IEI Technology IDS-H61 User manual

IDS-H61 Digital Signage Player
Page I
IEI Technology Corp.
User Manual
IDS-H61 Embedded System
MODEL:
IDS-H61
Fanless Digital Signage Player with Intel
®
Celeron® G530T
Dual-Core CPU, Intel® H61 Express Chipset, GbE LAN,
DisplayPort, DVI, RS-232, USB 2.0, SDHC Slot, RoHS Compliant
Rev. 1.00 – 7 February, 2013

IDS-H61 Digital Signage Player
Page II
Revision
Date Version Changes
7 February, 2013 1.00 Initial release

IDS-H61 Digital Signage Player
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IDS-H61 Digital Signage Player
Page IV
WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and(2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
You are cautioned that any change or modifications to the equipment not expressly
approve by the party responsible for compliance could void your authority to operate
such equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.

IDS-H61 Digital Signage Player
Page V
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 2
1.3 FRONT PANEL............................................................................................................. 3
1.4 REAR PANEL............................................................................................................... 3
1.5 BOTTOM PANEL.......................................................................................................... 4
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 5
1.7 DIMENSIONS............................................................................................................... 7
2 UNPACKING................................................................................................................. 8
2.1ANTI-STATIC PRECAUTIONS........................................................................................ 9
2.2 UNPACKING PRECAUTIONS......................................................................................... 9
2.3 UNPACKING CHECKLIST........................................................................................... 10
3 INSTALLATION ..........................................................................................................11
3.1 INSTALLATION PRECAUTIONS................................................................................... 12
3.1.1 High Surface Temperature ............................................................................... 12
3.2 SD CARD INSTALLATION.......................................................................................... 13
3.3 HDD INSTALLATION................................................................................................. 14
3.4 MOUNTING THE SYSTEM .......................................................................................... 16
3.5 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 18
3.5.1 Audio Line-out Connector................................................................................ 19
3.5.2 DisplayPort Connector.................................................................................... 19
3.5.3 LAN Connector ................................................................................................ 19
3.5.4 DVI-I Connector .............................................................................................. 20
3.5.5 Power Connector (12 V, Power Adapter) ........................................................ 21
3.5.6 RS-232 Serial Port Connector......................................................................... 21
3.5.7 USB 2.0 Connectors......................................................................................... 22
3.6 DRIVER INSTALLATION............................................................................................. 23
4 BIOS SCREENS........................................................................................................... 24

IDS-H61 Digital Signage Player
Page VI
4.1 INTRODUCTION......................................................................................................... 25
4.1.1 Starting Setup................................................................................................... 25
4.1.2 Using Setup...................................................................................................... 25
4.1.3 Getting Help..................................................................................................... 26
4.1.4 BIOS Menu Bar................................................................................................ 26
4.2 MAIN........................................................................................................................ 27
4.3ADVANCED............................................................................................................... 28
4.3.1 CPU Configuration.......................................................................................... 29
4.3.2 USB Configuration........................................................................................... 31
4.3.3 H/W Monitor.................................................................................................... 32
4.4 CHIPSET ................................................................................................................... 33
4.5 BOOT........................................................................................................................ 35
4.6 SECURITY................................................................................................................. 37
4.7 EXIT......................................................................................................................... 38
5 MAINTENANCE......................................................................................................... 40
5.1 SYSTEM MAINTENANCE OVERVIEW ......................................................................... 41
5.2 COMPONENT REPLACEMENT PROCEDURE ................................................................ 41
5.2.1 mSATA Replacement ........................................................................................ 42
5.2.2 SO-DIMM Replacement................................................................................... 43
6 INTERFACE CONNECTORS................................................................................... 45
6.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 46
6.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 47
6.2.1 Fan Connector (FAN1)..................................................................................... 47
6.2.2 Fan Connector (FAN2)..................................................................................... 48
6.2.3 Half-Size PCIe Mini Slot (CN3)....................................................................... 48
6.2.4 Full-Size PCIe Mini Slot (CN5)....................................................................... 49
6.2.5 Full-Size PCIe Mini Slot for mSATA (JP2)...................................................... 50
6.2.6 RS-485 Connector (CN8)................................................................................. 51
6.2.7 SATA Connector (SATA2)................................................................................. 51
6.2.8 SATA Power Connector (SATA_PWR1)........................................................... 51
6.2.9 SPI Flash Connector (JSPI1)........................................................................... 52
A SAFETY PRECAUTIONS......................................................................................... 53
A.1 SAFETY PRECAUTIONS ............................................................................................ 54

IDS-H61 Digital Signage Player
Page VII
A.1.1 General Safety Precautions............................................................................. 54
A.1.2 Anti-static Precautions .................................................................................... 55
A.1.3 Product Disposal............................................................................................. 56
A.2 MAINTENANCE AND CLEANING PRECAUTIONS........................................................ 56
A.2.1 Maintenance and Cleaning.............................................................................. 56
A.2.2 Cleaning Tools................................................................................................. 57
B BIOS MENU OPTIONS............................................................................................. 58
B.1 BIOS CONFIGURATION OPTIONS ............................................................................. 59
C WATCHDOG TIMER ................................................................................................ 60

