IKEA BEJUBLAD User manual

BEJUBLAD
GB
FR
DE
IT

ENGLISH 4
DEUTSCH 22
FRANÇAIS 41
ITALIANO 65
Please refer to the last page
of this manual for the full list
of IKEA appointed Authorized
Service Centre and relative
national phone numbers.
Gehen Sie dazu auf die letzte
Seite dieser Broschüre. Dort
nden Sie eine Übersicht mit den
entsprechenden Telefonnummern
und Kontaktdaten unserer
autorisierten Kundendienste.
Consultez la dernière page de ce
manuel pour la liste complète des
centre d’entretien et de réparation
agréés IKEA avec leur numéro de
téléphone respectifs.
Siete pregati di contattare il
numero del Centro Assistenza
Autorizzato incaricato da IKEA
riportato sull’ultima pagina di
questo manuale.

ENGLISH 4
Before using the appliance, read
these safety instructions. Keep
them nearby for future reference.
These instructions and the
appliance itself provide important
safety warnings, to be observed
at all times. The manufacturer
declines any liability for failure to
observe these safety instructions,
for inappropriate use of the
appliance or incorrect setting of
controls.
SAFETY WARNINGS
Very young children (0-3
years) should be kept away from
the appliance. Young children
(3-8 years) should be kept
away from the appliance unless
continuously supervised.
Children from 8 years old
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge can
use this appliance only if they
are supervised or have been
given instructions on safe use and
understand the hazards involved.
Children must not play with the
appliance.
Safety Information
Table of contents
Cleaning and user maintenance
must not be carried out by
children without supervision.
WARNING!: The appliance
and its accessible parts become
hot during use.
WARNING!: Avoid touching
heating elements or interior
surface during and after use - risk
of burns.
WARNING!: Never leave the
appliance unattended during
food drying. If the appliance
is suitable for probe usage,
only use a temperature probe
recommended for this oven - risk
of re.
Keep clothes or other
ammable materials away
from the appliance, until all the
components have cooled down
completely - risk of re.
Always be vigilant when cooking
foods rich in fat, oil or when
adding alcoholic beverages - risk
of re. Use oven gloves to remove
pans and accessories. At the end
of cooking, open the door with
caution: allowing hot air or steam
Safety Information 4
Product description 8
Control panel 9
First use 9
Daily use 10
Cooking tables 14
Cleaning and maintenance 15
What to do if ... 16
Technical data 17
Installation 17
Electrical connection 18
Environmental concerns 19
IKEA GUARANTEE 20

ENGLISH 5
to exit gradually before accessing
the cavity - risk of burns. Do not
obstruct hot air vents at the front
of the oven - risk of re.
Exercise caution when the
oven door is in the open or down
position, to avoid hitting the door.
WARNING!: If the door or
door seals are damaged, the
oven must not be operated until it
has been repaired – risk of injury.
WARNING!: Liquids and foods
must not be heated in sealed
containers – risk of explosion,
heating of beverages can result
in delayed eruptive boiling, care
must be taken when handling the
container – risk of burn.
Do not dry food or cloathing
or heat warming pads, slippers,
sponges and similar - risk of re.
When heating food in plastic or
paper containers, remains vigilant
on the oven - risk of re.
Contents of feeding bottles
and baby food jars shall be
stirred or shaken and temperature
checked - risk of burn. Do not
heat eggs in their shell and
shole hard-boiled eggs - risk of
explosion
Only use utensils suitable
for microwave oven. Do not use
metallic containers - risk of injury
Only use a temperature probe
recommended for this oven - risk
of re.
If smoke is emitted switch off
or unplug the appliance and
keep the door closed in order to
stie any ames.
If appliance is installed
above 850 cm heigh from oor,
care should be taken not to
displace turntable while removing
container - risk of injury.
Do not use your microwave
oven for deep-frying, because
the oil temperature cannot be
controlled.
PERMITTED USE
This appliance is intended to
be used in household and similar
applications such as:
Staff kitchen areas in shops,
ofces and other working
environments; Farm houses; By
clients in hotels, motels and other
residential environments; Bed and
breakfast type environments.
CAUTION: the appliance is
not intended to be operated by
means of an external switching
device, such as a timer, or
separate remote controlled
system.
This appliance is intended
to be used in household and
similar applications such as: staff
kitchen areas in shops, ofces
and other working environments;
farm houses; by clients in hotels,
motels, bed & breakfast and
other residential environments.

