IH GTA12 Programming manual

Page: 1 (copyright) Paul Nipper –2012. www.inductioncooker.co.za (click to view)
GTA12 COOKER QUICK START INSTRUCTIONS –VERSION 1

Page: 2 (copyright) Paul Nipper –2012. www.inductioncooker.co.za (click to view)
GTA12 IH INDUCTION COOKER QUICK START INSTRUCTIONS –Version 1
Thank You for your valued purchase of a GTA12 IH Induction cooker.
To start, please plug your GTA12 Induction cooker into a standard 3 pin wall outlet.
To switch ON:
To switch on, press the ON OFF logo once.
To use the HOTPOT function and/or to set Wattage:
Press the Function logo until Hotpot lights up.
1300 (watts) will display on the LDC panel.
The W(o) indicator will light up in the centre panel.(watts indicator)
Press the UP or DOWN arrows to adjust Wattage up or down from 120 watts to 2000 watts.
The wattage range is 120, 400, 800, 1000, 1200, 1300, 1500, 1600, 1800 and 2000.
To use the FIRE function:
Press the Function logo until Fire lights up.
400 (watts) will display on the LDC panel.
The W(o) indicator will light up in the centre panel.(watts indicator)
This is a PRESET FUNCTION and no adjustment is necessary.
Press the ON OFF logo once should you want to stop the Fire function sooner.
To FRY:
Press the Function logo until Fry lights up.
270 (degrees) will display on the LDC panel.
The C(o) indicator will light up in the centre panel.(degrees indicator).
Press the UP arrow to adjust temperature from 60 degrees to 270 degrees or to your preferred temperature.
Press the DOWN arrow to adjust temperature down to your preferred temperature or to 60 degrees.
The degrees range is 60, 80, 100, 120, 140, 160, 180, 200, 220 and 270.
TIP: TO FRY EGGS PERFECTLY, SET THE TEMPERATURE TO 80-100 DEGREES AND PLACE A LID ON THE PAN.

Page: 3 (copyright) Paul Nipper –2012. www.inductioncooker.co.za (click to view)
To use the SOUP function:
Press the Function logo until Soup lights up.
2:00 (hours) will display on the LDC panel.
The Min(o) indicator will light up in the centre panel.(timer indicator).
This is a PRESET FUNCTION to prepare soup gradually at a low temperature for 2 hours and no adjustment is
necessary.
After 120 minutes (2:00 hours), the Induction cooker will switch off automatically.
This function can be used in conjunction with the TIMER FUNCTION, BUT THEN ONLY THE HOURS CAN BE
SET FROM 1-3 HOURS.
Press the ON OFF logo once should you want to stop the Soup function sooner.
To BOIL Water:
To boil water, press the Function logo until Water lights up.
A1 will display on the LDC panel.
The Induction cooker will start automatically.
This is a PRESET FUNCTION to boil water and no adjustment is necessary.
Press the ON OFF logo once to stop the Water function as soon as the water is boiling.
TIP: A STAINLESS STEEL STEAM KETTLE WORKS PERFECTLY TO BOIL WATER FOR COFFEE/TEA, ETC.
To use the MILK function:
Press the Function logo until Milk lights up.
0:20 (minutes) will display on the LDC panel.
The Min(o) indicator will light up in the centre panel.(timer indicator).
This is a PRESET FUNCTION to heat up milk gradually for 20 minutes and no adjustment is necessary.
After 20 minutes the Induction cooker will switch off automatically.
Press the ON OFF logo once should you want to stop the Milk function sooner.
To use the STEAM function:
Press the Function logo until Steam lights up.
0:30 (min) will display on the LDC panel.
The Min(o) indicator will light up in the centre panel.(timer indicator).
This is a PRESET FUNCTION to steam gradually for 30 minutes and no adjustment is necessary.
After 30 minutes, the Induction cooker will switch off automatically.
Press the ON OFF logo once should you want to stop the Steam function sooner.

Page: 4 (copyright) Paul Nipper –2012. www.inductioncooker.co.za (click to view)
To set the TIMER:
First select your cooking option by pressing the Function logo.
Set your desired temperature (degrees) or wattage (power) as per each option’s instructions detailed above.
Then press the TIMER logo once.
0:00 (hours/minutes) will display on the LDC panel.
The Min(o) indicator will light up in the centre panel.(timer indicator).
Press the UP (right) arrow to adjust the timer in minutes up to your preferred time from 1 –59 minutes.
Press the DOWN (left) arrow to adjust the timer in hours up to your preferred time from 1 –24 hours.
The Hour range is 1 - 24 hours. The minute range is 1 - 59 minutes
The GTA12 Induction cooker can ALSO be utilised as a SLOW COOKER BY SETTING THE WATTAGE AND
TIMER or BY SETTING THE DEGREES AND TIMER ACCORDING TO YOUR REQUIREMENTS.
To check electricity (KWH) usage:
Press the Electricity logo once.
Your (Kilowatt hours) usage will display on the LDC panel.
The Volt(o) indicator will light up in the centre panel.(voltage)
To calculate electricity usage:
Multiply the units displayed (THE DIGITS DISPLAYED ON CENTRE LCD AFTER PRESSING THE ELECTRICITY
LOGO ONCE) by your local municipalities cost per KW unit.
If viz; the LCD display shows 0:20 then the actual usage will be
0.20 (usage) x R1.50c (approx municipality cost per KW unit) = R0.30c.
To switch OFF:
Press the ON OFF logo once whereby cooker will switch off immediately.
Alternately you can remove your pot whereby cooker switches itself off after 30 seconds.
To extend your GTA12 Induction Cookers lifespan, please switch off at the wall plug or remove plug from the
wall outlet when not in use.
Always switch off the induction cooker before you unplug it.