IDS-H61 Digital Signage Player
Page VIII
List of Figures
Figure 1-1: IDS-H61 Series Pluggable Module PC.......................................................................2
Figure 1-2: Front Panel ..................................................................................................................3
Figure 1-3: Rear Panel....................................................................................................................4
Figure 1-4: Bottom Panel...............................................................................................................4
Figure 1-5: IDS-H61 Dimensions (mm).........................................................................................7
Figure 3-1: SDHC Slot Cover Retention Screw..........................................................................13
Figure 3-2: SDHC Card Installation.............................................................................................13
Figure 3-3: Top Cover Retention Screws...................................................................................14
Figure 3-4: HDD Bracket Retention Screws...............................................................................14
Figure 3-5: Inserting the HDD......................................................................................................15
Figure 3-6: SATA Cable Connection...........................................................................................15
Figure 3-7: Installing the HDD .....................................................................................................16
Figure 3-8: Installing the Mounting Bracket ..............................................................................17
Figure 3-9: Pace the System onto the Mounting Bracket.........................................................17
Figure 3-10: Mounting the System..............................................................................................18
Figure 3-11: RJ-45 Ethernet Connector......................................................................................20
Figure 3-12: DVI-I Connector.......................................................................................................21
Figure 3-13: Power Jack Connector ...........................................................................................21
Figure 3-14: Serial Port Pinouts..................................................................................................22
Figure 5-1: System Cover Retention Screws.............................................................................42
Figure 5-2: mSATA Module Location..........................................................................................42
Figure 5-3: mSATA Module Installation......................................................................................43
Figure 5-4: SO-DIMM Removal ....................................................................................................44
Figure 5-5: SO-DIMM Installation................................................................................................44
Figure 6-1: Main Board Layout Diagram (Front Side)...............................................................46

IDS-H61 Digital Signage Player
Page IX
List of Tables
Table 1-1: Technical Specifications..............................................................................................6
Table 2-1: Package List Contents...............................................................................................10
Table 3-1: LAN Pinouts ................................................................................................................19
Table 3-2: RJ-45 Ethernet Connector LEDs...............................................................................20
Table 3-3: DVI Connector Pinouts...............................................................................................21
Table 3-4: Serial Port Pinouts......................................................................................................22
Table 3-5: USB Port Pinouts........................................................................................................22
Table 4-1: BIOS Navigation Keys................................................................................................26
Table 6-1: Peripheral Interface Connectors...............................................................................47
Table 6-2: Fan Connector (FAN1) Pinouts .................................................................................47
Table 6-3: Fan Connector (FAN2) Pinouts .................................................................................48
Table 6-4: Half-Size PCIe Mini Card Slot (CN3) Pinouts ...........................................................49
Table 6-5: Full-Size PCIe Mini Card Slot (CN5) Pinouts............................................................50
Table 6-6: Full-Size PCIe Mini Card Slot (CN2) Pinouts............................................................51
Table 6-7: RS-485 Connector (CN8) Pinouts..............................................................................51
Table 6-8: SATA Connector (SATA2) Pinouts ...........................................................................51
Table 6-9: SATA Power Connector (SATA_PWR2) Pinouts.....................................................51
Table 6-10: SPI Flash Connector (JSPI1) Pinouts.....................................................................52

IDS-H61 Digital Signage Player
Page X
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................27
BIOS Menu 2: Advanced..............................................................................................................28
BIOS Menu 3: CPU Configuration...............................................................................................29
BIOS Menu 4: USB Configuration...............................................................................................31
BIOS Menu 5: H/W Monitor..........................................................................................................32
BIOS Menu 6: Chipset..................................................................................................................33
BIOS Menu 7: Boot.......................................................................................................................35
BIOS Menu 8: Security.................................................................................................................37
BIOS Menu 9:Exit..........................................................................................................................38

IDS-H61 Digital Signage Player
Page 1
Chapter
1
1 Introduction

IDS-H61 Digital Signage Player
Page 2
1.1 Overview
Figure 1-1: IDS-H61 Series Pluggable Module PC
The IDS-H61 series is a fanless digital signage player with Intel® Celeron® dual-core
G530T processor and Intel® H61 Express Chipset. The IDS-H61 is preinstalled 4 GB of
DDR3 SO-DIMM and can accommodate up to 16 GB of DDR3 memory. Storage in the
system is handled by the preinstalled 32 GB mSATA module, the 2.5” SATA HDD bay and
the SDHC card slot on the front panel.
The IDS-H61 includes a DisplayPort output interface supporting up to 2560 x 1600
resolutions and a DVI-I connector supporting up to 1920 x 1200 resolutions. Other slots
and connectors include half-size and full-size PCIe Mini card slots, RS-232, Gigabit
Ethernet, USB 2.0 ports and audio out.
1.2 Features
The IDS-H61 has the following features
Fanless design
LGA1155 2.0 GHz Intel® Celeron® G530T CPU supported
Intel® HD Graphics with full HD video decoding capability
One 32 GB mSATA module preinstalled
One 2.5” SATA HDD bay
One SDHC card supported
One GbE LAN for high speed network applications

