IEI Technology HPCIE-Q170 User manual

1
Half-size PICMG 1.3 CPU Card supports LGA1151 Intel®
Core™ i7/i5/i3/Pentium®/Celeron® CPU, Intel® Q170,
DDR4, VGA, iDP, Dual Intel® PCIe GbE, USB 3.0, SATA 6Gb/s,
PCIe Mini, mSATA, HD Audio, Intel® AMT and RoHS
HPCIE-Q170
Quick Installation Guide
Version 1.0
November 9, 2015
Package Contents
HPCIE-Q170 package includes the following items:
1 x HPCIE-Q170 single board computer
1 x SATA cable
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2015 Copyright by IEI Integration Corp.
All rights reserved.

2
Specifications
CPU: 6th generation LGA1151 Intel® Core™ i7/i5/i3, Pentium® or
Celeron® processor
PCH: Intel® Q170
BIOS: UEFI BIOS
Memory: two 260-pin 1600/2133 MHz dual-channel non-ECC
unbuffered DDR4 SO-DIMM (system max. 32 GB)
Graphics: 9th generation Intel® HD Graphics, supporting DX11/12,
OpenCL 2.x and OpenGL 4.3/4.4 decode/encode for HEVC, VP8, VP9,
VDENC
Display Output:
1 x VGA (via Chrontel CH7517A, up to 1920x1200 @ 60Hz)
1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160 @
60Hz)
Ethernet:
LAN1: Intel® I219-LM with Intel® AMT 10.0 support
LAN2: Intel® I211 PCIe controller
Super I/O: Fintek F81866D
Embedded Controller: ITE IT8587VG
External I/O Interface
2 x RJ-45 GbE
2 x USB 3.0
1 x VGA
Internal I/O Interface
4 x USB 2.0 (1x4 pin, p=2.0)
2 x RS-232/422/485 (2x5 pin, p=2.0)
1 x iDP (1x4 pin, p=2.0)
1 x KB/MS (1x6 pin)
Storage:
2 x SATA 6G/s (Q170 supports RAID 0, 1)
1 x PCIe Mini supports mSATA & USB 2.0 mSATA

3
Expansion:
16 lanes PCIe signal from CPU via golden finger
(support x16 or x8 + x8 or x4 + x4 + x8)
4 lanes PCIe signal from Q170 via golden finger
Audio: supports 7.1 channel HD Audio by IEI AC-KIT-892HD kit
Front Panel
1 x Front panel connector supports power LED, HDD LED, speaker,
power button and reset button
SMBus: one SMBus (1x4 pin)
I
2C: one I2C (1x4 pin)
LAN LED: two LAN LED connectors (1x2 pin)
Digital I/O: one 8-bit digital I/O (2x5 pin)
Fan Connector
1 x Smart fan connector (1x4 pin)
Watchdog Timer: Software programmable supports 1~255 sec. system
reset
Power Supply
5V or 12 V DC input
Support AT/ATX mode
Operating Temperature: -20°C ~ 60°C
Humidity: 10% ~95%, non-condensing
Dimensions: 169 mm x 126 mm
Weight:
GW:1000g
NW:420g
Ordering Information
HPCIE-Q170-R10:
Half-size PICMG 1.3 CPU Card supports LGA1151 Intel® Core™
i7/i5/i3/Pentium®/Celeron® CPU, Intel® Q170, DDR4, VGA, iDP, Dual

