IKEA HUTTRA User manual

400011400208
© Inter IKEA Systems B.V. 2019 18535 AA-2119057-2


ENGLISH 4
5 يبرع

ENGLISH 4
Before using the appliance, read
these safety instructions. Keep
them nearby for future reference.
These instructions and the
appliance itself provide important
safety warnings, to be observed
at all times. The manufacturer
declines any liability for failure to
observe these safety instructions,
for inappropriate use of the
appliance or incorrect setting of
controls.
SAFETY WARNINGS
Very young children (0-3 years)
should be kept away from the
appliance. Young children (3-8
years) should be kept away from
the appliance unless continuously
supervised. Children from 8 years
old and above and persons
with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge can
use this appliance only if they
are supervised or have been
given instructions on safe use and
understand the hazards involved.
Children must not play with the
appliance. Cleaning and user
maintenance must not be carried
Safety Information
Table of contents
out by children without supervision.
Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances.
PERMITTED USE
CAUTION: The appliance is not
intended to be operated by means
of an external switching device,
such as a timer, or separate remote
controlled system.
This appliance is intended
to be used in household and
similar applications such as: staff
kitchen areas in shops, ofces
and other working environments;
farm houses; by clients in hotels,
motels, bed & breakfast and other
residential environments.
This appliance is not for
professional use. Do not use the
appliance outdoors.
The bulb used inside the
appliance is specically designed
for domestic appliances and is not
suitable for general room lighting
within the home (EC Regulation
244/2009).
The appliance is designed
for operation in places where the
Safety Information 4
Product description 9
First Use 9
Daily use 10
Helpful hints and tips 11
Cleaning and maintenance 13
What to do if... 14
Technical data 15
Environmental concerns 16
IKEA GUARANTEE 17

ENGLISH 5
ambient temperature comes within
the following ranges, according
to the climatic class given on the
rating plate. The appliance may
not work properly if it is left for a
long time at a temperature outside
the specied range.
Climatic class ambient
temperatures (°C)
SN: From 10 to 32
N: From 16 to 32
ST: From 16 to 38
T: From 16 to 43
This appliance does not
contain CFCs. The refrigerant
circuit contains R600a (HC).
Appliances with Isobutane
(R600a): isobutane is a natural
gas without environmental
impact, but is ammable.
Therefore, make sure the
refrigerant circuit pipes are
not damaged, especially
when emptying the refrigerant
circuit.
WARNING!: Do not damage
the appliance refrigerant circuit
pipes.
WARNING!: Keep ventilation
openings, in the appliance
enclosure or in the built-in structure,
clear of obstruction.
WARNING!: Do not use
mechanical, electric or chemical
means other than those
recommended by the Manufacturer
to speed up the defrost process.
WARNING!: Do not use or
place electrical devices inside
the appliance compartments if
they are not of the type expressly
authorised by the Manufacturer.
WARNING!: Ice makers and/
or water dispensers not directly
connected to the water supply must
be lled with potable water only.
WARNING!: Automatic ice-
makers and/or water dispensers
must be connected to a water
supply that delivers potable water
only, with mains water pressure
between 0.17 and 0.81 MPa (1.7
and 8.1 bar).
Do not store explosive
substances such as aerosol cans
and do not place or use gasoline
or other ammable materials in or
near the appliance.
Do not swallow the contents
(non-toxic) of the ice packs
(provided with some models).
Do not eat ice cubes or ice lollies
immediately after taking them out
of the freezer since they may cause
cold burns.
For products designed to use
an air lter inside an accessible fan
cover, the lter must always be in
position when the refrigerator is in
function.
Do not store glass containers
with liquids in the freezer
compartment since they may
break. Do not obstruct the fan (if

