Iiyama ProLite B1706S User manual

DEUTSCH
FRANCAIS
ENGLISH
USER MANUAL
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your
future reference.
NEDERLANDS

ENGLISH

ENGLISH
Congratulations!
The display you have just purchased carries the TCO’03 Displays
label. This means that your display is designed, manufactured
and tested according to some of the strictest quality and
environmental requirements in the world. This makes for a high
performance product, designed with the user in focus that also
minimizes the impact on our natural environment.
Some of the features of the TCO’03 Display requirements:
Ergonomics
• Good visual ergonomics and image quality in order to improve the working environment for the user
and to reduce sight and strain problems. Important parameters are luminance, contrast, resolution,
reflectance, colour rendition and image stability.
Energy
• Energy-saving mode after a certain time – beneficial both for the user and the environment
• Electrical safety
Emissions
• Electromagnetic fields
• Noise emissions
Ecology
• The product must be prepared for recycling and the manufacturer must have a certified
environmental management system such as EMAS or ISO 14 001
• Restrictions on
o chlorinated and brominated flame retardants and polymers
o heavy metals such as cadmium, mercury and lead.
The requirements included in this label have been developed by TCO Development in cooperation
with scientists, experts, users as well as manufacturers all over the world. Since the end of the 1980s
TCO has been involved in influencing the development of IT equipment in a more user-friendly
direction. Our labelling system started with displays in 1992 and is now requested by users and IT-
manufacturers all over the world.
For more information, please visit
www.tcodevelopment.com

ENGLISH
CE MARKING DECLARATION OF CONFORMITY
This LCD monitor complies with the requirements of the EC Directive 2004/108/EC “EMC
Directive” and 2006/95/EC “Low Voltage Directive”.
The electro-magnetic susceptibility has been chosen at a level that gives correct operation in
residential areas, business and light industrial premises and small-scale enterprises, inside as
well as outside of the buildings. All places of operation are characterised by their connection to
the public low voltage power supply system.
We reserve the right to change specifications without notice.
All trademarks used in this user manual are the property of their respective owners.
As an ENERGY STAR® Partner, iiyama has determined that this product meets the ENERGY STAR® guidelines for energy
efficiency.

ENGLISH
FOR YOUR SAFETY.............................................................................................. 1
SAFETY PRECAUTIONS ................................................................................ 1
SPECIAL NOTES ON LCD MONITORS.......................................................... 3
CUSTOMER SERVICE.................................................................................... 3
CLEANING....................................................................................................... 3
BEFORE YOU OPERATE THE MONITOR............................................................ 4
FEATURES ...................................................................................................... 4
CHECKING THE CONTENTS OF THE PACKAGE......................................... 4
FITTING AND REMOVAL OF BASE : ProLite B1706S / ProLite B1906S ....... 5
FITTING AND REMOVAL OF BASE : ProLite E1706S.................................... 6
FITTING AND REMOVAL OF BASE : ProLite E1906S.................................... 7
CONTROLS AND CONNECTORS : ProLite B1706S / ProLite B1906S.......... 8
CONTROLS AND CONNECTORS : ProLite E1706S / ProLite E1906S.......... 9
CONNECTING YOUR MONITOR : ProLite B1706S / ProLite B1906S ...........10
CONNECTING YOUR MONITOR : ProLite E1706S / ProLite E1906S ...........11
COMPUTER SETTING....................................................................................12
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE :
ProLite B1706S / ProLite B1906S ...................................................................13
ADJUSTING THE VIEWING ANGLE : ProLite E1706S / ProLite E1906S ......13
OPERATING THE MONITOR.................................................................................14
ADJUSTMENT MENU CONTENTS ................................................................15
SCREEN ADJUSTMENTS...............................................................................21
POWER MANAGEMENT FEATURE ...............................................................24
TROUBLE SHOOTING ..........................................................................................25
RECYCLING INFORMATION.................................................................................26
APPENDIX ............................................................................................................27
SPECIFICATIONS : ProLite B1706S ...............................................................27
SPECIFICATIONS : ProLite E1706S ...............................................................28
SPECIFICATIONS : ProLite B1906S ...............................................................29
SPECIFICATIONS : ProLite E1906S ...............................................................30
DIMENSIONS : ProLite B1706S......................................................................31
DIMENSIONS : ProLite E1706S......................................................................31
DIMENSIONS : ProLite B1906S......................................................................31
DIMENSIONS : ProLite E1906S......................................................................32
COMPLIANT TIMING.......................................................................................32
TABLE OF CONTENTS
We recommend recycling of used product. Please contact your dealer or iiyama
service center. Recycle information is obtained via the Internet, using the address:
http://www.iiyama.com
You can access the Web page of different countries from there.

