IHP SKYTECH J7675 User manual

REMOTE CONTROL OPERATION
BASIC CONSTRUCTION
Touch-Screen LCD and three push buttons will allowinputfrom user s.
LCD screen will provi de system status & input feedback to user.
Backlight will illuminate LCD screen for 5 seconds after any user i nput- the 1st touch
of the LCD screen will only illuminate the backlight (will not respond to associated zone
function)
To activate any command, the backlight for the screen must be on and the
command must be touched before the backlight goes
off .
Powered via four AAA sized batteries (6V nominal) with L
OW BATIERY INDICAT OR
(5 OV)
Touch-Screen LCD and Button Layout !Not to scale)
SET TEMP Zone
FLAME Zone
CHANNEL UNLOCK Zone
MODE Zone
ICHANNEL PROG Zone
.....1...___J ~MODE/SET Button
~)J__,__ UP Button
MODE/SET A .
-------
Figure 43 - Touch-Screen LCD and Button Layout

FUNCTIONAL DESCRIPTION
Note: All function adjustments will be auto-
maticallyaccepted 15-seconds afterpressing
a given touch zone or button. The user may
press the MODE/SET button to immediately
accept the adjustment manually.
CHANNEL SELECTION
This control may be operated in 3 different
sub-channels for applications where 2.4GHz
interference causes delayed operation of the
remotecontrol.Thefactory default isChannel
3. To change the channel on the transmitter:
• Touch the CHANNEL PROGRAM and
CHANNEL UNLOCK zones simultane-
ously and hold for 5-seconds.
• The LCD screen will go blank except
“Ch” will be displayed in the SET TEMP
Zone and either “01”, “02”, or “03” will
be displayed in the ROOM TEMPZone.
• Press the UP or DOWN buttons to
change the channel number (01-03).
• Pressthe MODE/SETButton to returnto
the normal operating display.
Receiver Operation Notes:
• The receiver manufacturer may refer to
channels 01, 02, or 03.
• Receiver must be paired with transmitter
in the receiver’s factory default channel.
• Once paired, the channel selection may
be changed in the transmitter per the
instructions above.
• Oncethechannelselection is changed in
the transmitter, the power supply to the
receiver must be removed for at least
30-seconds, then re-applied.
• The receiver will recognize the new
channel selection after about 30-sec-
onds to 1-minute and normal operation
will resume.
MODES OF OPERATION
OPERATION MODES:
• MANUAL OFF
• MANUAL ON
• THERMOSTAT (with optional PRO-
GRAM Mode)
The modes may be cycled in the order above
by touching the MODE Zone or pressing the
MODE/SET Button.
MANUAL OFF MODE:
• Transmits ame OFF command.
• Pilot Method: Intermittent Pilot Ignition
(IPI)/Spark-to-Pilot only (continuous/
standing pilot not allowed)
• Pilot ame will be turned OFF
• LCD Displays:
• MODE Zone: OFF is displayed
• ROOMTEMPZone:Measuredtempera-
ture is displayed
• SET TEMP Zone: Blank
• TIME/PROGZone:Currentday indicator
and current time is displayed
• FLAME Zone: Blank
MANUAL ON MODE:
• Transmits ame ON command.
• Pilot Method: Intermittent Pilot Ignition
(IPI)/Spark-to-Pilot only (continuous/
standing pilot not allowed)
• Pilot ame will be ignited before turn
Main Flame ON.
• LCD Displays:
• MODE Zone: ON is displayed
• ROOMTEMPZone:Measuredtempera-
ture is displayed
• SET TEMP Zone: Blank
• TIME/PROGZone:Currentday indicator
and current time is displayed
• FLAME Zone: A Flame Icon and ame
setting level number is displayed
THERMOSTAT MODE:
• Will cycle ame on and off based on
roomand set temperatures.Willtransmit
ON command if SET TEMP (+SWING)
is higher than ROOM TEMP and will
transmit OFF command if SET TEMP
(-SWING) is lower than ROOM TEMP.
• Built-in thermostat will measure room
temperature.
• All programming should be written for
deg. F and converted to deg. C when
selected.
• Temperatures may be displayed in
degrees F (factory default) or degrees
C. Press the UP and DOWN Buttons
simultaneously to change between
degrees F and C.
• SET TEMP: While in THERMOSTAT
mode, press the UP or DOWN Button

