IGEL UD2 / IZ2
HARDWARE MANUAL
VERSION 1.0 – February, 2018

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
2/11 Version 1.0 – February, 2018
Information
Copyright
This publication is protected under international copyright laws. All rights reserved. With
the exception of docu entation kept by the purchaser for backup purposes, no part of
this anual – including the products and software described in it – ay be reproduced,
anipulated, trans itted, transcribed, copied, stored in a data retrieval syste or
translated in any for or by any eans without the express written per ission of IGEL
Technology G bH.
Copyright © 2018 IGEL Technology G bH. All rights reserved.
Disclaimer
The specifications and infor ation contained in this anual are intended for infor ation
use only, are subject to change at any ti e without notice and should not be construed
as constituting a co it ent or obligation on the part of IGEL Technology G bH. IGEL
Technology G bH assu es no responsibility or liability for any errors or inaccuracies
that ay appear in this anual, including any pertaining to the products and software
described in it. IGEL Technology G bH akes no representations or warranties with
respect to the contents thereof and specifically disclai s any i plied warranties of
erchantability or fitness for any particular purpose.
Warranty
After purchase, just register with us online, and all your IGEL thin clients UD2, UD3, UD6
and UD7 will be upgraded fro a standard 2-year to a 5-year hardware warranty,
according to our end custo er hardware warranty declaration, at no additional cost.
The UD Pocket, UD9, IZ2 and IZ3 series will be upgraded to a 3-year hardware warranty.
The warranty upgrade does not cover any additional hardware options.
Find further infor ation on our website under
https://www.igel.co /product-warranty
IGEL is a registered trade ark of IGEL Technology G bH. All hardlware and software
na es are registered trade arks of the respective anufacturers. Errors and o issions
excepted. Subject to change without notice.
IGEL Technology G bH
Hanna-Kunath-Str. 31
28199 Bre en, Ger any
Tel.: [phone]
Fax: [phone]
[email protected]
Hardware eference
IGEL UD2 / IZ2 (IGEL-D220)
Docu ent Version 1.0 – February, 2018

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
3/11 Version 1.0 – February, 2018
Safety Instructions
Read these instructions carefully and save the for future reference.
• Disconnect this equip ent fro ains supply before cleaning. Don’t use liquid or sprayed
detergent for cleaning. Use oisture sheet or cloth for cleaning.
• Before opening the device, first switch it off and then disconnect the power plug. Observe
the specification in the user anual.
• The warranty will be invalidated if the device is da aged during the installation or
replace ent of syste expansions.
• Lay this equip ent on a reliable surface when installed. A drop or fall could cause injury.
• Make sure power adapter and power cord are placed in a way that people cannot step on
the . Do not place anything over the power adapter or power cord.
• All cautions and warnings on the equip ent should be noted.
• If the equip ent is not used for long ti e, disconnect the equip ent fro ains supply to
avoid being da aged by transient overvoltage.
• Make sure that no objects or liquids get inside the device (danger of electric shock, fire, short
circuit).
• If one of the following situations occurs, get the equip ent checked by a service personnel:
o The power adapter, power cord or plug is da aged.
o Liquid has penetrated into the equip ent.
o The equip ent has been exposed to oisture.
o The equip ent does not work well or you cannot get it work according to user anual.
o The equip ent has been dropped or da aged.
o The equip ent has obvious signs of breakage.
• Do not leave this equip ent in an unconditioned environ ent. Storage te perature below -
20 °C (-4 °F) or above 60 °C (140 °F) ay cause da age of the equip ent.
• Do not use this equip ent in an unconditioned environ ent. Unless otherwise stated in the
technical specifications operational conditions ay not exceed the following li its, it ay
da age the equip ent:
o Vertical usage:
Te perature: 0 °C to 35 °C, 32 °F to 104 °F
Hu idity: 10 % to 80 %, non-condensing
o Horizontal usage (only with optional rubber feet, no VESA ount):
Te perature: 0 °C to 35 °C, 32 °C to 95 °F
Hu idity: 10 % to 80 %, non-condensing
• Note that even in closed roo s local te peratures ay increase, for instance in case the
device is exposed to strong sun radiation. Protect the device fro external heat sources.
• Ensure that air is free to circulate through the product. Do not use in a poorly ventilated
place. Do not cover it with a cloth or place it on soft ground. Surrounding objects of the
device ay block the air flow.
• Horizontal usage with optional rubber feet: Tilt the housing to the left so that the power
button is one the left-hand side:

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
4/11 Version 1.0 – February, 2018
• Gloss warning for devices without display: This device is not intended for use in the direct
field of view at visual display workplaces. To avoid inco oding reflexions at visual display
workplaces this device ust not be placed in direct field of view.
• Lithiu battery caution:
o The Lithiu battery (button cell) installed in the device ay only be replaced by
authorised, specially trained personnel.
o Contact your supplier or the anufacturer for servicing and repairs.
o Danger of explosion if battery is incorrectly replaced.
o Dispose of used batteries according to the anufacturer’s instructions.
• Excessive sound pressure fro ear-/headphones can cause hearing da age/hearing loss.
Adjust ent of the volu e control as well as the equalizer to other settings than the centre
position ay increase the ear-/headphones output voltage and therefore the sound pressure
level. The use of factors influencing the ear-/headphones output other than those specified
by the anufacturer (e.g. operating syste , equalizer software, fir ware, driver) ay
increase the ear-/headphones output voltage and therefore the sound pressure level.
• UL 62368: This equip ent ust be grounded. The power cord for the equip ent ust only
be connected to socket-outlets providing earthing connection.
• Visit www.igel.co for the latest product infor ation and safety instructions updates.
• Specific Safety Instructions for UD9:
o To avoid da age or alfunction, do not use hard or abrasive objects for touching the
LCD odule.
o Do not exert pressure on the LCD odule.
o Use a soft dry cloth without che icals for cleaning, because the surface of polarizer is
very soft and easily scratched.
o It is dangerous that oisture co e into or contacted the LCD odule, because oisture
ay da age LCD odule when it is operating.
o If the liquid crystal aterial leaks fro the panel, it should be kept away fro the eyes or
outh. In case of contact with hands, skin or clothes, it has to be washed away
thoroughly with soap.
o When fixed patterns are displayed for a long ti e, re nant i age is likely to occur.
o Do not leave the LCD odule facing the sun.
Visit edocs.igel.co
for more information.

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
5/11 Version 1.0 – February, 2018
Connections
Part List
• Thin/Zero Client Unit
• Foot
• Power Supply with integrated DC Cable
• AC Power Cord
• DVI-VGA-Adapter
Power Connection Note
• Connect all accessories e. g. ouse, keyboard, screen (not part of the equip ent), and
Ethernet.
• Connect the AC power cord with the receptacle of the Power Supply.
• Connect the other end of the AC power cord with a suited ains socket.
• Connect the DC cable with the DC In receptacle on the rear side of the Thin Client.
• Switch on the Thin Client by use of the power button on the front side.
Power Switch
Cover
(Line-out, Mic-in, 1 x USB 3.0)
Foot
3 x USB 2.0
Ethernet
RJ45
DVI
-
D
DVI-I
Security Lock
12 V DC In

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
6/11 Version 1.0 – February, 2018
Technical Specifications
Syste
Available Operating Syste s IGEL OS 10
Manage ent IGEL Universal Manage ent Suite included
Processor Intel Ato E3815 1.46 GHz (Single-Core)
Chipset Build in SoC
Me ory
RAM 2 GB
Storage 4 GB
Graphics
Chipset Intel HD Graphics
Video Me ory 64-256 MB Shared Me ory
Ports 1x DVI-I, 1x DVI-D
Supported Resolutions Dualview 1920 x 1200
Network
Ethernet 10/100/1000 Base-T
Audio
Chipset Realtek ALC269
Ports Front: 1x line-out, 1x ic-in
Speakers 1x internal
Peripheral Interfaces
USB 2.0 3x back
USB 3.0 1x front
Security Lock 1x back
Di ensions and Weight
Device (DxWxH), vertical 200 x 48 x 182 (without foot stand)
205 x 63 x 194 (with foot stand)
Packaging (DxWxH) 275 x 95 x 260
Weight 1.31 kg (with foot stand and external power adapter)

