IKEA HUTTRA User manual

HUTTRA
GB
DE
FR
IT

Please refer to the last page
of this manual for the full list
of IKEA appointed Authorized
Service Centre and relative
national phone numbers.
Gehen Sie dazu auf die letzte
Seite dieser Broschüre. Dort
nden Sie eine Übersicht mit den
entsprechenden Telefonnummern
und Kontaktdaten unserer
autorisierten Kundendienste.
Consultez la dernière page de ce
manuel pour la liste complète des
centre d’entretien et de réparation
agréés IKEA avec leur numéro de
téléphone respectifs.
Siete pregati di contattare il
numero del Centro Assistenza
Autorizzato incaricato da IKEA
riportato sull’ultima pagina di
questo manuale.
ENGLISH 5
DEUTSCH 20
FRANÇAIS 35
ITALIANO 50

5
Before using the appliance, read
these safety instructions. Keep them
nearby for future reference. These
instructions and the appliance itself
provide important safety warnings,
to be observed at all times. The
manufacturer declines any liability
for failure to observe these safety
instructions, for inappropriate use
of the appliance or incorrect setting
of controls.
SAFETY WARNINGS
Very young children (0-3 years)
should be kept away from the
appliance. Young children (3-8
years) should be kept away from
the appliance unless continuously
supervised. Children from 8 years
old and above and persons
with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge can
use this appliance only if they
are supervised or have been
given instructions on safe use and
understand the hazards involved.
Children must not play with the
appliance. Cleaning and user
maintenance must not be carried
out by children without supervision.
Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances.
PERMITTED USE
CAUTION: The appliance is not
intended to be operated by means
of an external switching device,
such as a timer, or separate remote
controlled system.
This appliance is intended to
be used in household and similar
applications such as: staff kitchen
areas in shops, ofces and other
working environments; farm houses;
by clients in hotels, motels, bed &
breakfast and other residential
environments.
This appliance is not for
professional use. Do not use the
appliance outdoors.
The bulb used inside the
appliance is specically designed
for domestic appliances and is not
suitable for general room lighting
within the home (EC Regulation
244/2009).
The appliance is designed
for operation in places where the
ambient temperature comes within
Safety Information
Table of contents
Safety Information 5
Product description 10
First Use 10
Daily use 11
Helpful hints and tips 12
Cleaning and maintenance 14
What to do if... 15
Technical data 16
Environmental concerns 17
IKEA GUARANTEE 18
GB
ENGLISH

ENGLISH 6
the following ranges, according
to the climatic class given on the
rating plate. The appliance may not
work properly if it is left for a long
time at a temperature outside the
specied range.
Climatic class ambient
temperatures (°C)
SN: From 10 to 32
N: From 16 to 32
ST: From 16 to 38
T: From 16 to 43
This appliance does not
contain CFCs. The refrigerant
circuit contains R600a (HC).
Appliances with Isobutane
(R600a): isobutane is a natural
gas without environmental
impact, but is ammable.
Therefore, make sure the
refrigerant circuit pipes are not
damaged, especially when
emptying the refrigerant circuit.
WARNING!: Do not damage
the appliance refrigerant circuit
pipes.
WARNING!: Keep ventilation
openings, in the appliance
enclosure or in the built-in structure,
clear of obstruction.
WARNING!: Do not use
mechanical, electric or chemical
means other than those
recommended by the Manufacturer
to speed up the defrost process.
WARNING!: Do not use or
place electrical devices inside the
appliance compartments if they are
not of the type expressly authorised
by the Manufacturer.
WARNING!: Ice makers and/
or water dispensers not directly
connected to the water supply must
be lled with potable water only.
WARNING!: Automatic ice-
makers and/or water dispensers
must be connected to a water
supply that delivers potable water
only, with mains water pressure
between 0.17 and 0.81 MPa (1.7
and 8.1 bar).
Do not store explosive
substances such as aerosol cans
and do not place or use gasoline
or other ammable materials in or
near the appliance.
Do not swallow the contents
(non-toxic) of the ice packs
(provided with some models).
Do not eat ice cubes or ice lollies
immediately after taking them out
of the freezer since they may cause
cold burns.
For products designed to use
an air lter inside an accessible fan
cover, the lter must always be in
position when the refrigerator is in
function.
Do not store glass containers
with liquids in the freezer
compartment since they may break.
Do not obstruct the fan (if included)
with food items. After placing
the food check that the door of

