iHome iBT682 User manual

True Wireless Stereo
Color Changing
Rechargeable
Bluetooth Speakers
with Speakerphone
instruction manual
Model: iBT682
CHARGE
BEFORE
USE

Introduction
Thank you for purchasing the iHome iBT682. This product is designed to
provide True Wireless stereo sound for your Bluetooth audio device. Each
speaker can also be used separately. This instruction booklet explains the
basic operation and care of the unit. Please read them carefully and keep for
future reference.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or
excessive heat.
• Protect your furniture when placing your unit on a natural wood and
lacquered finish. A cloth or other protective material should be placed
between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water.
Stronger cleaning agents, such as benzene, thinner or similar materials
can damage the surface of the unit.
iBT682
1

iBT682
What’s Included
• 2 x iBT682 speakers
• 2x USB charging cables
2
iBT682 speakers
USB charging cables

iBT682
Front
Back
Meet Your iBT682
Bottom
Top
3
NOTE: only one of the two speakers is
show below; they are identical.
Bluetooth/
Speakerphone
Button
Color Mode
Button
USB
Charging
Port
Red Charging/
Battery Indicator Light
Blue/Green Status Indicator Light
Blue = Bluetooth Status
(single speaker)
Green = True Wireless Mode
Bluetooth Status
(both speakers)
Power off/on Switch
Microphone
o on
Service Number:
Charging Voltage:
iBT682-A-A
DC 5V, 500mA
IC: 986B-IBT682
FCC ID: EMOIBT682
iBT682
Patents: www.ihome.com/patents
www.ihome.com
Toll Free: 1-800-288-2792
Manufactured and Serviced
by SDI Technologies Inc.
Designed in the USA
Made in China

Getting Started: Charging the Speakers
CHARGE UNIT BEFORE USE/KEEP UNIT OFF FOR FASTER CHARGING
1. Connect the micro USB plug on the included combination cable to the
micro USB Charging/Aux-in USB Port on the side of the unit.
2. Connect the standard USB plug end of the cable to a powered USB
port on a computer, a USB AC adaptor or other USB charging device.
For first time use, charge each speaker for about 4 hours. The red
charge status indicator LED on top of the speaker glows while speaker
is charging.
Note: When unit is ON and not charging, the LED flashing red indicates
low battery (speaker needs charging).
iBT682
4
Charge via computer USB port, USB AC adaptor or other powered USB port
iHome iBT682 USB port
USB AC adaptor
(not included)
USB AC adaptor
connected to working outlet
iHome iBT682 USB port
Computer USB port
Computer
connected to
working
outlet
TIP: On some iOS (Apple) devices, you can view
the iBT682 battery status on your device’s screen.
When device is paired and connected, look for a
vertical battery icon next to the Bluetooth icon on
the upper right corner of the device’s screen.

Getting Started: First Time Use
True Wireless Stereo
Each of your iBT682 speakers are pre-synced to one another for True Wireless
stereo operation. This sync is permanent (neither speaker can be synced with
a different or third speaker). True Wireless link range is about 5 meters (about
16 feet). If one of the speakers is moved out of True Wireless range, the stereo
link between the two speakers will fail.
Power ON both speakers within 10 seconds for True Wireless
Slide the Power Off/On Switch located on the bottom of each speaker to ON
to turn it on and start True Wireless link. Tones will sound and each speaker
will flash green while attempting to establish a link. The indicator on the top
of each speaker will glow green when the True Wireless stereo link is successful
and an audio prompt will identify each speaker as left channel or right
channel. After successful True Wireless linking, the speakers will enter Bluetooth
pairing mode (see below). After first time power on, user must pair manually
(see page 6).
NOTE: Once speakers are linked, powering OFF one speaker will also turn the
other speaker off. To turn that speaker back on, move the Power Off/On Switch
to OFF then back to ON.
5
Using the iBT682
Left Speaker
o on
Patents: www.ihome.com/patents
www.ihome.com
Toll Free: 1-800-288-2792
Manufactured
and
Serviced
by SDI Technologies Inc.
Designed in the USA
Made in China
Right Speaker
o on
Patents: www.ihome.com/patents
www.ihome.com
Toll Free: 1-800-288-2792
Manufactured
and
Serviced
by SDI Technologies Inc.
Designed in the USA
Made in China
True Wireless range
about 5 Meters/16.4 feet

