Ihome Ib85 User manual

Model: iB85 English I/B (Front)

Print color : Black text on white paper

Size of manual: 180W x 270H (mm)

Date: Aug 29, 2013

Wearing Your Headphones

Your iHome iB85 Bluetooth headphones are supplied with padded ear cushions for long

wearing comfort. The headband can be extended to accommodate almost any head

size. There are ‘L’ and ‘R’ markings on the inside of the headband. When the headphones

are worn properly the controls will be on your left ear.

Using Your Headphones

Note: Some of the functions described below may not be supported on your speciﬁc

smartphone. Check with your smartphone owner’s manual to conﬁrm the features

supported by your phone.

Your headphones must be paired with your phone and turned on to perform any of the

following operations.

Receiving/Ending A Call

When you receive an incoming call, press the Multi-function button once to answer the

call through the headphones. When you are ﬁnished speaking press the Multi-function

button once more to end/disconnect the call.

To transfer a call between the headphones and the smartphone quickly press the

Multi-function button twice.

Making A Call

When you make a call on your smartphone the call may be automatically transferred to

the headphones if your smartphone supports this automatic transfer function. If not,

quickly press the Multi-function button twice to transfer the call to the headphones.

Voice Activated Calling

If your smartphone supports this feature with the headphones, press and hold the

Multi-function button for about 2 seconds to initiate the voice activated calling function,

then follow the instructions supplied with your phone.

Last Number Redial

If your phone supports this feature, quickly press the Multi-function button twice to redial

the last number you called.

Declining A Call

If you receive a call that you would rather not accept (indicated by the caller ID on your

phone) quickly press the Multi-function button twice to decline the call.

Volume Control

Press the Volume “ +” or “ –” to adjust the volume of the incoming calls or the music

volume level.

Introduction

Your new iHome Bluetooth stereo headphones are designed to link with your Bluetooth

enabled device to allow you to wirelessly listen to music and answer phone calls within

the normal 10 meter (30 feet) Bluetooth operating range. Your headphones also feature

DSP (Digital Signal Processing) for enhanced audio plus noise reduction and echo

cancellation circuitry.

What’s Included

• Bluetooth Stereo Headphones with Folding Headband

• USB Charging Cable

• Travel Pouch

Speciﬁcations

Bluetooth speciﬁcation: Supports V2.1+ EDR with Handsfree Proﬁle 1.0,

Headset Proﬁle 1.1 and A2DP proﬁle 1.2 (Class ll)

and Audio/Video Remote Control Proﬁle AVRP

Standby time: up to 360 hours (with fully charged battery)

Talk time: up to 12 hours (with fully charged battery)

Music Playing time: up to 12 hours (with fully charged battery)

Operating Distance: up to 10 meters / 30 feet

Certiﬁcations: CE, FCC, RoHS, BQB

Pairing With a Bluetooth Enabled Device For The First Time

If your smartphone, laptop, or music player, such as the iPod touch, is Bluetooth enabled

(supports the A2DP Bluetooth Proﬁle) you may pair these iHome headphones with your

device to listen to music and make or receive calls as long as the two devices are within

the Bluetooth operating range of approximately 30 feet of each other.

1. Make sure that your Bluetooth enabled device is ‘On’.

2. Press and hold the Multi-function button on your iB85 headphone for about 7 seconds

until the blue LED ﬂashes rapidly. This indicates that the iB85 has entered the 'pairing

mode'. (NOTE: If no device is paired within 3 minutes, the iB85 will exit the pairing

mode.)

3. Turn on the Bluetooth function of your device so that it begins searching for a

compatible device.

4. “iHome iB85” should appear on your laptop, phone or music player’s compatible

devices list. You may also see a message such as “Not Paired”. Tap on that message

to complete the pairing process. If your device asks for a ‘password’ to complete the

pairing process, enter ‘0000’ on the keypad of your device.

5. When pairing is successful the screen on your device should show “iHome iB85

Connected” or similar message and the blue LED indicator on the iB85 headphones

will remain ‘On’. Your headphones are now ready for use.

Auto-Linking With A Previously Paired Device

If your iB85 headphones were previously paired with a Bluetooth enabled device, your

headphones will attempt to auto-link with that device again whenever that device is within

the Bluetooth operating range.

1. Press and hold the Multi-function button on your iB85 headphones for about 4

seconds until the blue LED indicator slowly ﬂashes to indicate the headphones are in

the ‘Standby’ mode and searching for a previously paired device.

2. Make sure that the Bluetooth function of the previously paired device is ‘On’.

Note: If no previously paired device is found after 5 minutes the auto-linking function

stops and your iB85 headphones shut off automatically to preserve the battery life.

Switching the Power On and Off

1. Press and hold the Multi-function button for approximately 4 seconds until you hear

the power up tone. The LED indicator turns solid blue if linked or blinking blue if not

linked. This indicates that the power is ‘On’.

2. When the power is ‘On’ press and hold the Multi-function button for approximately 3

seconds until you hear the power down tone. The LED indicator brieﬂy turns red and

then shuts off. This indicates that the power is ‘Off’.

Model: iB85

Bluetooth wireless

headphones with mic

+ remote and pouch

Controls and Indicators

1. Multi-function button: Power On/Off,

Answer/End, Play/Pause, Pair

2. Power/Charging/Pairing Indicator

3. Volume +button

4. Volume

button

5. Microphone

6. Forward button

7. Back button

8. Micro USB Charging Port

(located under moisture resistant cover)

Charging Your Headphones

IMPORTANT: Your headphones operate on a built-in rechargeable lithium-ion battery. You

should charge the battery for a full 4 hours before ﬁrst time use.

1. Lift up the moisture resistant cover to expose the micro USB charging port.

2. Connect the micro USB plug on the charging cable to the micro USB port on the

headphones.

3. Connect the standard USB plug on the charging cable to any standard USB power

port such as found on a notebook computer, or the charging adapter for an iPod,

iPhone, etc.

4. The headphone will be automatically powered off once USB cable is connected.

Throughout the charging process, headphone remains off.

5. The Power/Charging/Pairing indicator will slowly ﬂash while the headphone is

charging. The indicator will turn Off when the battery is fully charged. It is

recommended not to leave the headphones charging for more than 5 hours

unattended.

Reminder: Allow the battery to charge for 4 hours before ﬁrst time use. Normal recharge

time after ﬁrst use should take about 3 hours. When fully charged the battery will provide

up to 12 hours of working time, or 360 hours of standby time.
