Ikan VXF17 User manual

What’s Included
QUICKSTART GUIDE
1 x VXF17 Monitor
1 x AC Adapter
1 x Table Stand (installed)
1 x Rack Ears (installed)
VXF17
17" Full HD 3G-SDI/HDMI Rackmount Studio and Field Monitor
[email protected] © 2016 ikan Corporation. All rights Reserved
www.ikancorp.com 713.272.8822
CHECKED BY

Getting Started
Front
1 2 3 4 5 6 7 8 9 10
Table
Stand
Top Handle
Rack
Ear
Rack
Ear
POWERO FF BATTERY F1F 2F 3F 4 SDI HDMID VI YUVY /C VIDEO EXIT MENU
1 2 3 4 5 6 7 8 9 10
Table
Stand
Top Handle
Rack
Ear
Rack
Ear
POWERO FF BATTERY F1F 2F 3F 4 SDI HDMID VI YUVY /C VIDEO EXIT MENU
11
2
3
4
5
6
7
8
9
10
DVI Selection Switch
Digital Visual Interface input
YUV Selection Switch
Analog Component or RGB input & output
Y/C Selection Switch
S-Video input & output
VIDEO Selection Switch
Composite input & output
EXIT Button
In MENU, it is to exit the menu.
MENU Knob
It is to display menu, select settings, and adjustments.
(Push the knob to select, turn the knob to adjust settings.)

Back
Getting Started
11
2
3
4
5
6
7
8
9
10
HD-SDI Input & Output BNC Connection
YPbPr - Component Input & Output BNC Connection
Y/C - S-Video Input & Output BNC Connection
VIDEO - Composite Input & Output BNC Connection
DVI Connection
HDMI Input & Output Connection
DC 12V-20V power terminal
XLR DC Connection
DC 12V-20V power terminal
Standard DC Connection
TALLY
• Do not provide power to tally connections.
• Tally light system is unpowered and works by closing
the contact between any of the grounding pins and the
pin for the desired LED color.
Vesa 100mm Mount Holes
Threaded for M4x.07 screws.Use to attach Pro Battery
Plate adapter.
123 4 5 6 7
8
9
1010 10
VIDEO
DVI
TALLY
IN OUT
DC12V-24V
HDMI
Y/CPrPbYHD-SDI
IN
OUT
Switch
1
2
On
50p
30p
1 2 3 4 5 6 7 8
1
PIN Number Signal
Yellow
Red
Green
GND
NC
2
3
8
4 5 6 7
HIGH DEFINITION
HD-SDI LCD MONITOR
www.ikancorp.com MADE IN CHINA
Model: VX17e
Picture Size: 17 inch
Resolution: 1440 x 900
Display Color: 16.2M
Aspect Ratio: FULL / 16:9 / 4:3
Color System: NTSC / PAL
Operating Volts: DC 12 ~ 20V
Power Consumption: 18 Watt
RoHS
COMPLIANT
1
23
4
Pin number Signal
1
2,3
4
GND
+12V
_
3G-SDI
3G-SDI

Configuration of Setting Menus
Brightness 0-100
Contrast 0-100
Chroma 0-100
Sharpness 0-100
Tint 0-100
Color Temp Manual RGB Setup
5600K R 0-255
6500K G 0-255
9300K B 0-255
Exit
Guides
Guides Option { OFF, 90%, 80%, 4:3 }
Guides Background { Normal, Half, Black }
Crosshair { OFF, ON }
Return
System Configuration
OSD Language English
OSD Duration 5-60 Seconds
Menu Setup User 1 - User 5
LED Control OFF, ON
DSLR Autoscaling OFF, DSLR Full, DSLR 16:9, DSLR 3:2
System Reset
Return
Function Setup
Luma Under Warn
Luma Over Warn
Function 1 Window 1
Window 2
HV Delay
Guides
Crosshair
Peaking
False Color
Clip Guide
Underscan
Check Field
Pixel
Function 2 (Same as Function 1)
Function 3 (Same as Function 1)
Function 4 (Same as Function 1)
Return
Exit

