IEI Technology HYPER-BW User manual

HYP E R -BW
Pico-ITX SBC with on-board SoC
Quick Installation Guide/ 快速安裝指南
Version 1.02 December 13, 2017
P a c kin g Lis t /
內容清單
1 x HYPER-BW single board computer with heatsink / HYPER-BW 單板電腦附散熱器
1 x RS-232 cable / RS-232 傳輸線
1 x SATA with power cable kit / SATA 信號與電源線
1 x QIG (Quick Installation Guide) / 快速安裝指南
1 x One Key Recovery CD / 一鍵還原光碟
1 x Utility CD / 公用程式光碟

1
Sp e c ific a tio n s / 規格
Specification HYP E R -BW
SoC
Intel® Pentium® N3710 on-board SoC
(up to 2.56GHz, quad-core, 2MB cache, TDP=6W)
Intel® Celeron® N3160 on-board SoC
(up to 2.24GHz, quad-core, 2MB cache, TDP=6W)
Intel® Celeron® N3060 on-board SoC
(up to 2.48GHz, dual-core, 2MB cache, TDP=6W)
Intel® Celeron® N3010 on-board SoC
(up to 2.24GHz, dual-core, 2MB cache, TDP=4W)
Intel® Celeron® x5-E8000 on-board SoC
(up to 2.00GHz, quad-core, 2MB cache, TDP=5W)
BIOS AMI UEFI BIOS
Me m o r y One 204-pin 1333/1600 MHz single-channel DDR3L SDRAM
unbuffered SO-DIMM slot supports up to 8 GB
Graphics Intel® HD Graphics Gen 8 Engine with 16 low-power execution
units, supporting DX11.1, OpenGL 4.2 and OpenCL1.2
Display Output Dual independent display
2 x Mini HDMI (up to 3840x2160@30Hz)
Ethernet LAN1: Realtek RTL8111 controller
EC IT8587
Watchdog Timer Software programmable support 1~255 sec. system reset
I/O Interface
Audio Connector 1 x HD Audio by 10-pin (2x5) header
Ethernet One RJ-45 port
Serial Ports 1 x RS-232 (by pin header)
US B Ports 1 x USB 3.0 (on rear I/O)
3 x USB 2.0 (1 on rear I/O, 2 by pin header)
Front Panel 1 x Front panel by 10-pin (1x10) header
(power LED, HDD LED, power button, reset button)
LAN LED 1 x 2-pin (1x2) header
Fan 1 x Smart fan connector by 4-pin (1x4) wafer
Expa n s ion 1 x M.2 2242 (B-Key)
Serial ATA 1 x SATA 6G/s with 5V SATA power connector
(No RAID) (SATA port0)
Environmental and Power Specifications
Power Supply 12V DC input only, support AT/ATX mode
1 x Power terminal block (1x2 pin)
Power Consumption [email protected] (Intel® Pentium® processor N3710 with 8 GB 1600
MHz DDR3L memory)

2
Operating Temperature -20°C ~ 60°C
Storage Temperature -30°C ~ 70°C
Humidity 5% ~ 95%, non-condensing
Vibra tio n 3G
Physical Specifications
Dimensions 100 mm x 72 mm
Weig h t GW/NW 600 g / 250 g
Ordering Information / 訂購資料
HYPER-BW-N4-R10

:
Pico-ITX SBC with Intel® Pentium® 14nm quad-core N3710 up to 2.56GHz (6W)
on-board SoC with dual Mini HDMI, PCIe GbE, M.2, USB 3.0, SATA 6Gb/s, COM, Audio
and RoHS
HYPER-BW-N3-R10

:
Pico-ITX SBC with Intel® Celeron® 14nm quad-core N3160 up to 2.24GHz (6W)
on-board SoC with dual Mini HDMI, PCIe GbE, M.2, USB 3.0, SATA 6Gb/s, COM, Audio
and RoHS
HYPER-BW-N2-R10

:
Pico-ITX SBC with Intel® Celeron® 14nm dual-core N3060 up to 2.48GHz (6W)
on-board SoC with dual Mini HDMI, PCIe GbE, M.2, USB 3.0, SATA 6Gb/s, COM, Audio
and RoHS
HYPER-BW-N1-R10