ENGLISH 6
included) with food items. After
placing the food check that the
door of compartments closes
properly, especially the freezer
door.
Damaged gaskets must be
replaced as soon as possible.
Use the refrigerator
compartment only for storing fresh
food and the freezer compartment
only for storing frozen food,
freezing fresh food and making ice
cubes.
Avoid storing unwrapped
food in direct contact with internal
surfaces of the refrigerator or
freezer compartments. Appliances
could have special compartments
(Fresh Food Compartment,
Zero Degree Box,...). Unless
differently specied in the specic
booklet of product, they can be
removed, maintaining equivalent
performances.
C-Pentane is used as blowing
agent in the insulation foam
and it is a ammable gas.
The most appropriate
compartments of the appliance
where specic types of food are
to be stored, taking into account
different temperature distribution
in different compartments in the
appliance, are as follows:
- Refrigerator compartment:
1) Upper area of the refrigerator
compartment & door - temperature
zone: Store tropical fruit, cans,
drinks, eggs, sauces, pickles, butter,
jam
2) Middle area of the refrigerator
compartment - cool zone: Store
cheese, milk, dairy food, deli food,
yoghurt
3) Lower area of the refrigerator
compartment - coldest zone: Store
cold cuts, desserts, meat and sh,
cheesecake, fresh pasta, sour
cream, pesto/salsa, home-cooked
food, pastry cream, pudding and
cream cheese
4) Fruit & vegetable drawer at
the bottom of the refrigerator
compartment: Store vegetables
and fruits (excluding tropical fruits)
5) Chiller compartment: Only store
meat and sh in the coldest drawer
- Freezer compartment:
4 star zone (****) compartment
is suitable for freezing foodstuffs
from ambient temperature and
for storing frozen food as the
temperature is evenly distributed
throughout the entire compartment.
Purchased frozen food has the
storage expiration date stated
on the packaging. This date
takes into account the type of
food being stored and therefore
this date should be respected.
Fresh food should be stored for
the following time periods: 1-3
months for cheese, shellsh, ice
cream, sausage, milk, fresh liquids;

ENGLISH 7
4 months for steak or chops
(beef, lamb); 6 months for butter
or margarine, poultry (chicken,
turkey); 8-12 months for fruits
(except citrus), roast meat (beef,
lamb), vegetables. Expiration dates
on the packaging of foods in the
2-star zone must be respected.
To avoid food contamination,
please observe the following:
– Opening the door for long
periods can cause a signicant
increase of the temperature in the
compartments of the appliance.
– Regularly clean surfaces that may
come into contact with food and
accessible drainage systems.
– Clean water tanks if they have
not been used for 48 h; ush
the water system connected to
a water supply if water has not
been drawn for 5 days.
– Store raw meat and sh in
suitable containers in the
refrigerator, so that it does not
come into contact with or drip
onto other food.
– Two-star frozen food
compartments are suitable for
storing pre-frozen food, storing or
making ice cream and ice cubes.
– Do not freeze fresh food in one,
two or three-star compartments.
– If the refrigerating appliance is
left empty for long periods, switch
off, defrost, clean, dry, and leave
the door open to prevent mould
developing inside the appliance.
INSTALLATION
The appliance must be
handled and installed by two or
more persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
Installation, including
water supply (if any), electrical
connections and repairs must
be carried out by a qualied
technician. Do not repair or
replace any part of the appliance
unless specically stated in the
user manual. Keep children away
from the installation site. After
unpacking the appliance, make
sure that it has not been damaged
during transport. In the event of
problems, contact the dealer or
your nearest Aftersales Service.
Once installed, packaging waste
(plastic, styrofoam parts etc.)
must be stored out of reach of
children - risk of suffocation. The
appliance must be disconnected
from the power supply before
any installation operation - risk of
electric shock. During installation,
make sure the appliance does not
damage the power cable - risk of
re or electric shock. Only activate
the appliance when the installation
has been completed.
Be careful not to damage
the oors (e.g. parquet) when
moving the appliance. Install the
appliance on a oor or support
strong enough to take its weight