4
Intel® PCIe GbE, USB 3.0, SATA 6Gb/s, PCIe Mini, mSATA, HD Audio,
Intel® AMT and RoHS
19800-000075-RS: KB/MS cable with bracket
32102-000100-200-RS: SATA power cable
32200-015100-RS: LPT cable
32200-074800-RS: RS-422/485 cable, 200mm
AC-KIT-892HD-R10: 7.1 channel HD Audio kit with Realtek ALC892
support dual audio streams
CF-1150SA-R10: special cooler kit for LGA1150, high-performance
compatible, 95W
CF-1150SB-R10: special cooler kit for LGA1150, High-performance
compatible, 65W
CF-1150SC-R20: special cooler kit for LGA1150, 1U chassis
compatible, 65W
CF-1150SE-R10: special cooler kit for LGA1150, 1U chassis
compatible, 95W
CF-1150SF-R10: special cooler kit for LGA1150, 1U chassis
compatible, 54W
DP-DP-R10: DisplayPort to DisplayPort converter board (for IEI IDP
connector)
DP-DVI-R10: DisplayPort to DVI-D converter board (for IEI IDP
connector)
DP-HDMI-R10: DisplayPort to HDMI converter board (for IEI IDP
connector)
DP-LVDS-R10: DisplayPort to LVDS converter board (for IEI IDP
connector)
DP-VGA-R10: DisplayPort to VGA converter board (for IEI IDP
connector)
SAIDE-KIT01-R10: SATA to IDE/CF converter board

5
Jumpers and Connectors
LABEL FUNCTION
J_ATX_AT1 AT/ATX mode select switch
J_CMOS1 Clear CMOS button
SW_BIOS1_1 BIOS setting jumper
COM1, COM2 Internal serial ports, RS-232/422/485
F_PANEL1 Front panel pin header
USB1, USB2 Internal USB 2.0 ports
CN1, CN2 External USB 3.0 ports
DIO1 8-bit digital I/O connector
JSPI1 BIOS SPI ROM programming connector
CPU_FAN1 CPU smart fan connector
LED_LAN1, LED_LAN2 LAN link LED connector
KB_MS1 Keyboard & mouse pin header
CPU12V1 +12V DC power input connector
SMB1 SMBus connector
I2C1 I2C connector
DP1 Internal display port connector
S_ATA1, S_ATA2 SATA 6Gb/s drive connectors
VGA1 External VGA connector
J_AUDIO1 Audio pin header
MPCIE1 mSATA module slot
LAN1, LAN2 RJ-45 GbE connectors
SW_BIOS1_1: BIOS Setting
PIN NO. DESCRIPTION
Short 1-2 BIOS1 (Default)
Short 2-3 BIOS2

6
USB SW1: External USB (CN1 & CN2) Power Setting BIOS Option
BIOS Option DESCRIPTION
+5V DUAL (default) Set the power source to +5V DUAL for the
external USB ports (CN1 & CN2)
+5V Set the power source to +5V for the
external USB ports (CN1 & CN2)
USB SW2: Internal USB (USB1 & USB2) Power Setting BIOS Option
BIOS Option DESCRIPTION
+5V DUAL (default) Set the power source to +5V DUAL for the
internal USB ports (USB1 & USB2)
+5V Set the power source to +5V for the
internal USB ports (USB1 & USB2)
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled(ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCI Azalia Configuration
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
------------------
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
J_ATX_AT1: AT/ATX Mode Select Switch
PIN NO. DESCRIPTION
Short 1 - 2 ATX Mode (default)
Short 2 - 3 AT Mode
J_CMOS1: Clear CMOS Button
PIN NO. DESCRIPTION
Open Normal Operation (Default)
Push Clear CMOS

7
J_FLASH1: Flash Descriptor Security Override Jumper
PIN NO. DESCRIPTION
Short 1 - 2 No override
Short 2 - 3 override
CHASSIS1: Chassis Intrusion Jumper
PIN NO. DESCRIPTION
Open Chassis close (default)
Short Chassis open
F_PANEL1: Front Panel Pin Header
PIN DESCRIPTION PIN DESCRIPTION
1 NC 6 PWR_LED+
2 PWRBTSW# 7 PWR_LED+
Power
Button 3 GND
Power
LED 8 GND
4 +V5S 9 RESET+
HDD
LED 5 HDD_LED-
Reset 10 GND
COM1, COM2: RS-232/422/485 Internal Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DCD 2 DSR
3 SIN 4 RTS
5 SOUT 6 CTS
7 DTR 8 RI
9 GND 10 GND