Description of Features
Guides > Crosshair
Display a crosshair on the center of screen.
System Configuration > Menu Setup > User 1 - User 5
This function recalls user defined values settings. The user setting will remain in memory
indefinitely and can be erased by using the reset option in the main menu.
DSLR Autoscaling
This function will allow users to extend their DSLR camera’s HDMI video output any
option of four - Normal, 3:2, 16:9, or Full Screen - convenience made simple.
Color Temperature > Manual > RGB Setup
Allows you to manually control the red, blue, and green channels from 0-255.
Function Setup > Luma Under Warn / Luma Over Warn
Adjustable Under Exposure and Over Exposed Warning feature gives the operator full
control of the False Color brightness values. By setting the preferred IRE exposure
limits, the operator is warned when the image exposure is exceeding of falling under the
preset IRE limit, providing customizable, full image exposure control.
Function Setup > Peaking
This is equipped with Monochrome Peaking features which hilight the desired focus
area in a bright, red outline. The operator adjusts the focus control until the red indicator
outlines on the desired area are razor sharp, indicating optimal focus. For the best
results, be sure the subject is properly exposed.
Function Setup > False Color
The False Color feature utilizes a full spectrum of assigned color indicators, ensuring
flawless shot exposure. As the camera iris is adjusted, the subject of the image will
change color based on specific brightness values indicating optimal exposure. See
included chart for color assignments.
Function Setup > Clip Guide
This adjustable upper Clip Guide levels to accurately display overexposed images in
any shooting condition. The operator simply assigns the upper IRE to their preference
and any exposure over the set IRE limit will flash in a vivid purple, indicating only the
overexposed area.
Function Setup > Check Field
Allows to see the image in monochrome or only the Red, Blue, and Green channels.
Function Setup > Pixel
A signal of any other resolution is scaled to fit this native resolution. There may be time when it
is desired to view the incoming signal without scaling. Enabling Pixel to Pixel mode turns off the
scaling and displays a 1440x900 pixel window of the original image. Each pixel of the panel
displays one pixel of the original image. The user may use the scroll wheel on top of the monitor
to move the window left, right. Push the scroll wheel again to toggle up and down.

Specifications
Supported Video Signals
Specifications
Aspect Ratio 16:10
Brightness 340 cd/m2
Build Material Steel
Color System PAL / NTSC / SECAM (Auto-Detected)
Contrast Ratio 450:1
Diagonal (Inch) 17 In.
Dimensions 15.125 x 11.75 x 1.75 In.
Display Technology TFT LCD with CCFL Backlight
Inputs 3G-SDI, HDMI, Component, Composite, DVI, S-Video
Operating Temperature 0°C~50°C (32°F~122°F)
Operating Volts DC 12-24V
Outputs 3G-SDI, HDMI, Component, Composite, S-Video
Pixel Pitch 0.1905 x 0.1905mm
Power Consumption 18w
Resolution 1920 x 1200
Response Time 5 ms
Screen Size 17 In.
Viewing Angle 110° Horizontal / 95° Vertical
Weight 11.5 lbs
Shipping Specifications
Shipping Dimensions 21.5 x 8 x 15.75 In.
Shipping Weight 15 lbs
Supported Video Signals
3G-SDI 1920 x 1080p @ 50, 59.94, 60 Hz
HD-SDI
1280 x 720p @ 50, 59.94, 60, Hz
1920 x 1080i @ 50, 59.94, 60 Hz
1920 x 1080psf @ 23.98, 24, 25, 29.97, 30 Hz
1920 x 1080p @ 23.97, 24, 25, 29.97, 30 Hz
SD-SDI 720 x 480i @ 60 Hz
720 x 576i @ 50 Hz
Video
NTSC-M, NTSC-J, NTSC 4.43
PAL B/G H I D, PAL M, PAL N
SECAM
YPrPb
720 x 480i @ 60 Hz
720 x 576i @ 50 Hz
1280 x 720p @ 23.97, 24, 25, 29.94, 30 Hz
1280 x 720p @ 50, 59.94, 60 Hz
1920 x 1080i @ 50, 59.94, 60 Hz
1920 x 1080psf @ 24, 25, 29.97, 30 Hz
1920 x 1080p @ 23.97, 24, 25, 29.94, 30 Hz
1920 x 1080p @ 50, 59.94, 60 Hz
HDMI
1920 x 1080p @ 50, 59.94, 60 Hz
720 x 480i & 720 x 480p @ 59.94, 60 Hz
720 x 576i & 720 x 576p @ 50 Hz
1280 x 720p @ 50, 59.94, 60 Hz
1920 x 1080i @ 50, 59.94, 60 Hz
1920 x 1080psf @ 24, 25, 29.97, 30 Hz
1920 x 1080p 23.97, 24, 25, 29.94, 30, 50, 59.94, 60 Hz
Visit www.ikancorp.com for full specifications

Learn More
More dynamic information at official website: www.ikancorp.com
Support
Contact email: [email protected]
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period is expired.
Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