ENGLISH 7
compartments closes properly,
especially the freezer door.
Damaged gaskets must be
replaced as soon as possible.
Use the refrigerator
compartment only for storing fresh
food and the freezer compartment
only for storing frozen food,
freezing fresh food and making ice
cubes.
Avoid storing unwrapped
food in direct contact with internal
surfaces of the refrigerator or
freezer compartments. Appliances
could have special compartments
(Fresh Food Compartment,
Zero Degree Box,...). Unless
differently specied in the specic
booklet of product, they can be
removed, maintaining equivalent
performances.
C-Pentane is used as blowing
agent in the insulation foam
and it is a ammable gas.
The most appropriate
compartments of the appliance
where specic types of food are
to be stored, taking into account
different temperature distribution
in different compartments in the
appliance, are as follows:
- Refrigerator compartment:
1) Upper area of the refrigerator
compartment & door - temperature
zone: Store tropical fruit, cans,
drinks, eggs, sauces, pickles, butter,
jam
2) Middle area of the refrigerator
compartment - cool zone: Store
cheese, milk, dairy food, deli food,
yoghurt
3) Lower area of the refrigerator
compartment - coldest zone: Store
cold cuts, desserts, meat and sh,
cheesecake, fresh pasta, sour
cream, pesto/salsa, home-cooked
food, pastry cream, pudding and
cream cheese
4) Fruit & vegetable drawer at
the bottom of the refrigerator
compartment: Store vegetables and
fruits (excluding tropical fruits)
5) Chiller compartment: Only store
meat and sh in the coldest drawer
- Freezer compartment:
4 star zone (****) compartment
is suitable for freezing foodstuffs
from ambient temperature and
for storing frozen food as the
temperature is evenly distributed
throughout the entire compartment.
Purchased frozen food has the
storage expiration date stated on
the packaging. This date takes
into account the type of food
being stored and therefore this
date should be respected. Fresh
food should be stored for the
following time periods: 1-3 months
for cheese, shellsh, ice cream,
ham/sausage, milk, fresh liquids;
4 months for steak or chops (beef,
lamb, pork); 6 months for butter or
margarine, poultry (chicken, turkey);

ENGLISH 8
8-12 months for fruits (except citrus),
roast meat (beef, pork, lamb),
vegetables. Expiration dates on the
packaging of foods in the 2-star
zone must be respected.
To avoid food contamination,
please observe the following:
– Opening the door for long
periods can cause a signicant
increase of the temperature in the
compartments of the appliance.
– Regularly clean surfaces that may
come into contact with food and
accessible drainage systems.
– Clean water tanks if they have
not been used for 48 h; ush
the water system connected to
a water supply if water has not
been drawn for 5 days.
– Store raw meat and sh in
suitable containers in the
refrigerator, so that it does not
come into contact with or drip
onto other food.
– Two-star frozen food
compartments are suitable for
storing pre-frozen food, storing or
making ice cream and ice cubes.
– Do not freeze fresh food in one,
two or three-star compartments.
– If the refrigerating appliance is
left empty for long periods, switch
off, defrost, clean, dry, and leave
the door open to prevent mould
developing inside the appliance.
INSTALLATION
The appliance must be
handled and installed by two or
more persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
Installation, including
water supply (if any), electrical
connections and repairs must
be carried out by a qualied
technician. Do not repair or replace
any part of the appliance unless
specically stated in the user
manual. Keep children away from
the installation site. After unpacking
the appliance, make sure that it
has not been damaged during
transport. In the event of problems,
contact the dealer or your
nearest Aftersales Service. Once
installed, packaging waste (plastic,
styrofoam parts etc.) must be stored
out of reach of children - risk of
suffocation. The appliance must
be disconnected from the power
supply before any installation
operation - risk of electric shock.
During installation, make sure the
appliance does not damage the
power cable - risk of re or electric
shock. Only activate the appliance
when the installation has been
completed.
Be careful not to damage the
oors (e.g. parquet) when moving
the appliance. Install the appliance
on a oor or support strong enough
to take its weight and in a place
suitable for its size and use. Make
sure the appliance is not near