ENGLISH 6
Do not install the appliance
behind a decorative door - risk o
re.
This appliance is not for
professional use. Do not use the
appliance outdoors.
No other use is permitted (e.g.
heating rooms).
Do not store explosive or
ammable substances (e.g.
gasoline or aerosol cans) inside
or near the appliance - risk of
re.
INSTALLATION
The appliance must be
handled and installed by two or
more persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
Installation, including water
supply (if any) and electrical
connections, and repairs must
be carried out by a qualied
technician. Do not repair or
replace any part of the appliance
unless specically stated in the
user manual. Keep children
away from the installation site.
After unpacking the appliance,
make sure that it has not been
damaged during transport.
In the event of problems, contact
the dealer or your nearest
After-sales Service. Once
installed, packaging waste
(plastic, styrofoam parts etc.)
must be stored out of reach of
children - risk of suffocation. The
appliance must be disconnected
from the power supply before
any installation operation -
risk of electrical shock. During
installation, make sure the
appliance does not damage
the power cable - risk of re or
electrical shock. Only activate the
appliance when the installation
has been completed.
This appliance is intended
to be used built-in. Do not use
it freestanding or place into a
cabinet.
After unpacking the appliance,
make sure that the appliance
door closes properly.
In the event of problems, contact
the dealer or your nearest After-
sales Service.
Carry out all cabinet cutting
works before tting the appliance
in the furniture and remove all
wood chips and sawdust.
Do not obstruct the minimum gap
between the worktop and the
upper edge of the oven - risk of
burn.
Do not remove the oven from its
polystyrene foam base until the
time of installation.
After installation, the bottom
of the appliance must no longer
be accessible - risk of burn.
ELECTRICAL WARNINGS
The rating plate is on the front
edge of the oven (visible when
the door is open).

ENGLISH 7
It must be possible to
disconnect the appliance from
the power supply by unplugging
it if plug is accessible, or by
a multipole switch installed
upstream of the socket and the
appliance must be earthed, in
conformity with national electrical
safety standards.
Do not use extension leads,
multiple sockets or adapters.
The electrical components must
not be accessible to the user
after installation. Do not use the
appliance when you are wet or
barefoot. Do not operate this
appliance if it has a damaged
power cable or plug, if it is not
working properly, or if it has been
damaged or dropped.
If the supply cord is damaged,
it must be replaced with an
identical one by the manufacturer,
its service agent or similarly
qualied persons in order to
avoid a hazard - risk of electrical
shock.
In case of replacement
of power cable, contact an
authorized service center.

ENGLISH 8
Product description
General
There are a number of accessories available
on the market. Before you buy, ensure they are
suitable for microwave use.
Ensure that the utensils you use are oven proof
and allow microwaves to pass through them
before cooking.
When you put food and accessories in the
microwave oven, ensure that they do not come
in contact with the interior of the oven.
This is especially important with accessories
made of metal or metal parts.
If accessories containing metal comes in
contact with the oven interior, while the oven is
in operation, sparking can occur and the oven
could be damaged.
Always ensure that the turntable is able to turn
freely before starting the oven.
All accessories are dishwasher safe with the
exception of the crisp plate.
The crisp plate should be cleaned using water
and a mild detergent. For stubborn dirt, rub
gently with a cloth. Always leave the crisp
plate to cool down before cleaning.
Aluminium foil can be used safely to shield
small areas of food as long as it does not
come in contact with the oven interior.
Turntable support
Use the turntable support under the Glass
turntable. Never put any other utensils on the
turntable support.
Fit rst the internal weel and then the external
part of the turntable support.
Glass turntable
Use the Glass turntable with all cooking
methods. It collects the dripping juices and
food particles that otherwise would stain and
soil the interior of the oven.
Place the Glass turntable on the turntable
support.
Crisp handle
Use the supplied special Crisp handle to
remove the hot Crisp plate from the oven.
Crisp-plate
Place the food directly on the Crisp-plate.
Always use the Glass turntable as support
when using the Crisp-plate.
Do not place any utensils on the Crisp-plate
since it will quickly become very hot and is
likely to cause damage to the utensil.
1
2
3
4
1Control Panel
2Grill element (Quartz)
3Cavity Lamp
4Door
Accessories
Turntable support
1x
Glass turntable
1x
Crisp-plate
1x
Crisp handle
1x