ENGLISH
1 FOR YOUR SAFETY
FOR YOUR SAFETY
WARNING
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor
and contact your dealer or iiyama service center immediately. Further use may be dangerous and can
cause fire or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of fire
or electric shock.
DO NOT PUT ANY OBJECT INTO THE MONITOR
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug
your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any
object inside may cause fire, electric shock or damage.
INSTALL THE MONITOR ON A FLAT, STABLE SURFACE
The monitor may cause an injury if it falls or is dropped.
DO NOT USE THE MONITOR NEAR WATER
Do not use where water may be splashed or spilt onto the monitor as it may cause fire or electric
shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the monitor only with the specified power supply. Use of an incorrect voltage will
cause malfunction and may cause fire or electric shock.
PROTECT THE CABLES
Do not pull or bend the power cable and signal cable. Do not place the monitor or any other heavy
objects on the cables. If damaged, the cables may cause fire or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in
power may cause malfunction. It is also advised not to touch the plug in these circumstances as it may
cause electric shock.
SAFETY PRECAUTIONS

ENGLISH
CAUTION
INSTALLATION LOCATION
Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky
areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun
shines directly on the monitor.
DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION
The monitor may topple and cause injury if not suitably located. Please also ensure that you do not
place any heavy objects on the monitor, and that all cables are routed such that children may not pull
the cables and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause fire.
To allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls.
Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the cabinet
will be blocked and the monitor may overheat if the stand is removed. This may cause fire or damage.
Operating the monitor on its back, side, upside down or on a carpet or any other soft material may also
cause damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR
When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal cable
is disconnected. If you do not disconnect them, it may cause fire or electric shock.
UNPLUG THE MONITOR
If the monitor is not in use for a long period of time it is recommended that it is left unplugged to avoid
accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable itself
as this may cause fire or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may damage
your computer.
DO NOT PUT FLOPPY DISKS NEAR THE SPEAKERS
Magnetically recorded data, such as on a floppy disk, may become corrupted by the magnetic field
produced by the speakers if the disks are placed on or near the speakers.
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room.
For optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches)
away from your eyes. When using the monitor over a prolonged time, a ten minute break every hour is
recommended as looking at the screen continuously can cause eye strain.
OTHERS
FOR YOUR SAFETY 2

ENGLISH
The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE When you first turn on the LCD monitor, the picture may not fit in the display area
because of the type of computer that is used. In this case, adjust the picture position
to the correct position.

Due to the nature of the LCD screen, an afterimage of the previous screen may
remain after switching the image, when the same image is displayed for hours. In this
case, the screen is recovered slowly by changing the image or turning off the Power
Switch for hours.

You may find slightly uneven brightness on the screen depending on the desktop
pattern you use.

SPECIAL NOTES ON LCD MONITORS
Contact your dealer or iiyama service center for the backlight replacement when the
screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.

Due to the nature of the backlight, the screen may flicker during initial use. Turn off
the Power Switch and then turn it on again to make sure the flicker disappears.

NOTE The fluorescent light used in the LCD monitor may have to be periodically replaced.
For the warranty coverage on this component, please check with local iiyama service
center.
If you have to return your unit for service and the original packaging has been
discarded, please contact your dealer or iiyama service center for advice or
replacement packaging.


WARNING If you drop any materials or liquids such as water into the monitor when cleaning,
unplug the power cable immediately and contact your dealer or iiyama service center.

CAUTION For safety reasons, turn off the power switch and unplug the monitor before you clean
it.

NOTE To protect the LCD panel, do not scratch or rub the screen with a hard object.

Never use any of the following strong solvents. These will damage the cabinet and the
LCD screen.

Thinner
Benzine
Abrasive cleaner
Spray-type cleaner
Wax
Acid or Alkaline solvent
Touching the cabinet with any product made from rubber or plastic for a long time may
cause degeneration or loss of paint on the cabinet.