ENGLISH 9
a heat source and that the four
feet are stable and resting on the
oor, adjusting them as required,
and check that the appliance is
perfectly level using a spirit level.
Wait at least two hours before
switching the appliance on, to
ensure that the refrigerant circuit is
fully efcient.
WARNING: When positioning
the appliance, ensure the supply
cord is not trapped or damaged.
WARNING: To avoid a hazard
due to instability, positioning
or xing of the appliance must
be done in accordance with the
manufacturer instructions. It’s
forbidden to place the refrigerator
in such way that the metal hose
of gas stove, metal gas or water
pipes, or electrical wires are in
contact with the refrigerator back
wall (condenser coil).
To guarantee adequate
ventilation, leave a space on both
sides and above the appliance.
The distance between the rear of
the appliance and the wall behind
the appliance should be 50 mm,
to avoid access to hot surfaces. A
reduction of this space will increase
the Energy consumption of product.
Please remove the power cord from
condenser hook during installation
before connecting product to
power supply.
ELECTRICAL WARNINGS
It must be possible to disconnect
the appliance from the power
supply by unplugging it if plug is
accessible, or by a multi-pole switch
installed upstream of the socket
in accordance with the wiring
rules and the appliance must be
earthed in conformity with national
electrical safety standards.
Do not use extension leads,
multiple sockets or adapters.
The electrical components must
not be accessible to the user
after installation. Do not use the
appliance when you are wet or
barefoot. Do not operate this
appliance if it has a damaged
power cable or plug, if it is not
working properly, or if it has been
damaged or dropped.
If the supply cord is damaged, it
must be replaced with an identical
one by the manufacturer, its service
agent or similarly qualied persons
in order to avoid a hazard - risk of
electric shock.
WARNING: Do not locate
multiple portable socket-outlets or
portable power supplies at the rear
of the appliance.
Feets of the product: in Fs not
available;in built in - the “feet are
not adjustable - and the METOD
cabinet should be levelled with
spirit level.

ENGLISH 10
Product description
Carefully read the operating instructions
before using the appliance.
3
1
4
5
8
7
6
2
Refrigerator compartment
(for storage of fresh food and beverages)
1Glass shelves
2Rating plate (at the side of crisper
drawer)
3Crisper drawer
4Thermostat control knob/light
5Dairy lid / Dairy compartment
6Adjustable door balcony
7Metal wire and bottle divider
8Bottle balcony
Freezer compartment
(marked with the symbol for storing
fresh food, frozen food and making ice
cubes)
9Ice cube tray
10 Low Temperature compartment door
Least cold zone
Intermediate temperature zone
Coldest zone
Features, technical information and
images may vary depending on model
First Use
Connect the appliance to the mains power
supply.
The ideal temperatures for preserving food
have already been set at the factory (3-5/
MED).
Note: After switching the appliance on,
it will be necessary to wait for 2 to 3
hours before a temperature suitable for a
standard appliance load is reached.
Accessories
Egg tray
1x
Ice tray
1x
Ice scraper
1x
9
10

ENGLISH 11
Daily use
Operation of the refrigerator and freezer
compartment
• Use the thermostat knob to adjust
the temperature of the refrigerator
compartment (or both compartments,
depending on the model), as shown in
gure 1. Move the knob to the position
to switch the whole appliance off.
Note: The ambient temperature, frequency
of door opening and position of the
appliance can affect the temperatures
inside the two compartments.
These factors must be taken into
consideration when setting the thermostat.
D
BC
A
AThermostat control knob
BLight button
CThermostat position setting notch
DLED light bulb (see instructions near the
light bulb)
Thermostat on 1/MIN: Low refrigeration
level
Thermostat on 3-5/MED: Medium
refrigeration
Thermostat on 7/MAX: Maximum
refrigeration
Thermostat on : Both refrigeration and
illumination are switched off.
Refrigerator compartment
Refrigerator compartment defrosting is
completely automatic. Droplets of water
on the rear wall inside the refrigerator
compartment indicate that the automatic
defrost phase is in progress. The defrost
water is automatically run into a drain
hole and collected in a container, where it
evaporates.
Caution! The refrigerator accessories
must not be placed in a dishwashe
Movable shelves
The walls of the refrigerator
are equipped with a series
of runners so that the
safety glass shelves can be
positioned as desired.
For better use of space, the
front halfshelves can lie over the rear ones.
Freezer compartment
This appliance is a refrigerator with a
star rating freezer compartment. Packed
frozen foods can be stored for the period
indicated on the packing. Fresh food can
also be frozen, ensuring that any contact
with already frozen food is avoided. The
quantity of fresh food that can be frozen
in a 24 hour period is given on the rating
plate. Re-freezing of partially defrosted
food is not recommended. This food should
be consumed within 24 hours. For further
information on freezing fresh food, refer to
the quick guide.
Important!
This appliance is sold in France. In
accordance with regulations valid in this
country it must be provided with a special
device (see gure) placed in the lower
compartment of the fridge to indicate the
coldest zone of it.