ENGLISH 8
and in a place suitable for its size
and use. Make sure the appliance
is not near a heat source and
that the four feet are stable and
resting on the oor, adjusting them
as required, and check that the
appliance is perfectly level using a
spirit level. Wait at least two hours
before switching the appliance on,
to ensure that the refrigerant circuit
is fully efcient.
WARNING: When positioning
the appliance, ensure the supply
cord is not trapped or damaged.
WARNING: To avoid a hazard
due to instability, positioning
or xing of the appliance must
be done in accordance with the
manufacturer instructions. It’s
forbidden to place the refrigerator
in such way that the metal hose
of gas stove, metal gas or water
pipes, or electrical wires are in
contact with the refrigerator back
wall (condenser coil).
To guarantee adequate
ventilation, leave a space on both
sides and above the appliance.
The distance between the rear of
the appliance and the wall behind
the appliance should be 50 mm,
to avoid access to hot surfaces. A
reduction of this space will increase
the Energy consumption of product.
Please remove the power cord from
condenser hook during installation
before connecting product to
power supply.
ELECTRICAL WARNINGS
It must be possible to
disconnect the appliance from the
power supply by unplugging it if
plug is accessible, or by a multi-
pole switch installed upstream of
the socket in accordance with the
wiring rules and the appliance
must be earthed in conformity with
national electrical safety standards.
Do not use extension leads,
multiple sockets or adapters.
The electrical components must
not be accessible to the user
after installation. Do not use the
appliance when you are wet or
barefoot. Do not operate this
appliance if it has a damaged
power cable or plug, if it is not
working properly, or if it has been
damaged or dropped.
If the supply cord is damaged,
it must be replaced with an
identical one by the manufacturer,
its service agent or similarly
qualied persons in order to avoid
a hazard - risk of electric shock.
WARNING: Do not locate
multiple portable socket-outlets
or portable power supplies at the
rear of the appliance.
Feets of the product: in Fs not
available;in built in - the “feet are
not adjustable - and the METOD
cabinet should be levelled with
spririt level.

ENGLISH 9
Product description
Carefully read the operating instructions
before using the appliance.
Refrigerator compartment
(for storage of fresh food and beverages)
1Glass shelves
2Rating plate (at the side of crisper
drawer)
3Crisper drawer
4Thermostat control knob/light
5Dairy lid / Dairy compartment
6Adjustable door balcony
7Metal wire and bottle divider
8Bottle balcony
Freezer compartment
(marked with the symbol for storing
fresh food, frozen food and making ice
cubes)
9Ice cube tray
10 Low Temperature compartment door
Least cold zone
Intermediate temperature zone
Coldest zone
Features, technical information and
images may vary depending on model
First Use
Connect the appliance to the mains power
supply.
The ideal temperatures for preserving food
have already been set at the factory (3-5/
MED).
Note: After switching the appliance on,
it will be necessary to wait for 2 to 3
hours before a temperature suitable for a
standard appliance load is reached.
Accessories
Egg tray
1x
Ice tray
1x
Ice scraper
1x
10
9
4
5
6
7
8
1
2
3

ENGLISH 10
Daily use
Operation of the refrigerator and freezer
compartment
• Use the thermostat knob to adjust
the temperature of the refrigerator
compartment (or both compartments,
depending on the model), as shown in
gure 1. Move the knob to the position
to switch the whole appliance off.
Note: The ambient temperature, frequency
of door opening and position of the
appliance can affect the temperatures
inside the two compartments.
These factors must be taken into
consideration when setting the thermostat.
D
A B C
AThermostat control knob
BLight button
CThermostat position setting notch
DLED light bulb (see instructions near the
light bulb)
Thermostat on 1/MIN:
Low refrigeration level
Thermostat on 3-5/MED:
Medium refrigeration
Thermostat on 7/MAX:
Maximum refrigeration
Thermostat on : Both refrigeration and
illumination are switched off.
Refrigerator compartment
Refrigerator compartment defrosting is
completely automatic. Droplets of water
on the rear wall inside the refrigerator
compartment indicate that the automatic
defrost phase is in progress. The defrost
water is automatically run into a drain
hole and collected in a container, where it
evaporates.
Caution! The refrigerator accessories
must not be placed in a dishwashe
Movable shelves
The walls of the
refrigerator are equipped
with a series of runners
so that the safety glass
shelves can be positioned
as desired.
For better use of space,
the front halfshelves can lie over the rear
ones.
Freezer compartment
This appliance is a refrigerator with a
star rating freezer compartment. Packed
frozen foods can be stored for the period
indicated on the packing. Fresh food can
also be frozen, ensuring that any contact
with already frozen food is avoided. The
quantity of fresh food that can be frozen
in a 24 hour period is given on the rating
plate. Re-freezing of partially defrosted
food is not recommended. This food should
be consumed within 24 hours. For further
information on freezing fresh food, refer to
the quick guide.
Important!
This appliance is sold in France. In
accordance with regulations valid in this
country it must be provided with a special
device (see gure) placed in the lower
compartment of the fridge to indicate the
coldest zone of it.