ENGLISH 9
Control panel
A D GB C E F
Setting the time
You will need to set the time when you
switch on the appliance for the rst time:
The two digits for the hour will ash on the
display.
Turn the adjustment knob to set the correct
hour and press to conrm. The two digits
for the minutes will start ashing. Turn the
adjustment knob to set the correct hour and
press to conrm.
Please note: to change the time at a later
point, press and hold Bfor at least 3
seconds while the microwave oven is off and
repeat the steps above. You may need to
set the time again following lengthy power
outages.
Setting display
Press for three seconds to enter in the
setting menù.
Turn the Adjustment knob Gto select Eco
and tonE and press to conrm.
First use
ASelection Knob
BBack
CStop
DDisplay
EStart
F Conrm
GAdjustment Knob
Retractable knobs
To use this type of knob, press it
in the middle.
The knob comes out.
Turn it to the required position.
Once cooking is over, turn the
knob to and press it again to
restore it to its original position.
Eco -->
When the Eco mode is on, the brightness
of the display will automatically switch
to a lower level after 1 minute. If the Eco
mode is off, the brightness will switch to
the same lower level after 3 minutes. It
will automatically switch back to the set
brightness level when a button is pressed or
the door is opened. When you display Eco
press to conrm.
You’ll display ON/OFF, select with Gknob
the desired one and press to conrm.
tonE -->
When the tonE mode is on, all the acustical
feedbacks are turned off.
When you display tonE press to conrm.
You’ll display ON/OFF, select with Gknob
the desired one and press to conrm.

ENGLISH 10
Start protection / Safety lock
This function is automatically activated
for safety one minute after the oven has
returned to “stand by mode“. (The oven is in
“stand by” when the clock is displayed or if
the clock has not been set, when the display
is blank).
Open and close the door, then press to
start the function.
Cooling down
When a function is nished, the oven
may carry out a cooling procedure. This
is normal. After this procedure the oven
switches off automatically. The cooling
procedure can be interrupted without any
harm to the oven by opening the door.
Setting the timer
When the oven is switched off, the display
can be used as a timer. The timer does not
activate any of the cooking cycles.
To activate and set the cooking timer you
require, turn the adjustment knob.
Press to countdown start. An audible
signal will sound and the display will
indicate once the timer has nished counting
down the selected time.
To make a change to the timer once it has
been activated, turn the adjustment knob,
then press OK to conrm.
To interrupt it or return to the current time
display, turn the adjustment knob until 0:00
is on the display and press .
Please note: Once the timer has been
activated, you can activate a function as
well: The timer will continue to count down
the selected time automatically without
having any effect on the function. To go
back to viewing the timer, wait for the
Daily use
function to nish or stop the oven function by
pressing two times.
WARNING : Overheating the liquid beyond
boiling point can occur without evidence
of bubbling. This could result in a sudden
boil over of the hot liquid. To prevent this
possibility the following steps should be
taken :
1. Avoid using straight-sided containers
with narrow necks.
2. Stir the liquid before placing the
container in the appliance and let the
teaspoon remain in the container.
3. After heating, allow standing for a short
time, stirring again before carefully
removing the container from the
appliance.
Jet start
This function is used for quick reheating
of food with a high water content such as;
clear soups, coffee or tea.
Press the button to automatically start
with full microwave power level and the
cooking time set to 30 seconds. Each
additional press increases the time with 30
seconds.
Microwave oven functions table
Function Description of
function
OFF For switching off the oven.
MICROWAVES
For quickly cooking
and reheating food or
beverages.
CRISP
For perfectly browning a
dish, both on the top and
bottom of the food. This
function must only be used
with the special Crisp plate.
GRILL
For browning, grilling and
gratins. We recommend
turning the food during
cooking. For best results,
preheat the grill for 3-5
minutes.

