IKEA SUPERKALL User manual

SUPERKALL
Design and Quality
IKEA of Sweden
GB
KR

Please refer to
www.IKEA.com
and select your local store for local store phone numbers
and opening time.

웹사이트
www.IKEA.com
을 참조해 가까운 매장의 전화번호 및 운영 시간을 확인하세요 .

ENGLISH 5
한국어 23

ENGLISH 5
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe and
accessible location for future reference.
Children and vulnerable people safety
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use
of the appliance in a safe way and understand the hazards
involved.
• Children aged from 3 to 8 years are allowed to load and
unload the appliance provided that they have been properly
instructed.
• This appliance may be used by persons with very extensive
and complex disabilities provided that they have been
properly instructed.
• Children of less than 3 years of age should be kept away from
the appliance unless continuously supervised.
• Do not let children play with the appliance.
Content
Safety information 5
Safety instructions 7
Installation 9
First use 11
Product description 12
Operation 13
Daily use 14
Hints and tips 15
Care and cleaning 16
Troubleshooting 18
Technical information 20
Environmental concerns 20
IKEA GUARANTEE 21

ENGLISH 6
• Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
• Keep all packaging away from children and dispose of it
appropriately.
General Safety
• This appliance is intended to be used in household and similar
applications such as:
- Farm houses; sta kitchen areas in shops, oces and other
working environments;
- By clients in hotels, motels, bed and breakfast and other
residential type environments.
• To avoid contamination of food respect the following
instructions:
- do not open the door for long periods;
- clean regularly surfaces that can come in contact with food
and accessible drainage systems;
- store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
• WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.

ENGLISH 7
• When the appliance is empty for long period, switch it o,
defrost, clean, dry and leave the door open to prevent mould
from developing within the appliance.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualied persons in order to avoid a hazard.
Safety instructions
Installation
Warning! Only a qualied person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Do not use the appliance before installing
it in the built-in structure due to safety
manner.
• Follow the installation instructions supplied
with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Make sure the air can circulate around the
appliance.
• At rst installation or after reversing the
door wait at least 4 hours before connecting
the appliance to the power supply. This is to
allow the oil to ow back in the compressor.
• Before carrying out any operations on the
appliance (e.g. reversing the door), remove
the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the rain.
• Do not install the appliance where there is
direct sunlight.
• Do not install this appliance in areas that
are too humid or too cold.
• When you move the appliance, lift it by the
front edge to avoid scratching the oor.
Electrical Connection
Warning! Risk of re and electric shock.
Warning! When positioning the
appliance, ensure the supply cord is not
trapped or damaged.
Warning! Do not use multi-plug
adapters and extension cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power supply.
• Always use a correctly installed shockproof
socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Please refer to
www.IKEA.com
and contact our local store for local store
phone numbers and opening time or have
an electrician to change the electrical
components.
• The mains cable must stay below the level
of the mains plug.
• Connect the mains plug to the mains socket
only at the end of the installation. Make
sure that there is access to the mains plug
after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.

ENGLISH 8
Use
Warning! Risk of injury, burns, electric
shock or re.
The appliance contains ammable
gas, isobutane (R600a), a natural gas with a
high level of environmental compatibility. Be
careful not to cause damage to the refrigerant
circuit containing isobutane.
• Do not change the specication of this
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless they
are stated applicable by the manufacturer.
• If damage occurs to the refrigerant circuit,
make sure that there are no ames and
sources of ignition in the room. Ventilate
the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure on
the drink container.
• Do not store ammable gas and liquid in
the appliance.
• Do not put ammable products or items
that are wet with ammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are wet
or damp.
• Do not freeze again food that has been
thawed.
• Follow the storage instructions on the
packaging of frozen food.
• Wrap the food in any food contact
material before putting it in the freezer
compartment.
Internal lighting
Warning! Risk of electric shock.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature, vibration,
humidity, or are intended to signal
information about the operational status
of the appliance. They are not intended to
be used in other applications and are not
suitable for household room illumination.
Care and cleaning
Warning! Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• This appliance contains hydrocarbons in the
cooling unit. Only a qualied person must
do the maintenance and the recharging of
the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If the
drain is blocked, defrosted water collects in
the bottom of the appliance.
How to reach us if you need our service
• The IKEA after sales customer service center
will assist you on the phone with basic
trouble-shooting for your appliances at the
time of service call request. Please refer to
www.IKEA.com
and select your local store for local store
phone numbers and opening time.

