Ikegami PCS-400P Series User manual

PCS-400P Series Dome
Installation & Setup Guide

1
Table of contents 1
Introduction 2
Disposal Instructions 2
List of Contents 3
7HFKQLFDO6SHFL¿FDWLRQ4
Wall Mounting Bracket 6
External / Internal Wall Mount Dome 7
Mounting 7
Address Switches Access 8
Electrical Connections 8
Internal Tile Mount Dome 9
Mounting 9
Address Switches Access 10
Electrical Connections 10
Address Switches Setting and Controller Protocols 11
Unit ID Switch Setting Table A 12
Unit ID Switch Settings Table B 13
Menu Structure - Introduction 14
Menu Structure - Notes 14
Run Menu 15
Setup Menu 16
Motion Menu 16
Motion Menu - Formatting Position 17
Motion Menu - Setting Up a Tour 18
Motion - Setting Up a Mimic Tour 19
Video Settings 20
Joystick Settings 21
Privacy Menu 22
Alarms Menu 23
Alarms Menu - Alarm Mask Setup 24
Alarms Menu - Alarm Holiday Setup 25
Display Options 26
Display Options - Editing Default Position Text 27
Display Options - Displaying Error List 27
Display Options - Setting up Date & Time 28
Special Settings 29
Special Settings - Setting Timout Time 30
Special Settings - Setting Timeout Action 30
Change Password 31
Index 32
Table of contents
Table of Contents

2PCS-400P Series Dome Installation & Setup Guide
Introduction / Disposal Instructions
Introduction
Thank you very much for choosing the Ikegami Fully Functional Dome Camera. Please carefully read this
Instruction Manual to keep your camera at full capacity.
Handling precautions
Do not open the case of camera and never touch
inside, where precision parts are assembled when
the unit is powered as an accident may result.
Be very careful not to drop the camera.
Installation location and conditions
Be sure to keep off the power while installing the
product.
Outline
PCS-400P series is provided with an optical zoom lens
and a ¼” CCD of 440,000 pixels. It is an integrated
CCD camera and high-speed pan and tilt system.
The unit requires external control equipment to
access all functions.
1
2
3
!
Features:
The camera employs a compact optical zoom lens
to support diverse viewing conditions from wide
shots to telephoto.
The camera incorporates a Sens-Up function to
strongly support night time surveillance in dimly
lit areas. The function enables the camera to be
used with illumination of 0.05 lux.
In low illumination, it can automatically switch to
black and white images with sensitivity for infra-
red. This is ideal for monitoring an object clearly.
The camera also can be used as an ultra-sensi-
tive camera in combination with the
Sens-Up function.
The rotating section can move and track at high
speeds.
ü
ü
ü
ü
Instructions for Disposal of Electric and Electronic Equipment
in Private Household
Disposal of used Electric and Electronic Equipment
(Applicable in the European union and other European countries with
separate collection systems)
This symbol on the product, or in the related documents in the package, indicates
that this product shall not be treated as normal household waste. Instead, it
should be taken to a proper applicable collection point or depot for the recycling
of electric and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent possible
negative consequences for the environment and human health, which could oth-
erwise be caused by inappropriate waste handling of this product.
The recycling of materials will help to conserve natural resources.
For more detailed information about recycling of this product, please
contact your local city authority, your household waste disposal service or the
place where you purchased the product.
Introduction

3
Tile Mount Dome
Components supplied:
1. Tile mount dome unit
3RZHUVXSSO\ZLWK¿WWHG$ODUP&DUG
3. Installation and Setup Guide CD
&DYLW\¿[LQJVFUHZV
Wall Mount Dome
Components supplied:
1. Wall mount dome unit
3RZHUVXSSO\ZLWK¿WWHG$ODUP&DUG
([WHUQDO0RGHORQO\
3. Installation and Setup Guide CD
4. Cable assembly
5. Wall mount bracket
List of Contents
List of Contents
List of Contents