ENGLISH 11
Function Description of
function
GRILL COMBI
For quickly cooking
and gratinating dishes,
combining the microwave
and grill functions.
AUTOMATIC
DEFROST
To defrosting meat, poultry,
sh, vegetables and bread.
AUTOMATIC
FUNCTION
To use specic cooking
cycle for 10 food
categories.
Set a function
After having selected the function you
require, you can change its settings.
The display will show the settings that can
be changed in sequence.
POWER LEVEL
When the icon ashes on the display,
turn the adjustment knob to change the
selected item, press to conrm, and
proceed with the following settings.
Please note: once the function has been
activated, the power can be changed by
pressing two times to access the power
settings menu, then turning the adjustment
knob to change the setting.
DURATION
When the icon ashes on the display,
turn the adjustment knob to set the desired
cooking time.
Once the displayed cooking time
corresponds with what you desire, press
to conrm and start the function.
Please note: During cooking, you can
adjust the cooking time by turning the knob;
each time you press , the cooking time
increases by 30 seconds.
Activate the function
Once you have applied the settings you
require, press to activate the function.
Every time the button is pressed again,
the cooking time will be increased by an
additional 30 seconds (only for the manual
functions).
Please note: You can press at any time
to pause the function that is currently active.
Power level Microwaves only
Power Suggested use:
1000 W Reheating of beverages, water, clear
soups, coffee, tea or other food with
a high water content. If the food
contains egg or cream choose a
lower power.
800 W Cooking of vegetables, meat etc.
650 W Cooking of sh.
500 W More careful cooking e.g. high
protein sauces, cheese and egg
dishes and to nish cooking
casseroles.
350 W Simmering stews, melting butter and
chocolate.
160 W Defrosting. Softening butter, cheeses.
90 W Softening Ice cream
Crisp
Use this function to reheat and cook pizzas
and other dough based food. It is also
good for frying bacon and eggs, sausages,
hamburgers etc.
The oven automatically use’s Microwaves
and Grill in order to heat the Crisp-plate.
This way the Crisp-plate will rapidly reach
its working temperature and begin to brown
and crisp the food. It is not possible to
change or switch, the Power level or Grill,
on/off, when using the Crisp function.
Ensure that the Crisp-plate is correctly
placed in the middle of the Glass turntable.
The oven and the crisp-plate become very
hot when using this function.
Do not place the hot crisp-plate on any
surface susceptible to heat.

ENGLISH 12
i
IMPORTANT: Be careful, not to touch
the ceiling near the Grill element.
Use oven mittens or the special Crisp handle
supplied when removing the hot Crisp-plate.
Only use the supplied Crisp plate with this
function. Other available Crisp plates on the
market will not give the correct result when
using this function.
i
IMPORTANT: The Crisp-plate may be
preheated before use (max. 3 min.).
Always use the Crisp function when
preheating the crisp-plate.
Grill
Use this function to quickly give a plesant
brown surface to the food.
Turn the food during cooking.
Ensure that the utensils used are heat
resistant and ovenproof before grilling with
them.
i
IMPORTANT: Do not use plastic
utensils when grilling. They will melt.
Items of wood or paper are not suitable
either.
Combi
Use this function to cook such food as
Gratins, Lasagne, Poultry and Baked
potatoes.
Grill combi
Power Suggested use:
650 W Cooking Vegetables and
Gratins
350 - 500 W Cooking Poultry and Lasagne
160 - 350 W Cooking Fish and frozen gratins
160 W Cooking Meat
90 W Gratinating fruit
Auto defrost
Use this function for defrosting Meat, Poultry,
Fish, Vegetables and Bread.
Auto Defrost should only be used if the net
weight is between 100 g-2.5 kg.
Always place the food on the glass
turntable.
Food Hints
Meat
(100 g - 2.0 Kg)
Minced meat, cutlets, steaks
or roasts. Turn food when
oven prompts.
Poultry
(100 g - 2.5 Kg)
Chicken whole, pieces or
llets. Turn food when oven
prompts.
Fish
(100 g - 1.5 Kg)
Whole, steaks or llets. Turn
food when oven prompts.
Vegetables
(100 g - 1.5 Kg)
Mixed vegetables, peas,
broccoli etc. Turn food when
oven prompts.
Bread
(100 g - 1.0 Kg)
Loaf, buns or rolls. Turn food
when oven prompts.
Manual defrost
Check and inspect the food regularly.
Experience will give you the times needed
for various amounts.
Frozen food in plastic bags, plastic lms or
cardboard packages can be placed directly
in the oven as long as the package has no
metal parts (e.g. metal twist ties).
The shape of the package alters the
defrosting time. Shallow packets defrost
more quickly than a deep block.
Separate pieces as they begin to defrost.
Individual slices defrost more easily.
Shield areas of food with small pieces of
aluminum foil if they start to become warm
(e.g. chicken legs and wing tips).
Turn large joints halfway through the
defrosting process.
Boiled food, stews and meat sauces defrost
better if stirred during defrosting time.
When defrosting it is better to under-thaw
the food slightly and allow the process to
nish during standing time.