CABINET Stains can be removed with a cloth lightly moistened with a mild detergent solvent. Then
wipe the cabinet with a soft dry cloth.
LCD
SCREEN
Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.
CUSTOMER SERVICE
CLEANING
3 FOR YOUR SAFETY

ENGLISH
The following accessories are included in your package. Check to see if they are enclosed with the
monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama
office.
*1The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using
a power supply higher than this rating, then a power cable with a rating of 10A/
250V must be used.However, all guarantees and warranties are void for any
problems or damage caused by a power cable not supplied by iiyama.
*2 Accessory for ProLite E1706S.
*3 Accessory for ProLite B1706S / ProLite B1906S.
Power Cable*1 
D-Sub Signal Cable DVI-D Cable

Audio Cable Stand-Base Stand*2
Screw for stand fixing*3 
User Manual
BEFORE YOU OPERATE THE MONITOR
CHEKING THE CONTENTS OF THE PACKAGE
CAUTION
FEATURES
Supports Resolutions up to 1280 × 1024
High Contrast 800:1 (Typical) , ACR Function Available / Brightness 250cd/m2
(Typical) / Quick Response Time 5ms (Typical)
Digital Character Smoothing
Automatic Set-up
Stereo Speakers
2 × 1W Stereo Speakers

Plug & Play VESA DDC2B Compliant
Windows®95/98/2000/Me/XP/Vista Compliant
Power Management (ENERGY STAR®VESA DPMS Compliant)
Ergonomic Design: TCO ’03
VESA Mounting Standard (100mm×100mm) Compliant
Keyhole for Security Lock
BEFORE YOU OPERATE THE MONITOR 4

ENGLISH
5 BEFORE YOU OPERATE THE MONITOR
Put the monitor on a stable surface. The monitor may cause injury or damage if it
falls or is dropped.

Do not give a strong impact to the monitor. It may cause damage.

Unplug the monitor before removal or installation to avoid electric shock or damage.

The monitor is supplied complete with a stand-base. If you prefer to wall mount the monitor, please
follow the instructions below to remove the stand-base. Be sure to include the stand with the monitor if
it is necessary to return the unit.
CAUTION
FITTING AND REMOVAL OF BASE : ProLite B1706S / ProLite B1906S
<Installation>
APut a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay
the monitor flat on a table with front face down.
B
Install the Stand-Base to the Monitor.
CFix the Monitor with the Stand by the screw firmly, and the knob of the screw push down.
<Remove>
APut a piece of soft cloth on the table beforehand to prevent the monitor from being scratched. Lay
the monitor flat on a table with front face down.
BPull up the knob of the screws, and remove the screw and the Stand-Base.
<Stopper pin>
Please stand the monitor and then remove the stopper
pin on the back of the stand slowly while pushing top
face of the stand before you install the monitor. Careful
attention is required as the monitor is sprung loaded
and may expand quickly when removing it.
Stopper pin
Stand-Base
Screw for
Stand-Base fixing
The knob of the screw
push down

ENGLISH
Install the stand on a stable surface. The monitor may cause injury or damage if it
falls or is dropped.

CAUTION
Do not give a strong impact to the monitor. It may cause damage.

Unplug the monitor before installation to avoid electric shock or damage.

<Installation>
<Remove>
APut a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
Lay the monitor flat on a table with front face down.
B
Hold the monitor and push the Stand.
CHold the monitor and push the Stand-Base.
APut a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
Lay the monitor flat on a table with front face down.
B
Press the stopper at the bottom of the stand and remove the Stand-Base from the stand.
CPress the stopper at the back of the stand and remove the Stand from the monitor.
Stand-Base
Stand
Stand-Base
Stand
Stopper
Stopper
FITTING AND REMOVAL OF BASE : ProLite E1706S
BEFORE YOU OPERATE THE MONITOR6

ENGLISH
Install the stand on a stable surface. The monitor may cause injury or damage if it
falls or is dropped.

CAUTION
Do not give a strong impact to the monitor. It may cause damage.

Unplug the monitor before installation to avoid electric shock or damage.

