IKEA W10270272 User manual

THANK YOU for purchasing this high-quality product. If you should experience a problem not covered in TROUBLESHOOTING,
please visit www.whirlpool.com for additional information. If you still need assistance, call us at 1-866-664-2449.
You will need your model and serial number, located on the inside wall of the refrigerator compartment.
REFRIGERATOR SAFETY
Table of Contents / Índice / Table des matières
REFRIGERATOR SAFETY ...............................1
INSTALLATION INSTRUCTIONS....................2
REFRIGERATOR USE......................................8
REFRIGERATOR CARE ...................................9
TROUBLESHOOTING ....................................10
WARRANTY ....................................................12
SEGURIDAD DEL REFRIGERADOR.............13
INSTRUCCIONES DE INSTALACIÓN...........14
USO DE SU REFRIGERADOR.......................20
CUIDADO DE SU REFRIGERADOR .............22
SOLUCIÓN DE PROBLEMAS .......................23
GARANTÍA ......................................................25
SÉCURITÉ DU RÉFRIGÉRATEUR................27
INSTRUCTIONS D’INSTALLATION ..............28
UTILISATION DU RÉFRIGÉRATEUR............34
ENTRETIEN DU RÉFRIGÉRATEUR..............36
DÉPANNAGE ..................................................37
GARANTIE ......................................................39
REFRIGERATOR USER INSTRUCTIONS
W10270272
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING

2
Proper Disposal of Your Old Refrigerator
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous
– even if they will sit for “just a few days.” If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not easily
climb inside.
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety.”
■Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside of
your refrigerator before using it. See the cleaning instructions in
“Refrigerator Care.”
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electric shock, or injury to persons when using the refrigerator, follow basic precautions,
including the following:
WARNING:
SAVE THESE INSTRUCTIONS
■ Plug into a grounded 3 prong outlet.
■ Do not remove ground prong.
■ Do not use an adapter.
■ Do not use an extension cord.
■ Disconnect power before servicing.
■ Replace all parts and panels before operating.
■ Remove doors from your old refrigerator.
■ Use nonflammable cleaner.
■ Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■ Use two or more people to move and install refrigerator.
■ Disconnect power before installing ice maker (on ice maker
kit ready models only).
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
When MovingYour Refrigerator:
Your refrigerator is heavy. When moving the refrigerator for
cleaning or service, be sure to cover the floor with
cardboard or hardboard to avoid floor damage. Always pull
the refrigerator straight out when moving it. Do not wiggle or
“walk” the refrigerator when trying to move it, as floor
damage could occur.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.

3
Location Requirements
To ensure proper ventilation for your refrigerator, allow for a ¹⁄₂"
(1.25 cm) space at the top and behind the refrigerator. If your
refrigerator has an ice maker, allow extra space at the back for the
water line connections. When installing your refrigerator next to a
fixed wall, leave 2¹⁄₂" (6.3 cm) minimum on the hinge side (some
models require more) to allow for the door to swing open.
NOTE: It is recommended that you do not install the refrigerator
near an oven, radiator, or other heat source. Do not install the
refrigerator in a location where the temperature will fall below 55°F
(13°C).
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an extension
cord.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, turn the refrigerator to OFF. Depending on
your model, turn the freezer control to the word OFF, or press the
Freezer down arrow touch pad until a dash (–) appears in both the
Freezer and Refrigerator displays as shown. Disconnect the
refrigerator from the electrical source. When you are finished,
reconnect the refrigerator to the electrical source and reset the
temperature controls to the desired setting. See “Using the
Controls.”
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
2¹⁄₂" (6.3 cm)
¹⁄₂" (1.25 cm)
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

4
Water Supply Requirements
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
TOOLS NEEDED:
IMPORTANT:
■All installations must meet local plumbing code requirements.
■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve
which reduces water flow and clogs more easily.
■Use copper tubing and check for leaks. Install copper tubing
only in areas where the household temperatures will remain
above freezing.
■For models with water filters, the disposable water filter
should be replaced at least every 6 months.
Water Pressure
A cold water supply with water pressure of between 35 and
120 psi (241 and 827 kPa) is required to operate the water
dispenser and ice maker. If you have questions about your water
pressure, call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 35 and 120 psi (241 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See “Water Filtration
System.”
If you have questions about your water pressure, call a licensed,
qualified plumber.
Connect the Water Supply
Read all directions before you begin.
IMPORTANT: If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
Connect to Water Line
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Find a ¹⁄₂" to 1¹⁄₄" (12.7 mm to 31.8 mm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but the following procedure
must be followed: Drill on the top side of the pipe, not the
bottom. This will help keep water away from the drill. This
also keeps normal sediment from collecting in the valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the rear of the refrigerator to the water
pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄" (6.35 mm)
O.D. (outside diameter) copper tubing. Be sure both ends of
copper tubing are cut square.
5. Using a cordless drill, drill a ¹⁄₄" hole in the cold water pipe you
have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" drilled hole in
the water pipe and that the washer is under the pipe clamp.
Tighten the packing nut. Tighten the pipe clamp screws slowly
and evenly so the washer makes a watertight seal. Do not
overtighten.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten or
you may crush the copper tubing.
8. Place the free end of the tubing in a container or sink, and turn
ON the main water supply. Flush the tubing until water is clear.
Turn OFF the shutoff valve on the water pipe.
■Flat-blade screwdriver
■⁷⁄₁₆" and ¹⁄₂" Open-end or two
adjustable wrenches
■¹⁄₄" Nut driver
■¹⁄₄" Drill bit
■Cordless drill
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
F
G
A
B
C
D
E