ENGLISH 13
Standing time after defrosting always
improves the result since the temperature
will then be evenly distributed throughout
the food.
Automatic Functions
The oven will automatically calculate the
ideal settings. Where indicated, the function
can only be used in combination with the
Crisp plate provided. Turn or stir the food
when prompted.
CATEGORIES
Once you have chosen one of the automatic
functions, you will need to select a category
for the food you are cooking (For food
classes see table below).
Category Food Weight
DINNER PLATES 250-500 g
FROZEN LASAGNA 250-500 g
BAKED POTATOES
(turn when prompted) 200 g-1 kg
FRESH VEGETABLES
(cut uniformly and add
2 to 4 tablespoons of
water. Cover)
200-800 g
FROZEN VEGETABLES
(turn when prompted,
cover) 200-800 g
POPCORN 100 g
FRENCH FRIES
(spread out in a single
layer on the Crisp
plate and sprinkle
with salt before
cooking)
200-500 g
Category Food Weight
PIZZA
(use the Crisp plate) 300-800 g
CHICKEN WINGS,
CHICKEN PIECES
(lightly oil the Crisp
plate.)
200-500 g
FRIED CUTLETS
(Crisp plate must be
preheated) 200-500 g
When the icon ashes on the display,
turn the adjustment knob to select the digit
that corresponds to the desired category,
then press to conrm.
WEIGHT
To achieve the best results, the automatic
functions require you to enter the weight of
the food, selecting from amongst the default
settings: the oven will calculate the ideal
length of time for the function to run for each
category of food.
When the default setting appears on the
display and the icon ashes, turn the
adjustment knob to enter the weight, then
press to conrm and start the function.

ENGLISH 14
Cooking tables
Food Function Preheating Power
(W) Cooking Time (Min)
Sponge cake - - 7 - 10
Fruit pie - - 12 - 20
Cookies - - 3 - 5
Savoury tarts and quiche Lorraine
(1 - 1.2 kg) - - 18 - 25
Dinner Plates (250 - 500 g) -750 4 - 7
Lasagna / baked pasta -500 15 - 25
Frozen lasagna (500 - 700 g) -500 18 - 25
Frozen pizza (300 g) - - 7 - 8
Meat (chops, steak) -500 12 - 20
Poultry (whole, 800 g - 1.5 kg) - 350 - 500 35 - 50 *
Chicken llets or pieces X ** - 10 - 25
Roasts - 160 - 350 45 - 60 *
Sausages / skewers - - 20 - 40 *
Sausages/hamburgers X ** - 6 - 16 *
Fish (steaks or llets) X 160 - 350 15 - 30 *
Whole sh - 500 - 650 20 - 40 *
Baked potatoes - 350 - 500 20 - 40 *
Potato wedges - - 25 - 30
Baked apples - 160 -350 15 -25
* Turn the food halfway through cooking ** Preheat the Crisp plate for 3-5 minutes