ENGLISH 9
Disposal
Warning! Risk of injury or suocation.
• Disconnect the appliance from the mains
supply.
• Cut o the mains cable and discard it.
• Remove the door to prevent children and
pets to be closed inside of the appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains ammable
gas. Contact your municipal authority
for information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat exchanger.
Installation
Warning! Refer to Safety chapters.
Warning! Refer to installation
instruction document to install your
appliance.
Warning! Fix the appliance in
accordance with installation instruction
document to avoid a risk of instability
of the appliance.
Warning!
Installation in cabinet
The appliance is intended to be built
in a cabinet. Refer to the separate
Assembly Instructions for detailed
installation.
Inspection checklist
Please follow the inspection checklist before using your appliance. If any answer is "NO",
follow the relevant action. Remember to write down the product serial number and
article number as required and attach your receipt to this page.
Product serial number (Ser. No.):
.....................................
Product article number (Art. No.):
.....................................
Purchasing date:
.....................................
XXX.XXX.XX
Serial No.: xxxxxxxxxxxxxxx
Picture for reference only
To check If the answer is YES If the answer is NO
Check if the tube is inside
the evaporative tray (refer to
section "Evaporative tray").
No action Put the tube inside the
evaporative tray.
Make sure gasket seals all
around the door when the
door is closed.
No action Refer to the assembly
instruction -door alignment.
Check if there is no collision
between parts/furniture while
opening and closing the door.
No action Refer to the assembly
instruction -door alignment.

ENGLISH 10
To check If the answer is YES If the answer is NO
Install the appliance in the
built-in structure.
No action Follow the assembly instruction
for the proper installation.
Make sure that at rst
installa- tion or after reversing
the door the appliance stands
in vertical position for at least
4 hours before it is connected
to the power supply.
No action Wait 4 hours before connecting
the appliance to the power
supply.
Evaporative tray
Before using the appliance make sure that
melting water outlet is connected to the
evaporative tray above the compressor.
Location
To ensure appliance's best functionality, you
should not install the appliance in the nearby
of the heat source (oven, stoves, radiators,
cookers or hobs) or in a place with direct
sunlight. Make sure that air can circulate
freely around the back of the cabinet.
This appliance should be installed in a dry,
well ventilated indoor position.
This appliance should be installed in a dry,
well ventilated indoor where the ambient
temperature corresponds to the climate class
indicated on the rating plate of the appliance:
Climate class Ambient temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C

ENGLISH 11
The correct operation of the appliance
can only be guaranteed within the
specied temperature range.
If you have any doubts regarding where
to install the appliance, please turn to
the vendor, to our customer service.
It must be possible to disconnect
the appliance from the mains power
supply. The plug must therefore be
easily accessible after installation.
Electrical connection
Before plugging in, ensure that the voltage
and frequency shown on the rating plate
correspond to your domestic power supply.
The appliance must be earthed. The power
supply cable plug is provided with a contact.
For this purpose. If the domestic power supply
socket is not earthed, connect the appliance
to a separate earth in compliance with current
regulations, consulting a quali ied electrician.
The manufacturer declines all responsibility
if the above safety precautions are not
observed.
Ventilation requirements
The air low behind the appliance must be
sucient.
5 cm
min.
200cm2
min.
200cm2
Caution! Refer to the installation
instructions for the installation.
Door reversibility
• Please refer to the separate document
with instructions on installation and door
reversal.
Caution! At every stage of reversing the
door protect the oor from scratching
with a durable material.
First use
Cleaning the interior
Before using the appliance for the rst time,
the interior and all internal accessories should
be washed with lukewarm water and some
neutral soap to remove the typical smell of a
brand-new product, then dried thoroughly.
Caution! The accessories and parts of the
appliance are not suitable for washing in a
dishwasher.
Caution! Do not use detergents, abrasive
powders, chlorine or oil-based cleaners as
they will damage the nish.

ENGLISH 12
Product description
Product overview
1 Door balconies 7Control panel
2 Bottle balcony 8Glass shelves
3 Freezer drawers 9LED lighting
4 Freezer tray Least cold zone
5 Vegetable drawer Intermediate temperature zone
6 Glass shelf Coldest zone