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
7/11 Version 1.0 – February, 2018
Environ ental Conditions
Strictly follow safety instructions and respect environ ental conditions!
Cooling fanless convection
Operating Te perature 0 °C – 40 °C vertical
0 °C – 35 °C horizontal (with optional rubber feet only)
Operating Hu idity 20 % – 90 % non-condensing
Electrical Data
Power Supply external
Power Supply AC Input 100 – 240 V / 50 – 60 Hz
Power Supply DC Output 12 V / 3 A External Power Adapter
(Au1361203n or A140-1120300N)
Power Consu ption 4.7 W (idle) / 0.6 W (sleep) / < 0.6 W (off)
(@230 V, 50 Hz)
Typical Energy Consu ption
(ENERGY STAR)
E
TEC
22.6 kWh (per year)
E
TEC, ax
62.0 kWh (per year)
Options for Device Mounting
For ounting options visit also edocs.igel.co .
VESA Mount for ounting on the back of a onitor
vertical ounting only!
Rubber feet for horizontal place ent of the device
Optional Accessories
USB-to-Serial Adapter for connecting peripherals that require a serial port
USB-to-Parallel Adapter for connecting printers that require a parallel port
Shared WorkPlace (only UD2) it allows user-dependent configuration based on setting
profiles
Multi edia Codec Pack
(only IGEL OS)
required for ulti edia re-direction and full ulti edia
functionality

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
8/11 Version 1.0 – February, 2018
egulatory Compliance Information
FCC Compliance Statement
This equip ent has been tested and found to co ply with the li its for a Class B digital device,
pursuant to Part 15 of the FCC rules. These li its are designed to provide reasonable protection
against har ful interference in a residential installation. This equip ent generates, uses and can
radiated radio frequency energy and, if not installed and used in accordance with the instructions,
ay cause har ful interference to radio co unications. However, there is no guarantee that
interference will not occur in a particular installation. If this equip ent does cause har ful
interference to radio or television reception, which can be deter ined by turning the equip ent
off and on, the user is encouraged to try to correct the interference by one or ore of the following
easures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equip ent and receiver.
• Connect the equip ent into an outlet on a circuit different fro that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables ust be used in order to co ply with e ission li its.
Changes or odifications not expressly approved by the party responsible for co pliance could
void the user’s authority to operate the equip ent.
TÜV-GS Statement
This device is not intended for use in the direct field of view at visual display workplaces. To avoid
inco oding reflexions at visual display workplaces this device ust not be placed in the direct
field of view.
ENE GY STA Information
IGEL Thin Clients with a Microsoft Windows E bedded Standard or Linux operating syste have
been shipped enabled for power anage ent. The display Sleep ode will be activated after 15
inutes of user inactivity (default setting). The standby settings can be anaged via the BIOS
and local setup. The activation fro the standby or Off ode can be done locally (by oving of
the ouse or pressing a key on the key board) and via the Ethernet connection (Wake-On-LAN).
Energy Star Progra
Power anaging your ENERGY STAR qualified co puter can save up to 340 kWh annually or 25€
($35) per year. These energy savings are equivalent to:
• Preventing over 225 kg (500 lbs) of CO
2
e issions per year
• Planting over 185  (2,000 sq ft.) of forest
To learn how to power anage your co puters at your office all at once through network
solutions, please go to: www.energystar.gov.
ENERGY STAR is the govern ent-backed progra that helps us all save oney and protect our
environ ent with energy-efficient products and practices (see www.energystar.gov).