ENGLISH 15
Cleaning and maintenance
Cleaning is the only maintenance normally
required.
Failure to maintain the oven in a clean
condition could lead to deterioration of the
surface that could adversely affect the life
of the appliance and possibly result in a
hazardous situation.
i
IMPORTANT: do not use metal
scouring pads, abrasive cleansers,
steel-wool pads, gritty washcloths, etc.
which can damage the control panel, and
the interior and exterior oven surfaces. Use
a sponge with a mild detergent or a paper
towel with spray glass cleaner. Apply spray
glass cleaner to a paper towel.
Do not spray directly on the oven.
At regular intervals, especially if spill overs
have occurred, remove the turntable, the
turntable support and wipe the base of the
oven clean.
This oven is designed to operate with the
turntable in place.
i
IMPORTANT: do not operate the
microwave oven when the turntable
has been removed for cleaning.
Use a mild detergent, water and a soft cloth
to clean the interior surfaces, front and rear
of the door and the door opening.
i
IMPORTANT: do not allow grease or
food particles to build up around the
door.
For stubborn stains, boil a cup of water
in the oven for 2 or 3 minutes. Steam will
soften the marks.
i
IMPORTANT: do not use steam
cleaning appliances when cleaning
your microwave oven.
Adding some lemon juice to a cup of water,
placing this on the turntable and boiling for
a few minutes can eliminate odors inside the
oven.
The Grill element does not need cleaning
since the intense heat will burn off any
splashes, but the cavity ceiling near it may
need regular cleaning. This should be done
with warm water, detergent and a sponge.
If the Grill is not used regularly, it should be
run for 10 minutes a month to burn off any
splashes.
Dishwasher safe
• Turntable support.
• Glass turntable.
• Crisp handle.
Careful cleaning
The Crisp-plate should be cleaned in mild,
detergent water. Heavily soiled areas can
be cleaned with a scouring sponge and a
mild cleanser.
Always let the crisp-plate cool off before
cleaning.
i
IMPORTANT: do not immerse or rinse
with water while the crisp-plate is hot.
Quick cooling may damage it.

ENGLISH 16
Problem Possible cause Solution
The appliance does not
work.
The mains power supply or the
appliance is not connected.
Check your fuses and ensure that there is
power avaliable.
The door isn’t closed. Open and then close the door before you
try again.
The display shows the
letter “F” followed by a
letter or number
Software fault. Contact you nearest After-sales Service
Centre and state the letter or number that
follows the letter “F”.
The food is unevenly
heated.
Very thin parts such as chicken
wingtips and such are not
shielded.
Shield the thinner parts with aluminum foil.
The food was heated at a
power level too high.
Choose a lower power level.
The turntable has stopped. Check that the turntable and turntable
support is in place and the food is well
centered, not touching the cavity walls.
Food isn’t turning. The turntable has stopped. Check that the turntable and turntable
support is in place and the cavity bottom
is clean.
What to do if ...
WARNING!: Do not remove
any cover. The door seals and the
door seals areas must be regularly
inspected for damage. If these
areas are damaged the appliance
should not be operated until it
have been repaired by a qualied
technician.before performing any
maintenance operation - risk of
electrical shock. Never use steam
cleaning equipment.
Authorized Service Centre
Before calling the Authorized Service Centre:
1. See if you can solve the problem on your
own (see the “What to do if ...” table).
2. Switch the appliance off and on again to see
if the problem has disappeared.
If the fault persists after the above checks,
contact IKEA Authorized Service Centre.
Always specify:
- the type of fault;
- exact type and model of appliance;
- the Authorized Service Centre number (the
number given after the word “Service” on the
rating plate) located on the inside edge of the
oven cavity (visible when the door is open);
- your full address;
- your telephone number.
- If any repairs are required, please contact
IKEA Authorized Service Centre(to guarantee
that original spare parts will be used and
repairs carried out correctly).