ENGLISH 11
Helpful hints and tips
Hints for energy saving
• Do not open the door frequently or leave
it open longer than absolutely necessary.
• If the ambient temperature is high, the
temperature regulator is on the higher
setting and the appliance is fully loaded,
the compressor may run continuously,
causing frost or ice on the evaporator.
If this happens, turn the temperature
regulator toward lower settings to allow
automatic defrosting and so a saving in
electricity consumption.
Hints for fresh food refrigeration
To obtain the best performance:
• Do not store warm food or evaporating
liquids in the refrigerator.
• Do cover or wrap the food, particularly if
it has a strong avour.
• Position food so that air can circulate
freely around it.
Hints for refrigeration
• Meat (all types) : wrap in polythene bags
and place on the glass shelf above the
vegetable drawer.
For safety, store in this way only one or
two days at the most.
• Cooked foods, cold dishes, etc.: these
should be covered and may be placed
on any shelf.
• Fruit and vegetables: these should be
thoroughly cleaned and placed in the
drawer.
• Butter and cheese: these should be
placed in special airtight containers or
wrapped in aluminium foil or polythene
bags to exclude as much air as possible.
• Milk bottles: these should have a cap
and should be stored in the bottle rack
on the door.
• Bananas, potatoes, onions and garlic:
if not packed, must not be kept in the
refrigerator.
Hints for freezing
To help you make the most of the freezing
process, here are some hints:
• The maximum quantity of food which can
be frozen in 24 hours is shown on the
rating plate.
• The freezing process takes 24 hours.
No further food to be frozen should be
added during this period.
• Freeze only top quality, fresh and
thoroughly cleaned foodstuffs.
• Prepare food in small portions to enable
it to be rapidly and completely frozen
and to make it possible subsequently to
thaw only the quantity required.
• Wrap up the food in aluminium foil
or polythene and make sure that the
packages are airtight.
• Do not allow fresh, unfrozen food to
touch food which is already frozen, thus
avoiding a rise in temperature of the
latter.
Freezing fresh food
Place the fresh food to be frozen inside the
freezer compartment. Avoid direct contact
with already frozen food. To freeze the
quantity of food shown on the serial tag,
remove the top drawer and place the food
directly on the rack.
Making ice cubes
Fill the ice cube tray up to 2/3 with water
and place in the freezer compartment. Do
not use sharp or pointed objects to detach
the tray.

ENGLISH 12
• Lean foods store better and longer than
fatty ones; salt reduces the storage life of
food.
• Water ices, if consumed immediately
after removal from the freezer
compartment, can possibly cause the skin
to be freeze burnt.
• It is advisable to show the freezing in
date on each individual pack to enable
you to keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this
appliance, you should:
• Make sure that the commercially frozen
foodstuffs were adequately stored by the
retailer.
• Make sure that frozen foodstuffs are
transferred from the foodstore to the
freezer in the shortest possible time.
• Do not open the door frequently or leave
it open longer than absolutely necessary.
• Once defrosted, food deteriorates
rapidly and cannot be refrozen.
• Do not exceed the storage period
indicated by the food manufacturer.

