Ignition WRX-1 User manual

U S E R M A N U A L
WRX-1
Single DMX universe receiver

2 / 9
WRX- 1
Table of contents
1. Safety instructions ........................................................................................................................... 3
1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3
2. Description....................................................................................................................................... 4
3. Front panel details........................................................................................................................... 5
4. Rear panel details............................................................................................................................ 5
5. Technical data ................................................................................................................................. 6
6. Installation........................................................................................................................................ 8
6.1. To link with a transmitter.......................................................................................................... 8
6.2. To unlink from a transmitter..................................................................................................... 8
7. Trussholders mounting.................................................................................................................... 8

3 / 9
WRX- 1
1. Safety instructions
This device is suitable for indoor use only.
All modifications to the device will void the warranty.
Repairs are to carry out by skilled personnel only.
Use only fuses of the same type and original parts as spare parts.
Protect the unit from rain and humidity to avoid fire and electric shocks.
Make sure to unplug the power supply before opening the housing.
1.1.FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or exceeding 131°F /55°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug.
When not using the device for an extended period of time, be sure to disconnect the plug
from the receptacle.

4 / 9
WRX- 1
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or problems.
Make sure the electrical connection is carried out by qualified personnel. All electrical
and mechanical connections have to be carried out according to the European safety
standards.
2. Description
The WRX-1 indoor receiver is a user-friendly single receiver with “One-Button-2-Go“technology. The
WRX-1 receives all 512 channels DMX (one universe) wireless through the W-DMX technology that is
proven to be safe, reliable and easy to use.
WRX-1 can be used for both Multicasting and Point-to-Point systems. In a Multicast system, each
DMX 512 device has its own WRX-1, which negates the need for DMX 512 cable as the entire system
is wireless. In a Point-to-Point situation, W-DMX is used to “bridge” a distance.
There can of course be a combination of these two modes, for example a WSX-1 connected to the
console can transmit to 6 units of WRX-1, and each of the WRX-1 has a fixture connected that is
daisychained to several other units by cable on either same or different DMX addresses.
The WRX-1 has a built in universal power supply with 90-250 V guaranteed worldwide use without
problems.
All WRX-1 units are delivered with multipurpose brackets for easy mounting and rigging, as well as
standard 2 dBI rubber whip antenna. A multitude of other antenna options are available to increase the
standard transmission range.
All W-DMX products use the license free 2.45 GHz ISM band, and are certified for use in the United
States, Canada, Japan, and all European Union countries.
The WRX-1 uses FHSS, Frequency Hopping Spread Spectrum, along with a number of other
techniques to avoid interference and create a very reliable wireless link.

5 / 9
WRX- 1
3. Front panel details
Antenna Shows the receiving state
OFF:not linked with a transmitter
ON: linked with a transmitter
Rapid Flash: Linking with transmitters
ON: correct Power input
present
4. Rear panel details
Powercon In and Out
12V In
for Accu-
Pack
Usage
DMX Out
3Pin XLR
5Pin XLR
Rj45

6 / 9
WRX- 1
5. Technical data
DMX INTERFACE
Full compliance with USITT DMX-512 (1990) & 512-A standards
Maximum number of transceivers on a single bus: 32 (compliant with the EIA/TIA RS-485 standard)
Data rate
250kbps (slew rate limited to minimize EMI)
Electrostatic discharge protection
+/- 15 kV
DMX frame rate and frame size
Auto sensing
Frame rate
1 (min) to 44 (max) frames per second
Frame size
1 (min) to 512 (max) channels
Recovery from loss of DMX input or radio link
Less than 1 second
Loss of DMX input or radio link: After one second (if there is no resumption), the DMX output will
cease to transmit and go into a high impedance mode
Power characteristics
High voltage input
90-260 VAC
Low voltage input
12VDC
Average current (transmit mode)
200 mA @ 12VDC
RF characteristics
W-DMX uses Adaptive Frequency Hopping Spread Spectrum (AFHSS) and changes frequency every
910 us
Tested link range 450m (Low power EU mode using standard antenna in an urban area)
Operational frequency range
2402-2479MHz (ISM band)
EU/ASIA RF output power
20dBm or 100mW
FCC RF output power
25dBm or 275mW
Channel bandwidth
1 MHz
Sensitivity at 0.1% Packet Error Rate
95dBm
Approvals
FCC: 15.247&68 Class B; Canada ICES 003; Japan ARIB STD-T66
CE; EN 301 489-1; 301 489-17; EN 300-328-1; EN 300-328; EN 609 50

7 / 9
WRX- 1
Enclosure
Diecast aluminium casing
Operating temp range
0°C to +55°C (32°F to 131°F)
Dimensions (W x H x D)
219 x 45 x 131 mm (8.6“ x 1.8“ x 5.2“)
Weight
1005 g (35.45 oz)
Connectors
N-type female antenna connector, N-RP-SMA adaptor included
2 Neutrik XLR 5-pin gold plated DMX connectors
2 RJ45, DMX over Cat5 cable links
1 DC input, pluggable terminal strip, Phonix MSTB 2,5
1 AC input, IEC-6C

8 / 9
WRX- 1
6. Installation
1. Attach the antenna to the connector on the front panel. If using the standard antenna, use also
the supplied adaptor.
2. Link the DMX source to the DMX out socket on the rear panel.
3. Connect power to the unit either via the Powercon input (90 to 250 VAC) or the DC power
input (12 VDC). If using the AC input, fit an appropriate mains plug to the supplied power cord
–this should be carried out only by a qualified electrician.
6.1.To link with a transmitter
1. Ensure that this receiver is not linked with any other transmitter (W-DMX indicators should be
OFF)
2. On the transmitter unit, press and release the LINK button. The transmitter will scan for all
unlinked receivers for a period of ten seconds.
3. If successful, the receiver’s W-DMX indicator will go ON.
6.2.To unlink from a transmitter
1. On the receiver, press and hold the LINK button until the W-DMX indicator goes OFF. The
receiver is now unlinked.
7. Trussholders mounting
Use a standard Truss clamp to be inserted in the screw hole on top of the box.
Make sure that the installation is safe and secure.
