for 30 seconds. Your
monitoring company will also be notified on a keypad tamper.
NOTE:
1. If the ARMED indicator is flashing upon entry, there has been a violation. The
intruder may still be inside! Call for assistance.
2. If a strobe (or flashing light) has been installed and an alarm condition is registered,
the light will continue flashing until a valid [USER CODE] is entered.
To Disarm with a Remote Control
1. Press the arm/disarm remote button.
3. The system will disarm and the arm/disarm indicator (if installed) will turn off.
4. If programmed to do so, the siren will sound briefly - verify with your installer.
Emergency Situations
Fire Alarm
Hold down the key until the beep
If the [F] key is pressed until the keypad beeps (approximately 1 second) a FIRE
ALARM condition will be activated.
The FIRE ALARM CONDITION can also be triggered by a smoke detector connected
to an appropriately programmed zone.
The siren will sound (1 second on, 1 second off) and the FIRE REPORTING CODE
will be transmitted to the monitoring company.
To silence the siren enter a 4 digit [USER CODE]. The siren will stop sounding after
10 minutes if no user code is entered.
Panic Alarm
Hold down the key until the beep
If the [P] key is pressed until the keypad beeps (approximately 1 second) a PANIC
ALARM condition will be activated.
Any FIXED PANIC or REMOTE PANIC buttons which may have been installed can
also activate a PANIC ALARM.
If audible panic option has been selected, the siren will sound. A PANIC
REPORTING CODE will be transmitted to the monitoring company.
To silence the siren, enter a valid 4 digit [USER CODE]. If the siren is not cancelled,
it will stop automatically after the programmed SIREN TIME OUT period.
Ensure that your installer has enabled this function if it is required.
Press this key only in an emergency situation that requires response by
emergency personnel.

Owner’s Manual
700-624-01C
16
Medical Alarm
Hold down the key until the beep
If the [M] key is pressed until the keypad beeps (approximately 1 second) a
MEDICAL ALARM condition will be activated.
The keypad's buzzer will sound rapidly for 5 seconds to indicate that a medical
alarm has been initiated.
Duress Code
+ [DURESS CODE]
This special 4 digit user code should only be used in the unique situation where an
intruder forces one to disarm the system "under duress".
When the [DURESS CODE] is entered, the control panel disarms normally -
however a DURESS REPORTING CODE is transmitted to the monitoring company
to inform them that you have been forced to disarm by an intruder.
It is advisable to choose a code that can be easily remembered by all family (or
staff) members.
System Memory
Alarm Memory
The Alarm Memory displays any zones which were violated the last time the system was
armed. If the ARMED indicator is flashing before you disarm the system, a violation has
occurred. To view which zone was violated.
Hold down the key until the beep
1. Disarm the panel with a valid [User Code], if the system is armed.
2. Hold down [0] until the keypad buzzer sounds.
5. The READY indicator will turn off and the keypad buzzer will sound briefly.
6. Flashing zones indicate which zones were violated during the last armed period.
7. The memory status will be displayed for five seconds, or until the [#] is pressed.
8. The alarm memory will be erased the next time the system is armed.
Zone Bypassed Memory
The Zone Bypassed Memory displays any zones which were bypassed during the most
recent arming cycle.
then
1. Hold down [0] until the keypad buzzer sounds.
2. The READY indicator will turn off and the keypad buzzer will sound briefly.
3. Flashing zones indicate which zones were violated during the last armed cycle.
4. To view any bypassed zones, press the [1] key once and bypassed zones will flash.
5. The memory status will be displayed for five seconds.

Owner’s Manual
700-624-01C
17
Zone Tamper Memory
The Zone Tamper Memory displays any zones where a tamper condition has occurred.
then
1. Hold down [0] until the keypad buzzer sounds.
2. The READY indicator will turn off and the keypad buzzer will sound briefly.
3. Flashing zones indicate which zones were violated during the last armed period.
4. To view any tampered zones, press the [2] key once flashing zones where tampered.
5. The memory status will be displayed for five seconds.
System Configuration
User Codes
The IDS806 Alarm Panel has 15 programmable user codes.
Code 1: Master User Code
Code 2 –13:General User Codes
Code 14: Maid’s Code
Code 15: Duress Code
Entering New and Changing Existing User Codes
+ [MASTER USER CODE] + + [CODE NUMBER] + + [NEW CODE] +
1. Hold down the [*] key until the keypad buzzer sounds.
2. The ARMED and READY indicators will flash alternately, indicating that the system is
in the mode which allows programming of user codes.
3. Enter the [MASTER USER CODE] (the default is 1234) followed by the [*] key.
4. The ARMED and READY indicators will begin to flash simultaneously indicating that
the correct master code was entered. If an invalid code was entered, the keypad
buzzer will beep three times, and exit the programming mode.
5. Enter the [USER CODE NUMBER] you wish to change (1-15) followed by the [*] key.
6. Enter the new 4 digit [USER CODE] and press the [*] key.
7. Repeat steps 5-6 to enter or change other user codes.
8. Once all the codes are programmed, press the [#] key to exit.