ENGLISH 13
Cleaning and maintenance
Regularly clean the appliance with a cloth
and a solution of hot water and neutral
detergent specically formulated for
refrigerator interiors. Do not use abrasive
cleaners or tools. Use the tool provided
to regularly clean the defrost water drain
outlet, located on the rear wall of the
refrigerator compartment near the crisper
draw, in order to ensure defrost water is
removed correctly (see Fig. 1).
Before servicing or cleaning the appliance,
unplug it from the mains or disconnect the
power supply.
Fig. 1
Defrosting the freezer compartment
It is perfectly normal for ice to form. The
amount of ice which forms and the rate
at which it accumulates will depend on
ambient temperature and humidity, and on
the frequency of door opening.
Set the coldest temperature four hours
before removing food from the freezer
compartment, so as to extend the storage
time of food during defrosting.
To defrost, switch the appliance off and
remove the drawers. Place the frozen food
in a cool place.
Leave the freezer door open to allow the
frost to melt.
To prevent water leaking onto the oor
during defrosting, place an absorbent cloth
on the bottom of the freezer compartment
and wring it out regularly.
Clean the interior of the freezer. Rinse and
dry carefully.
Switch the appliance on again and place
food back in the freezer compartment.
Food storage
Wrap food to protect it from any water,
humidity or condensation; this will prevent
the spread of any odours in the refrigerator,
while also ensuring better storage of frozen
food.
Never place warm food in the freezer.
Cooling hot foods before freezing saves
energy and prolongs the life of the
appliance.
If the event of prolonged disuse
Disconnect the appliance from the power
supply, remove all food, defrost and clean
the appliance. Leave the doors open just
enough to allow air to circulate inside the
compartments.
This will prevent the formation of mould and
unpleasant odours.
In the event of a power cut
Keep the doors of the appliance closed.
This will allow the food to stay cold as long
as possible. If food has defrosted even
partially, do not re-freeze it. Consume within
24 hours.

ENGLISH 14
Problem Possible causes: Solutions:
The appliance does not
operate
There might be a problem
with the electric power
supply to the appliance.
Check that:
• there isn’t a power supply failure
• the power plug is correctly inserted in
the power socket and the two-pole
switch, if present, is in the correct
position (on)
• the electric circuit safety devices
installed in the house are fully functional
• the power supply cable is not broken
The inside LED light bulb
does not work.
The LED light bulb might
need replacing.
Disconnect the appliance from the
electric power supply, check the LED
light bulb and replace with a new one if
necessary (see “Daily use”).
The temperature inside
the compartments is not
cold enough.
There may be several
causes (see “Solutions”)
Check that:
• The doors are closed correctly
• The appliance is not placed near a heat
source.
• the temperature set is appropriate.
• Air circulation through the ventilation
grills at the bottom of the appliance is
not obstructed.
There is water at the
bottom of the refrigerator
compartment
The defrost water drain is
obstructed.
Clean the defrost water drain hole (see
“Cleaning and maintenance”).
The inside light ashes “Door open” alarm active.
It is activated when the
refrigerator compartment
door remains open for a
prolonged period of time.
To stop the alarm, close the refrigerator
door.
On reopening the door, check the light
works
What to do if...
Note:
Gurgling, hissing and humming noises from the refrigerating system are normal.
Remove the LED light bulb
To remove the LED light bulb turn
anticlockwise as shown in gure.

ENGLISH 15
Technical data
Dimensions HUTTRA
Height (min-max) 819-899
Width 597
Depth 545
Net Volume (l)
Refrigerator 108
Freezer 18
Defrost system
Refrigerator Automatic
Freezer Manual
Star Rating 4
Rising Time (h) 10
Freezing capacity (kg/24 h) 2
Energy consumption (kwh/24h) 0.571
Energy consumption (kwh/24h) 0.386*
Noise level (dba) 38
Energy class 3 star rating
Energy class A++*
The technical information is situated
in the rating plate on the internal
side of the appliance and in the
energy label
*(Regulation (EC) No. 1060/2010 of 28 September 2010)
Before contacting the After-Sales Service:
Switch the appliance on again to see if the
problem has disappeared. If not, switch it
off again and repeat the operation after an
hour.
If your appliance still does not work
properly after carrying out the checks listed
in the troubleshooting guide and switching
the appliance on again, contact the After-
sales service, clearly explaining the problem
and specifying:
• the type of fault;
• the model;
• the type and serial number of the
appliance (given on the rating plate);
• the Service number (the number
after the word SERVICE on the
rating plate inside the appliance).