4PCS-400P Series Dome Installation & Setup Guide
Technical Specifications
7HFKQLFDO6SHFLÀFDWLRQV
Menu System
The PCS-400P on screen menu system offers a simple, intuitive and powerful interface to the complete set of dome features,
with password protection for increased security.
Password protection: Built in
Languages supported: English, French, Spanish, German, Italian
Drive Capabilities
1XPEHURI3UHVHWV XVHUFRQ¿JXUDEOH
1XPEHURI3DWWHUQ7RXUV PLQXWHXVHUFRQ¿JXUDEOH
1XPEHURI6ORZ7RXUV XVHUFRQ¿JXUDEOH
1XPEHURI)DVW7RXUV XVHUFRQ¿JXUDEOH
Preset Accuracy: 0.05°
Tilt Range: 0 to 90 degrees
   ZLWKZLWKRXWERWWRPÀLS 
Joystick Control: Variable selectable speed ranges for precision control
Variable speed adjustment with zoom depth
Pan speed: 0.01°/s to 360°/s
Tilt speed: 0.01°/s to 200°/s
Preset Moves: Pan speed: 200°/s
Tilt speed: 200°/s
Power Fail: Last action restoration on power up
Software Upgrades: Fully upgradeable over RS-485 link both prior to and post installation
Video System
Privacy Zones: 24
Video Effects: Freeze frame
Video Format: PAL / NTSC
Scanning System: 2:1 Interlace
Image Sensor: 1/4 inch interline transfer CCD
/HQV   &DPHUD6SHFL¿FVHHWDEOH
Camera PCS-418P PCS-426P PCS-436P
Lens 18x optical zoom
I PPZLGHWRPPWHOH
F=1.4 to F3.0
26x optical zoom
I PPZLGHWRPPWHOH
F=1.6 to F3.8
36x optical zoom
I PPZLGHWRPPWHOH
F=1.6 to F4.5
Digital zoom [[ZLWKRSWLFDO]RRP [[ZLWKRSWLFDO]RRP [[ZLWKRSWLFDO]RRP
9LHZLQJDQJOH+ 48.0° ZLGHHQGWR°WHOHHQG 55.0° ZLGHHQGWR°WHOHHQG °ZLGHHQGWR°WHOHHQG
Minimum working distance PPZLGHDQGWRPPWHOHHQG PPZLGHHQGWRPPWHOHHQG PPZLGHHQGWRPPWHOHHQG
2SWLFDO]RRPVSHHG VHFRQGVZLGHWRWHOHSKRWR
'LJLWDO]RRPVSHHG VHFRQGVGLJLWDOZLGHWRGLJLWDOWHOHSKRWR
$QJOHRI9LHZ+  ZLGHWRWHOH
6HQVLWLYLW\  OX[),5(FRORXUOX[),5(%:
Shutter speed: Automatic with manual override
   3DOVVVVV
   176&VVVVV
,ULV&RQWURO  $XWRPDWLFZLWKPDQXDORYHUULGHVWHSV
Focus: Automatic with manual override
White Balance: Automatic
Gain: Automatic
IR Filter: Automatic
Technical Specifications

5
9LGHR2XWSXW  9DULDEOH9SSWR9SSRKPVVWHSV
Video Lift: 8 steps
Communication Protocols
RS-485: Ikegami i-LAN 485
Pelco P
Pelco D
Phillips
Samsung
Dennard
Kalatel
Sensormatic
Ultrack
VTC
Co-axial: Pelco Coaxitron™
BBV
Mechanical Features
,35DWLQJ  ,3RQO\IRU([WHUQDOPRGHO
Housing Construction: Vandal resistant die-cast aluminium
Bubble Construction: Vandal resistant polycarbonate
Internal Mechanism: Die-cast aluminium
Housing Finish: Grey powder coat
Weight: 5.5kg
'LPHQVLRQV  PPGLDPHWHUKHPLVSKHUH[PPKHLJKW([WHUQDO,QWHUQDO
   PP[PP7LOH
Electrical System
Power Supply: 18-28 VAC/DC
Input Power: 10VA nominal
Surge Protection: Built in surge protection
Limited lightning protection
Environmental
(QYLURQPHQWDOVSHFL¿FDWLRQVVXEMHFWWRFKDQJH
0LQWHPSHUDWXUH  ±&RQO\IRU([WHUQDOPRGHO
Max temperature: 50°C
Revision History: 03/11/2006 V1.0
Technical Specifications
Installation :: Technical Specifications