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
9/11 Version 1.0 – February, 2018
EPEAT Note
IGEL Technology G bH is an EPEAT subscriber. EPEAT is operated by the nonprofit Green
Electronics Council. EPEAT is used by the U.S. Govern ent to identify greener products. For
ore infor ation visit https://www.epeat.net.
The following odels are EPEAT Silver rated in the U.S.:
IGEL IZ2-HDX
IGEL IZ2-RFX
IGEL IZ2-Horizon
IGEL UD2-LX
For all EPEAT registered odels visit https://www.epeat.net.
WEEE and Battery Waste Note
In accordance with EU directive 2012/19/EU on Waste Electrical and Electronic Equip ent
(WEEE) and Directive 2006/66/EC for waste batteries, custo ers and anufacturers are
responsible for returning and recycling their old equip ent and batteries. IGEL now offers a
convenient return service.
As of August 15, 2005, all IGEL Thin Clients sold bear the WEEE and battery waste seal. All Thin
Clients labelled with this sticker are taken back and disposed of i ediately at no charge
(including the battery). For IGEL custo ers, this eans better service and greater convenience,
because IGEL Technology handles the professional recycling of all Thin Clients (including the
lithiu battery).
Report disposal online: Under the heading, “Waste Manage ent WEEE” on the IGEL Ho epage
(www.igel.co ) there is an online for that ust be filled in for the old IGEL units to be picked
up. Such infor ation as the address, series nu ber, contact person, nu ber of units to be
re oved and the desired disposal date are urgently required for the s ooth processing of waste.
Pickup: I ediately after sending in your data, you will receive fro the IGEL Service Center a
notice of confir ation of receipt. Then an IGEL service e ployee will contact you to arrange a
date to pick up the unit.
IGEL WEEE Nu ber: DE 79295479 / WEE/GE4266QU.
This product contains no postconsu er recycled plastic (0 %) and no renewable / biobased
plastic aterials (0 %). The packaging aterial contains the following recycling content:
Corrugated cardboards between 33 % and 69 %, plastic bags 0 %.
oHS and EACh Note
This product of IGEL Technology G bH fulfils the require ents of the EU directive 2011/65/EU
on the Restriction of the Use of certain Hazardous Substances in Electrical and Electronic
Equip ent (RoHS). The product is arked accordingly.
The EU Regulation 1907/2006 for Registration, Evaluation, Authorisation and restriction of
Che icals (REACh) shall i prove the protection of hu an health and the environ ent fro the
risks that can be posed by che icals. IGEL fulfils this regulation by infor ing custo ers and
partners about aterials on the Candidate List of Substances of Very High Concern (SVHC) in our
products in a concentration above 0.1 % weight by weight (w/w).
Find current infor ation about SVHC aterials on our website under
http://www.igel.co /ter s-conditions

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
10/11 Version 1.0 – February, 2018
Ericom PowerTerm
Terminalemulation
Lern How to Activate the Ericom PowerTerm
Terminalemulation of Your IGEL Thin Client
To use your Erico PowerTer Ter inale ulation you need a free license key fro IGEL. To get
to the activation for please register yourself at our support and ticket syste here:
www.igel.co /powerter .
After successful registration you have access to free technical support, and to the IGEL Service-
and Repair-Center as well as to the license activation for .
To activate your PowerTer license please fill out the license activation for . Enter the total
nu ber and MAC addresses of the devices to be activated. The following link provides a step-by-
step description on how to use the UMS to extract a list of MAC addresses for a large nu ber of
devices: www.igel.co /powerter _ ac
You will receive the required license keys via e ail fro our IGEL service tea . Using the Universal
Manage ent Suite (UMS) you can then re otely deploy the licenses tothe devices in your
network.

IGEL Technology G bH Hardware Manual IGEL UD2 / IZ2
11/11 Version 1.0 – February, 2018