5
Connect to Refrigerator
Depending on your model, the water line may come down from
the top or up from the bottom. Follow the connection instructions
for your model.
Style 1
1. Remove plastic cap from water valve inlet port. Attach the
copper tube to the valve inlet using a compression nut and
sleeve as shown. Tighten the compression nut. Do not
overtighten. Confirm copper tubing is secure by pulling on
copper tubing.
2. Create a service loop with the copper tubing. Avoid kinks
when coiling the copper tubing. Secure copper tubing to
refrigerator cabinet with a “P” clamp.
3. Turn on water supply to refrigerator and check for leaks.
Correct any leaks.
Style 2
1. Create a service loop (minimum diameter of 2 ft [61 cm]) with
the copper tubing. Avoid kinks when coiling the copper
tubing.
2. Remove the plastic cap from water valve inlet port. Place a
compression nut and sleeve on the copper tubing.
3. Insert the end of the copper tubing into the water valve inlet
port. Shape tubing slightly so that the tubing feeds straight
into the port to avoid kinks.
4. Slide the compression nut over the sleeve and screw into the
water valve inlet port.
5. Using an adjustable wrench, hold the nut on the plastic water
line to keep it from moving. Then, with a second wrench turn
the compression nut on the copper tubing counterclockwise
to completely tighten. Do not overtighten.
6. Check connection by pulling on copper tubing. Attach copper
tubing to refrigerator cabinet with a “P” clamp. Turn on water
supply to refrigerator and check for leaks. Correct any leaks.
Complete the Installation
1. Plug into a grounded 3 prong outlet.
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to completely
fill the ice container.
Refrigerator Door(s) and Drawer
TOOLS NEEDED: ⁵⁄₁₆", ³⁄₈", ¹⁄₄" hex-head socket wrench, a
#2 Phillips screwdriver, and a flat-blade screwdriver.
IMPORTANT:
■All graphics referenced in the following instructions are
included later in this section after “Final Steps.”
■If you only want to remove and replace the doors, see
“Remove Door(s) and Hinges” and “Replace Door(s) and
Hinges.”
■Before you begin, turn the refrigerator control OFF, and
remove food and adjustable door or utility bins from the doors.
A. Copper tubing
B. “P” clamp
C. Compression nut
D. Compression sleeve
E. Water valve inlet port
A. Plastic water tubing
B. Sleeve
C. Compression nut
D. Copper tubing
A
B
C
D
E
B
A
C
D
A. Plastic water line
B. Water valve inlet port
C. Compression nut
D. Copper tubing
E. “P” clamp
B
A
C
D
E
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

6
Remove and Replace Refrigerator Door Handles
■Using a ³⁄₃₂" Allen wrench, loosen the two setscrews located
on the side of each handle. Pull the handle straight out from
the door. Make sure you keep the screws for reattaching the
handles. See Metal Handle graphic 1.
■To replace the handles, reverse the directions.
Remove Doors and Hinges
1. Unplug refrigerator or disconnect power.
2. Keep the refrigerator doors closed until you are ready to lift
them free from the cabinet.
NOTE: Provide additional support for the refrigerator door
while the hinges are being removed. Do not depend on the
door gasket magnets to hold the door in place while you are
working.
3. Starting with the right-hand side door, remove the parts for the
top hinge as shown in Top Hinge graphic. Lift the refrigerator
door from the bottom hinge pin.
4. Remove the hinge pin cover from the bottom hinge pin and
keep it for later use. See Bottom Hinge graphic.
5. Before removing the left-hand side door, disconnect the wiring
plug located on top of the top hinge by wedging a flat-blade
screwdriver or your fingernail between the two sections. See
Wiring Plug graphic.
NOTE: The green, ground wire remains attached to the hinge.
6. Remove the parts for the left-hand side door top hinge as
shown in the Top Hinge graphic. Lift the door from the bottom
hinge pin.
NOTE: Remove the hinge pin cover from the bottom hinge pin
and keep it for later use. See Bottom Hinge graphic.
Replace Doors and Hinges
1. Assemble the parts for the top hinges as shown in Top Hinge
graphic. Do not tighten the screws completely.
2. Replace the parts for the bottom hinges as shown in Bottom
Hinge graphic. Tighten screws. Replace the refrigerator doors.
NOTE: Provide additional support for the refrigerator doors
while the hinges are being moved. Do not depend on the door
gasket magnets to hold the doors in place while you are
working.
3. Align each door so that the bottom of the refrigerator door
aligns evenly with the top of the freezer drawer. Tighten all
screws.
4. Reconnect the wiring plug on top of the left-hand side
refrigerator door.
5. Replace the top hinge covers.
Remove and Replace Freezer Drawer
IMPORTANT:
■Two people may be required to remove and replace the freezer
drawer.
■All graphics are included later in this section after “Final
Steps.”
Remove and Replace Drawer Handle
■Using a ³⁄₃₂" Allen wrench, loosen the two setscrews located
on the side of each handle. Pull the handle straight out from
the drawer. Make sure you keep the screws for reattaching the
handles. See Metal Handle graphic 2.
■To replace the handle, reverse the directions.
Remove Drawer Front
1. Open the freezer drawer to full extension.
2. Loosen the four screws attaching the drawer glides to the
drawer front. See Drawer Front Removal graphic.
NOTE: Loosen screws three to four turns. Keep the screws in
the drawer front.
3. Lift drawer front upward and off the screws. See Drawer Front
Removal graphic.
Replace Drawer Front
1. Slide the drawer glides out of the freezer compartment. Insert
the screws in the top of the drawer front into the slots in the
drawer brackets. See Drawer Front Replacement graphic.
2. Pull the drawer brackets toward you to insert the two screws
in the bottom of the drawer front into the brackets. See
Drawer Front Replacement graphic.
3. Completely tighten the four screws.
Final Steps
1. Check all holes to make sure that hole plugs and screws are in
place. Reinstall top hinge cover as shown in Top Hinge
graphic.
2. Plug into a grounded 3 prong outlet.
3. Return all removable door parts to door and food to
refrigerator.
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

7
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
Door Removal & Replacement
A.
3
/ 32 " Setscrew
A.
3
/ 32 " Setscrew
A
A
Metal Handle
Metal Handle
1
2
Top Hinges
A. Hinge Cover Screw
B. Top Hinge Cover
C.
5
/ 16 " Hex Head Hinge Screws
D. Top Hinge
B
A
C
D
A. Hinge Pin Cover
C. Hinge Screws
B. Bottom Hinge
Bottom Hinges
Wiring Plug
A
B
C
Drawer Front Removal
A. Loosen 4 Door Bracket Screws
A
Drawer Front Replacement

8
Adjust the Doors
Your refrigerator has two adjustable rollers located at the base of
the refrigerator. If your refrigerator seems unsteady or you want
the door to close more easily, use the instructions below.
1. Remove the base grille. Grasp the grille firmly and pull it
toward you.
2. Using a ³⁄₈" hex driver, turn the roller adjustment screw on
each side to raise or lower that side of the refrigerator.
NOTE: Having someone push against the top of the
refrigerator takes some weight off the adjustment screws and
rollers. This makes it easier to turn the screws. It may take
several turns of the roller adjustment screw to adjust the tilt of
the refrigerator.
■To raise, turn the roller adjustment screw to the right.
■To lower, turn the roller adjustment screw to the left.
Turn the brake foot clockwise until it is firmly against the floor
to keep the refrigerator from rolling forward when the freezer
drawer is pulled open.
3. Open the door again to make sure that it closes as easily as
you like. If not, tilt the refrigerator slightly more to the rear by
turning both leveling screws clockwise. It may take several
more turns, and you should turn both screws the same
amount.
4. Replace the base grille.
REFRIGERATOR USE
Opening and Closing Doors
(French door models)
There are two refrigerator compartment doors. The doors can be
opened and closed either separately or together.
There is a vertically-hinged seal on the left refrigerator door.
■When the left side door is opened, the hinged seal
automatically folds inward so that it is out of the way.
■When both doors are closed, the hinged seal automatically
forms a seal between the two doors.
Using the Controls
The temperature controls are located at the top front of the
refrigerator compartments.
Temperature Controls
For your convenience, the temperature controls are preset at the
factory. When you first install your refrigerator, make sure the
controls are still set to the recommended setting as shown.
Recommended Setting “4”
IMPORTANT:
■The recommended setting should be correct for normal
household refrigerator use. The controls are set correctly
when milk or juice is as cold as you like and when ice cream is
firm.
■Wait 24 hours for your refrigerator to cool completely before
adding food. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer temperature
controls to a colder than recommended setting will not cool
the compartments any faster.
■If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
To Turn Off/On:
Press the freezer down arrow touch pad until a dash (-) appears in
both the refrigerator and freezer displays. Neither compartment
will cool.
Humidity Control (on some models)
The humidity control turns on a heater to help reduce moisture on
the door hinge seal. Use in humid environments or when you
notice moisture on the door hinge seal. The refrigerator uses more
energy when Humidity Control is on.
■Press the control to ON when the environment is warm and
more humid, or if you notice moisture on the door hinge seal.
■Press the control to OFF to save energy when the environment
is less humid.
A. Front roller adjustment screw
B. Brake foot
A
B
A. Hinged seal
A