6PCS-400P Series Dome Installation & Setup Guide
Installation - Wall Mounting Bracket
Safety Note!
Make sure the power supply is switched off before connecting the power cable.
!
Installation :: Wall Mounting Bracket
Wall Mounting Bracket
8VLQJWKHEDVHFDVWLQJDVDWHPSODWHGULOODQG¿WZDOOSOXJVWRWKHPRXQWLQJVXUIDFH)LWDQGVFUHZWKHEDVHFDVW-
ing to the mounting surface.
7KHFDEOHORRPQHHGVWREHURXWHGWKURXJKWKHYDULRXVPRXQWLQJEUDFNHWFRPSRQHQWVSULRUWR¿QDODVVHPEO\
3. Screw the Cover to the Base Casting using the 4 x trilobular thread forming screws supplied.
)LWWKH$UP$NH\KROHVVORWVRYHUWKH0VFUHZKHDGV¿WWHGWRWKHFRYHUWKHQURWDWHWRORFNDQGWLJKWHQWKH
screws.
5. Slide the Plastic Cover down the arm, align the two brass pegs in the base casting with the corresponding holes in
the plastic cover and push down.
$WWDFKWKHVHFRQG$UP%WRWKH¿UVWDUPDQG¿WWKHWZR0VFUHZDQGQXWVHWVVXSSOLHG
%HIRUH¿WWLQJWKH'RPHDWWDFKWKH6DIHW\&DEOHWRWKH(\HOHWRQWKHHQGRI$UP%)LWWKH'RPHWRWKHEUDFNHW
DUPE\DOLJQLQJWKHNH\KROHVORWVZLWKWKH0VFUHZKHDGV¿WWHGWRWKH'RPHURWDWHWRORFNWKHQWLJKWHQWKHVFUHZV
8. Slide the Plastic Cover down the arm and locate it as in point 5 above.
Base Casting
Cover
Plastic Cover
Arm B
(with Eyelet)
Safety Cable
Dome
Plastic Cover
Arm A
(without Eyelet)

7
Installation :: External / Internal Wall Mount Dome :: Mounting
Fitting of the Safety Cable:
/LIWWKHSODVWLFFRYHUDZD\IURPWKH¿[LQJSRLQWRQ
the wall bracket.
2. Clip the caribenna at the end of the safety cable into
WKHH\HOHWWKDWLV¿WWHGWRWKHZDOOEUDFNHW
Caribenna
Eyelet
Connecting the Power Cable:
1. Connect power cable to the socket on the top of the
Dome unit.
2. Screw down the locking ring to secure the power
cable.
External / Internal Wall Mount Dome
Mounting
Locking
ring
Power Cable
Socket
Safety Note!
$OZD\V¿WWKHVDIHW\FDEOHEHIRUHFRQQHFWLQJWKHSRZHU
FDEOHDQG¿[LQJWRGRPHWRLW¶VEUDFNHW
!Safety Note!
Make sure the power supply is switched off before con-
necting the power cable.
!
Mounting the Dome Unit:
1. Make sure the four M6 cap head screws are
un-screwed so the heads of the screw are at least 5
mm above the top of the Dome unit.
2. Align the four screws through the holes in the
bracket and rotate the dome so the screws move into
the slots in the bracket.
3. Tighten up the M6 cap head screws with the socket
driver provided.
4. Push the plastic cover back down over the bracket.
M6 Cap Head
Screws
Installation - Wall Mounting Bracket

