GTB2 COOKER QUICK START INSTRUCTIONS UPDATED – VERSION 3
Page: 1 (copyright) Paul Nipper - 2012 www.inductioncooker.co.za (click to view)

GTB2 IH INDUCTION COOKER QUICK START INSTRUCTIONS UPDATED – Version 3
Thank You or your valued purchase o a GTB2 IH Induction cooker.
To start, please plug your GTB2 Induction cooker into a standard 3 pin wall outlet.
To switch ON:
To switch on, press the ON OFF button once.
You will hear a single beep and ‘- - - - ‘ will display on the centre LDC panel.
Only the ON OFF light will display a red light.
To BOIL Water:
To BOIL water, press the Water button once.
The Water lcd will display a red light.
A1 will display on the LDC panel and you will hear a single beep.
The Induction cooker will start automatically.
This is a PRESET FUNCTION to boil water and no adjustment is necessary.
Press the ON OFF button once to stop the water unction as soon as the water is boiling.
TIP: A STAINLESS STEEL STEAM KETTLE WORKS PERFECTLY TO BOIL WATER FOR COFFEE/TEA, ETC.
To FRY:
To FRY press the FRY button once.
270 (degrees) will display on the LDC panel and you will hear a single beep.
The Fr lcd will display a red light.
The C(o) indicator will light up in the centre panel.(degrees indicator).
Press the UP arrow to adjust temperature rom 60 degrees to 270 degrees or to your pre erred temperature.
Press the DOWN arrow to adjust temperature down to your pre erred temperature or to 60 degrees.
The degrees range is 60, 80, 100, 120, 140, 160, 180, 200, 220 and 270.
TIP: TO FRY EGGS PERFECTLY, SET THE TEMPERATURE TO 80 DEGREES AND PLACE A LID ON THE PAN.
To use the HOTPOT function and/or to set Wattage:
Press the Hotpot button once.
1300 (watts) will display on the LDC panel and you will hear a single beep.
The Hotpot lcd will display a red light.
The W(o) indicator will light up in the centre panel.(watts indicator)
Press the UP or DOWN arrows to adjust Wattage up or down rom 120 watts to 2000 watts.
The wattage range is 120, 400, 800, 1000, 1200, 1300, 1500, 1600, 1800 and 2000.
Page: 2 (copyright) Paul Nipper - 2012 www.inductioncooker.co.za (click to view)

To use the MIL function:
Press the Milk button once.
0:20 (minutes) will display on the LDC panel and you will hear a single beep.
The Milk lcd will display a red light.
The Min(o) indicator will light up in the centre panel.(timer indicator).
This is a PRESET FUNCTION to heat up milk gradually or 20 minutes and no adjustment is necessary.
A ter 20 minutes the Induction cooker will switch o automatically.
Press the ON OFF button once should you want to stop the Milk unction sooner.
To use the SOUP function:
Press the Soup button once.
2:00 (hours) will display on the LDC panel and you will hear a single beep.
The Soup lcd will display a red light.
The Min(o) indicator will light up in the centre panel.(timer indicator).
This is a PRESET FUNCTION to prepare soup gradually at a low temperature or 2 hours and no adjustment is
necessary.
A ter 120 minutes (2:00 hours), the Induction cooker will switch o automatically.
This unction can be used in conjunction with the TIMER FUNCTION, BUT THEN ONLY THE HOURS CAN BE
SET FROM 1-3 HOURS.
Press the ON OFF button once to stop the Soup unction.
To set the TIMER:
First select your cooking option, Hotpot(Watts), Soup(Timer-hours), Milk(Timer- minutes) or Fr (Degrees).
Set your desired temperature (degrees) or wattage (power) as per each options instructions detailed above.
Then press the TIMER button once.
0:00 (hours/minutes) will display on the LDC panel and you will hear a single beep.
The Timer lcd will display a red light.
The Min(o) indicator will light up in the centre panel.(timer indicator).
Press the UP (right) arrow to adjust the timer in minutes up to your pre erred time rom 1 – 59 minutes.
Press the DOWN (left) arrow to adjust the timer in hours up to your pre erred time rom 1 – 24 hours.
TIP: TO QUICKLY SET THE TIMER AND TO PROLONG THE LIFE OF THE TOUCHPADS, KEEP YOUR FINGER ON
THE UP OR DOWN ARROW BUTTON AND ADJUSTMENT WILL SCROLL AUTOMATICALLY WITHOUT HAVING
TO KEEP PRESSING THE UP OR DOWN BUTTON. HOURS DISPLAYS LEFT AND MINUTES DISPLAYS RIGHT.
The Hour range is 1 - 24 hours. The minute range is 1 - 59 minutes
The GTB2 Induction cooker can ALSO be utilised as a SLOW COOKER BY SETTING THE WATTAGE AND
TIMER or BY SETTING THE DEGREES AND TIMER ACCORDING TO YOUR REQUIREMENTS.
Page: 3 (copyright) Paul Nipper - 2012 www.inductioncooker.co.za (click to view)