9
Adjusting Controls
If you need to adjust the temperature in either the refrigerator or
freezer compartment, use the settings listed in the chart below as
a guide.
For controls press the up or down arrow touch pads. Except when
starting the refrigerator, do not adjust either control more than one
setting at a time. Wait 24 hours between adjustments for the
temperature to stabilize.
Crisper Humidity Control
You can control the amount of humidity in the moisture-sealed
crisper. Depending on your model, adjust the control to any
setting between FRUIT and VEGETABLES or LOW and HIGH.
FRUIT / LOW (open) for best storage of fruits and vegetables with
skins.
VEGETABLES / HIGH (closed) for best storage of fresh, leafy
vegetables.
Ice Maker
(on some models)
Turning the Ice Maker On/Off
To turn the ice maker ON, simply lower the wire shutoff arm.
To manually turn the ice maker OFF, lift the wire shutoff arm to the
OFF (arm up) position and listen for the click.
NOTE: Your ice maker has an automatic shutoff. As ice is made,
the ice cubes will fill the ice storage bin and the ice cubes will
raise the wire shutoff arm to the OFF (arm up) position. Do not
force the wire shutoff arm up or down.
Ice Production Rate
■The ice maker should produce a complete batch of ice
approximately every 3 hours.
■To increase ice production, lower the freezer and refrigerator
temperature. See “Using the Controls.” Wait 24 hours
between adjustments.
Remember
■Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
■The quality of your ice will be only as good as the quality of the
water supplied to your ice maker. Avoid connecting the ice
maker to a softened water supply. Water softener chemicals
(such as salt) can damage parts of the ice maker and lead to
poor quality ice. If a softened water supply cannot be avoided,
make sure the water softener is operating properly and is well
maintained.
■Do not store anything on top of the ice maker or in the ice
storage bin.
REFRIGERATOR CARE
Cleaning
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to avoid
buildup of odors. Wipe up spills immediately.
IMPORTANT:
■Because air circulates between both sections, any odors
formed in one section will transfer to the other. You must
thoroughly clean both sections to eliminate odors. To avoid
odor transfer and drying out of food, wrap or cover foods
tightly.
■For stainless steel models, stainless steel is corrosion-
resistant and not corrosion-proof. To help avoid corrosion of
your stainless steel, keep your surfaces clean by using the
following cleaning instructions.
To Clean Your Refrigerator:
NOTE: Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, muriatic acid,
cleaning waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on exterior surfaces (doors and
cabinet), plastic parts, interior and door liners or gaskets. Do not
use paper towels, scouring pads, or other harsh cleaning tools.
1. Unplug refrigerator or disconnect power.
2. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
3. Clean the exterior surfaces.
Painted metal: Wash painted metal exteriors with a clean,
soft cloth or sponge and a mild detergent in warm water.
Rinse surfaces with clean, warm water and dry immediately to
avoid water spots.
Stainless steel: Wash stainless steel surfaces with a clean,
soft cloth or sponge and a mild detergent in warm water.
Rinse surfaces with clean, warm water and dry immediately to
avoid water spots.
NOTE: When cleaning stainless steel, always wipe with the
grain to avoid cross-grain scratching.
4. There is no need for routine condenser cleaning in normal
home operating environments. If the environment is
particularly greasy or dusty, or there is significant pet traffic in
the home, the condenser should be cleaned every 2 to
3 months to ensure maximum efficiency.
CONDITION/REASON: ADJUSTMENT:
REFRIGERATOR too warm REFRIGERATORControl
one setting higher
FREEZER too warm/too little ice FREEZER Control one
setting higher
REFRIGERATOR too cold REFRIGERATORControl
one setting lower
FREEZER too cold FREEZER Control one
setting lower
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

10
If you need to clean the condenser:
■Remove the base grille.
■Use a vacuum cleaner with a soft brush to clean the grille,
the open areas behind the grille and the front surface area
of the condenser.
■Replace the base grille when finished.
5. Plug in refrigerator or reconnect power.
Changing the Light Bulb
NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to
replace the bulb with an appliance bulb of the same size, shape,
and wattage (no greater than 40 watts).
1. Unplug the refrigerator or disconnect power.
2. Remove the light shield, if necessary.
Freezer drawer models
■Top of the refrigerator compartment - Slide the light shield
toward the back of the compartment to release it from the
light assembly.
■Top of freezer compartment - The light shield opens from
the back. Firmly press forward on the notches in the back
of the shield and pull the shield down.
NOTE: You may need to remove the upper freezer shelf or
basket to access the light assembly.
Freezer door models
■Top of the refrigerator compartment - Slide the shield
toward the back to release it from the light assembly.
■Top of freezer compartment - Squeeze and pull rear of
light shield toward you to release the tabs, then pull down.
3. Replace the burned-out bulb(s) with an appliance bulb(s) no
greater than 40 watts.
4. Replace the light shield.
Freezer drawer models
■Top of the refrigerator compartment - Insert the tabs on
the shield into the liner holes on each side of light
assembly. Slide the shield toward the front until it locks
into place.
NOTE: To avoid damaging the light shield, do not force
the shield beyond the locking point.
■Top of the freezer compartment - Insert the front tabs of
the shield into the liner and snap the back portion of the
shield over the light assembly.
Freezer door models
■Top of the refrigerator compartment - Insert the tabs on
the shield into the liner holes on each side of the light
assembly. Slide the shield toward the front until it locks.
NOTE: To avoid damaging the light shield, do not force
the shield beyond the locking point.
■Top of freezer compartment - Insert front tabs of light
shield into liner and snap the back of the shield over light
assembly.
5. Plug in refrigerator or reconnect power.
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Refrigerator Operation
The refrigerator will not operate
■Power cord unplugged? Plug into a grounded 3 prong outlet.
■Is outlet working? Plug in a lamp to see if the outlet is
working.
■Household fuse blown or circuit breaker tripped? Replace
the fuse or reset the circuit breaker. If the problem continues,
call an electrician.
■Are controls on? Make sure the refrigerator controls are on.
See “Using the Control(s).”
■New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
NOTE: Adjusting the temperature controls to coldest setting
will not cool either compartment more quickly.
The motor seems to run too much
Your new refrigerator may run longer than your old one due to its
high-efficiency compressor and fans. The unit may run even
longer if the room is warm, a large food load is added, doors are
opened often, or if the doors have been left open.
The refrigerator seems noisy
Refrigerator noise has been reduced over the years. Due to this
reduction, you may hear intermittent noises from your new
refrigerator that you did not notice from your old model. Below are
listed some normal sounds with explanations.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

