fadini Elpro 12 PLUS User manual

- FUNZIONE PASSO PASSO
- UOMO PRESENTE
- APERTURA PEDONALE
- LUCE DI CORTESIA
- DIAGNOSTICA A LED LUMINOSI
LIBRETTO DI ISTRUZIONI
I
F
GB
D
E
Dis. N. 4086 Via Mantova 177/A - 37053 Cerea (Verona) Italy Tel. [phone]
- Fax [phone] e-mail: [e-mail] - www.fadini.net
Elpro 12 PLUS
MONOFASE PER SCORREVOLE
NYOTA 115
Elpro 12 PLUS
Elpro 12 PLUS
Elpro 12 PLUS
Elpro 12 PLUS
meccanica
FADINI
F
Made in Italy
- SPIA DI SEGNALAZIONE DELLO
STATO DELL'AUTOMAZIONE
- FUNZIONE OROLOGIO
- STEP BY STEP OPERATIONS
- HOLD-ON SWITCHED
(DEADMAN) CONTROL
- PEDESTRIAN OPENING
- COURTESY LIGHT
INSTRUCTIONS
SINGLE-PHASE FOR NYOTA 115
SLIDING GATE OPERATOR
- FAULT INDICATION BY LEDs
- GATE STATUS INDICATION
- TIME CLOCK OPTION
NOTICES D'INSTRUCTION
MONOPHASE POUR OUVRE-
PORTAIL COULISSANT NYOTA 115
- FONCTION PAS-PAS
- HOMME MORT
- OUVERTURE PIETON
- LAMPE TEMOIN
- DIAGNOSE A LED VOYANT A DIODE
- SIGNALISATION DE L'ETAT DE
L'AUTOMATION PAR LED
- FONCTION HORLOGE
EINPHASIG FÜR
SCHIEBETORANTRIEBE NYOTA 115
ANLEITUNG
- SCHRITT-IMPULS-FUNKTION
- TOTMANN-BEDIENUNG
- GEHTÜRFUNKTION
- BEDIENUNGSLICHT
- DIAGNOSE-LED
- AUTOMATION-STATUS
ANZEIGELAMPE
- UHR-FUNKTION
- FUNCIONAMIENTO PASO A PASO
- HOMBRE PRESENTE
- ABERTURA PARA PASO DE PEATONES
- LUZ AUXILIAR
- DIAGNOSTICO POR MEDIO DE LED LUMINOSOS
FOLLETO DE INSTRUCCIONES
MONOFASICO PARA VERJAS
DESLIZANTES NYOTA 115
- LÁMPARA TESTIGO QUE
SEÑALA ELE ESTADO DEL
AUTOMATISMO
- FUNCIÓN RELOJ

In case of failure of the panel:
- Check voltage supply. It must be 230V 50Hz single-phase
- Check fuses
- Check photocells if contacts are normally closed
- Check all NC contacts
- Check that no voltage drop has occurred from the control
panel to the electric motor
Led Status Indication:
L1= 230V 50Hz power supply. Alight
L2= Photocells, if obstructed light goes off
L3= Open. Alight whenever an Open pulse is given
L4= Close. Alight whenever a Close pulse is given
L5= Stop. It goes off on pulsing Stop
L6= Radio. It goes on by pressing a transmitter button
L8= Limit switch Close; off when gate is closed
L9= Limit switch Open; off when gate is open
The electronic control panel Elpro 12 Plus, new generation, is designed to operate the sliding gate operator Nyota 115. Power supply is 230V 50Hz
single-phase. Built in full compliance with BT 93/68/CE Low Voltage and EMC 93/68/CE Electro-Magnetic Compatibility Regulations. Fitting operations
are recommended by a qualified technician in conformity to the existing safety standards.
The manufacturing company declines any responsability for incorrect handling and application; also, it reserves the right to change or update the
control panel any time.
PLEASE NOTE:
- The control panel must be installed in a sheltered, dry place, inside the box provided with it.
- Fit the mains to the control panel with a 0.03A high performance circuit breaker.
- Use 1.5mm² section wires for voltage supply, electric motor and flashing lamp.
Maximum recommended distance 50m.
Use 1mm² section wires for limit switches, photocells, push-buttons/key-switch and accessories.
- Bridge terminals 1 and 2 if no photocells are required.
- Bridge terminals 3 and 6 if no key- or push-button switches are required.
N.W: To fit extra accessories such as lights, CCTV etc. use only solid state relays to prevent damages to the microprocessor.
DIP-SWITCH
145678
2
ON
OFF
3
Dip-Switch:
1= ON. Photocells. Stop while opening
2= ON. Radio. No reversing while opening
3= ON. Automatic closing
4= ON. Preflashing activated
5= ON. Radio. Step by step. Stop in between
6= ON. Dead Man Control (Dip 4=OFF and Dip 3=OFF)
7= ON. No lamp on during dwell time
8= OFF. No function
Elpro12 PLUS
GB
L7= Gate Status; it flashes on gate opening
thegateopener
Made in Italy
PULIN 3 26
27
28
3
DIP-SWITCH ON
OFF
145678
23
L2 L3 L4 L5 L9
L8
L6 L7
L1
F4 Fuse = 1A
24V Transformer
Protection
RADIO
PLUG-IN
CARD
CONNECTOR
PEDESTRIAN OPENING from 3 up to 30s
-
+
ELPRO 12 PLUS
18
16 17
NEUTRAL
M
SINGLE-PHASE
ELECTRIC
MOTOR
24V OUTPUT (max. load:
2 PAIRS PHOTOCELLS
1 RADIO RECEIVER)
INDICATION LAMP
24V max. 3W
STOP
NEUTRAL
PUSH BUTTONS
OPEN
CLOSE
PHOTOCELLS
SAFETY EDGES
RADIO CONTACT
LIMIT SWITCH CLOSE LIMIT SWITCH OPEN
LIMIT SWITCH NEUTRAL
-
+
-
+
-
+
R65 R64 R63 R62
COURTESY LIGHT from 2 up to 255s DWELL TIME from 2 up to 128s MOTOR RUN TIME OPEN/CLOSE from 2 up to 128s
F3 Fuse = 630mA
Transformer Protection
F2 Fuse = 8A
Mains
F1 Fuse = 8A
Mains
19 20 21 22
29
23 24 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
SAFETY CONTACT
COURTESY LIGHT
100W max.
CAPACITOR
230V 25W max.
FLASHING LAMP
230V SINGLE-PHASE
VOLTAGE SUPPLY
TRANSFORMER
TRIMMER
Drwg. No. 4086
MICROPROCESSOR
E 12 plus 1 4

