The Visual Professionals.
ikan 2006 Product Catalog
LCD Monitors Teleprompter Kits Fluorescent Lights Studio Accessories

Ikan was built for enhancing and developing integrated video equipment, such as our lights
and monitors. Purchasing your production gear resembles purchasing a home. You seek
your architect, appraisers, banks, attorneys, etc... All with one Budget in mind that your
vendors for the reliable hardware, design, service, and support needed for the productions.
They need to utilize these vendors with the confidence that everyone is part of the team with
the same work ethic, goals with superior results in mind.
Ikan is such a resource. Ikan serves its clients as an employee, offering the loyalty of a
family member with economics of a local distributor. Ikan assures our clients that our quality
product will illuminate and enhance productions with the utmost in efficiency and reliability.
Although we cannot be on every set, stage, or location ikan guarantees we will be there
when you need us, and sometimes we will be there even when you didn't know we were.
T h e G o a l

$69.95
The PT1000 is a small and light portable
teleprompter kit. It mounts to the hotshoe on your
camera and is light enough to be shoulder
mounted. You don't have to deal with the big bulky
mirrors of traditional teleprompters that cost double
or triple the price of a PT1000.
It Takes 5 minutes to setup.
PT1000 Teleprompter Kit
$699
Kit Includes
- 8” High Resolution
LCD Monitor
> VGA
> S-Video
> Composite
- Flip Horizontal and Vertical
- Easy to use Software
(windows only)
- Hardware attached
to the camera
Optional Jog Shuttle
Available
- More Control
- Adjust Direction
- Adjust Speed
- Start & Stop

LCD Monitors
Accessories
Our multi-functional LCD monitors range in size from 2.5
inches to 9 inches. All monitors feature antiglare TFT
displays with wide viewing angles for use in the field
or the studio.
Battery Box
$24.95
Battery Box w/charger
$89.95
Sun Hood
$24.95
(not available for V2500)
Battery Plate
for Sony or Canon Batteries
$59.95
Mount on a
tripod or crane.
Use as a preview monitor. Mount on a camera

- Anti-glare screen
- Rear T-channel Mount
- Built-in speaker/volume control
- Resolution: 480x234
- Viewing angles: 65/65(R/L)
- Operating Volts: DC 9-12V
- Power Consumption: <7W
- Dimension: 2.7"x2.8"x1.1"
- Weight 3.5 ounces
With a razor sharp image
and a super low cost,
the V2500 2.5"miniature color LCD
is perfect!
For “sticking” on a
monitor, on a deck,
camera, rack ear, talent desk,
on a jib, in a rack case, behind a
set,under a microphone, as a video return
monitor on a Betacam, and many more
applications...
V2500
$99.95
Package Includes:
- AV Cable
- Power Supply
You Get The Picture!

Metal Rack Unit
RM2500
$595
This rack unit is the perfect addition for any studio. Utilizing
four V2500 monitors enclosed in a high quality,durable
rack unit you get the best of both worlds: affordability,
quality, and at half the price of the competition!
- Four V2500 LCD TFT monitors
- Rackmount Unit pre-assembled with monitors
- All video cables
- Power supply for four monitors
- Occupies 2U
- Four V2500 LCD TFT monitors
- Rackmount Unit pre-assembled with monitors
- All video cables
- Power supply for four monitors
The RM1002K can be used as a table top mount so
you're not limited to only a rack. The RM1002K takes up
2U and is also made with light acrylic, so it’s light weight!
It comes complete with cables and one power source for
ease and confidence.
Desktop/Rack Unit
RM1002K
$549