8PCS-400P Series Dome Installation & Setup Guide
Accessing the Address Switches:
1. Rotate the internal drive, making sure not to touch
the sensitive PCB, until the two address switches can
be seen through the internal cover.
2. The address switches can now be rotated using a
VPDOOÀDWVFUHZGULYHUWRWKHDSSURSULDWHVHWWLQJV
Safety Note!
Make sure the power supply is switched off before
removing the internal mechanism.
Removal of Internal Mechanism:
1. Un-screw the three M5 cap head screws in the lower
housing. The screws are captive and will not fall out of
the lower housing.
2. The internal mechanism will drop by approximately
5 mm. A safety plate in the upper housing will hold it
there.
3. Rotate the internal mechanism anti-clockwise to free
it from the safety plate.
4. The mechanism can now be lowered and the internal
power cable can be disconnected from the top of the
internal mechanism.
Address Switch Access
M5 Cap Head
Screws
Installation - Wall Mount Dome
Installation :: External / Internal Wall Mount Dome :: Address Switch Access
!
Access
Switches
Electrical Connections
The External / Internal Wall Mount Dome external con-
nections are via an Amphenol connector with 1 metre
FRPSRVLWHÀ\LQJOHDGFRPSULVLQJRIFRD[SRZHUSDLU
and RS-485 pair.
The lead should be connected to the boxed PSU that is
supplied with the Dome.
If the lead needs to be extended it should be kept to a
minimum and not exceed 25 m.
The lead connections are as follows:
Red wire: 24 V AC Live
Blue wire: 24 V AC Neutral
<HOORZZLUH  56µ$¶
*UHHQZLUH  56µ%¶
Coax screen: BNC screen
Coax signal: BNC centre pin

9
Internal Tile Mount Dome – Mounting
Hole Cutting Template:
&XWWKHEHORZSUR¿OHLQWRWKHWLOH\RXZLOOEHPRXQW-
ing the Dome into.
Disassemble of Ceiling Mount:
1. Unclip the Cover Ring from the Ceiling Mount Dome.
2. Unscrew the Locking Screw, it is captive in the
Locking Ring and should not completely fall out.
3. Rotate the internal mechanism assembly anti-clock-
wise and remove it from the External Cover.
Installation :: Internal Tile Mount Dome :: Mounting
!
Installation - Tile Mount Dome
Safety Note!
0DNHVXUHWKHSRZHUVXSSO\LVVZLWFKHGRIIEHIRUH¿W-
ting the Internal Mechanism.
Locking
Ring
Cover
Ring
Locking
Screw
External Cover Mounting:
1. Mount the External Cover into the pre-cut tile using
the M4 Cavity Screws supplied
2. Connect the screw terminal block and BNC con-
nector as described in the Ceiling Mount - Electrical
Connection part of this Guide.
Fitting of Internal Mechanism Into External
Cover:
1. Insert the Internal Mechanism into the external
cover. Rotate clockwise until the mechanism moves
further in, then rotate clockwise further until the
mechanism stops turning and the Locking ring clicks.
2. Screw in the locking screw to stop the Internal
Mechanism from being un-screwed.
3. Clip on the Cover Ring.

10 PCS-400P Series Dome Installation & Setup Guide
Installation - Tile Mount Dome
Address Switch Access
1. Remove internal mechanism as shown in section
µ'LVDVVHPEOHRIFHLOLQJPRXQW¶
2. Rotate internal drive until you can access the
address switches through the hole in the internal
housing.
Safety Note!
Make sure the power supply is switched off before wir-
ing up the Dome.
Installation :: Internal Tile Mount Dome :: Address Switch Access
!
Electrical Connections
1. Please see below the electrical connections for the
Ceiling Mount Dome.
2. Wire up the screw terminal socket provided accord-
ing to the pin-out.
Terminal switch
for RS-485
ON OFF
S1 Access
Switches
Coax Screen
Coax Signal
Earth
Earth
RS485 - “A”
RS485 - “B”
24V AC/DC
24V AC/DC