thegateopener
Made in Italy
Elpro12 PLUS
GB
Flashing lamp:
19 20
230V MAX 25W
4
ON: Pre-flashing
OFF: No pre-flashing
Power supply:
OPERATING MODES
HIGH VOLTAGE ELECTRICAL CONNECTIONS
7
ON: Lamp is not operating during
Dwell time. Automatic mode.
OFF: It flashes during Dwell Time.
Automatic Mode.
POWER SUPPLY
230V 50Hz SINGLE-PHASE
21 22
DIP-SWITCH 4 and 7:
12
Button switch:
3456
STOP
COMMON/
NEUTRAL
OPOEN
CLOSE
Photocells and Safety Edge:
12 13
1
DIP-SWITCH 1:
ON: Photocells stop gate while opening,
reverse it once obstacle is removed
OFF: Photocells do not stop gate while
opening, reverse it in case of an
obstacle
PHOTOCELLS
AND SAFETY EDGE
24V OUTPUT (MAX. LOAD:
2 PAIRS PHOTOCELLS
1 RADIO RECEIVER)
Limit switch:
LIMIT SWITCH
CLOSE
NEUTRAL
10
89
LIMIT SWITCH
OPEN
Light ON = Open gate
Light OFF = Close gate
Flashing (fast) 0.5s= Closing gate
Flashing (normally) 1s= Opening gate
Flashing (slowly) 2s= gate is stopped
24V 3W Indication Light:
311
Push Button Switch Pulin 3:
26
27
28
3
NEUTRAL
Led to indicate status
of Open - Stop - Close
switches
Safety Contact:
This contact must be
N.C. for the control
panel to be allowed
to work
Radio Contact:
COMMON/
NEUTRAL
CONTACT RADIO
7
3
- Open/Close (Standard)
- Travel reversing on
pulsing
- Step by step 2
ON: Gate is not reversed while opening
OFF: Any pulse reverses the gate
5
ON: Step by step. Stop in between
OFF: Standard operating mode
DIP-SWITCH 2 and 5 (NEVER set BOTH of them
ON at the same time):
14 15
LOW VOLTAGE ELECTRICAL CONNECTIONS
Capacitor and Single-phase Motor:
-
+
R65
MOTOR RUN
TIME
OPEN/CLOSE
FROM 2 UP TO 128s
R64
-
+
DWELL TIME
FROM 2 UP TO 128s
29 30 18
16 17
NEUTRAL
M
Capacitor
20µF for 0.5HP
40µF for 1.0HP
CourtesyLight
230Vmax.100W:
23 24
Trimmer R63
-
+
COURTESY LIGHT
FROM 2 UP TO 255s
How it works: Set the clock to the required times. On the pre-set time the gate is automatically opened and held open. Any
further pulsing (even by remote control) is not accepted by the system until the time pre-set by the clock has expired. On
expiring and after the pre-set dwell time the gate is closed automatically.
R62 trimmer on to zero, Dip-Switch 3=ON.
DIP-SWITCH No.3=ON Automatic Closing
Time clock:
3
ON= Automatic Closing
OFF= No Automatic. Semi-automatic
closing by pulse
43
COMMON
COMMON
OPEN
NO
-
+
Pedestrian Trimmer R62
set on to zero
Hold on switched (Deadman) control:
Pedestrian Opening:
Trimmer R62
-
+
from 3 to 30s. It can be activated
by any pulse (eg. by remote
control) superior to 2s
3
DIP-SWITCH 3
ON= Automatic Closing
OFF= No Automatic. Semi-automatic
closing by pulse
Automatic / Semiautomatic:
Automatic Operation: any pulse opens the gate, the gate
stays open as long as the Dwell time expires as set by R64
trimmer, then it closes automatically, no pulsing is required.
Semi-automatic Operation: any pulse opens the gate
that stays open. A second pulse to Close is required for
the gate to close.
Open and Close operations are achieved "by
holding a switch on" (no relay self-holding in
involved) therefore a phisical attendance is
required to keep the gate opening or closing
until either the button or key is released.
DIP-SWITCH 6
6
ON= Deadman Control. Dip-switch 4=OFF
and Dip-switch 3=OFF
OFF= Standard Operations
Dwell Time
from 2 to 128s
-
+
Trimmer R64
COMMON
OPEN
4
3
Drwg. No. 4086