IDS-H61 Digital Signage Player
Page 3
One DisplayPort connector
One DVI-I connector
Four USB 2.0 ports
One RS-232 DB-9 serial port
One audio line-out jack
RoHS compliant design
1.3 Front Panel
The front panel of the IDS-H61 contains one SDHC slot, two USB 2.0 ports, LED
indicators and a power button. The LED indicators are listed below. An overview of the
front panel is shown in 62Figure 1-2.
1 x Storage device (SD card/HDD) LED indicator
1 x USB LED indicator
1 x LAN LED indicator
1 x Status LED indicator (Blinking: booting; Solid: complete booting)
Figure 1-2: Front Panel
1.4 Rear Panel
The IDS-H61 rear panel provides access to the following external I/O connectors:
1 x 12 V DC input jack

IDS-H61 Digital Signage Player
Page 4
1 x Audio line-out jack
1 x DisplayPort connector
1 x GbE RJ-45 connector
1 x RS-232 DB-9 serial port
2 x USB 2.0 port connectors
1 x DVI-I connector
1 x Reset button
An overview of the rear panel is shown in 62Figure 1-3 below.
Figure 1-3: Rear Panel
1.5 Bottom Panel
The bottom panel of the IDS-H61 contains several screw holes for VESA mount.
Figure 1-4: Bottom Panel

IDS-H61 Digital Signage Player
Page 5
1.6 Technical Specifications
The specifications for the IDS-H61 are listed below.
IDS-H61-C-4GB
CPU 2.0GHz Intel® Celeron® G530T dual-core CPU (2M cache)
System Chipset Intel® H61 Express Chipset
System Memory Two 1333 MHz 2 GB DDR3 SDRAM SO-DIMM preinstalled
(system max. 16 GB)
Graphics Intel® HD Graphics
Max. Output Resolution DVI-I: 1920 x 1200
DisplayPort: 2560 x 1600
Ethernet One Intel® 82579LM GbE controller
Display One DVI-I connector
One DisplayPort 1.1 connector
Serial Port One RS-232 DB-9 serial port
USB Four USB 2.0 ports
Audio One audio out (5.1 channel Realtek ALC662 HD Audio codec)
Storage One 32 GB mSATA module preinstalled
One 2.5” SATA HDD bay
One SDHC card slot on the front panel
Expansion Slot Two PCIe Mini full-size slots(one preinstalled with a 32 GB mSATA module)
One PCIe Mini half-size slot (reserved for Wi-Fi module)
Wireless Optional 802.11b/g/n Wi-Fi
Buttons One power button
One reset button

IDS-H61 Digital Signage Player
Page 6
Chassis Construction Aluminum Alloy (top cover) with heavy duty metal
Mounting VESA 75 mm or 100 mm
Power Input 12V DC
Power Consumption 41 W @ full loading
Operating Temperature 0ºC ~ 45ºC with air flow
Storage Temperature -10 ºC ~ 55ºC
Color Black
Weight (Net/Gross) 2.1kg/4.5kg
Dimensions (W x D x H) 267 mm x 160 mm x 45 mm
Operation Vibration MIL-STD-810F 514.5C-1 with SATA HDD
MIL-STD-810F 514.5C-2 with mSATA
EMC FCC, CE, LVD
Supported OS Microsoft Windows 7 or Microsoft Windows Embedded Standard 7
Table 1-1: Technical Specifications

IDS-H61 Digital Signage Player
Page 7
1.7 Dimensions
The physical dimensions of the IDS-H61 embedded systems are shown in 62Figure 1-5.
Height: 45.00 mm
Width: 267.00 mm
Length: 160.00 mm
Figure 1-5: IDS-H61 Dimensions (mm)

IDS-H61 Digital Signage Player
Page 8
Chapter
2
2 Unpacking

IDS-H61 Digital Signage Player
Page 9
2.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation may result in
permanent damage to the IDS-H61 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the IDS-H61. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the IDS-H61 or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the IDS-H61, place it on an
antic-static pad. This reduces the possibility of ESD damaging the IDS-H61.
2.2 Unpacking Precautions
When the IDS-H61 is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 2.1.
Make sure the packing box is facing upwards so the IDS-H61 does not fall out
of the box.
Make sure all the components shown in Section 2.3 are present.

IDS-H61 Digital Signage Player
Page 10
2.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the IDS-H61 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The IDS-H61 is shipped with the following components:
Quantity Item Image
1 IDS-H61 digital signage player
1 Power adapter
1 Wall mount kit
1 Driver and manual CD
Table 2-1: Package List Contents