11
■Buzzing - heard when the water valve opens to fill the ice
maker
■Pulsating - fans/compressor adjusting to optimize
performance
■Hissing/Rattling - flow of refrigerant, movement of water
lines, or from items placed on top of the refrigerator
■Sizzling/Gurgling - water dripping on the heater during
defrost cycle
■Popping - contraction/expansion of inside walls, especially
during initial cool-down
■Water running - may be heard when ice melts during the
defrost cycle and water runs into the drain pan
■Creaking/Cracking - occurs as ice is being ejected from the
ice maker mold.
The doors will not close completely
■Door blocked open? Move food packages away from door.
■Bin or shelf in the way? Push bin or shelf back in the correct
position.
The doors are difficult to open
■Gaskets dirty or sticky? Clean gaskets and contact surfaces
with mild soap and warm water. Rinse and dry with soft cloth.
Temperature and Moisture
Temperature is too warm
■New installation? Allow 24 hours following installation for the
refrigerator to cool completely.
■Door(s) opened often or left open? Allows warm air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
■Large load of food added? Allow several hours for
refrigerator to return to normal temperature.
■Controls set correctly for the surrounding conditions?
Adjust the controls a setting colder. Check temperature in
24 hours. See “Using the Control(s).”
There is interior moisture buildup
NOTE: Some moisture buildup is normal.
■Humid room? Contributes to moisture buildup.
■Door(s) opened often or left open? Allows humid air to enter
refrigerator. Minimize door openings and keep doors fully
closed.
Ice and Water
The ice maker is not producing ice or not enough ice
■Refrigerator connected to a water supply and the supply
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
■Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
■Ice maker turned on? Make sure wire shutoff arm or switch
(depending on model) is in the ON position.
■New installation? Wait 24 hours after ice maker installation
for ice production to begin. Wait 72 hours for full ice
production.
■Freezer door closed completely? Firmly close the freezer
compartment door. If the freezer compartment door will not
close all the way, see “The doors will not close completely,”
earlier in this section.
■Large amount of ice recently removed? Allow 24 hours for
ice maker to produce more ice.
■Ice cube jammed in the ice maker ejector arm?
Remove ice from the ejector arm with a plastic utensil.
■Water filter installed on the refrigerator? Remove filter and
operate ice maker. If ice volume improves, then the filter may
be clogged or incorrectly installed. Replace filter or reinstall it
correctly.
■Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See “Water Supply Requirements.”
The ice cubes are hollow or small
NOTE: This is an indication of low water pressure.
■Water shutoff valve not fully open? Turn the water shutoff
valve fully open.
■Kink in the water source line? A kink in the line can reduce
water flow. Straighten the water source line.
■Water filter installed on the refrigerator? Remove filter and
operate ice maker. If ice quality improves, then the filter may
be clogged or incorrectly installed. Replace filter or reinstall it
correctly.
■Reverse osmosis water filtration system connected to
your cold water supply? This can decrease water pressure.
See “Water Supply Requirements.”
■Questions remain regarding water pressure? Call a
licensed, qualified plumber.
Off-taste, odor or gray color in the ice
■New plumbing connections? New plumbing connections
can cause discolored or off-flavored ice.
■Ice stored too long? Discard ice. Wash ice bin. Allow
24 hours for ice maker to make new ice.
■Odor transfer from food? Use airtight, moisture proof
packaging to store food.
■Are there minerals (such as sulfur) in the water? A water
filter may need to be installed to remove the minerals.
■Water filter installed on the refrigerator? Gray or dark
discoloration in ice indicates that the water filtration system
needs additional flushing. Flush the water system before using
a new water filter. Replace water filter when indicated. See
“Water Filtration System.”
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

12
IKEA MAJOR APPLIANCE WARRANTY
How long is the IKEA limited warranty valid?
This limited warranty is valid for five years from the date of purchase, when this major appliance is operated and maintained according to
instructions attached to or furnished with the product, unless the appliance is named LAGAN in which case this limited warranty is valid for one
year from the date of purchase. This limited warranty is valid only in the United States or Canada and applies only when the major appliance is
used in the country in which it was purchased. Proof of original purchase date is required to obtain service under this limited warranty.
Which appliances are not covered by the IKEA five (5) year limited warranty?
For major appliances named “LAGAN,” this limited warranty is valid for one year from the date of purchase.
Who will execute the service?
This limited warranty is provided by Whirlpool Corporation or Whirlpool Canada LP (hereafter “Whirlpool”). Service must be provided by a
Whirlpool designated service company.
What does this limited warranty cover?
The limited warranty will pay for factory specified parts and repair labor to correct defects in materials or workmanship that existed when the
major appliance was purchased. The exceptions are specified under the headline “What is not covered under this limited warranty?”.
What will be done to correct the problem?
The designated service company will examine the product and decide, at its sole discretion, if it is covered under this limited warranty. If
considered covered, the designated service company will then repair the defect. Your sole and exclusive remedy under this limited warranty shall
be product repair as provided herein.
What is not covered under this limited warranty?
■Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or repair house
fuses, or to correct house wiring or plumbing.
■Service calls to repair or replace appliance light bulbs, air filters or water filters. Consumable parts are excluded from warranty coverage.
■Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is used in a
manner that is inconsistent to published user or operator instructions and/or installation instructions.
■Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in accordance with
electrical or plumbing codes, or use of consumables or cleaning products not approved for use.
■Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage results from
defects in materials or workmanship and is reported within 30 days from the date of purchase.
■Any food loss or medicine loss due to refrigerator or freezer product failures.
■Pick up and delivery. This major appliance is intended to be repaired in your home.
■Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
■Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an authorized
servicer is not available.
■The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance with
published installation instructions.
■Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered or cannot be
easily determined.
The cost of repair or replacement under these excluded circumstances shall be borne by the customer.
Disclaimer of Implied Warranties
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO FIVE YEARS (ONE YEAR FOR MAJOR APPLIANCES NAMED “LAGAN”) OR THE SHORTEST
PERIOD ALLOWED BY LAW. Some states and provinces do not allow limitations on the duration of implied warranties of merchantability or
fitness, so this limitation may not apply to you. This warranty gives you specific legal rights, and you also may have other rights that vary from
state to state or province to province.
Limitation of Remedies; Exclusion of Incidental and Consequential Damages
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
WHIRLPOOL SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the
exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty gives you
specific legal rights, and you also may have other rights that vary from state to state or province to province.
How to reach us if you need our service
If outside the 50 United States and Canada, contact your authorized IKEA retailer to determine if another warranty applies.
If you need service, please read the Installation Instructions and/or the “Troubleshooting” section of the Use & Care Guide before contacting us.
If you need additional help, do not hesitate to contact us in the U.S.A. and Canada at 1-866-664-2449. 2/09
For additional product information, visit www.whirlpool.com.
If you do not have access to the Internet and you need assistance using your product or you would like to schedule service, you may
contact Whirlpool at the number below.
Have your complete model number ready. You can find your model number and serial number on the label, located on the inside wall of the
refrigerator compartment.
For assistance or service, call 1-866-664-2449.
If you need further assistance, you can write to Whirlpool with any questions or concerns at the address below:
In the U.S.A.:
Whirlpool Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
In Canada:
Whirlpool Brand Home Appliances
Customer eXperience Centre
1901 Minnesota Court
Mississauga, Ontario L5N 3A7
Please include a daytime phone number in your correspondence.
Please keep these User Instructions and the model number information for future reference.