ENGLISH 12
Helpful hints and tips
Hints for energy saving
• Do not open the door frequently or leave
it open longer than absolutely necessary.
• If the ambient temperature is high, the
temperature regulator is on the higher
setting and the appliance is fully loaded,
the compressor may run continuously,
causing frost or ice on the evaporator.
If this happens, turn the temperature
regulator toward lower settings to allow
automatic defrosting and so a saving in
electricity consumption.
Hints for fresh food refrigeration
To obtain the best performance:
• Do not store warm food or evaporating
liquids in the refrigerator.
• Do cover or wrap the food, particularly if
it has a strong avour.
• Position food so that air can circulate
freely around it.
Hints for refrigeration
• Meat (all types) : wrap in polythene bags
and place on the glass shelf above the
vegetable drawer.
For safety, store in this way only one or
two days at the most.
• Cooked foods, cold dishes, etc.: these
should be covered and may be placed
on any shelf.
• Fruit and vegetables: these should be
thoroughly cleaned and placed in the
drawer.
• Butter and cheese: these should be
placed in special airtight containers or
wrapped in aluminium foil or polythene
bags to exclude as much air as possible.
• Milk bottles: these should have a cap
and should be stored in the bottle rack
on the door.
• Bananas, potatoes, onions and garlic:
if not packed, must not be kept in the
refrigerator.
Hints for freezing
To help you make the most of the freezing
process, here are some hints:
• The maximum quantity of food which can
be frozen in 24 hours is shown on the
rating plate.
• The freezing process takes 24 hours.
No further food to be frozen should be
added during this period.
• Freeze only top quality, fresh and
thoroughly cleaned foodstuffs.
• Prepare food in small portions to enable
it to be rapidly and completely frozen
and to make it possible subsequently to
thaw only the quantity required.
• Wrap up the food in aluminium foil
or polythene and make sure that the
packages are airtight.
• Do not allow fresh, unfrozen food to
touch food which is already frozen, thus
avoiding a rise in temperature of the
latter.
Freezing fresh food
Place the fresh food to be frozen inside the
freezer compartment. Avoid direct contact
with already frozen food. To freeze the
quantity of food shown on the serial tag,
remove the top drawer and place the food
directly on the rack.
Making ice cubes
Fill the ice cube tray up to 2/3 with water
and place in the freezer compartment. Do
not use sharp or pointed objects to detach
the tray.

ENGLISH 13
• Lean foods store better and longer than
fatty ones; salt reduces the storage life of
food.
• Water ices, if consumed immediately
after removal from the freezer
compartment, can possibly cause the skin
to be freeze burnt.
• It is advisable to show the freezing in
date on each individual pack to enable
you to keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this
appliance, you should:
• Make sure that the commercially frozen
foodstuffs were adequately stored by the
retailer.
• Make sure that frozen foodstuffs are
transferred from the foodstore to the
freezer in the shortest possible time.
• Do not open the door frequently or leave
it open longer than absolutely necessary.
• Once defrosted, food deteriorates
rapidly and cannot be refrozen.
• Do not exceed the storage period
indicated by the food manufacturer.