V70007”
$349
V90009”
$449
The V9000 features a larger 9” TFT screen making viewing easy even at a
distance. It’s light weight, minimal power-consumption and at a low cost makes
it a necessity for all DV cameras, decks, and studios.
The V7000 LCD Monitor is a small versatile wide screen 7” solution.
- 16:9 and 4:3 Aspect Ratios
- Full Range of Quality Controls
- 1440 x 234 Resolution
- Horizontal and Vertical Flip
- Built-in Speakers
- 16:9 and 4:3 Aspect Ratios
- Full Range of Quality Controls
- 1440 x 234 Resolution
- Horizontal and Vertical Flip
- Built-in Speakers
V7000 Includes:
Remote control
Power Supply
AV Cable
Camera Mount
Mounting Bracket
Car Adapter
V9000 Includes:
Remote control
Power Supply
AV Cable
Camera Mount
Mounting Bracket
Car Adapter

The V8000T LCD monitor
is the most versatile of the bunch
with its touch screen capabilities
and VGA inputs makes it a handy
Kiosk and a portable field monitor.
V8000T 8”
$449
Touchscreen!
- Turns your laptop into a dual monitor workstation.
- Small Video Monitor for News Vans
- 4:3 on camera monitor.
- Touchscreen kiosk
- VGA Touchscreen
- Composite and Y/C Input
- 1024 x 768 Resolution
- Mac and PC Compatible
V8000T Includes:
- Remote Control
- AC Adapter
- AV Cables
- VGA Cable
- Mounting Bracket
- Car Adapter

- Low energy consumption, cost efficient output.
- 3000K lamps included (3200,5200,& 5600 available)
- Longer bulb life.
- No heat lighting
- Bulit-in barn doors.
- Integrated dimmer.
- Integrated eggcrate and filter channel.
- Light-weight aluminum construction for optimal rigidity and durability.
- Height adjustable yoke.
- Built-in ballast.
- DMX models available.
- Less expensive than the competitors at pro levels.
Accessories
Fluorescent Lights
Gel Frames
Starting at $20
Egg Crates
Starting at $30
Soft Case
Starting at $89.95
“The ikan fluorescent lighting systems provide
an excellent value for the dollar in a no-fuss package.”
- Pete Bauer/DV Info Net. -
“All in all we very much liked the performance
of the ikan S200D and would welcome it
as a permanent resident in the studio.”
- Bruce Coykendall/VideoMaker -
Hard Case
Starting at $240
DMX Controllers
Starting at $299

Tubes: Two 55watt Bulbs
Size: 23"x7.8"x3.9"
Weight: 9.2 lbs
Tubes: Four 55watt Bulbs
Size: 14"x23"x3.9"
Weight: 13.4 lbs
Tubes: Six 55watt Bulbs
Size: 22"x20"x3.9"
Weight: 18.9 lbs
Tubes: Eight 55watt Bulbs
Size: 22.8"x7.8"x3.9"
Weight: 21.3 lbs
3ft 9ft 12ft 3ft 9ft 12ft
3ft 9ft 12ft
3ft 9ft 12ft
S-Series Lights single column
S200 $699
S200D* $749
S400 $949
S400D* $999
S600 $1,299
S600D* $1,349
S800 $1,599
S800D* $1,649
* D stands for DMX model.
288 83 44
787 197 99
1124 306 145
1486 377 183
** Light digrams are measured in Foot Candles.

L-Series Lights dual column
Tubes: Two 55watt Bulbs
Size: 6” x 43.3“ x 4.3”
Weight: 15 lbs
Tubes: Four 55watt Bulbs
Size: 8.1” x 43.3” x 4.3”
Weight: 17 lbs
Tubes: Eight 55watt Bulbs
Size: 14.6” x 43.3” x 4.3”
Weight: 24 lbs
Tubes: 12 - 55watt Bulbs
Size: 21.5” x 43.3” x 4.3”
Weight: 37 lbs
1m 2m 3m
1m 2m 3m
1m 2m 3m
L200 $699
L200D*$749
L400 $999
L400D*$1,049
L800 $1,649
L800D*$1,699
L1200 $2,099
L1200D*$2,149
1m 2m 3m
Also Available:
L1600 $2,875
L1600D*$2,895
*DMX model.
2800 700 350 11500 3900 1830
16200 5300 2600
4300 1500 790
** Light diagrams are measured in LUX.