ENGLISH 16
Environmental concerns
1. Packing
The packing material is 100% recyclable
and bears the recycling symbol . For
disposal, comply with the local regulations.
Keep the packing materials (plastic bags,
polystyrene parts, etc.) out of the reach of
children, as they are a potential source of
danger.
2. Scrapping/Disposal
The appliance is manufactured using
recyclable material.
This appliance is marked in compliance with
European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring the correct disposal of this
appliance, you can help prevent potentially
negative consequences for the environment
and the health of persons.
The symbol on the appliance, or on
the accompanying documents, indicates
that this appliance should not be treated
as domestic waste but must be taken to a
special collection centre for the recycling of
electrical and electronic equipment.
When scrapping the appliance, make it
unusable by cutting off the power cable
and removing the doors and shelves so
that children cannot easily climb inside and
become trapped.
Scrap the appliance in compliance with
local regulations on waste disposal, taking it
to a special collection centre;
do not leave the appliance unattended
even for a few days, since it is a potential
source of danger for children.
For further information on the treatment,
recovery and recycling of this product,
contact your competent local ofce, the
household waste collection service or the
shop where you purchased the appliance.
Declaration of conformity
• This appliance has been designed for
preserving food and is manufactured
in compliance with Regulation (CE) No.
1935/2004.
n
• This appliance has been designed,
manufactured and marketed in
compliance with:
- safety objectives of the “Low Voltage”
Directive 2006/95/CE (which
replaces 73/23/CEE and subsequent
amendments);
- the protection requirements of Directive
“EMC” 2004/108/EC.

ENGLISH 17
How long is the IKEA guarantee valid?
This guarantee is valid for ve (5) years - two
(2) years if the appliance is named LAGAN or
TILLREDA - from the original date of purchase
of your appliance at IKEA or from the
installation date with maximum limit of three
months from the purchase date.
The original sales receipt, is required as proof
of purchase.
If service work is carried out under guarantee,
this will not extend the guarantee period for
the appliance.
Once a warranted product has been replaced,
the replaced product warranty will be valid
for the balance period from date of original
purchase invoice
Who will execute the service?
IKEA service provider will provide the
service through its own service operations or
authorized service partner network.
What does this guarantee cover?
• The guarantee covers faults of the
appliance, which have been caused by
faulty construction or material faults from
the date of purchase from IKEA or from the
installation date with maximum limit of three
months from the purchase date.
• This guarantee applies to domestic use only.
• The exceptions are specied under the
headline “What is not covered under this
guarantee?” Within the guarantee period,
• The costs to remedy the fault e.g. repairs,
parts, labour and travel will be covered,
provided that the appliance is accessible for
repair without special expenditure. On these
conditions the respective local regulations
are applicable.
• Replaced parts become the property of
IKEA.
• In case of non-repairable product, the retail
value of the replacement will not exceed
the purchase price that was paid by the
customer
What will IKEA do to correct the problem?
• IKEA appointed Service Provider will
examine the product and decide, at its
sole discretion, if it is covered under this
guarantee. If considered covered, IKEA
Service Provider or its authorized service
partner through its own service operations,
will then, at its sole discretion, either repair
the defective product or replace it with the
same or a comparable product.
What is not covered under this guarantee?
• Normal wear and tear.
• Deliberate or negligent damage, damage
caused by failure to observe operating
instructions, incorrect installation or by
connection to the wrong voltage, damage
caused by chemical or electrochemical
reaction, rust, corrosion or water damage
including but not limited to damage caused
by excessive lime in the water supply,
damage caused by abnormal environmental
conditions.
• Consumable parts including batteries and
lamps.
• Non-functional and decorative parts which
do not affect normal use of the appliance,
including any scratches and possible colour
differences.
• Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of lters, drainage systems or
soap drawers.
• Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
• Cases where no fault could be found during
a technician’s visit.
• Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where non-
original parts have been used.
IKEA GUARANTEE