11
Installation - Address Switch Settings
Installation :: Address Switches Settings and Controller Protocols
The address switches are used to set up the control-
ler protocol and the unit ID of each dome. There are
XQLW,'¶VDQGDPD[LPXPRIFRQWUROSURWRFROV
Currently there are 12 485 and 6 up-the-coax control
protocols available.
7KHIROORZLQJ¿JXUHVDQGWDEOHVRXWOLQHKRZWRVHWXS
address switches on a unit.
$GGUHVVVZLWFKHV66DQG6VKRZQLQ)LJXUH
are used to set up the unit ID and the controller proto-
col. S1 and S2 are hex switches used to set the unit ID
DQG6)LJXUHLVXVHGWRVHWWKHFRQWUROOHUSURWRFRO
Address Switches Settings and Controller Protocols
Figure 1. Top view of the address switches
Figure 2. Plan view of S3
Setting the Controller Protocol Using S3
6ZLWFKHVDQG)LJXUHRQ6DUHXVHGWRVHW
WKHSURWRFRO7DEOHVKRZVWKHVHWXSFRQ¿JXUDWLRQIRU
each controller protocol. It also shows which table to
refer to in order to set up the unit ID for that protocol
correctly.
S3 switches Unit Id
Table
Protocol 1 2 3 7
Ikegami PCS i-LAN
ON ON ON A
Dennard 485 A
Pelco P 9600 B
Pelco P 4800 ON A
Phillips 9600 ON B
Phillips 2400 ON A
Kalatel DP ON B
Sensormatic ON ON A
Ultrack ON ON B
Samsung SCC300 ON A
Samsung SSC2000 ON ON ON B
VTC Scorpio ON B
Pelco D 2400 ON ON A
Pelco coax ON ON A
%D[DOODOW¿[HG ON ON ON B
Baxall alternate ON ON ON A
%D[DOO¿[HG ON ON ON B
Baxall ON ON ON ON A
BBV ON ON ON ON B
Table 1. Controller Protocol Switch Settings
Figure 3. Controller protocol switches on S3
NOTE: The unit ID setting is dependant on the
controller protocol. Unit ID Table A can be found on
page 12. Unit ID Table B can be found on page 13.
S1 S2 S3
ON
12345678
ON
12345678
Controller
protocol
switches
S3-8:
Terminal switch
for RS485

12 PCS-400P Series Dome Installation & Setup Guide
Installation - Address Switch Settings
Installation :: Address Switches Settings and Controller Protocols :: Unit ID Switch Settings Table A
Hex Switch
Settings
Camera ID S1 S2
101
202
303
404
505
606
0
808
909
10 0 A
11 0 B
12 0 C
13 0 D
14 0 E
15 0 F
16 1 0
 11
18 1 2
19 1 3
20 1 4
21 1 5
22 1 6
23 1 
24 1 8
25 1 9
26 1 A
 1B
28 1 C
29 1 D
30 1 E
31 1 F
32 2 0
33 2 1
34 2 2
35 2 3
36 2 4
 25
38 2 6
39 2 
40 2 8
41 2 9
42 2 A
43 2 B
44 2 C
45 2 D
46 2 E
 2F
48 3 0
49 3 1
50 3 2
51 3 3
52 3 4
53 3 5
54 3 6
55 3 
56 3 8
 39
58 3 A
59 3 B
60 3 C
61 3 D
62 3 E
63 3 F
64 4 0
Hex Switch
Settings
Camera ID S1 S2
65 4 1
66 4 2
 43
68 4 4
69 4 5
 46
 4
 48
 49
 4A
 4B
 4C
 4D
 4E
 4F
80 5 0
81 5 1
82 5 2
83 5 3
84 5 4
85 5 5
86 5 6
 5
88 5 8
89 5 9
90 5 A
91 5 B
92 5 C
93 5 D
94 5 E
95 5 F
96 6 0
 61
98 6 2
99 6 3
100 6 4
101 6 5
102 6 6
103 6 
104 6 8
105 6 9
106 6 A
 6B
108 6 C
109 6 D
110 6 E
111 6 F
112 0
113 1
114 2
115 3
116 4
  5
118 6
119 
120 8
121 9
122 A
123 B
124 C
125 D
126 E
  F
Unit ID Switch Settings Table A
8VH7DEOH$IRUVHWWLQJWKHXQLW,'¶VZKHQ
using the following controller protocols:
• Dennard 485
• Pelco P 4800
• Phillips 2400
• Sensormatic
• Samsung SCC3000
• Pelco D 2400
• Baxall alternate
• Baxall
Table 2. Unit ID switch settings Table A

