Ikan 7" HDMI LCD Monitor with IPS Panel User manual
www.ikancorp.com
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.
1.713.272.8822
© 2014 ikan Corporation. All right reserved
What’s included
Checked by
VH7i
7" HDMI LCD Monitor with IPS Panel QUICKSTART GUIDE
1 x VH7i Monitor
1 x AC Adapter
1 x Camera Shoe Mount
1 x DV Battery Adapter (Check one)
BP5-S Sony "L" Series
BP5-SU Sony "BP-U" Series
BP5-C Canon "900" Series
BP5-E6 Canon E6 Battery
BP5-P Panasonic "D54" Series
SeriesBP5-PG6 Panasonic G6
BP5-N Nikon “EN-EL15”Series
VH7i
7" HDMI LCD Monitor with IPS Panel QUICKSTART GUIDE
LOCK
MENU EXIT/
ASPECT
HDMI
OUT
HDMI
IN
4310
8
910 7 10 12 6 5
21
F1 F2
ON OFF
www.ikancorp.com 713-272-8822
1
Menu Button. Scroll Wheel
Used to enter and navigate menu
EXIT/Aspect
Used to exit the menu. When outside of the
menu used to change scrrecn aspect ratio
Function 2
Function Key actions are selected in the menu
Function 1
Function Key actions are selected in the menu
Power Switch
Power ON/OFF
HDMI Input Terminal
DC 7-24v Power Terminal
Standard DC Connection
HDMI Output Terminal
USB terminal
For factory service use only
3.5mm Head Phone Output
1/4-20 Threaded Insert (On top & Bottom)
DV Battery Plate Slot
Mounting ikan DV Battery Plate
2
3
4
5
6
8
7
9
10
11
12
VH7i
7" HDMI LCD Monitor with IPS Panel QUICKSTART GUIDE
The MANUAL function allows you to change the values of Red, Green, and Blue (RGB).
This function recalls user dened values settings .The user setting will remain in memory
indenitely and can be erased by using the reset option in the main menu.
Select throught various aspect ratio masks.( 15:9, 4:3, 1:5:1 , 1.85:1, 2:1 , 2.35:1 )
The DSLR Scaling function will allow users to extend their DSLR camera’s HDMI video
output any option of four – Normal, 3:2, 16:9 or Full Screen – convenience made simple.
This function displays the blanking portion of the incoming signal.
The LCD panel in this display has a native display of 1280 x 800 pixels. A signal of any
other resolution is scaled to t this native resolution. There may be time when it is
desired to view the incoming signal without scaling. Enabling Pixel to Pixel mode turns
off the scaling and displays a 1280 x 800 pixel window of the original image. Each pixel
of the panel displays one pixel of the original image. The user may use the arrow buttons
(buttons 3-6) on the monitor face to move the window left, right, up and down to see the
desired portion of the image.
The VH7i is equipped with Monochrome Peaking features which highlight the desired
focus area in a bright, red outline. The operator adjusts the focus control until the red
indicator outlines on the desired area are razor sharp, indicating optimal focus. For the
best results, be sure the subject is properly exposed.
The False Color feature utilizes a full spectrum of assigned color indicators, ensuring
awless shot exposure. As the camera Iris is adjusted, the subject of the image will
change color based on specic brightness values indicating optimal exposure. See
included chart for color assignments.
As an additional tool associated with the VH7i’s False Color feature, ikan’s exclusive
Adjustable Under Exposure and Over Exposed Waning feature gives the operator full
control of the VH7i False Color brightness values. By setting the preferred IRE exposure
limits, the operator is warned when the image exposure is exceeding or falling under
the preset IRE limit, providing customizable, full image exposure control.
The VH7i offers adjustable upper Clip Guide levels to accurately display overexposed
images in any shooting condition. The operator simply assigns the upper IRE to their
preference and any exposure over the set IRE limit will ash in a vivid purple, indicating
only the over exposed area.
This function displays a side by side comparison of the incoming video signal. Pushing
the F1/2 button one time will enter the mode. Each time the F1/2 button is pushed it
will freeze the current frame on the right hand side of the display while the left continues
to display the live signal. Pressing the exit button will exit the window mode.
Use Window 1 for 16:9 signals and Window 2 for 4:3 signals.
Display a crosshair on the center of screen.
Brightness 0-100
Contrast 0-100
Chroma 0-100
Sharpness 0-100
Tint 0-100
Color Temp. 5600 K
6500 K
9300 K
MANUAL
OSD Language English
Chinese
OSD Duration 5-60 second
Luma Under Warn
Luma Over Warn
Fuction 1-4 Window 1
Window 2
HV Delay
Guides
Peaking
False Color
Clip Guide
Underscan
DSLR Scaling
Check Field
Pixel
Guide Masks
Menu Setup User 1-5
System Reset
CONFIGURATION OF SETTING MENUS
Crosshair
VH7i
7" HDMI LCD Monitor with IPS Panel QUICKSTART GUIDE
www.ikancorp.com 713-272-8822
Supported Video Signals
HDMI 720x480i & 720x480p @ 59.94, 60 Hz
720x576i & 720x576p @ 50 Hz
1280x720p @ 50, 59.94, 60 Hz
1920x1080i @ 50, 59.94, 60 Hz
1920x1080psf @ 24, 25, 29.97, 30 Hz
1920x1080p @ 23.97, 24, 25, 29.94, 30, 50, 59.94, 60 Hz
SPECIFICATIONS:
Screen Size: 7"
Aspect Ratio: 16:10
Resolution: 1280 x 800
Viewing angle: 178° horizontal/178° vertical
Display Technology: IPS
Brightness: 400 cd/m2
Contrast Ratio: 800:1
Response Time: 30ms
Pixel Pitch: 0.11775×0.11775 (mm)
Built In Speaker: N/A
Power Consumption: 6.5W
Input Voltage: DC 7V - 24V
Operating Temperature: 0°C ~ 50°C (32°F ~122°F)
Cooling System: PAL/NTSC/SECAM (Auto-Detected)
Build Material: Plastic
Dimensions: 4.9 x 7.1 x 0.59"
Weight : 0.5 lbs
Shipping Dimensions: 3.1 x 14.75 x 7.75"
Shipping Weight: 2 lbs
Dimensions (Metric): 124 x 180 x 14.9mm
Weight (Metric): 0.22 kg
Shipping Dimensions (Metric): 374 x 196 x 76mm
Shipping Weight (Metric): 0.90 kg
UPC Code: (C)847983012688 (E6) 847983012671 (N) 847983012664 (P) 847983012657
(P) 847983012640 (PG6) 847983012640 (S) 847983012633 (SU) 847983012626