8
CPU_FAN1: CPU Smart Fan Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 3 FANIO
2 +12V 4 PWM
JSPI1: BIOS SPI ROM Programming Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +V3.3M_SPI_CON 4 SPI_CLK_SW
2 SPI_CS 5 SPI_SI_SW
3 SPI_SO_SW 6 GND
DIO1: Digital I/O Pin Header
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 VCC
3 DOUT3 4 DOUT2
5 DOUT1 6 DOUT0
7 DIN3 8 DIN2
9 DIN1 10 DIN0
CN1, CN2: External USB 3.0 Port
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VBUS 2 D-
3 D+ 4 GND
5 STDA_SSRX_N 6 STDA_SSRX_P
7 GND 8 STDA_SSTX_N
9 STDA_SSTX_P
USB1, USB2: USB 2.0 Port Pin Header
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC 2 GND
3 DATA- 4 DATA+
5 DATA+ 6 DATA-
7 GND 8 VCC

9
I2C1: I2C Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 3
PCH_GP39
(I2C_CLK)
2 PCH_GP38
(I2C_DAT) 4 +5V
SMB1: SMBus Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 3 SMBCLK
2 SMBDATA 4 +5V
CPU12V1: +12V DC Power Input Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 +12V 4 +12V
KB_MS1: Keyboard & Mouse Pin Header
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC 4 KBDATA
2 MSDATA 5 KBCLK
3 MSCLK 6 GND
LED_LAN2: LAN2 LED Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3VLAN 2 LAN2_LINK_ACT-
LED_LAN1: LAN1 LED Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3VLAN 2 LAN1_LINK_ACT-

10
J_AUDIO1：Audio Kit Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 HDA_SYNC 2 HDA_BIT_CLK
3 HDA_SDOUT 4 HDA_SPKR
5 HDA_SDIN 6 HDA_RST#
7 HDA_VCC 8 HDA_GND
9 HDA_+12V 10 HDA_GND
S_ATA1, S_ATA2: SATA 6Gb/s Drive Connectors
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 SATA_TX+
3 SATA_TX- 4 GND
5 SATA_RX+ 6 SATA_RX-
7 GND
DP1: Internal Display Port Pin Header
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 HPD 2 AUXP
3 GND 4 AUXN
5 AUX_CTRL_DET_D 6 GND
7 GND 8 LANE2P
9 LANE3P 10 LANE2N
11 LANE3N 12 GND
13 GND 14 LANE0P
15 LANE1P 16 LANE0N
17 LANE1N 18 +3.3V
19 +5V 20 NC

11
MPCIE1: mSATA Slot
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 PCIE_WAKE# 2 +3.3V
3 N/C 4 GND
5 N/C 6 1.5V
7 N/C 8 N/C
9 GND 10 N/C
11 MSATA_CLK# 12 N/C
13 MSATA _CLK 14 N/C
15 GND 16 N/C
17 PLTRST_N 18 GND
19 N/C 20 +3.3V
21 GND 22 PLTRST_N
23 SATA_RX+ 24 +3.3V
25 SATA_RX- 26 GND
27 GND 28 1.5V
29 GND 30 SMB_CLK
31 SATA_TX- 32 SMB_DATA
33 SATA_TX+ 34 GND
35 GND 36 USB_DATA-
37 GND 38 USB_DATA+
39 +3.3V 40 GND
41 +3.3V 42 N/C
43 +3.3V 44 N/C
45 CLINK_CLK 46 N/C
47 CLINK_DATA 48 1.5V
49 CLINK_RST# 50 GND
51 MSATA_DET 52 +3.3V

12
Board Layout: Jumper and Connector Locations

13
(Unit: mm)