ENGLISH 17
Technical data
Model identication: BEJUBLAD 904 117 47
Supply Voltage 220-240V / 50Hz
Rated Power Input 2300 W
Fuse 10 A
MW output power 1000 W
Grill 800 W
Outer dimensions (HxWxD) 397 x 595 x 468
Cavity inner dimensions (HxWxD) 200 x 405 x 380
The technical informations are situated in the rating plate inside the appliance.
Data for test heating performance in accordance with IEC 60705.
The International Electrotechnical Commission has developed a standard for comparative
testing of heating performance of different microwave ovens. We recommend the following
for this oven:
Test Amount Approx. time Power level Container
12.3.1 Egg custard 750 g 11 - 12 min 650 W Pyrex 3.227
12.3.2 Sponge cake 475 g 9 min 650 W Pyrex 3.827
12.3.3 Meatloaf 900 g 16 - 18 min 800 W Pyrex 3.838
13.3 Meat defrost 500 g 14 min 160 W
NOTE: this information is only for the qualied technician.
Mounting the appliance
Follow the supplied separate mounting
instructions when installing the appliance.
Installation and repairs must be carried out
by a qualied technician, in compliance with
the manufacturer’s instructions and local
safety regulations. Do not repair or replace
any part of the appliance unless specically
stated in the user manual.
Children should not perform installation
operations. Keep children away during
installation of the appliance. Keep the
packaging materials (plastic bags,
polystyrene parts, etc.) out of reach of
children, during and after the installation of
the appliance.
Use protective gloves to perform all
unpacking and installation operations.
The appliance must be handled and
installed by two or more persons.The
appliance must be disconnected from the
power supply before carrying out any
installation operation.
After unpacking the appliance, make sure
that it has not been damaged during
transport. In the event of problems, contact
the dealer or your nearest After-sales
Service.
After unpacking the appliance, make sure
that the appliance door closes properly.
In the event of problems, contact the dealer
or your nearest After-sales Service. To
prevent any damage, only remove the oven
from its polystyrene foam base at the time
of installation.
During installation, make sure the appliance
does not damage the power cable.
Installation

ENGLISH 18
Prior to connecting
Check that the voltage on the rating plate
corresponds to the voltage in your home.
The rating plate is on the front edge of the
oven (visible when the door is open).
Do not remove the microwave inlet
protection plates located on the side of the
oven cavity walls. They prevent grease and
food particles from entering the microwave
inlet channels.
Ensure the oven cavity is empty before
mounting.
Ensure that the appliance is not damaged.
Check that the oven door closes rmly
against the door support and that the
internal door seal is not damaged. Empty
the oven and clean the interior with a soft,
damp cloth. Do not operate this appliance
if it has a damaged mains cord or plug, if
it is not working properly, or if it has been
damaged or dropped. Do not immerse the
mains cord or plug in water. Keep the cord
away from hot surfaces. Electrical shock, re
or other hazards may result.
After connecting
The oven can be operated only if the oven
door is rmly closed.
Regulation require that the appliance is
earthed.
The manufacturer will accept no
responsibility for injury to persons, animals
or damage to objects arising from the
non-observance of this requirement.
The manufacturers are not liable for any
problems caused by the user’s failure to
observe these instructions.
Failure to observe these instructions may
lead to risks. The Manufacturer declines any
liability for injury to persons or animals or
damage to property if these advices and
precautions are not respected.
CAUTION: The appliance is not intended to
be operated by means of an external timer
or separate remote control system.
After installation, the electrical components
must not be accessible to the user.
For installation to comply with current
safety regulations, an omnipolar switch with
minimum contact gap of 3mm is required.
WARNING : The power cable must be long
enough for connecting the appliance, once
tted in its housing, to the main power
supply.
Do not pull the power supply cable.
If the power cable is damaged it must
be replaced with an identical one. The
power cable must only be replaced by a
qualied technician in compliance with the
manufacturer instruction and current safety
regulations. Contact an authorized service
center.
Do not operate this appliance if it has a
damaged mains cord or plug, if it is not
working properly, or if it has been damaged
or dropped. Do not immerse the mains cord
or plug in water. Keep the cord away from
hot surfaces.
Do not touch the appliance with any wet
part of the body and do not operate it when
barefoot.
For appliances with tted plug, if the plug is
not suitable for you socket outlet, contact a
qualied technician.
Do not use extension leads, multiple sockets
or adapters. Do not connect the appliance
to a socket which can be operated by
remote control.
Electrical connection