to change the SET TEMP (45-90 deg. F,
7-32 deg. C); the new set temperature
will automatically be accepted after 2
seconds.Thefactory default SETTEMP
is 68 deg. F.
• SWING Temperature: This model does
not allow for SWING temperature adjust-
ment. This model utilizes thermostatic
ame modulation that will modulation
the main ame based on the difference
between room temperature and set tem-
perature (see example below).
• Important - factory SWING TEMPERA-
TURE setting is 2 degrees. The thermo-
static ame modulation feature will not
allow this SWING to be changed.
EXAMPLE:
Set Temperature Room Temp. Flame Level
74F OFF
73F Level 1
Set Temperature (72) 72F Level 2
71F (or less) Level 3
• PilotMethod: Continuous/Standing Pilot
only (Intermittent Pilot Ignition (IPI)/
Spark-to-Pilot not allowed).
• Pilot ame will remain ON when Main
Flame Cycles ON and OFF.
• Manual Flame Adjustment while in
THERMOSTAT mode: If Flame-A is
manually adjusted while in thermostat
mode, it will override the automatic
ame setting until the ame cycles off,
then back ON thermostatically; when
the ame cycles ON again, automatic
ame adjustment will resume. Automatic
ame adjustment will also resume if the
operational mode is cycled out of, then
back into THERMOSTAT mode or if the
SET temperature is changed.
• THERMOSTAT OFF LCD Displays:
• MODE Zone: THERMO and OFF is
displayed
• ROOMTEMPZone:Measuredtempera-
ture is displayed
• SET TEMP Zone: SET TEMP is dis-
played
• TIME/PROGZone:Currentday indicator
and current time is displayed
• FLAME Zone: Blank
• THERMOSTAT ON LCD Displays:
• MODE Zone: THERMO and ON are
displayed
• ROOMTEMPZone: Measured tempera-
ture is displayed
• SET TEMP Zone: SET TEMP is dis-
played
• TIME/PROGZone: Current dayindicator
and current time is displayed
• FLAME Zone: A Flame Icon and ame
setting level number is displayed
Thermostat Disable Feature
• TheThermostat Mode (descr bedabove)
may be disabled for applications where a
thermostat is not allowed or undesirable.
When Thermostat Mode is Disabled:
• The Modes of operation will cycle be-
tween MANUAL ON and MANUAL OFF
(omitting THERMO).
• Program Operation (described below) is
also disabled.
• The SET TEMP zone will be blank.
• The room temperature will still be mea-
sured & displayed in the ROOM TEMP
Zone.
• The TIME/PROG zone will continue to
display the Clock and Day of week, but
none of the icons associated with Pro-
gram Mode will be displayed.
• To disable or re-enable the Thermostat,
the transmitter must be in MANUAL
OFF Mode, then touch and hold the
SETTEMPZone andthe DOWNButton
simultaneously for 10- seconds. The
LCD screen will go blank except either
THERMO and OFF or THERMO and
ON will ash 3-times (0.5-seconds OFF,
0.5-seconds ON) to indicate the change
has been made.
DAY AND TIME DISPLAY
• The current day of week and time of
day will be continuously displayed in the
TIME/PROGZone (exceptduringSetup
operations).
• The day of week will be displayed as
one of the following: S, M, T, W, T, F, S
• The time of day will be in 12-hour AM,
12-hour PM format. Midnight will be
displayed as 12:00am.
• Day/Time Setup:
1. Press and hold the MODE Zone for 5
seconds to enter Day/Time Setup.

2. Touch the UP or DOWN Buttons to adjust
the day of week (press the MODE/SET
Button or wait for 15 seconds for adjust-
ment to be accepted, then enter hour of
day adjustment).
3. Press the UP or DOWN Buttons to
adjust the hour of the day. The time will
advance in 1-hour increments; AM and
PM will change when the hour advances
to 12:00 midnight and 12:00 noon re-
spectively(pressthe MODE/SETButton
or wait for 15 seconds for adjustment to
be accepted, then enter minute of hour
adjustment).
4. Press the UP or DOWN Buttons to ad-
just the minute of the hour. The time will
advance in 1-minute increments (press
the MODE/SET Button or wait for 15
seconds and the transmitter will exit
Day/Time Setup and return to normal
operation).
5. LCD Displays – when in Day/Time
Setup:
• MODE Zone: Blank
• ROOM TEMP Zone: Blank
• SET TEMP Zone: Bank
• TIME/PROG Zone: Day of Week, or
Time of Day will Flash
• FLAME Zone: Blank
•
Program Operation
• Touch the TIME/PROG Zone to activate
ordeactivateProgramOperation.Touch-
ing the MODE Zone or pressing the
MODE/SET Button will also deactivate
ProgramOperation. When ProgramOp-
eration is deactivated, the transmitter will
return to MANUAL OFF Mode.
• Program Operation will cycle replace
ignition ON and OFF based on time set-
tings (2 weekend periods and 2 weekday
periods) and thermostat settings. Press
the MODE/SET Button or wait for 15
seconds to advance to each subsequent
program setting.
• Pilot Method (same as Thermostat
Mode): Continuous/Standing Pilot
only (Intermittent Pilot Ignition (IPI)/
Spark-to-Pilot not allowed).
• Pilot ame will remain ON when Main
Flame Cycles ON and OFF.
• To enter Program Setup, touch and hold
the TIME/PROG Zone for 5 seconds.
• Program OFF LCD Displays:
• MODE Zone: OFF
• ROOMTEMPZone: Measured tempera-
ture is displayed
• SET TEMP Zone: Blank
• TIME/PROG Zone: Current day indica-
tor, current time, and Program status
(P1- OFF or P2-OFF) is displayed
• FLAME Zone: Blank
• Program ON LCD Displays:
• MODE Zone: THERMO and either ON
or OFF is displayed
• ROOMTEMPZone: Measured tempera-
ture is displayed
• SET TEMP Zone: SET TEMP is dis-
played
• TIME/PROG Zone: Current day indica-
tor, current time, and Program status
(P1- ON or P2-ON) is displayed
• FLAME Zone:
 If Thermostat is ON, A Flame Icon and
ame setting level number is displayed.
 If Thermostat is OFF, display is blank.
Program Disable Feature
• The Program Mode (described above)
may be disabled for applications where
a program operation is not allowed or
undesirable. When Program Mode is
Disabled:
• The user will not be able to activate
Program Mode
• The user will not be able to enter
Program Setup or edit Program Mode
settings.
• The TIME/PROG zone will continue to
display the Clock and Day of week, but
none of the icons associated with Pro-
gram Mode will be displayed.
• To disable or re-enable the Program
Mode, the transmitter must be in MAN-
UAL OFF Mode, then touch and hold
the TIME/PROG Zone and the DOWN
Button simultaneously for 10-seconds.
The LCD screen will go blank except
eitherPROGRAMandOFF(OFFdisplay
in MODE Zone) or PROGRAM and ON
(ON display in MODE Zone) will ash
3-times (0.5-seconds OFF, 0.5-seconds