13
LE AGRADECEMOS la compra de este producto de alta calidad. Si usted experimenta un problema que no se haya cubierto en
SOLUCIÓN DE PROBLEMAS, visite www.whirlpool.com para obtener información adicional. Si considera que aún necesita
ayuda, llámenos al 1-866-664-2449.
Necesitará tener a mano su número de modelo y de serie ubicados en la pared interior del compartimiento del refrigerador.
SEGURIDAD DEL REFRIGERADOR
INSTRUCCIONES PARA
EL USUARIO DEL REFRIGERADOR
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesión grave.
Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que
puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre
todos los mensajes de seguridad.
ADVERTENCIA
PELIGRO
Este es el símbolo de advertencia de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a
usted y a los demás.
Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra
“PELIGRO” o “ADVERTENCIA”. Estas palabras significan:
Para reducir el riesgo de incendio, choque eléctrico, o lesiones personales al usar su refrigerador siga
estas precauciones básicas, incluidas las siguientes:
ADVERTENCIA: INSTRUCCIONES IMPORTANTES DE SEGURIDAD
CONSERVAR ESTAS INSTRUCCIONES
■ Conecte a un contacto de pared de conexión a tierra de
3 terminales.
■ No quite la terminal de conexión a tierra.
■ No use un adaptador.
■ No use un cable eléctrico de extensión.
■ Desconecte el suministro de energía antes de darle servicio.
■ Vuelva a colocar todos los componentes y paneles antes de
hacerlo funcionar.
■ Remueva las puertas de su refrigerador viejo.
■ Use un limpiador no inflamable.
■ Mantenga los materiales y vapores inflamables, tales como
gasolina, alejados del refrigerador.
■ Use dos o más personas para mover e instalar el
refrigerador.
■ Desconecte el suministro de energía antes de instalar la
fábrica de hielo (en aquellos modelos que incluyen el juego
de instalación de la fábrica de hielo).

14
Cómo deshacerse adecuadamente de
su refrigerador viejo
IMPORTANTE: El atrapamiento y asfixia de niños no es un
problema del pasado. Los refrigeradores tirados y abandonados
son un peligro, aun si van a quedar ahí “por unos pocos días”. Si
Ud. está por deshacerse de su refrigerador viejo, por favor siga
las instrucciones que se dan a continuación para prevenir
accidentes.
Antes de tirar su viejo refrigerador o congelador:
■Saque las puertas.
■Deje los estantes en su lugar, así los niños no pueden meterse
adentro con facilidad.
INSTRUCCIONES DE INSTALACIÓN
Desempaque el refrigerador
Cómo quitar los materiales de empaque
■Quite los restos de cinta y goma de las superficies de su
refrigerador antes de encenderlo. Frote un poco de
detergente líquido para vajillas sobre el adhesivo con los
dedos. Limpie con agua tibia y seque.
■No use instrumentos filosos, alcohol para fricciones, líquidos
inflamables o productos de limpieza abrasivos para eliminar
los restos de cinta o goma. Estos productos pueden dañar la
superficie de su refrigerador. Para más información, vea
“Seguridad del refrigerador”.
■Deshágase de todos los materiales de embalaje o recíclelos.
Limpieza antes del uso
Una vez que usted haya quitado todos los materiales de
empaque, limpie el interior de su refrigerador antes de usarlo. Vea
las instrucciones de limpieza en “Cuidado de su refrigerador”.
Requisitos de ubicación
Para asegurar la ventilación apropiada de su refrigerador, permita
un espacio de ¹⁄₂" (1,25 cm) en la parte superior y detrás del
refrigerador. Si su refrigerador tiene fábrica de hielo, asegúrese de
que haya espacio adicional atrás para las conexiones de la línea
de agua. Cuando instale su refrigerador junto a una pared fija,
deje 2¹⁄₂" (6,3 cm) mínimo del lado de la bisagra (algunos modelos
requieren más), para permitir que la puerta se abra
completamente.
ADVERTENCIA
Peligro de Asfixia
Remueva las puertas de su refrigerador viejo.
No seguir esta instrucción puede ocasionar la muerte
o daño al cerebro.
ADVERTENCIA
Peligro de Peso Excesivo
Use dos o más personas para mover e instalar
el refrigerador.
No seguir esta instrucción puede ocasionar una
lesión en la espalda u otro tipo de lesiones.
Cómo mover su refrigerador:
Su refrigerador es pesado. Cuando mueva el refrigerador
para limpiarlo o para darle servicio, cerciórese de cubrir
el piso con cartón o madera para evitar daños en el mismo.
Al mover el refrigerador, siempre tire directamente hacia
afuera. No menee el refrigerador de lado a lado ni lo haga
“caminar” cuando lo trate de mover ya que podría dañar
el piso.
Información importante para saber acerca de los estantes
y tapas de vidrio:
No limpie los estantes y tapas de vidrio con agua caliente
mientras están fríos. Los estantes y tapas pueden romperse
si se exponen a cambios bruscos de temperatura o impacto,
como sería un golpe brusco. El vidrio templado se ha
diseñado para hacerse añicos. Esto es normal. Los estantes
y tapas de vidrio son muy pesados. Use ambas manos al
sacarlos para evitar que se caigan.
ADVERTENCIA
Peligro de Explosión
Mantenga los materiales y vapores inflamables,
tales como gasolina, alejados del refrigerador.
No seguir esta instrucción puede ocasionar la muerte,
explosión, o incendio.