ENGLISH 18
• Repairs caused by installation which is faulty
or not according to specication
• The use of the appliance in a non-domestic
environment i.e. professional use.
• Transportation damages. If a customer
transports the product to his home or
another address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product to the
customer’s delivery address, then damage
to the product that occurs during this
delivery will be covered by IKEA.
• Damage resulting from power outage,
power surges or dips, uctuating voltage or
improper voltage All workout parts are not
covered by the guarantee e.g.: lters and
cleanliness.
• Cost for carrying out the initial installation
of the IKEA appliance. However, if an
IKEA appointed Service Provider or its
authorized service partner repairs or
replaces the appliance under the terms
of this guarantee, the appointed Service
Provider or its authorized service partner
will reinstall the repaired appliance or install
the replacement, if necessary.
• All plumping and electrical installation, are
not the responsibility of IKEA, and customer
must complete these work before the
execution work.
How country law applies
The IKEA guarantee gives you specic legal
rights, which cover or exceed all the local legal
demands. However these conditions do not
limit in any way consumer rights described in
the local legislation.
Area of validity
This warranty is valid only in the country where
the product has been purchased; the services
will be provided in the framework of the
guarantee conditions.
An obligation to carry out services in the
framework of the guarantee exists only if
the appliance complies and is installed in
accordance with:
- the technical specications of the country in
which the guarantee claim is made;
- the Assembly Instructions and User Manual
Safety Information.
The dedicated AFTER SALES for IKEA
appliances
Please don’t hesitate to contact IKEA
appointed After Sales Service Provider to:
• make a service request under this
guarantee;
• ask for clarications on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture;
• ask for clarication on functions of IKEA
appliances.
To ensure that we provide you with the best
assistance, please read carefully the Assembly
Instructions and/or the User Manual before
contacting us.
How to reach us if you need our service
Please refer to the last
page of this manual for the
full list of IKEA appointed
Authorized Service Centre
and relative national phone
numbers.
In order to provide you a quicker
service, we recommend to use the
specic phone numbers listed on this
manual. Please also always refer to
the IKEA article number (8 digit code)
placed on the rating plate of your
appliance.
SAVE THE SALES RECEIPT!
It is your proof of purchase and required
for the guarantee to apply. The sales
receipt also reports the IKEA name and
article number (8 digit code) for each of
the appliances you have purchased.

UNITED ARAB EMIRATES
Toll free:
Web:
800 4532
www.IKEA.com
:
:
QATAR
Toll free:
Web:
e-mail:
800 4532
www.IKEA.qa
Ikea_qatar@alfuttaim.com
:
:
:
EGYPT
Hotline:
Web:
e-mail:
16576
www.IKEA.eg
IkeaCairo.customerservice@alfuttaim.com
:
:
:
STATE OF KUWAIT
Contact centre:
Web:
e-mail:
+965 18 40 40 8
www.IKEA.com.kw
:
:
:
JORDAN
Contact centre:
Web:
+962 6 400 1000
www.IKEA.jo
:
:
KINGDOM OF SAUDI ARABIA
Contact centre:
Our phone lines are open:
Saturday - Thursday
Friday
92000-4532
09:00 AM - 10:00 PM
2:00 PM - 10:00 PM
:
:
BAHRAIN
Contact centre:
Our telephone lines are open
all day
80001120
09:00 AM - 10:00 PM
:

17
IKEA
IKEA
IKEA
IKEA
IKEA
-
-
IKEA
IKEA
IKEA
IKEA
IKEA
IKEA
i
IKEA
8
i
8IKEA
Other manuals for HUTTRA
4
This manual suits for next models
1
Table of contents
Languages:
Other IKEA Refrigerator manuals

IKEA
IKEA FROSTFRI User manual

IKEA
IKEA LAGAN FCF186/44 User manual

IKEA
IKEA FROSTIG User manual

IKEA
IKEA FROSTIG BCF201/65 User manual

IKEA
IKEA FROSTIG User manual

IKEA
IKEA IK8RXCGMXW00 User manual

IKEA
IKEA NUTID Guide

IKEA
IKEA KÖLDGRADER User manual

IKEA
IKEA LAGAN LFCF223/92 User manual

IKEA
IKEA DJUPFRYSA User manual