:
Pico-ITX SBC with Intel® Celeron® 14nm dual-core N3010 up to 2.24GHz (4W)
on-board SoC with dual Mini HDMI, PCIe GbE, M.2, USB 3.0, SATA 6Gb/s, COM, Audio
and RoHS
HYPER-BW-E8-ECO-R10

:
Pico-ITX SBC with Intel® Atom® 14nm quad-core x5-E8000 up to 2.00GHz (5W)
on-board SoC with dual Mini HDMI, PCIe GbE, M.2, USB 3.0, SATA 6Gb/s, COM, Audio,
ECO packing and RoHS
HYPER-BW-E8-R10

:
Pico-ITX SBC with Intel® Atom® 14nm quad-core x5-E8000 up to 2.00GHz (5W)
on-board SoC with dual Mini HDMI, PCIe GbE, M.2, USB 3.0, SATA 6Gb/s, COM, Audio
and RoHS
32000-070301-RS

: Dual-port USB cable
AC-KIT-892HD-R10 : Realtek ALC892 7.1 channel HD Audio board, RoHS

3
Connector Pinouts / 連接器腳位定義
US B_CON1: External USB 2.0 and USB 3.0 connector
Pin Description Pin Description
1 +5V 2 USB2P0_DM0_L
3 USB2P0_DP0_L 4 GND
5 USB3P0_RXDN0_C 6 USB3P0_RXDP0_C
7 GND 8 USB3P0_TXDN0_C
9 USB3P0_TXDP0_C 10 +5V
11 USB2P0_DM1_L 12 USB2P0_DP1_L
13 GND
CO M1: RS-232 s erial port connector
Pin Description Pin Description
1 NDCD1 6 NDSR1
2 NRXD1 7 NRTS1
3 NTXD1 8 NCTS1
4 NDTR1 9 NRI1
5 GND 10 GND
F_PANEL1: Front panel connector
Pin Description Pin Description
1 NC 2 PWRBTN_SW
3 GND 4 HDDLED+
5 HDDLED- 6 PWRLED+
7 HDDLED+ 8 GND
9 EXTRST- 10 GND
J_ AUDIO 1: HDA audio connector
Pin Description Pin Description
1 HDA_SYNC 2 HDA_BCLK
3 HDA_SDO 4 HDA_SPKR
5 HDA_SDI 6 HDA_RST#
7 +5V 8 AGND
9 +12V 10 AGND

4
US B2: US B 2.0 connector
Pin Description Pin Description
1 +5V 2 GND
3 USB20_C_N2 4 USB20_C_P3
5 USB20_C_P2 6 USB20_C_N3
7 GND 8 +5V
S P I1 : BIOS FW connector
Pin Description Pin Description
1 +SPI_VCC 2 SPI_CS0#_CN
3 SPI_SO0_CN 4 SPI_CLK0_CN
5 SPI_SI0_CN 6 GND
EC_J P1: EC FW connector
Pin Description Pin Description
1 SMB_CLK_FW 2 SMB_DATA_FW
CP U_FAN1: CP U fa n connector
Pin Description Pin Description
1 GND 2 +12V
3 FANIO1 4 FANOUT1
S MBUS 1: S MBu s connector
Pin Description Pin Description
1 GND 2 SMB_DATA
3 SMB_CLK 4 +V5S
LED_LAN1: LAN1 link LED connector
Pin Description Pin Description
1 +3.3VLAN 2 LAN1_LED_LINK#

5
PWR1: +12VDC power input connector
Pin Description Pin Description
1 GND 2 12V
S ATA1 : S ATA connector
Pin Description Pin Description
1 GND 2 SATA_TX0+
3 SATA_TX0- 4 GND
5 SATA_RX0+ 6 SATA_RX0-
7 GND
S ATA_ P W R 2 : SATApower connector
Pin Description Pin Description
1 +5V 2 GND
SP1: Buzzer connector
Pin Description Pin Description
1 5V 2 GND
J _ ATX_ AT1 : AT/ AT X p o w e r mode selection
Pin Description
Short 1-2 ATX power mode (default)
Short 2-3 AT power mode
J _CMOS 1: Clear CMOS button
Pin Description
Open Normal operation
Push Clear CMOS

6
Dim e n s io n s / 尺吋 (Unit: mm)

7