15
NOTA: No se recomienda instalar el refrigerador cerca de un
horno, radiador u otra fuente de calor. No instale el refrigerador en
un lugar donde la temperatura sea menor de 55°F (13°C).
Requisitos eléctricos
Antes de mover el refrigerador a su ubicación final, es importante
asegurarse que tiene la conexión eléctrica adecuada.
Método de conexión a tierra recomendado
Se requiere una fuente de energía eléctrica de 115 Voltios, 60 Hz.,
CA solamente y con fusibles de 15 ó 20 amperios, conectada a
tierra. Se recomienda que use un circuito separado sólo para su
refrigerador. Use un tomacorriente que no se pueda apagar con
un interruptor. No use un cable eléctrico de extensión.
NOTA: Antes de realizar cualquier tipo de instalación, limpieza o
de quitar un foco de luz, ponga el refrigerador en OFF (Apagado).
Dependiendo del modelo, gire el control del congelador hacia la
palabra OFF o presione el botón con la flecha hacia abajo del
congelador hasta que aparezca un guión (-) en la pantalla del
congelador y la del refrigerador, como se muestra. Desconecte el
refrigerador de la fuente de suministro eléctrico. Cuando haya
terminado, reconecte el refrigerador a la fuente de energía
eléctrica y vuelva a poner los controles de temperatura en la
posición deseada. Vea “Uso de los controles”.
Requisitos del suministro de agua
Reúna las herramientas y piezas necesarias antes de comenzar la
instalación. Lea y siga las instrucciones provistas con cualquiera
de las herramientas enlistadas aquí.
HERRAMIENTAS NECESARIAS:
IMPORTANTE:
■Todas las instalaciones deben hacerse de acuerdo a los
requisitos locales de plomería.
■No use una válvula perforadora o una válvula de montura de
³⁄₁₆" (4,76 mm), la cual reduce el flujo de agua y se obstruye
con más facilidad.
■Use tubería de cobre y revise si hay fugas. Instale la tubería de
cobre sólo en áreas donde la temperatura vaya a permanecer
por encima del punto de congelación.
■Para modelos con filtros de agua, el filtro de agua desechable
deberá reemplazarse por lo menos cada 6 meses.
Presión del agua
Se necesita un suministro de agua fría con presión de agua entre
35 y 120 lbs/pulg² (241 y 827 kPa) para hacer funcionar el
despachador de agua y la fábrica de hielo. Si tiene preguntas
acerca de la presión del agua, llame a un plomero competente
autorizado.
Suministro de agua por ósmosis inversa
IMPORTANTE: La presión del suministro de agua que sale de un
sistema de ósmosis inversa y va a la válvula de entrada de agua
del refrigerador necesitará ser entre 35 y 120 lbs/pulg² (241 y
827 kPa).
Si se conecta un sistema de filtración de agua de ósmosis inversa
al suministro de agua fría, la presión de agua al sistema de
ósmosis inversa necesitará ser de un mínimo de 40 a 60 lbs/pulg²
(276 a 414 kPa).
Si la presión de agua hacia el sistema de ósmosis inversa es
menor de 40 a 60 lbs/pulg² (276 a 414 kPa):
■Verifique si el filtro de sedimentos en el sistema de ósmosis
inversa está bloqueado. Reemplácelo si fuera necesario.
■Deje que se vuelva a llenar el tanque de almacenaje del
sistema de ósmosis inversa después del uso intenso.
■Si su refrigerador tiene un filtro de agua, se podrá reducir la
presión aún más si se usa en conjunto con un sistema de
ósmosis inversa. Saque el filtro de agua. Vea “Sistema de
filtración de agua”.
Si tiene preguntas acerca de la presión del agua, llame a un
plomero competente autorizado.
2¹⁄₂" (6,3 cm)
¹⁄₂" (1,25 cm)
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
■Destornillador de hoja plana
■Llaves de boca de ⁷⁄₁₆" y ¹⁄₂" o
dos llaves ajustables
■Llave de tuercas de ¹⁄₄"
■Broca de ¹⁄₄"
■Taladro inalámbrico

16
Conecte el suministro de agua
Lea todas las instrucciones antes de comenzar.
IMPORTANTE: Si enciende el refrigerador antes de conectar la
tubería de agua, APAGUE la fábrica de hielo.
Conexión a la línea de agua
1. Desenchufe el refrigerador o desconecte el suministro de
energía.
2. CIERRE el suministro principal de agua. ABRA la llave de agua
más cercana el tiempo suficiente para que la tubería de agua
se vacíe.
3. Localice una tubería de agua fría vertical de ¹⁄₂" a 1¹⁄₄"
(12,7 mm a 31,8 mm) cerca del refrigerador.
IMPORTANTE:
■Asegúrese de que sea una tubería de agua fría.
■Una tubería horizontal funcionará, pero debe seguirse el
procedimiento indicado a continuación: taladre por el lado
de arriba de la tubería, no por debajo. Esto ayudará a
mantener el agua alejada del taladro. Esto también evita
que se acumule el sedimento normal en la válvula.
4. Determine la longitud de la tubería de cobre que necesite.
Mida desde la conexión de la parte trasera del refrigerador
hasta la tubería de agua. Agregue 7 pies (2,1 m) para poder
mover el refrigerador para limpiarlo. Use tubería de cobre de
¹⁄₄" (6,35 mm) de diámetro externo. Asegúrese que ambos
extremos de la tubería de cobre están cortados a escuadra.
5. Usando un taladro inalámbrico, taladre un orificio de ¹⁄₄" en la
tubería de agua fría que ha seleccionado.
6. Afiance la válvula de cierre a la tubería de agua fría con la
abrazadera para tubería. Asegúrese de que el extremo de
salida se encuentre sujeto firmemente en el orificio taladrado
de ¹⁄₄" en la tubería de agua y que la arandela está bajo la
abrazadera de la tubería. Apriete la tuerca de presión. Apriete
los tornillos de la abrazadera para tubería lentamente y en
forma pareja de manera que la arandela provea un cierre
hermético. No apriete demasiado.
7. Deslice la manga de compresión y la tuerca de compresión
sobre la tubería de cobre como se muestra. Inserte el extremo
de la tubería en el extremo de salida en forma pareja hasta
donde sea posible. Atornille la tuerca de compresión en el
extremo de salida usando la llave de tuercas ajustable. No
apriete demasiado porque se puede quebrar la tubería de
cobre.
8. Coloque el extremo libre de la tubería en un recipiente o
fregadero y ABRA el suministro principal de agua. Enjuague la
tubería hasta que el agua salga limpia. CIERRE la válvula de
cierre de la tubería de agua.
Conexión al refrigerador
Dependiendo de su modelo, la línea de agua puede bajar de la
parte superior o subir de la parte inferior. Siga las instrucciones de
conexión para su modelo.
Estilo 1
1. Quite la tapa de plástico del puerto de entrada de la válvula de
agua. Fije el tubo de cobre a la entrada de la válvula usando
una tuerca de compresión y manga de compresión como se
muestra. Ajuste la tuerca de compresión. No apriete
demasiado. Verifique que la tubería de cobre esté segura,
jalándola.
2. Haga un lazo de servicio con la tubería de cobre. Evite
torceduras al enrollar la tubería de cobre. Asegure la tubería
de cobre a la carcasa del refrigerador con una abrazadera
en “P”.
3. Abra el suministro de agua al refrigerador y revise si hay fugas
de agua. Tape cualquier fuga que encuentre.
Estilo 2
1. Haga un lazo de servicio (diámetro mínimo de 2 pies [61 cm])
con la tubería de cobre. Evite torceduras al enrollar la tubería
de cobre.
2. Quite la tapa de plástico del puerto de entrada de la válvula de
agua. Coloque una manga y tuerca de compresión en la
tubería de cobre.
3. Introduzca el extremo de la tubería de cobre al puerto de
entrada de la válvula de agua. Moldee ligeramente la tubería
de tal forma que la tubería entre de forma recta al puerto para
evitar torceduras.
A. Tubería de agua fría
B. Abrazadera para tubería
C. Tubería de cobre
D. Tuerca de compresión
E. Manga de
compresión
F. V álvula de cierre
G. Tuerca de presión
F
G
A
B
C
D
E
A. Tubería de cobre
B. Abrazadera en “P”
C. Tuerca de compresión
D. Manga de compresión
E. Puerto de entrada de
la válvula de agua
A
B
C
D
E