To check electricity ( WH) usage:
Press the Electricit button once.
0:00 (Kilowatt hours) will display on the LDC panel and you will hear a single beep.
The Volt(o) indicator will light up in the centre panel.(voltage)
The Electricit lcd will display a red light.
I you press the Electricity button a second time, U229 – U232 Volts will be displayed depending on which
cooking unction is being used at the time.
Pressing the voltage a third time will clear the KWH reading and display will reset and start at 0:00.
To calculate electricity usage:
Multiply the units displayed (THE DIGITS DISPLAYED ON CENTRE LCD AFTER PRESSING THE ELECTRICITY
BUTTON ONCE) by your local municipalities cost per KW unit.
I viz; the LCD display shows 0:20 then the actual usage will be
0.20 (usage) x R1.50c (approx municipalit cost per KW unit) = R0.30c.
To switch OFF:
Press the ON OFF button once whereby cooker will switch o immediately.
Alternately you can remove your pot whereby cooker switches itsel o a ter 30 seconds.
Nothing will display on the LDC panel and you will hear a single beep.
To extend your GTB2 Induction Cookers li espan,
please switch off at the wall plug or remove plug rom wall outlet when not in use.
TIP: TO QUICKLY SET THE OPTIONS AND TO PROLONG THE LIFE OF THE TOUCHPADS, KEEP YOUR FINGER
ON THE UP OR DOWN ARROW BUTTON AND ADJUSTMENT WILL SCROLL AUTOMATICALLY WITHOUT
HAVING TO KEEP PRESSING THE UP OR DOWN BUTTON.
Page: (copyright) Paul Nipper - 2012 www.inductioncooker.co.za (click to view)

PRECAUTIONS BEFORE USING YOUR GTB2 INDUCTION COO ER
1. The crystalline glass top is made o strong, hard and non-porous properties. In case o glass top breakage,
disconnect the appliance rom the electrical socket immediately and contact me.
2. Do not place small metal kitchen utensils such as pan lids, knives, or other metal objects on the induction-
heating zone. I the induction cooker is switched on, there is a risk o them becoming hot.
3. When using your induction cooker, don't place any magnetic sensitive objects on the glass top, such as
credit cards, etc.
4. Scienti ic tests have shown that the induction cooker presents no danger or anyone using a pacemaker.
Please keep a 30 cm distance rom the unit while the induction cooker is in use.
5. Put the appliance on a horizontal sur ace but keep away rom the wall or other articles by at least 5-10cm.
6. To prevent an electric shock, do not put articles like iron wire or tools into the air entrance or outlet.
7. Immediate clean up with a so t non scratch cloth is recommended when water is le t on the top plate.
8. Do not submerse the Induction cooker under water.
9. Do not clean the cooker top while it is still hot. Some cleaners produce umes when applied to a hot
sur ace. Wipe and clean the ceramic glass plate and the appliance with a damp cloth once it has cooled o
and i necessary only use non-abrasive glass cleaning solution or some mild cleaning agent on spills.
10. Clean the induction cooker a ter each use. Turn O the induction cooker and disconnect plug rom
power source, and wait until the unit has cooled down be ore cleaning.
11. Ensure that your inger is placed in the centre o the touch pad button area o Induction cooker. I the
inger is not placed on the centre o a pad, the induction cooker may not respond to the selection made.
Touch the pad lightly with lat part o your entire ingertip.
12. Never put empty cookware on the powered-on induction cooker and allow it to heat up, as this could
cause the cookware to become distorted or damage the induction coil.
13. Always switch off the induction cooker before you unplug it.
POTS & PANS SUITABLE FOR THE GTB2 INDUCTION COO ER
1. Iron.
2. Cast iron.
3. Stainless steel*.
4. Enamelware.
5. Stainless steel base whistle kettle.
Above pots and pans must have a lat bottom and diameter o between 12 and 22 cm.
Test the cookware with a magnet to be sure cookware is made with Induction compatible material.
*All pots and pans must have a magnetic base.
Page: 5 (copyright) Paul Nipper - 2012 www.inductioncooker.co.za (click to view)

POTS & PANS UNSUITABLE FOR THE GTB2 INDUCTION COO ER
1. Pot with diameter below 5 cm.
2. Stainless steel pots and pans with aluminium base.
3. Pottery.
4. Glass pans.
5. Aluminium pans.
6. Bronze pans.
7. Copper pots.
8. Pans with eet.
MODEL SPECIFICATIONS:
Model no: GTB2
Size: 350(L) x 280(w) x 65mm(h)
Coil width: 200mm
Power: 2000 watts (can be set rom 120w - 2000w)
Temperature: 60 - 270 degrees Celsius
Timer: 1 minute - 24 hours
Cord length: 1 meter
ADDITIONAL FUNCTIONS:
* CENSOR TOUCH CONTROL
* 10 LEVEL SETTINGS, TEMPERATURE & POWER
* 4 DIGIT LED DISPLAY
* INTELLIGENT COOKING FUNCTIONS – SOUP, WATER, HOTPOT, MILK & FRY
* ENERGY CONSUMPTION METER
* BOIL DRY, HIGH & LOW VOLTAGE PROTECTION
* AUTO OFF IF POT REMOVED AFTER 30 SECONDS
HOW DOES YOUR GTB2 INDUCTION COO ER WOR ?
A high requency induction coil located underneath the crystalline glass top plate heats the cooking pan by
magnetic riction. The heat is produced directly within the pots or pans. It is controlled by an electronic
circuit to o er superior per ormance and unctions. During cooking, no energy is lost between the Induction
cooker and the ood. When you switch it o , cooking is stopped immediately.
Enjoy your GTB2 Induction Cooker!
Thank You.
Kind Regards
Paul Nipper
IH Induction Cookers
www.inductioncooker.co.za
Tel: [phone]
08 August 2012