<Installation>
<Remove>
APut a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
Lay the monitor flat on a table with front face down.
B
Hold the monitor and push the Stand-Base.
APut a piece of soft cloth on the table beforehand to prevent the monitor from being scratched.
Lay the monitor flat on a table with front face down.
B
Press the stopper at the bottom of the stand and remove the Stand-Base from the arm.
Stand-Base
Stand
Stand-Base
Stand
Stopper
FITTING AND REMOVAL OF BASE : ProLite E1906S
7 BEFORE YOU OPERATE THE MONITOR

ENGLISH
APower Switch ( )
B
Menu / Select Button (MENU)
C+ / Volume Button ( + )
D
- / ECO Button ( - )
EAuto Button (AUTO)
FPower Indicator
Blue: Normal operation
Orange: Power Management
The monitor enters into power management mode which reduces the power
consumption to less than 1W when receiving no horizontal and/or vertical
sync signal.
GSpeakers
HD-SUB mini 15pin Connector (D-SUB)
I
DVI-D 24pin Connector (DVI-D)
J
Cable Holder
K
Audio Connector (AUDIO IN)
L
AC Connector (AC IN)
MKeyhole for Security Lock
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
CONTROLS AND CONNECTORS : ProLite B1706S / ProLite B1906S
NOTE
BEFORE YOU OPERATE THE MONITOR 8
<Front> <Back>
NOTE

ENGLISH
APower Switch ( )
B
Menu / Select Button (MENU)
C+ / Volume Button ( + )
D
- / ECO Button ( - )
EAuto Button (AUTO)
FPower Indicator
Blue: Normal operation
Orange: Power Management
The monitor enters into power management mode which reduces the power
consumption to less than 1W when receiving no horizontal and/or vertical
sync signal.
GSpeakers
HD-SUB mini 15pin Connector (D-SUB)
I
DVI-D 24pin Connector (DVI-D)
J
Audio Connector (AUDIO IN)
K
AC Connector (AC IN)
L
Keyhole for Security Lock
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
CONTROLS AND CONNECTORS : ProLite E1706S / ProLite E1906S
NOTE
9 BEFORE YOU OPERATE THE MONITOR
<Front> <Back>
NOTE

ENGLISH
Power Cable
(Accessory)
Audio Cable (Accessory)
D-Sub Signal Cable
(Accessory)
DVI-D Signal Cable
(Accessory)
Computer
BEFORE YOU OPERATE THE MONITOR 10
CONNECTING YOUR MONITOR : ProLite B1706S / ProLite B1906S
[Example of Connection]
AEnsure that both the computer and the monitor are switched off.
BConnect the computer to the monitor with the signal cable.
CConnect the monitor to the audio equipment with the Audio Cable for computer when using the
audio features.
DConnect the Power Cable to the monitor first and then to the power supply.
EPower of the monitor and the computer is turned on.
NOTE The signal cables used for connecting the computer and monitor may vary with the type of
computer used. An incorrect connection may cause serious damage to both the monitor and
the computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If
a special cable is required please contact your local iiyama dealer or regional iiyama office.
For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama
office for a suitable adaptor.
Make sure you tighten the finger screws at each end of the signal cable.
<Back>
[ Collect Cables ]
APut the cables through the cable holder.
BCollect cables at the back of the stand.

ENGLISH
Power Cable
(Accessory)
Audio Cable (Accessory) Computer
D-Sub Signal Cable
(Accessory)
DVI-D Signal Cable
(Accessory)
11 BEFORE YOU OPERATE THE MONITOR
CONNECTING YOUR MONITOR : ProLite E1706S / ProLite E1906S
[Example of Connection]
AEnsure that both the computer and the monitor are switched off.
BConnect the computer to the monitor with the signal cable.
CConnect the monitor to the audio equipment with the Audio Cable for computer when using the
audio features.
DConnect the Power Cable to the monitor first and then to the power supply.
EPower of the monitor and the computer is turned on.
NOTE The signal cables used for connecting the computer and monitor may vary with the type of
computer used. An incorrect connection may cause serious damage to both the monitor and
the computer. The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If
a special cable is required please contact your local iiyama dealer or regional iiyama office.
For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama
office for a suitable adaptor.
Make sure you tighten the finger screws at each end of the signal cable.
<Back>

ENGLISH
BEFORE YOU OPERATE THE MONITOR 12
Signal Timing
Change to the desired signal timing listed on page 32: COMPLIANT TIMING.
Windows 95/98/2000/Me/XP/Vista Plug & Play
The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on
Windows 95/98/2000/Me/XP/Vista by connecting the monitor to DDC2B compliant computer with the
Signal Cable supplied.
For installation on Windows 95/98/2000/Me/XP: The monitor Information File for iiyama monitors
may be necessary for your computer and obtained via the Internet, using the address:
http://www.iiyama.com

Monitor Drivers are not required in most cases for Macintosh or Unix operating systems.
For further information, please contact your computer dealer first for advice.