17
4. Deslice la tuerca de compresión sobre la manga y atornille en
el puerto de entrada de la válvula de agua.
5. Con una llave de tuercas ajustable, sostenga la tuerca sobre
la línea de agua de plástico para evitar que se mueva. Luego,
con una segunda llave, gire la tuerca de compresión que está
en la tubería de cobre, en el sentido contrario de las
manecillas del reloj para apretar completamente. No apriete
demasiado.
6. Verifique la conexión jalando la tubería de cobre. Sujete la
tubería de cobre a la carcasa del refrigerador con una
abrazadera en “P”. Abra el suministro de agua al refrigerador y
revise si hay fugas de agua. Tape cualquier fuga que
encuentre.
Complete la instalación
1. Conecte a un contacto de pared de conexión a tierra de
3terminales.
NOTA: Deje transcurrir 24 horas para la producción del primer
lote de hielo. Deshágase de los tres primeros lotes de hielo
producidos. Deje transcurrir 3 días para que se vuelva a llenar de
hielo el recipiente.
Puerta(s) y cajón del refrigerador
HERRAMIENTAS NECESARIAS: Llave de cubo de cabeza
hexagonal de ⁵⁄₁₆", ³⁄₈", y ¹⁄₄", destornillador Phillips N° 2 y un
destornillador de hoja plana.
IMPORTANTE:
■Todas las ilustraciones a las que se hace referencia en las
siguientes instrucciones se incluyen más adelante en esta
sección después de “Pasos finales”.
■Si usted sólo quiere quitar las puertas y volverlas a colocar,
vea las secciones “Cómo quitar las puertas y las bisagras” y
“Cómo volver a poner las puertas y las bisagras en su lugar”.
■Antes de comenzar, gire el control del refrigerador a OFF
(Apagado), saque los alimentos y la puerta regulable o
recipientes de uso general de las puertas.
Cómo quitar y volver a colocar las manijas
de la puerta del refrigerador
■Con una llave Allen de ³⁄₃₂", afloje los dos tornillos fijos
ubicados en el lado de cada manija. Jale la manija
directamente hacia afuera de la puerta. Asegúrese que guarda
los tornillos para reinstalar las manijas. Vea la ilustración
Manija de metal 1.
■Para volver a colocar las manijas, invierta las instrucciones.
Cómo quitar la puerta y las bisagras
1. Desenchufe el refrigerador o desconecte el suministro de
energía.
2. Mantenga las puertas del refrigerador cerradas hasta que esté
listo para levantarlas y quitarlas de la carcasa.
NOTA: Mientras quita las bisagras siempre disponga de un
soporte adicional para la puerta del refrigerador. No se confíe
en que los imanes de la junta de la puerta van a sostener la
puerta en su lugar mientras trabaja.
3. Comenzando por la puerta del lado derecho, saque las piezas
de la bisagra superior, como se muestra en la ilustración
Bisagra superior. Levante y saque la puerta del refrigerador
del pasador inferior de la bisagra.
4. Saque la cubierta del pasador de la bisagra inferior y guárdela
para usarla más tarde. Vea la ilustración Bisagra inferior.
5. Antes de sacar la puerta del lado izquierdo, desconecte el
enchufe de cableado que está ubicado sobre la bisagra
superior introduciendo un destornillador de hoja plana o la
uña entre las dos secciones. Vea la ilustración Enchufe de
cableado.
NOTA: El alambre verde a tierra permanece sujeto a la
bisagra.
A. Tubería de agua de plástico
B. Manga
C. Tuerca de compresión
D. Tubería de cobre
A. Línea de agua de plástico
B. Puerto de entrada de la
válvula de agua
C. Tuerca de compresión
D. Tubería de cobre
E. Abrazadera en “P”
B
A
C
D
B
A
C
D
E
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
ADVERTENCIA
Peligro de Choque Eléctrico
Desconecte el suministro de energía antes de sacar
las puertas.
No seguir esta instrucción puede ocasionar la muerte
o choque eléctrico.