ON) to indicate the change has been
made.
Flame-A (or Main)Adjustment
Transmits a flame height setti ng com-
mand to the control module to adjustthe
Flame-A hei ght
Available settings are 1-3 with a factory
default of 3. Referto the THERMOSTAT
Mode section for additional details on
flame modul at ion in THERMOSTAT
mode.
While in MANUAL ON, THERMOSTAT
ON,
or PROGRAM ON modes, touch
the FLAME Zone to enter Flame-AAd-
justment, then press the UP or DOWN
buttons to raise and lower the flame;
press the MODE/SET Button or wait for
15 seconds to accept the
new setting
LCD Display When setting the Flame-A
height, the Flame-A icon, and F la me-A
setti ng number will flash in the FLAME
Zone.
Child-Lock Operation
Child -L ockoperation prevents anyuser
inputto the transmitte
r. No mode of op-
eration or feature may be adjusted when
Child-Lock is activated. All automatic
functions (thermostat. program.etc l will
continue normally
To activate or deactivate the Child-Lock
feature, press and hold the MODE/SET
and DOWN Buttons simultaneously for
5 seconds.
LCD Displays
• When activated, the LOCK icon will ap-
pear in the MODE Zone.
• If any touch-zone or button is pressed
when activated, the LCD backlight will
illuminate and the LOCK icon will flash
for 5 seconds in the MODE Zone.
Room Temperature Limit
The Room Tem pe rature Limit Shut-
down feature will operate in MANUAL
ON, THERMOSTAT ON mode , and
PROGRAM ON modes. If the roomtem-
perature reaches 95 deg. F or greater,
thetransmitter
will automatically change
to MANUAL OFF mode and send a
MANUAL OFF command to the control
module. If the
user turns the cont rol
back ON and the room temperature is
still 95F or greater, the transmitter will
switch to back manual OFF and send
another OFF command the next time
thetransmitterreads & updatestheroom
temperature (2-minute update interval
).
PAIRING
The remote and receiver are paired at the
factory but
in case they do not communicate
after proving the batteries are fresh, repair-
ing may be necessa r y. F ollow the steps
bel ow to repair the remote to the receiver.
It is helpful to have a flashlight so you can
see the connections as
descr ibed below.
Be fore pr oceed i ng , locate the S1 but-
ton on the r eceiver shown in the figure
bel ow . You will need to access this button
during the re-pairing procedure and only
have 20 seconds to press and release it
To enter pairing mode press and hold t he
MODE/SET Button for 10-seconds.
Transmitter will transmit a pairing sig-
nal for
20 -seconds, then automatically
exit pairing mode and return to normal
operation.
LCD Displays -When pairing mode is
activated:
1. MODE Zone: Blank
2. ROOM TEMP Zone: The letters "On"
will flash.
3. SET TEMP Zone The letter "P" is
displayed
4. TIME/PROG Zone: Blank
5. FLAME Zone Blank
Receiver O pe ra ti on No te: Once transmitter
is in pairing mode, press the yellow
or black
pairing button on the receive r.
•EJ
(&)
u
I
6
I ~
I ~
SUPPlY
I
Connect Battery Plug Here
S1 Button
Co nt rol Module