For additional information on how to download the driver for your touch screen monitor,
please access the internet site noted above.
COMPUTER SETTING
NOTE

ENGLISH
13 BEFORE YOU OPERATE THE MONITOR
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE :
ProLite B1706S / ProLite B1906S
For optimal viewing it is recommended to position
yourself directly opposite to the full face of the
monitor, then adjust the monitor’s height and angle
to your own preference.
Hold the panel so that the monitor does not topple
when you change the monitor’s height or angle.
You are able to adjust the monitor's height up to
110mm, angle up to 170 degrees right and left, 20
degrees upward.
NOTE Do not touch the LCD screen when you
change the height or the angle. It may
cause damage or break the LCD screen.
 Careful attention is required not to catch
your fingers or hands when you change
the height or the angle.
110mm
20
5
ADJUSTING THE VIEWING ANGLE : ProLite E1706S / ProLite E1906S
For optimal viewing it is recommended to look at the full
face of the monitor.
Hold the stand so that the monitor does not topple when
you change the monitor’s angle.
You are able to adjust the monitor’s angle up to 20
degrees upward, 5 degrees downward.
In order to ensure a healthy and relaxed body position
when using the monitor at visual display workstations, it
is recommended that the adjusted tilt angle should not
exceed 10 degrees. Adjust the monitor’s angle to your
own preference.
NOTE Do not touch the LCD screen when you change
the angle. It may cause damage or break the
LCD screen.
Careful attention is required not to catch your
fingers or hands when you change the angle.

ENGLISH
OPERATING THE MONITOR 14
OPERATING THE MONITOR
To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT
TIMING shown on page 32. You are also able to adjust the picture by following the button operation
shown below. For more detailed adjustments, see page 21 for SCREEN ADJUSTMENTS.
Press the MENU Button to start the On Screen Display feature. There are additional
Menu items which can be switched by using the + / - Buttons.
BSelect the Menu item which contains the adjustment icon relating to the adjustment
you want to make. Press the MENU Button. Then, use the + / - Buttons to highlight
the desired adjustment icon.
CPress the MENU Button again. Use the + / - Buttons to make the appropriate
adjustment or setting.
Adjustments for H. / V. Position, Clock and Phase are saved for each signal timing. Except for these
adjustments, all other adjustments have only one setting which applies to all signal timings.
When button operations are aborted during adjustment, On-Screen Display disappears when the
time set for the Time out has passed. Also, the AUTO button can be used to return previous menu
and turn off the On-Screen Display.

NOTE

For example, to correct for vertical position, select Menu item of Image Setup and then press the
MENU Button. Then, select V.Position by using the + / - Buttons.
An adjustment page appears after you press the MENU Button. Then, use the + / - Buttons to
change the vertical position settings. The vertical position of the overall display should be changing
accordingly while you are doing this.
Press the AUTO Button lastly, it ends, any changes are saved in the memory.
Any changes are automatically saved in the memory when the On Screen Display
disappears.
Turning off the power should be avoided while using the Menu.
DPress the AUTO Button to leave the menu, and the settings you just made would
be automatically saved.
Luminance
Contrast
Brightness
Eco
Picture Mode
50
50
Off
Standard
ACR ON
Image Setup
Clock
Phase
H.Position
V.Position
50
50
50
50

ENGLISH
ADJUSTMENT MENU CONTENTS
Adjustment Item Problem / Option Button to Press
Luminance
Too dark
Too bright
Brightness *
Contrast Too dull
Too intense
*Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too
bright.
15 OPERATING THE MONITOR
Luminance
Contrast
Brightness
Eco
Picture Mode
50
50
Off
Standard
ACR ON
Mode1 Brightness of back-light is reduced.
Mode2 Brightness of back-light is reduced more than Mode1.
Off Normal
Eco
Mode3 Brightness of back-light is reduced more than Mode2.
Picture Mode
Standard For general windows environment and monitor
default setting.
Text For text editing and viewing in a word processing
environment.
Internet For internet environment.
Game For PC game environment.
Movie For movie and video environment.
Sport For sport environment.
ACR Increased Contrast Ratio
On
Off Typical Contrast Ratio
ACR adjusts brightness according to the image, and improve the contrast ratio during
move playing.
Contrast, Brightness, sRGB, Eco and Picture Mode cannot be adjusted and selected while
ACR is active.
NOTE
You can skip the Menu items and display an adjustment scale directly by using the following button
operations.

ECO: Press the - Button when the Menu is not displayed.
Direct
Direct