Owner’s Manual
700-624-01C
18
Deleting User Codes
Follow steps 1-5 of the previous procedure but in step 6 only press the [*] key. That
particular code will be deleted.
Maid’s Code
The maid’s code (user 14) may be used to limit access to the premises. The maid’s code
will only disarm the system if the same code was used for arming. If armed with a code
other than a maid’s code, the system will view an attempt to disarm with the maid’s
code as an invalid entry. Any valid user code will disarm the system if it has been armed
with the maid’s code.
EXAMPLE:
If a maid is expected on a Monday, arming the system on a Monday morning using the
maid’s code will allow the maid to disarm the system. On days that any other user code
(i.e. not a maid’s code) has been used to arm the system entering the maid’s code will
not disarm the system.
Stay Zones
Stay zones are those zones which are bypassed automatically when the system is STAY
ARMED. To avoid triggering the alarm, zones such as bedrooms, or other areas which
require access, must be bypassed. Stay zones need only be programmed once. Each time
the system is armed in the stay mode the preselected stay zones will be bypassed
automatically. This also depends on which stay profile is active.
NOTE:
Zones, such as panic zones, Arm/Disarm zones cannot be selected.
To Program Stay Zones
+ [ZONE NUMBER] +
1. Hold down the [3] key until the keypad buzzer sounds. The AWAY indicator will flash
to show that the panel is in the Stay Zone programming mode.
2. Press the [NUMBER] corresponding to the zone you wish to be a STAY zone.
3. The relevant zone indicator will come on. (Buzz zones will be shown by flashing
indicators. See Pg. 19. A Buzz zone cannot be selected as a Stay zone; the Buzz status
must be cleared first.)
4. Repeat step 2 until all stay zones are selected.
5. Press the [#] key to exit the Stay zone programming mode.

Owner’s Manual
700-624-01C
19
To Cancel the Stay Zones
+ [ZONE NUMBER] +
If an area programmed as a STAY zone will no longer be entered during STAY arm, then
the zone should be removed from the stay profile. This will allow the system to protect
that area during a stay arm cycle.
1. Hold down the [3] key until the keypad buzzer sounds. The AWAY indicator will flash
to show that the panel is in the Stay zone programming mode.
2. Press the [NUMBER] corresponding to the STAY zone you wish to cancel.
3. The relevant zone indicator will turn off.
4. Repeat step 2 until all stay zones are selected.
5. Press the [#] key to exit the Stay zone programming mode.
NOTE:
The system will automatically exit this mode after 60 seconds.
The 806 has two stay profiles that could be used if required
Buzz Zones
Buzz zones are used when Stay arming. When triggered, buzz zones will cause the
keypad buzzer to sound for a period of 30 seconds during which time a valid user code
must be entered. If a valid user code is not entered during this period, the system will
register an alarm condition. It is advisable to program Buzz zones if you are likely to
accidentally trigger these zones or if you have pets.
This feature helps prevent unnecessary false alarms.
NOTE:
Instant zones, such as panic zones, cannot be selected.
To Program Buzz Zones
+ [ZONE NUMBER] +
1. Hold down the [4] key until the keypad buzzer sounds. The AWAY indicator will flash
to show that the panel is armed in the Buzz zone programming mode.
9. Press the [NUMBER] corresponding to the zone you wish to be a Buzz zone.
10. The lit zone indicator will show the relevant Buzz zone. (Stay zones will be shown
by flashing indicators. See Pg. 18. A Stay zone cannot be selected as a Buzz zone;
the Stay status must be cleared first).
11. Repeat steps 2 until all the required Buzz zones are programmed.
12. Press the [#] key to exit the buzz programming mode.

Owner’s Manual
700-624-01C
20
To Cancel Buzz Zones
+ [ZONE NUMBER] +
1. Hold down the [4] key until the keypad buzzer sounds. The AWAY indicator will flash
to show that the panel is armed in the Buzz zone programming mode.
2. Press the [NUMBER] corresponding to the BUZZ zone you wish to cancel.
3. The relevant zone indicator will turn off.
4. Repeat step 2 until all buzz zones are cancelled.
5. Press the [#] key to exit the buzz zone programming mode.
NOTE:
The system will automatically exit this mode after 60 seconds.
Chime Zones
The chime mode allows the user to monitor nominated zones while the system is
disarmed. The keypad buzzer will sound 5 times when the nominated zone is violated -
the siren will NOT sound and no alarm condition will be reported.
EXAMPLE:
You wish to know when someone enters or exits the front door; the keypad will beep
each time the door is opened if that zone is programmed as a chime zone.
To Program the Chime Zones
+ [ZONE NUMBER] +
1. Hold down the [2] key until the keypad buzzer sounds.
2. The AWAY indicator will flash to show that the panel is in the chime zone
programming mode.
3. To program a zone as a chime zone, press the key corresponding to that zone. The
zone indicator will come on.
4. Program any other zones you wish to select as chime zones as per step 3.
5. Press the [#] key to exit the chime programming mode.
To Cancel the Chime Zones
+ [ZONE NUMBER] +
1. Hold down the [2] key until the keypad buzzer sounds.
2. The AWAY indicator will flash to show that the panel is in chime programming mode.
3. To cancel any chime zones, press the key corresponding to that zone. The zone
indicator will turn off.
4. Repeat step 3 until all the chime zones are cancelled.
5. Press the [#] key to exit the chime programming mode.
NOTE:
The system will automatically exit this mode after 60 seconds.