Bluetooth: Pairing Your Device the First Time
Pairing is the set-up process to introduce your Bluetooth-capable device to
the iBT682. Once your device is paired, the speakers can recognize it and you
can play your audio through them. Turn on your Bluetooth device and make
it “discoverable” by turning on Bluetooth mode (check in Options or Settings).
• The first time both speakers are turned on, after establishing the True Wireless
link, the speakers will enter auto-pairing mode and attempt to connect to a
Bluetooth device. The status indicator light on the top of each speaker will
flash quickly and the left speaker will flash blue.
• “iHome iBT682” should appear in your device’s Bluetooth menu. Select “iHome
iBT682” to connect it. If prompted for a passcode, enter “1234” on your device’s
keypad.
If pairing is successful, 1 beep will
sound and the status indicator
light will appear solid on each
speaker, indicating the iBT682 is
ready to play music. There should
also be an indication on your
device. If no device is successfully
paired within 3 minutes the
iBT682 will default to standby
mode. Once the iBT682 is paired
to a device, it will attempt to
autolink when the device is
within Bluetooth range (about
33 feet).
Manual Pairing
1. Slide the Power Off/On Switch on each speaker to ON. True
Wireless linking should take about 10 seconds.
2. Press and hold the Bluetooth Button (located on the back) on
the left speaker for 2 seconds.
3. Select “iHome iBT682” on your device’s Bluetooth menu to
complete pairing.
6
Using the iBT682
For iPhone
iHome iBT682 iHome iBT682
iHome iBT682 iHome iBT682
For other

Pairing with a Single iBT682 Speaker (Mono Operation)
To use a single speaker, just turn one on instead of both. To use both speakers
separately, place each outside of True Wireless range (about 16 feet) then turn
on and pair each speaker separately with a different device. When separately
paired speakers are returned to within True Wireless range, each will maintain
separate pairing unless one is powered off then powered back on, in which case
it will attempt True Wireless linking. Note: Each separately paired speaker will
appear on your device as “iHome iBT682” (just as when you pair both speakers
together). You can select the desired instance or remove “iHome iBT682” and
re-pair unit(s) again.
Playing Audio Via Bluetooth
1. Slide the Power Off/On Switch on BOTH speakers to ON within 10 seconds.
Following True Wireless linking,the Bluetooth status indicator will glow solid blue
when a linked device is in range and detected. You can then listen to audio
streamed wirelessly from your paired Bluetooth device.
2. Use controls on your Bluetooth device to adjust volume and to play, pause and
navigate tracks.
3. When done listening, slide the Power Off/On Switch to OFF on both speakers.
Speakerphone Operation
NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a
call.
1. When a call is received, playing music is muted to hear the ring tone and the
cabinet lights flash green. Press the Bluetooth/Speakerphone Button to
answer the call, or press and hold to reject the call. For call waiting function,
press the button again to answer a second call, and once more to return to the
original call. Press and hold to end the current call and return to a remaining call.
2. When a call is completed, press the Bluetooth/Speakerphone Button to end
the call and resume previous function.
7
Using the iBT682

Using Color Modes
There are five color modes, which you cycle through in this order:
a. Slow Fade (colors slowly fade from one into the next
b. Fast Change (colors change rapidly)
c. One Color (select a favorite color)
d. Pulse to Music (lights flash to the beat of the music)
e. Off (no display)
1. Slide the Power Off/On Switch to ON to turn the unit ON.
2. Press the Color Mode Button repeatedly on either speaker to cycle to the
desired color mode. For One Color mode, first cycle to Fast Change mode then
press the Color Mode Button when the desired color appears. For Pulse to
Music, make sure the volume on your connected Bluetooth device is above 50%.
3. When done, slide the Power Off/On Switch to OFF to turn the unit OFF.
8
Using the iBT682

8
Unit doesn’t respond (no power)
• Make sure unit is completely charged.
• Check that all connections are correct and properly plugged in.
• Make sure your device is properly paired with the iBT682.
• Make sure the unit is on
Unit doesn’t respond (locked up/ “frozen”)
If the unit does not respond, try resetting the unit. Press and hold the
Bluetooth Button for about 10 seconds. Note that doing so will clear
settings, and any Bluetooth devices will need to be re-paired.
Trouble pairing device with iBT682
Bluetooth implementation varies depending on your device’s hardware and
operating system. Please see our website for updates on pairing.
• When you power ON the speaker, it will automatically link with the last
previously paired Bluetooth device if the device is still within range
(about 33 feet). To pair with a different device you must turn off
Bluetooth capability on the already paired device, or take it out of range.
• If your device does not auto-link when within range, re-pair the device. To
do so, first delete the iBT682 from your Bluetooth devices menu.
• Make sure your device is working properly. Check your device’s manual
for details on Bluetooth pairing and linking.
For further information and to see the latest instructions, visit
www.ihome.com/support
© 2016 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
9
Troubleshooting