S800
S800
S800
Chroma Key Wall
Lighting Examples
S800
S600 S600
Subject
S400
L600
S400 L600
L600
S400 S400
S200
S200
Figure 1. Chroma Key wall.
Figure 2. interview set.
Figure 3. News anchors.
Figure 4. 2 light interview.
1. 3. 4.
2.
Couch
Desk
Subject Legend
Camera

Brifocus 650 Halogen Cool Touch
The Brifocus 650 Halogen Cool Touch is designed to be the
perfect balance between affordability and usability. This 650 watt
open faced tungsten fixture features focusing capabilities with an
exceptionally even field of illumination, and cool touch casing.Its
lightweight and efficient no heat design makes it ideal for either
for use in the field or the studio.
Light Includes:
- 650 Watt Focusing Flood Light
- Cable Strap
- Safety Latch
- Professional Power Switch
- 4 Door Barndoor
Options
Soft boxes $ 69.95
Light stands $ 39.95
- Cable Strap
- Safety Latch
- Professional power switch
$249

Light Stands
Midi Pro Stand
Applications:
Light weight fixtures such
as softboxes and small
incandecent lights.
Heavy Duty Junior Stand
Applications:
S200 Series Lights
L200 Series Lights
S400 Series Lights
L400 Series Lights
Master Combo HD Stand
Applications:
S400 Series Lights
L400 Series Lights
S600 Series Lights
S800 Series Lights
L800 Series Lights
High Roller Stand
Applications:
S800 Series Lights
L800 Series Lights
L1200 Series Lights
L1600 Series Lights
Master series C-Stand
Applications:
General use stand used to
hold reflectors and other
lighting equipment.
023AC 145M 226M 300C CS40M
$74.75 $149.95 $199.00 $379.00 $129.00
Optional
40" Extension Grip Arm $34.95
Lbs.
33.8”
98.4”
2.8 lbs
42.9”
2.2 lbs
Lbs.
45.2”
157.8”
13.2 lbs
46”
2.2 lbs
Lbs.
51”
133”
20 lbs
51.9”
88.1 lbs
Lbs.
55.9”
168.5”
33.9 lbs
50.7”
88.1 lbs
Lbs.
55.1”
118.8”
15.1 lbs
37.4”
22 lbs
Specs. Specs. Specs. Specs. Specs.

Grip Accessories
Iron Casting C Clam
Used to mount our Ikan
fluorescent lights and other lights
to ceiling grids in studios. For use
with light to heavy duty lights.
Stage Clamp w/16mm Stud
Used to mount our Ikan fluorescent
lights and other lights to ceiling grids
in studios. For use with light to
medium duty lights.
Ceiling Clip w/male adapter
Used to mount our light duty
lights to office building type ceilings.
EZ-TIE Cable Grip
Great product for organizing all of
you cables.
Sandbag
Used to stabalize light stands
and other equipment.
Safety Wire
Used for extra protection when
hanging lights from a ceiling grid.
$3.95 SW-01 Dia. 3.5mm,
80cm Length
$3.95 SW-02 Dia. 3.0mm, 75cm
Length w/PVC Sleeve
$5.95 SW-03 Dia. 5.0mm,
105cm Length
$4.95 SW-04 Dia. 4.5mm, 80cm
Length w/PVC Sleeve
$14.95 $12.95
$16.95 $29.95
$12.95
$14.95
Small
Large
Gaffer Tape
Tape that leaves no sticky
residue behind. Used to tape
down cables for safety.
Glossy $13.95
LCD Monitor Arm
Used to mount LCD Monitor
on a stand.
$69.95

Ikan Corp. 3720 Stoney Brook - Houston, TX 77063 713-272-8822
www.ikancorp.com
Leading the world to a better place.