13
Installation - Address Switch Settings
Installation :: Address Switches Settings and Controller Protocols :: Unit ID Switch Settings Table B
Hex Switch
Settings
Camera ID S1 S2
181
282
383
484
585
686
8
888
989
10 8 A
11 8 B
12 8 C
13 8 D
14 8 E
15 8 F
16 9 0
 91
18 9 2
19 9 3
20 9 4
21 9 5
22 9 6
23 9 
24 9 8
25 9 9
26 9 A
 9B
28 9 C
29 9 D
30 9 E
31 9 F
32 A 0
33 A 1
34 A 2
35 A 3
36 A 4
 A5
38 A 6
39 A 
40 A 8
41 A 9
42 A A
43 A B
44 A C
45 A D
46 A E
 AF
48 B 0
49 B 1
50 B 2
51 B 3
52 B 4
53 B 5
54 B 6
55 B 
56 B 8
 B9
58 B A
59 B B
60 B C
61 B D
62 B E
63 B F
64 C 0
Hex Switch
Settings
Camera ID S1 S2
65 C 1
66 C 2
 C3
68 C 4
69 C 5
 C6
 C
 C8
 C9
 CA
 CB
 CC
 CD
 CE
 CF
80 D 0
81 D 1
82 D 2
83 D 3
84 D 4
85 D 5
86 D 6
 D
88 D 8
89 D 9
90 D A
91 D B
92 D C
93 D D
94 D E
95 D F
96 E 0
 E1
98 E 2
99 E 3
100 E 4
101 E 5
102 E 6
103 E 
104 E 8
105 E 9
106 E A
 EB
108 E C
109 E D
110 E E
111 E F
112 F 0
113 F 1
114 F 2
115 F 3
116 F 4
 F5
118 F 6
119 F 
120 F 8
121 F 9
122 F A
123 F B
124 F C
125 F D
126 F E
 8F
Unit ID Switch Settings - Table B
8VH7DEOH%IRUVHWWLQJWKHXQLW,'¶VZKHQ
using the following controller protocols:
• Ikegami i-LAN 485
• Pelco P 9600
• Phillips 9600
• Kalatel DP
• Ultrack
• VTC Scorpio
%D[DOODOW¿[HG
%D[DOO¿[HG
• BBV
Table 3. Unit ID switch settings Table B

14 PCS-400P Series Dome Installation & Setup Guide
Menu Structure
PCS-400P Series Dome uses a straightforward, simple, intuitive conventional menu structure which features:
Multilingual: menu can be displayed in English, French, German, Italian and Spanish.
6LPSOL¿HGLQWXLWLYHPHQXV
Minimised menu pages and key entry for actions
Alphanumeric password protection
62 preset positions, 8 fast and 8 slow tours, 4 one-minute joystick mimic tours, all of which are easy to set up
from one screen
Comprehensive alarm options with timed masking
Simple position title insertion
Comprehensive general features
Video gain and lift micro adjust
Real time clock
ü
ü
ü
ü
ü
ü
ü
ü
ü
ü
Menu Structure - Introduction
Menu Structure :: Introduction
Selecting the BACK
arrow will take the user
to the previous menu
screen
The FORWARD arrow
FRQ¿UPVWKHLWHPVHOHF-
tion and returns the user
to the appropriate menu.
The BACKWARD
arrow deletes the last
item selected by the user.
In this guide the
light border indicates the
LWHPLVÀDVKLQJ
Menu Structure - Notes