ENGLISH 19
Environmental concerns
WARNING!: It is hazardous for
anyone other than a competent
person to carry out any service
or repair operation that involves
the removal of a cover which give
protection against exposure to
microwave energy.
WARNING!: Failure to maintain
the oven in a clean condition could
lead to deterioration of the surface
that could adversely affect the life of
the appliance and possibly result in
a hazardous situation.
WARNING!: The oven shall be
cleaned regularly and any food
deposits removed.
WARNING!: Ensure that the
appliance is switched off and
disconnected from the power supply
before performing any maintenance
operation - risk of electrical
shock. Never use steam cleaning
equipment.
WARNING!: Do not use harsh
abrasive cleaners or metal scrapers
to clean the door glass since they
can scratch the surface, which may
result in shattering of the glass.
Ensure the appliance is cooled
down before any cleaning or
maintenance. - risk of burn
WARNING!: Switch off the
appliance before replacing the lamp
- risk of electrical shock.
DISPOSAL OF PACKAGING MATERIALS
The packaging material is 100% recyclable
and is marked with the recycle symbol .
The various parts of the packaging must
therefore be disposed of responsibility and in
full compliance with local authority regulations
governing waste disposal.
SCRAPPING OF HOUSEHOLD APPLIANCES
This appliance is manufactured with
recyclable or reusable materials. Dispose of
it in accordance with local waste disposal
regulations. For further information on the
treatment, recovery and recycling of household
electrical appliances, contact your local
authority, the collection service for household
waste or the store where you purchased
the appliance. This appliance is marked in
compliance with European Directive 2012/19/
EU, Waste Electrical and Electronic Equipment
(WEEE). By ensuring this product is disposed
of correctly, you will help prevent negative
consequences for the environment and human
health.
The symbol on the product or on the
accompanying documentation indicates that
it should not be treated as domestic waste but
must be taken to an appropriate collection
center for the recycling of electrical and
electronic equipment.
ENERGY SAVING TIPS
Only preheat the oven if specied in the
cooking table or your recipe. Use dark
lacquered or enamelled baking trays as they
absorb heat better. Food requiring prolonged
cooking will continue to cook even once the
oven is switched off.
n

ENGLISH 20
How long is the IKEA guarantee valid?
This guarantee is valid for ve years from
the original date of purchase of your
appliance at IKEA. The original sales receipt,
is required as proof of purchase. If service
work is carried out under guarantee, this
will not extend the guarantee period for the
appliance.
Who will execute the service?
IKEA service provider will provide the
service through its own service operations or
authorized service partner network.
What does this guarantee cover?
The guarantee covers faults of the
appliance, which have been caused by
faulty construction or material faults from the
date of purchase from IKEA. This guarantee
applies to domestic use only. The exceptions
are specied under the headline “What is
not covered under this guarantee?” Within
the guarantee period, the costs to remedy
the fault e.g. repairs, parts, labour and travel
will be covered, provided that the appliance
is accessible for repair without special
expenditure. On these conditions the EU
guidelines (Nr. 99/44/EG) and the respective
local regulations are applicable. Replaced
parts become the property of IKEA.
What will IKEA do to correct the problem?
IKEA appointed Service Provider will
examine the product and decide, at its
sole discretion, if it is covered under this
guarantee. If considered covered, IKEA
Service Provider or its authorized service
partner through its own service operations,
will then, at its sole discretion, either repair
the defective product or replace it with the
same or a comparable product.
What is not covered under this guarantee?
• Normal wear and tear.
• Deliberate or negligent damage,
damage caused by failure to observe
operating instructions, incorrect
installation or by connection to the wrong
voltage, damage caused by chemical or
IKEA GUARANTEE
electrochemical reaction, rust, corrosion
or water damage including but not
limited to damage caused by excessive
lime in the water supply, damage caused
by abnormal environmental conditions.
• Consumable parts including batteries
and lamps.
• Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible color differences.
• Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of lters, drainage systems or
soap drawers.
• Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
• Cases where no fault could be found
during a technician’s visit.
• Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where non-
original parts have been used.
• Repairs caused by installation which is
faulty or not according to specication.
• The use of the appliance in a non-
domestic environment i.e. professional
use.
• Transportation damages. If a customer
transports the product to his home or
another address, IKEA is not liable for
any damage that may occur during
transport. However, if IKEA delivers
the product to the customer’s delivery
address, then damage to the product
that occurs during this delivery will be
covered by IKEA.
• Cost for carrying out the initial installation
of the IKEA appliance.
• However, if an IKEA appointed Service
Provider or its authorized service partner
repairs or replaces the appliance