Page: 5 (copyright) Paul Nipper –2012. www.inductioncooker.co.za (click to view)
PRECAUTION BEFORE USING YOUR GTA12 INDUCTION COOKER
1. The crystalline glass top is made of strong, hard and non-porous properties. In case of glass top breakage,
disconnect the appliance from the electrical socket immediately and contact me.
2. Do not place small metal kitchen utensils such as pan lids, knives, or other metal objects on the induction-
heating zone. If the induction cooker is switched on, there is a risk of them becoming hot.
3. When using your induction cooker, don't place any magnetic sensitive objects on the glass top, such as
credit cards, etc.
4. Scientific tests have shown that the induction cooker presents no danger for anyone using a pacemaker.
Please keep a 30 cm distance from the unit while the induction cooker is in use.
5. Put the appliance on a horizontal surface but keep away from the wall or other articles by at least 5-10cm.
6. To prevent an electric shock, do not put articles like iron wire or tools into the air entrance or outlet.
7. Immediate clean up with a soft non scratch cloth is recommended when water is left on the top plate.
8. Do not submerse the Induction cooker under water.
9. Do not clean the cooker top while it is still hot. Some cleaners produce fumes when applied to a hot
surface. Wipe and clean the ceramic glass plate and the appliance with a damp cloth once it has cooled off
and if necessary only use non-abrasive glass cleaning solution or some mild cleaning agent on spills.
10. Clean the induction cooker after each use. Turn Off the induction cooker and disconnect plug from
power source, and wait until the unit has cooled down before cleaning.
11. Ensure that your finger is placed in the centre of the touch pad button area of Induction cooker. If the
finger is not placed on the centre of a pad, the induction cooker may not respond to the selection made.
Touch the pad lightly with flat part of your entire fingertip.
12. Never put empty cookware on the powered-on induction cooker and allow it to heat up, as this could
cause the cookware to become distorted or damage the induction coil.
13. Always switch off the induction cooker before you unplug it.
POTS & PANS SUITABLE FOR THE GTA12 INDUCTION COOKER
1. Iron.
2. Cast iron.
3. Stainless steel*.
4. Enamelware.
5. Stainless steel base whistle kettle.
Above pots and pans must have a flat bottom and diameter of between 12 and 22 cm.
Test the cookware with a magnet to be sure cookware is made with Induction compatible material.
*All pots and pans must have a magnetic base.

Page: 6 (copyright) Paul Nipper –2012. www.inductioncooker.co.za (click to view)
POTS & PANS UNSUITABLE FOR GTA12 INDUCTION COOKER
1. Pot with diameter below 5 cm.
2. Stainless steel pots and pans with aluminium base.
3. Pottery.
4. Glass pans.
5. Aluminium pans.
6. Bronze pans.
7. Copper pots.
8. Pans with feet.
MODEL SPECIFICATIONS:
Model no: GTA12
Size: 350(L) x 280(w) x 65mm(h)
Coil width: 200mm
Power: 2000 watts (can be set from 120w - 2000w)
Temperature: 60 - 270 degrees Celsius
Timer: 1 minute - 24 hours
Cord length: 1 meter
ADDITIONAL FUNCTIONS:
* CENSOR TOUCH CONTROL
* 10 LEVEL SETTINGS, TEMPERATURE & POWER
* 4 DIGIT LED DISPLAY
* INTELLIGENT COOKING FUNCTIONS –HOTPOT, FIRE, FRY, SOUP, WATER, MILK & STEAM
* ENERGY CONSUMPTION METER
* BOIL DRY, HIGH & LOW VOLTAGE PROTECTION
* AUTO OFF IF POT REMOVED AFTER 30 SECONDS
HOW DOES YOUR GTA12 INDUCTION COOKER WORK?
A high frequency induction coil located underneath the crystalline glass top plate heats the cooking pan by
magnetic friction. The heat is produced directly within the pots or pans. It is controlled by an electronic
circuit to offer superior performance and functions. During cooking, no energy is lost between the Induction
cooker and the food. When you switch it off, cooking is stopped immediately.
Enjoy your GTA12 Induction Cooker!
Thank You.
Kind Regards
Paul Nipper
IH Induction Cookers
www.inductioncooker.co.za
Tel: [phone]
05 August 2012