ENGLISH 14
Cleaning and maintenance
Regularly clean the appliance with a cloth
and a solution of hot water and neutral
detergent specically formulated for
refrigerator interiors. Do not use abrasive
cleaners or tools. Use the tool provided
to regularly clean the defrost water drain
outlet, located on the rear wall of the
refrigerator compartment near the crisper
draw, in order to ensure defrost water is
removed correctly (see Fig. 1).
Before servicing or cleaning the appliance,
unplug it from the mains or disconnect the
power supply.
Fig. 1
Defrosting the freezer compartment
It is perfectly normal for ice to form. The
amount of ice which forms and the rate
at which it accumulates will depend on
ambient temperature and humidity, and on
the frequency of door opening.
Set the coldest temperature four hours
before removing food from the freezer
compartment, so as to extend the storage
time of food during defrosting.
To defrost, switch the appliance off and
remove the drawers. Place the frozen food
in a cool place.
Leave the freezer door open to allow the
frost to melt.
To prevent water leaking onto the oor
during defrosting, place an absorbent cloth
on the bottom of the freezer compartment
and wring it out regularly.
Clean the interior of the freezer. Rinse and
dry carefully.
Switch the appliance on again and place
food back in the freezer compartment.
Food storage
Wrap food to protect it from any water,
humidity or condensation; this will prevent
the spread of any odours in the refrigerator,
while also ensuring better storage of frozen
food.
Never place warm food in the freezer.
Cooling hot foods before freezing saves
energy and prolongs the life of the
appliance.
If the event of prolonged disuse
Disconnect the appliance from the power
supply, remove all food, defrost and clean
the appliance. Leave the doors open just
enough to allow air to circulate inside the
compartments.
This will prevent the formation of mould and
unpleasant odours.
In the event of a power cut
Keep the doors of the appliance closed.
This will allow the food to stay cold as long
as possible. If food has defrosted even
partially, do not re-freeze it. Consume within
24 hours.

ENGLISH 15
Problem Possible causes: Solutions:
The appliance does not
operate
There might be a problem
with the electric power
supply to the appliance.
Check that:
• there isn’t a power supply failure
• the power plug is correctly inserted in
the power socket and the two-pole
switch, if present, is in the correct
position (on)
• the electric circuit safety devices
installed in the house are fully functional
• the power supply cable is not broken
The inside LED light bulb
does not work.
The LED light bulb might
need replacing.
Disconnect the appliance from the
electric power supply, check the LED
light bulb and replace with a new one if
necessary (see “Daily use”).
The temperature inside
the compartments is not
cold enough.
There may be several
causes (see “Solutions”)
Check that:
• The doors are closed correctly
• The appliance is not placed near a heat
source.
• the temperature set is appropriate.
• Air circulation through the ventilation
grills at the bottom of the appliance is
not obstructed.
There is water at the
bottom of the refrigerator
compartment
The defrost water drain is
obstructed.
Clean the defrost water drain hole (see
“Cleaning and maintenance”).
The inside light ashes “Door open” alarm active.
It is activated when the
refrigerator compartment
door remains open for a
prolonged period of time.
To stop the alarm, close the refrigerator
door.
On reopening the door, check the light
works
What to do if...
Note:
Gurgling, hissing and humming noises from the refrigerating system are normal.
Remove the LED light bulb
To remove the LED light bulb turn
anticlockwise as shown in gure.

ENGLISH 16
Technical data
Dimensions HUTTRA
Height (min-max) 819-899
Width 597
Depth 545
Net Volume (l)
Refrigerator 108
Freezer 18
Defrost system
Refrigerator Automatic
Freezer Manual
Star Rating 4
Rising Time (h) 10
Freezing capacity (kg/24 h) 2
Energy consumption (kwh/24h) 0.395
Noise level (dba) 38
Energy class A++
The technical information is situated
in the rating plate on the internal
side of the appliance and in the
energy label
Before contacting the After-Sales Service:
Switch the appliance on again to see if the
problem has disappeared. If not, switch it
off again and repeat the operation after an
hour.
If your appliance still does not work
properly after carrying out the checks listed
in the troubleshooting guide and switching
the appliance on again, contact the After-
sales service, clearly explaining the problem
and specifying:
• the type of fault;
• the model;
• the type and serial number of the
appliance (given on the rating plate);
• the Service number (the number
after the word SERVICE on the
rating plate inside the appliance).