10
Internal Rechargeable Lithium-ion Battery
This device uses an internal rechargeable lithium-ion battery that should
last the lifetime of the device. If you suspect your battery may be dead,
try charging it several times. If the battery does not recharge, please
contact Customer Service at -1-800-288-2792.
WARNING/DISPOSAL OF UNIT
Please do NOT attempt to change the battery yourself. Doing so may
damage the unit and will void the warranty. When disposing of unit, follow
the disposal instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes,
since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the
prevailing community regulations that apply to the disposal of
batteries/electronics. If there are no local regulations concerning
battery/electronics disposal, please dispose of the device in a waste bin
for electronic devices.
• Many electronics retailers now recycle batteries and other electronic
components at no charge. Check to see which ones in your area do so.
CAUTION
The battery used in this device may present a risk of fire, explosion or
chemical burn if mistreated
• Never use or charge the battery if it appears to be leaking, discolored,
deformed, or in any way abnormal.
• Never disassemble the unit or attempt to remove battery as that could
cause leakage of alkaline solution or other electrolytic substance.
• Always confirm that the temperature is 5°C – 35° C (41° - 95° Fahrenheit)
before you charge the battery. Leakage or deterioration of the battery
may occur if this warning is not heeded.
• Never expose the battery to any liquid.
• Never expose the battery to excessive heat such as direct sunlight or fire.
Never use the battery pack in an unventilated vehicle where excessive
internal temperatures may be encountered.
• Always keep the battery out of the reach of infants and small children.

11
FCC Information
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment.
• Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of
RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian
information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la
section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut
obtenir l'information canadienne sur l'exposition et la conformité de rf.
iBT682
FCC ID:EMOIBT682
IC:986B-IBT682
This device complies with Part 15 of the FCC Rules, operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

Consumer Product Safety Guide
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and
manufactured to ensure your personal safety. However, improper use can
result in potential electrical shock or fire hazards. Please read all safety and
operating instructions carefully before installation and use, and keep these
instructions handy for future reference. Take special note of all warnings
listed in these instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example:
near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a
wet basement.
2. Ventilation – The unit should be situated so that its location or position does
not interfere with its proper ventilation. For example, it should not be situated
on a bed, sofa, rug or similar surface that may block ventilation openings.
Also, it should not be placed in a built-in installation, such as a bookcase or
cabinet, which may impede the flow of air through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators,
heat registers, stoves or other appliances (including amplifiers) that produce
heat.
4. Power Sources – The unit should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance.
Only use the AC adapter that came with the unit.
5. Power-Cable Protection – Power supply cables should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them. It is always best to have a clear area from where the cable exits the unit
to where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only as recommended. See the
Maintenance section of this manual for cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall
and liquids are not spilled into any openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product
manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket
and disconnect the antenna or cable system during a lightning storm or when
it is left unattended and unused for long periods of time. This will prevent
damage to the product due to lightning and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service
personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate
normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of
time, such as a month or longer, charge the unit fully before storage
13. Servicing – The user should not attempt to service the unit beyond those
methods described in the user’s operating instructions. Service methods not
covered in the operating instructions should be referred to qualified service
personnel.
14. Magnetic Interference: This product’s speakers contain powerful magnets
which could cause interference or damage to sensitive equipment such as
hard drives, CRT televisions and monitors, as well as medical, scientific, and
navigational devices. Keep this unit away from these products at all times.
12

iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI),
warrants this product to be free from defects in workmanship and materials,
under normal use and conditions, for a period of one (1) year from the date of
original purchase.
Should this product fail to function in a satisfactory manner, it is best to first
return it to the store where it was originally purchased. Should this fail to resolve
the matter and service still be required by reason of any defect or malfunction
during the warranty period, SDI will repair or, at its discretion, replace this
product without charge. This decision is subject to verification of the defect or
malfunction upon delivery of this product to the Factory Service Center
authorized by Customer Service.
If service is required, please call Customer Service at 1-800-288-2792 to obtain
a Return Authorization Number and shipping instructions.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which
it was designed. It does not cover (i) products which have been damaged by
negligence or willful actions, misuse or accident, or which have been modified or
repaired by unauthorized persons; (ii) cracked or broken cabinets, or units
damaged by excessive heat; (iii) damage to digital media players, CD’s or tape
cassettes (if applicable); (iv) the cost of shipping this product to the Factory
Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend
to owners of the product other than to the original purchaser. In no event will SDI
or any of its affiliates, contractors, resellers, their officers, directors,
shareholders, members or agents be liable to you or any third party for any
consequential or incidental damages, any lost profits, actual, exemplary or
punitive damages. (Some states do not allow limitations on implied warranties or
exclusion of consequential damages, so these restrictions may not apply to you.)
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
Your acknowledgment and agreement to fully and completely abide by the above
mentioned disclaimer of warranty is contractually binding to you upon your
transfer of currency (money order, cashier's check, or credit card) for purchase of
your SDI product.
© 2016 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
iBT682-3152016-A (EN) Printed in China
LIMITED 1 YEAR WARRANTY