15
When a programmed position or tour is selected
the menu will be cleared from the screen and the
unit will execute the appropriate function.
If a position or tour is not set a message will be
displayed, POSITION NOT SET or TOUR NOT SET,
respectively.
Access to preset positions 32-62 is possible by
clicking on the FORWARD arrow located under
position 24.
Selecting RUN from the MAIN MENU allows
a user to go to a pre-set position or start a tour.
There are 62 pre-set positions, 8 slow tours (S
fast tours (FDQGRQHPLQXWHPLPLFWRXUVM).
1
Start up screen
1
2
2
Run menu screen
Run Menu
Run menu screen
3
Access to preset positions 1-31 is possible by
clicking on the BACKWARD arrow located above
position 39.
3
Menu Structure - Setup Menu
Menu Structure :: Run menu

16 PCS-400P Series Dome Installation & Setup Guide
The default password is “AAAAAA”; once entered
6 stars displays on the screen and the SETUP menu
appears. If the PASSWORD menu is re-displayed it
means the incorrect password has been entered.
The SETUP menu gives the operator full access
to set up presets and tours as well as other features
of the unit. SETUP menu is password protected.
12
Setup menu Password screen
2
Start up screen
1
Menu Structure - Setup Menu
Setup Menu
Menu Structure :: Setup :: Motion
Selecting MOTION from SETUP menu allows an
operator to set up preset positions and tours.
1
Setup menu screen
1
Selecting a position takes the operator to the
FORMAT POSITION menu.
2
2
Motion menu screen
Motion Menu

17
Motion menu screen Motion menu screen
Motion Menu - Formatting a Position
Menu Structure :: Setup :: Motion :: Format Position
The FORMAT POSITION menu allows the
operator to setup a preset position. The top line
displays the position number and its status.
STORE CURRENT VIEW sets the current unit view
to the currently selected position number.
GOTO POSITION exits the menu and moves the
unit to the position.
EDIT POSITION TEXT takes the operator to the
EDIT POSITION TEXT menu.
DELETE POSITION removes the position and
resets its status.
3
3
Format Position menu screen
4
Edit Position menu screen
In the EDIT POSITION TEXT menu custom
text can be entered which will be displayed on the
screen when at the position.
NOTE: GOTO POSITION, EDIT DEFAULT
TEXT and DELETE POSITION will only function if
the position has been set.
4
1
Access to preset positions 32-62 is possible by
clicking on the FORWARD arrow located under
position 24.
1
2
Access to preset positions 1-31 is possible by
clicking on the BACKWARD arrow located above
position 39.
2
Menu Structure - Setup Menu

18 PCS-400P Series Dome Installation & Setup Guide
Menu Structure :: Setup :: Motion :: Set Up Tour
Selecting a slow (SXRUIDVWFXWRXUIURPWKH
MOTION menu takes the operator to the SETUP
TOUR menu.
A slow tour has a dwell time of 6 seconds and travel
time between positions of 10 seconds. A fast tour
has a dwell time of 6 seconds and a travel time
between positions of 1 second.
2
1
Setup menu screen
2
Motion menu screen
Motion Menu - Setting Up a Tour
In the EDIT TOUR menu, the tour can be set up
by selecting the positions wanted for that tour. Each
tour can contain up to 8 positions.
6HOHFWLQJWKHIRUZDUGDUURZFRQ¿UPVWKHQHZWRXU
setup, whereas the backward arrow deletes the last
position from the tour.
4
3
Set Up Tour menu screen
4
Edit Tour menu screen
SET UP TOUR menu displays the selected tour
and its status.
EDIT TOUR takes the operator the to the EDIT
TOUR menu.
START TOUR will exit the menu structure and ex-
ecute the currently selected tour.
DELETE TOUR deletes the currently selected tour.
NOTE: START TOUR and DELETE TOUR will
only function if the selected tour has been set.
3
Menu Structure - Setup Menu
Selecting MOTION from SETUP menu allows an
operator to set up tours.
1