ENGLISH 17
Environmental concerns
1. Packing
The packing material is 100% recyclable
and bears the recycling symbol . For
disposal, comply with the local regulations.
Keep the packing materials (plastic bags,
polystyrene parts, etc.) out of the reach of
children, as they are a potential source of
danger.
2. Scrapping/Disposal
The appliance is manufactured using
recyclable material.
This appliance is marked in compliance with
European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring the correct disposal of this
appliance, you can help prevent potentially
negative consequences for the environment
and the health of persons.
The symbol on the appliance, or on
the accompanying documents, indicates
that this appliance should not be treated
as domestic waste but must be taken to a
special collection centre for the recycling of
electrical and electronic equipment.
When scrapping the appliance, make it
unusable by cutting off the power cable
and removing the doors and shelves so
that children cannot easily climb inside and
become trapped.
Scrap the appliance in compliance with
local regulations on waste disposal, taking it
to a special collection centre;
do not leave the appliance unattended
even for a few days, since it is a potential
source of danger for children.
For further information on the treatment,
recovery and recycling of this product,
contact your competent local ofce, the
household waste collection service or the
shop where you purchased the appliance.
Declaration of conformity
• This appliance has been designed for
preserving food and is manufactured
in compliance with Regulation (CE) No.
1935/2004.
• n
• This appliance has been designed,
manufactured and marketed in
compliance with:
- safety objectives of the “Low Voltage”
Directive 2014/35/EU (which replaces
2006/95/CE and subsequent
amendments);
- the protection requirements of Directive
“EMC” 2014/30/EU.

ENGLISH 18
IKEA GUARANTEE
How long is the IKEA guarantee valid?
This guarantee is valid for ve years from
the original date of purchase of your
appliance at IKEA. The original sales receipt,
is required as proof of purchase. If service
work is carried out under guarantee, this
will not extend the guarantee period for the
appliance.
Who will execute the service?
IKEA service provider will provide the
service through its own service operations or
authorized service partner network.
What does this guarantee cover?
The guarantee covers faults of the
appliance, which have been caused by
faulty construction or material faults from the
date of purchase from IKEA. This guarantee
applies to domestic use only. The exceptions
are specied under the headline “What is
not covered under this guarantee?” Within
the guarantee period, the costs to remedy
the fault e.g. repairs, parts, labour and travel
will be covered, provided that the appliance
is accessible for repair without special
expenditure. On these conditions the EU
guidelines (Nr. 99/44/EG) and the respective
local regulations are applicable. Replaced
parts become the property of IKEA.
What will IKEA do to correct the problem?
IKEA appointed Service Provider will
examine the product and decide, at its
sole discretion, if it is covered under this
guarantee. If considered covered, IKEA
Service Provider or its authorized service
partner through its own service operations,
will then, at its sole discretion, either repair
the defective product or replace it with the
same or a comparable product.
What is not covered under this guarantee?
• Normal wear and tear.
• Deliberate or negligent damage,
damage caused by failure to observe
operating instructions, incorrect
installation or by connection to the wrong
voltage, damage caused by chemical or
electrochemical reaction, rust, corrosion
or water damage including but not
limited to damage caused by excessive
lime in the water supply, damage caused
by abnormal environmental conditions.
• Consumable parts including batteries
and lamps.
• Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible color differences.
• Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of lters, drainage systems or
soap drawers.
• Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
• Cases where no fault could be found
during a technician’s visit.
• Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where non-
original parts have been used.
• Repairs caused by installation which is
faulty or not according to specication.
• The use of the appliance in a non-
domestic environment i.e. professional
use.
• Transportation damages. If a customer
transports the product to his home or
another address, IKEA is not liable for
any damage that may occur during
transport. However, if IKEA delivers
the product to the customer’s delivery
address, then damage to the product
that occurs during this delivery will be
covered by IKEA.
• Cost for carrying out the initial installation
of the IKEA appliance.
• However, if an IKEA appointed Service
Provider or its authorized service partner
repairs or replaces the appliance