ENGLISH 13
Operation
Control panel
1
2
1 Temperature indicator
2 Function button
Switching on
Warning! Refer to "Electrical
connection" section of the Safety
chapter.
Connect the mains plug to the power socket.
The display on the control panel turns on. To
change temperature, refer to the section for
temperature regulation.
When operating the appliance for the
rst time, set the appliance at a colder
temperature and run it without loading any
food until it auto stops at the set temperature.
Usually it takes 2 or 3 hours, then set a desired
temperature and put food in the appliance.
Do not use sharp object to control the touch
panel.
Switching o
• To switch the appliance o, press and hold
the 2Function button on the control
panel for 10seconds. After 30seconds, the
appliance will switch o all loads are turned
o, and the display and control of the
refrigerator will be all o in the power o
mode.
• To switch the appliance on again, press the
2Function button.
To disconnect the appliance from the power
supply, disconnect the mains plug from the
power socket.
Locking/unlocking
• If the door is closed and no button
operation occurs for 30 seconds, the control
panel will be locked. Button operation is
invalid.
• To unlock the control panel, press and hold
the 2Function button on the control panel
for 3seconds. Button operation is available.
Temperature regulation for refrigerator
compartment
• Press the 2Function button on the control
panel to toggle a preset temperature.
The four LEDs indicated from ** to *
corresponds to the following temperatures:
2°C, 4°C, 6°C and 8°C. The appliance will run
at the newly set temperature 30seconds
later.
Adjust the temperature setting by keeping
in mind that the temperature inside the
appliance depends on:
• room temperature
• how often the door is opened
• the quantity of food stored
• the location of the appliance
Important! If the ambient temperature is
high or the appliance is fully loaded, and the
appliance is set to the lowest temperatures, it
may run continuously causing frost to form on
the rear wall. In this case a higher temperature
must be set to allow automatic defrosting and
therefore reduced energy consumption.

ENGLISH 14
Daily use
Freezing calendar
3-6
1-2
10 -12
3-4
10 -12
3-6
10 -12
3-6
10 -12
3-6
• The symbols show dierent types of frozen
goods.
• The numbers indicate storage times in
months for the appropriate types of frozen
goods. Whether the upper or lower value of
the indicated storage time is valid depends
on the quality of the foods and treating
before freezing.
Freezing fresh food
• The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
• The freezing process lasts 24 hours: during
this period do not add other food to be
frozen.
Storage of frozen food
• When rst starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
2hours on the colder setting.
• Successful freezing depends on the correct
packaging. When you close and seal the
package you must not allow air or moisture
in or out. If you do, you could have food
odour and taste transfer throughout the
refrigerator, and also dry out frozen food.
• Note: Never put bottled food or drinks in
the freezer compartment.
• For best performance, leave enough space
in the freezer and refrigerator compartment
for air to circulate around the packages.
Also let enough room at the front so the
door can close tightly.
Warning! In the event of accidental
defrosting, for example due to a
power failure, the defrosted food
must be consumed quickly or cooked
immediately, cooled and then re-frozen.
Thawing
Deep-frozen or frozen food, prior to being
used, can be thawed in the refrigerator
compartment or at room temperature,
depending on the time available for this
operation.
Small pieces may even be cooked still frozen,
directly from the freezer: in this case, cooking
will take longer.
Storage of food in the refrigerator
compartment
• Cover or wrap the food, particularly if it has
a strong avour.
• Position the food so that air can circulate
freely around it.
Positioning the door balconies
Picture for reference only
• To permit storage of food packages of
various sizes, the door balconies can be
placed at dierent heights.
• Carefully remove a door balcony from the
support, then reposition it as desired.

ENGLISH 15
Movable shelves
Picture for reference only
• The walls of the refrigerator are equipped
with a series of runners so that the safety
glass shelves can be positioned as desired.
Caution! Do not move the glass shelf
above the vegetable drawer to ensure
correct air circulation.
Vegetable drawer
Picture for reference only
• The drawers can be pulled out for cleaning.
• The drawer is suitable for storing fruit and
vegetables.
• The drawer can be pulled out for cleaning.
Hints and tips
Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound from
coils sound when refrigerant is pumped.
• A whirring and pulsating sound from the
compressor when refrigerant is pumped.
• A sudden cracking noise from inside
appliance caused by thermic dilatation
(a natural and not dangerous physical
phenomenon).
Hints for energy saving
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• If the ambient temperature is high and very
low internal temperature is set and the
appliance is fully loaded, the compressor
may run continuously, causing frost or ice
on the evaporator. If this happens, set the
internal temperature toward warmer one to
allow automatic defrosting and so a saving
in electricity consumption.
Hints for fresh food refrigeration
• Do not store warm food or evaporating
liquids in the refrigerator.
• Cover or wrap the food, particularly if it has
a strong avour.
• Position food so that air can circulate freely
around it.
Hints for refrigeration
Useful hints:
• Meat (all types): wrap in a suitable
packaging and place it on the glass shelf
above the vegetable drawer. Store meat for
at most 1-2 days.
• Cooked foods, cold dishes: cover and place
on any shelf.
• Fruit and vegetables: clean thoroughly
and place in a special drawer. Bananas,
potatoes, onions and garlic must not be
kept in the refrigerator if not packed.
• Butter and cheese: place in a special airtight
container or wrap in an aluminium foil or
a polythene bag to exclude as much air as
possible.
• Bottles: close with a cap and place on the
door bottle shelf, or (if available) on the
bottle rack.
Cautions for Use
• The more food stu put in or the more and
the longer for once the door is opened, the
more it needs electric consumption, which
even leads malfunction.
• Re-plug in the power plug at the interval of