18
6. Saque los componentes de la bisagra superior de la puerta
del lado izquierdo, como se muestra en la ilustración Bisagra
superior. Levante y saque la puerta del pasador inferior de la
bisagra.
NOTA: Saque la cubierta del pasador de la bisagra inferior y
guárdela para usarla más tarde. Vea la ilustración Bisagra
inferior.
Cómo volver a poner la puerta y las bisagras en su lugar
1. Ensamble los componentes de las bisagras superiores, como
se muestra en la ilustración Bisagra superior. No atornille
completamente los tornillos.
2. Vuelva a colocar los componentes de las bisagras inferiores,
como se muestra en la ilustración Bisagra inferior. Apriete los
tornillos. Vuelva a poner en su lugar las puertas del
refrigerador.
NOTA: Mientras quita las bisagras siempre disponga de un
soporte adicional para las puertas del refrigerador. No se
confíe en que los imanes de la junta de las puertas van a
sostener las puertas en su lugar mientras trabaja.
3. Alinee cada puerta de modo que la base de la puerta del
refrigerador esté alineada en forma pareja con la parte
superior del cajón del congelador. Apriete todos los tornillos.
4. Vuelva a conectar el enchufe de cableado en la parte superior
de la puerta del lado izquierdo del refrigerador.
5. Vuelva a colocar las cubiertas de la bisagra superior.
Cómo quitar y volver a colocar el cajón del congelador
IMPORTANTE:
■Tal vez se necesiten dos personas para quitar y volver a
colocar el cajón del congelador.
■Todas las ilustraciones se incluyen en esta sección, más
adelante, después de “Pasos finales”.
Cómo quitar y volver a colocar la manija del cajón
■Con una llave Allen de ³⁄₃₂", afloje los dos tornillos fijos
ubicados en el lado de cada manija. Jale la manija
directamente hacia afuera del cajón. Asegúrese de guardar
los tornillos para reinstalar las manijas. Vea la ilustración
Manija de metal 2.
■Para volver a colocar la manija, invierta las instrucciones.
Para quitar el frente del cajón
1. Abra el cajón del congelador en toda su extensión.
2. Afloje los cuatro tornillos que sujetan las guías del cajón al
frente del cajón. Vea la ilustración Remoción del frente del
cajón.
NOTA: Afloje los tornillos girándolos tres o cuatro veces.
Mantenga los tornillos en el frente del cajón.
3. Levante el frente del cajón hacia arriba y fuera de los tornillos.
Vea la ilustración Cómo quitar el frente del cajón.
Para volver a colocar el frente del cajón
1. Deslice las guías fuera del compartimiento del congelador.
Inserte los tornillos en la parte superior del frente del cajón,
dentro de las ranuras que están en los soportes del cajón. Vea
la ilustración Cómo volver a colocar el frente del cajón.
2. Jale los soportes del cajón hacia usted para colocar los dos
tornillos en la base del frente del cajón, dentro de los
soportes. Vea la ilustración Cómo volver a colocar el frente del
cajón.
3. Apriete por completo los cuatro tornillos.
Pasos finales
1. Revise todos los orificios para cerciorarse que los tapones de
los orificios y los tornillos estén en su lugar. Vuelva a colocar la
cubierta de la bisagra superior, como se muestra en la
ilustración Bisagra superior.
2. Conecte a un contacto de pared de conexión a tierra de 3
terminales.
3. Regrese todas las partes removibles a la puerta y la comida al
refrigerador.
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.

19
ADVERTENCIA
Peligro de Choque Eléctrico
Desconecte el suministro de energía antes de sacar las puertas.
No seguir esta instrucción puede ocasionar la muerte o choque eléctrico.
Cómo quitar y volver a poner la puerta en su lugar
A. Tornillo de ajuste de ³⁄₃₂"
A. Tornillo de ajuste de ³⁄₃₂ "
A
A
Manija metálica
Manija metálica
1
2
Bisagras superiores
A. Tornillo para la cubierta de
la bisagra
B. Cubierta de la bisagra superior
C. Tornillos de cabeza hexagonal
para bisagra de ⁵⁄₁₆"
D. Bisagra superior
B
A
C
D
A. Cubierta del pasador de la bisagra
C. Tornillos para bisagra
B. Bisagra inferior
Bisagras inferiores
Enchufe de cableado
A
B
C
Cómo quitar el frente del cajón
A. Afloje los 4 tornillos de
soporte de la puerta
A
Cómo volver a colocar el frente del cajón

20
Ajuste las puertas
Su refrigerador tiene dos rodillos regulables ubicados en la base
del refrigerador. Si su refrigerador parece poco firme o si usted
desea que la puerta se cierre con más facilidad, siga las
instrucciones a continuación.
1. Quite la rejilla de la base. Tome la rejilla con firmeza y jálela
hacia usted.
2. Con un destornillador hexagonal de ³⁄₈", gire el tornillo
regulador del rodillo que está a cada lado, para levantar o
bajar ese lado del refrigerador.
NOTA: Haga que alguien empuje la parte superior del
refrigerador, lo cual quita el peso de los tornillos reguladores y
los rodillos. Esto facilita el giro de los tornillos. Puede precisar
darle varias vueltas al tornillo regulador para ajustar la
inclinación del refrigerador.
■Para levantarlo, gire el tornillo regulador del rodillo hacia la
derecha.
■Para bajarlo, gire el tornillo regulador del rodillo hacia la
izquierda.
Gire el pie del freno hacia la derecha hasta que quede
firmemente contra el piso, para evitar que el refrigerador
ruede hacia adelante cuando se abra el cajón del congelador.
3. Abra la puerta nuevamente para verificar que se cierra con la
facilidad que usted desea. De lo contrario, incline el
refrigerador ligeramente más hacia la parte posterior, girando
ambos tornillos niveladores hacia la derecha. Puede tomar
varias vueltas más, y usted deberá girar ambos tornillos la
misma cantidad de veces.
4. Vuelva a colocar la rejilla de la base.
USO DE SU REFRIGERADOR
Cómo abrir y cerrar las puertas
(Modelos de dos puertas con congelador
en la parte inferior)
El compartimiento del refrigerador tiene dos puertas. Las puertas
pueden abrirse y cerrarse ya sea en forma separada o juntas.
Hay una junta con bisagras verticales en la puerta izquierda del
refrigerador.
■Cuando se abre la puerta izquierda, la junta con bisagras se
pliega hacia adentro automáticamente, para quedar fuera del
camino.
■Cuando ambas puertas están cerradas, la junta con bisagras
forma automáticamente un sello entre las dos puertas.
Uso de los controles
Los controles de temperatura están ubicados en la parte frontal
superior de los compartimientos del refrigerador.
Controles de temperatura
Para su conveniencia, los controles de temperatura vienen
prefijados de fábrica. Cuando instale el refrigerador por primera
vez, asegúrese de que los controles estén todavía fijados en los
ajustes recomendados, como se muestra.
Ajuste recomendado “4”
IMPORTANTE:
■El ajuste recomendado debe ser el correcto para un uso
doméstico normal del refrigerador. Los controles están
ajustados correctamente cuando la leche o los jugos están
tan fríos como Ud. desea y cuando el helado tiene
consistencia firme.
■Espere 24 horas para que el refrigerador se enfríe
completamente antes de agregar alimentos. Si agrega
alimentos antes de que el refrigerador se haya enfriado por
completo, sus alimentos podrían echarse a perder.
NOTA: Poner los controles de temperatura del refrigerador y
del congelador en un ajuste más frío que el recomendado no
enfriará más rápido los compartimientos.
A. Tornillo regulador del rodillo delantero
B. Pie de freno
A
B
A. Junta con bisagra
A