ENGLISH 19
under the terms of this guarantee,
the appointed Service Provider or its
authorized service partner will reinstall
the repaired appliance or install the
replacement, if necessary.
• This does not apply within Ireland,
customer should contact the local
IKEA dedicated after sales line or the
appointed Service Provider for further
information.
(just for GB)
These restrictions do not apply to fault-free
work carried out by a qualied specialist
using our original parts in order to adapt
the appliance to the technical safety
specications of another EU country.
How country law applies
The IKEA guarantee gives you specic legal
rights, which cover or exceed all the local
legal demands. However these conditions
do not limit in any way consumer rights
described in the local legislation.
Area of validity
For appliances which are purchased in
one EU country and taken to another EU
country, the services will be provided in
the framework of the guarantee conditions
normal in the new country.
An obligation to carry out services in the
framework of the guarantee exists only if
the appliance complies and is installed in
accordance with:
- the technical specications of the country
in which the guarantee claim is made;
- the Assembly Instructions and User
Manual Safety Information.
The dedicated AFTER SALES for IKEA
appliances
Please don’t hesitate to contact IKEA
appointed Authorized Service Centre to:
• make a service request under this
guarantee;
• ask for clarications on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture;
• ask for clarication on functions of IKEA
appliances.
To ensure that we provide you with the
best assistance, please read carefully the
Assembly Instructions and/or the User
Manual before contacting us.
How to reach us if you need our service
Please refer to the last page
of this manual for the full list
of IKEA appointed Authorized
Service Centre and relative
national phone numbers.
In order to provide you a quicker
service, we recommend to use the
specic phone numbers listed on this
manual. Always refer to the numbers
listed in the booklet of the specic
appliance you need an assistance for.
Please also always refer to the IKEA
article number (8 digit code) and 12
digit service number placed on the
rating plate of your appliance.
SAVE THE SALES RECEIPT!
It is your proof of purchase and
required for the guarantee to apply.
The sales receipt also reports the IKEA
name and article number (8 digit code)
for each of the appliances you have
purchased.
Do you need extra help?
For any additional questions not related
to After Sales of your appliances please
contact your nearest IKEA store call centre.
We recommend you read the appliance
documentation carefully before contacting us.

20
Diese Sicherheitsanweisungen vor
dem Gebrauch durchlesen. Diese
Anweisungen zum Nachschlagen
leicht zugänglich aufbewahren.
In diesen Anweisungen sowie auf
dem Gerät selbst werden wichtige
Sicherheitshinweise angegeben,
die durchgelesen und stets
beachtet werden müssen. Der
Hersteller übernimmt keine Haftung
für die Nichtbeachtung dieser
Sicherheitshinweise, für unsachgemäße
Verwendung des Geräts oder falsche
Bedienungseinstellung.
SICHERHEITSHINWEISE
Babys und Kleinkinder (0-3
Jahre) müssen vom Gerät fern
gehalten werden. Jüngere Kinder
(3-8 Jahre) müssen vom Gerät fern
gehalten werden, es sei denn, sie
werden ständig beaufsichtigt. Dieses
Gerät darf von Kindern ab 8 Jahren
sowie Personen mit herabgesetzten
physischen, sensorischen oder geistigen
Fähigkeiten und Mangel an Erfahrung
und Kenntnissen nur unter Aufsicht oder
nach ausreichender Einweisung durch
eine für ihre Sicherheit verantwortliche
Person verwendet werden. Kinder
dürfen nicht mit dem Gerät spielen.
Die Reinigung und Pege des Geräts
darf von Kindern nicht ohne Aufsicht
durchgeführt werden. Kindern im
Alter von 3 bis 8 Jahren ist es erlaubt,
Lebensmittel in Kühlgeräte ein- und
daraus auszuräumen.
ZULÄSSIGE NUTZUNG
VORSICHT: Das Gerät ist nicht
für den Betrieb mit einer externen
Schaltvorrichtung, z. B. einem Timer
oder einer separaten Fernbedienung,
ausgelegt.
Dieses Gerät ist für
Haushaltsanwendungen und
ähnliche Anwendungen konzipiert,
zum Beispiel: Mitarbeiterküchen
im Einzelhandel, in Büros oder in
anderen Arbeitsbereichen; Gutshäuser;
von Kunden in Hotels, Motels,
Frühstückspensionen und anderen
Wohneinrichtungen.
Dieses Gerät ist nicht für den
professionellen Gebrauch ausgelegt.
Das Gerät ist nicht für die Benutzung im
Freien geeignet.
Die im Gerät verwendete Lampe
ist speziell für Elektrogeräte konzipiert
und ist nicht für die Beleuchtung von
Räumen geeignet (EUVerordnung
244/2009).
Das Gerät ist für den Einsatz
in Räumen mit nachstehenden
Umgebungstemperaturbereichen
ausgelegt, die ihrerseits von der
Klimaklasse auf dem Typenschild
Sicherheitsinformationen
Inhaltsverzeichnis
DE
DEUTSCH
Sicherheitsinformationen 20
Beschreibung des Geräts 25
Inbetriebnahme 25
Täglicher Gebrauch 26
Nützliche Tipps und Tricks 27
Reinigung und Pege 29
Was tun, wenn... 30
Technische Daten 31
Umweltschutz 32
IKEA GARANTIE 33