ENGLISH 16
over ten minutes.
• Do not store bottled drink in the freezer,
so as to prevent from being broken and
damaging the refrigerator.
• Open the door as less as possible during
power-cut.
• When defrosting, never use any sharp or
metallic objects to remove the frost on the
surface of the evaporator as it will damage
the evaporator.
• Do not touch foods and containers in the
freezing compartment with your wet hands
so as to prevent from being frostbitten.
Hints for freezing
• To help you make the most of the freezing
process, here are some important hints:
• The freezing process takes 24 hours. No
further food to be frozen should be added
during this period.
• Freeze only top quality, fresh and
thoroughly cleaned, foodstus.
• Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible subsequently to thaw only
the quantity required.
• Wrap up the food in aluminium foil or
polythene and make sure that the packages
are airtight.
• Do not allow fresh, unfrozen food to touch
food which is already frozen, thus avoiding
a rise in temperature of the latter.
• Lean foods store better and longer than
fatty ones; salt reduces the storage life of
food.
• Water ices, if consumed immediately after
removal from the freezer compartment, can
possibly cause the skin to be freeze burnt.
• It is advisable to show the freezing in date
on each individual pack to enable you to
keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this
appliance, you should:
• Make sure that the commercially frozen
foodstus were adequately stored by the
retailer.
• Make sure that frozen foodstus are
transferred from the food store to the
freezer in the shortest possible time.
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• Once defrosted, food deteriorates rapidly
and cannot be refrozen.
• Do not exceed the storage period indicated
by the food manufacturer.
Care and cleaning
Warning! Refer to Safety chapters.
General warnings
Caution! Unplug the appliance
before carrying out any maintenance
operation.
This appliance contains hydrocarbons
in its cooling unit; maintenance and
recharging must therefore only be
carried out by authorized technicians.
The accessories and parts of the
appliance are not suitable for washing
in a dishwasher.
Cleaning the interior
Before using the appliance for the rst time,
the interior and all internal accessories should
be washed with lukewarm water and some
neutral soap to remove the typical smell of a
brand-new product, then dried thoroughly.
Caution! Do not use detergents or
abrasive powders, as these will damage
the nish.

ENGLISH 17
Initial power on
Caution! Before inserting the power
plug in to the outlet and switching on
the cabinet for the rst time, leave the
appliance standing upright for at least
4 hours. This will assure a sucient
amount of time for the oil to return
to the compressor. Otherwise the
compressor or electronic components
may sustain damage.
Periodic cleaning
Caution! Do not pull, move or damage
any pipes and/or cables inside the
cabinet.
Caution! Do not damage the cooling
system.
Caution! When moving the cabinet, lift
it by the front edge to avoid scratching
the oor.
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and wipe
clean to ensure they are clean and free from
debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser and the
compressor at the back of the appliance
with a brush. This operation will improve
the performance of the appliance and save
electricity consumption.
Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from electricity
supply.
2. Remove all food.
3. Defrost (if necessary) and clean the
appliance and all accessories.
4. Clean the appliance and all accessories.
5. Leave the door/doors open to prevent
unpleasant smells.
Caution! If you want to keep the
appliance switched on, ask somebody
to check it once in a while to prevent
the food inside from spoiling in case of
a power failure.
Defrosting refrigerator compartment
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
every time the motor compressor stops,
during normal use. The defrost water drains
out through a trough into a special container
at the back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the
defrost water drain hole at the back of the
refrigerator compartment to prevent the
water overowing and dripping onto the food
inside.
For this purpose use the tube cleaner provided
in the accessory bag.
Defrosting freezer compartment
The freezer compartment has automatic
defrosting function.
Due to seasonal changes, a thick layer of frost
may form. To defrost manually, observe the
followings.
• Disconnect the appliance from the power
supply, and leave open the freezer door.
• Remove all foods, ice cube tray and shelf or
transfer to refrigerator compartment.
• Clean and wipe out the melted frost with a
cloth.
• After defrosting, connect the appliance to
the power supply.
Caution! To avoid damaging the
freezer compartment wall, do not use
any sharp objects to remove the frost
or separate the frozen food.

ENGLISH 18
Troubleshooting
Warning! Refer to Safety chapters.
What to do if...
Problem Possible Cause Solution
The appliance does not operate.
The appliance is switched o. Switch on the appliance.
The mains plug is not connected to
the mains socket correctly
Connect the mains plug to the mains
socket correctly. Refer to "Electrical
connection" section of the safety
chapter.
There is no voltage in the mains
socket.
Connect a dierent electrical appliance
to the mains socket. Contact a qualied
electrician.
The appliance is noisy. The appliance is not placed stably. Check if the appliance stands stable.
The lamp does not work. The lamp is defective. Refer to "Replacing the lamp".
The compressor operates
continually.
Temperature is set incorrectly. Refer to "Operation" chapter.
Many food products were inserted
at the same time.
Insert less food products at the same
time.
The room temperature is too high. Refer to climate class chart on the
rating plate.
Food products placed in the
appliance were too warm.
Allow food products to cool to room
temperature before storing.
The door is not closed correctly. Refer to "Closing the door".
The temperature in the appliance is
too low/too high.
The temperature is not set correctly. Set a higher/lower temperature.
The door is not closed correctly. Refer to "Closing the door".
The food products temperature is
too high.
Let the food products temperature
decrease to room temperature before
storage.
Many food products are inserted at
the same time.
Wait some hours and then check the
temperature again.
The thickness of the frost is greater
than 0.16"-0.20". Defrost the appliance.
The door has been opened often. Open the door only if necessary.
There is no cold air circulation in the
appliance.
Make sure that there is cold air
circulation in the appliance.
There is too much condensed water
on the rear wall of the refrigerator.
Door was opened too frequently. Open the door only when necessary.
Door was not closed completely. Make sure the door is closed
completely.
Stored food was not wrapped. Wrap food in suitable packaging before
storing it in the appliance.
Water ows inside the refrigerator.
The drain hole at the back of the
appliance is clogged.
Clean the drain hole with a piece of
wire.
Food products prevent water from
owing into the water collector,
Make sure that food products do not
touch the rear plate.

ENGLISH 19
Problem Possible Cause Solution
Water ows on the oor,
The door is not closed well.
Refer to "Closing the door", or refer to
the troubleshooting item below ("The
door does not close completely").
The drip pan cracks.
The IKEA after sales customer service
center will assist you on the phone at
the time of service call request.
Please refer to
www.IKEA.com
and select your local store for local
store phone numbers and opening
time.
The defrost water drain is clogged. Clean the drain hole with a piece of
wire.
The door does not close completely.
The shelves are out of position. Make sure the shelves are in correct
position. Refer to "Movable shelves".
The gaskets are dirty. Clean the gaskets. Refer to "Care and
cleaning".
The appliance is not level. Make sure the appliances is installed in
level.
Malfunction alarm
If the appliance malfunctions, a LED indicatior
on the control panel will ash to indicate a
fault.
1
• 1 ashes: Temperature sensor failure of the
refrigerator chamber
• 2 ashes: Defrosting sensor failure of the
refrigerator chamber
• 3 ashes: Defrosting sensor failure of the
freezer chamber
• 4 ashes: Failure of ambient temperature
sensor
If your appliance still is not working
properly after making the above checks,
the IKEA after sales customer service
center will assist you on the phone at the
time of service call request.
Please refer to
www.IKEA.com
and select your local store for local store
phone numbers and opening time.
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to the
separate Assembly Instructions.
3. If necessary, replace the defective door
gaskets. Contact the After Sales Service.
Replacing the lamp
The appliance is equipped with a lamp for
interior lighting.
Only service is allowed to replace the lighting
device.
Please reach out to IKEA, referring to
www.IKEA.com
and select your local store for local store
phone numbers and opening time.

ENGLISH 20
Technical information
Product category
Product type Refrigerator-Freezer
Installation type Built-in
Product dimensions
Height 1785mm
Width 540mm
Depth 545mm
Net volume
Fridge 182L
Freezer 59L
Defrost system
Fridge Auto
Freezer Auto
Energy consumption 39.56kWh/m
Noise level 44 dB (A)
Energy class Class 3
Voltage 220V—
Frequency 60 Hz
Environmental concerns
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle
it. Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of this
product with the household waste. Return
the product to your local recycling facility or
contact your municipal oce.
