Ikegami HSS-200 Quick guide

4 Keyer
16 Input 6 Output
2M/E

Programmable Effects
7 modes of Programmable Effects are available as below:
Assign Mode Preset Wipe Pattern can be customized and stored.
Effect Memory Up to 100 patterns of M/E assignment, Transition pattern and Key Setup can be stored.
User DFE Up to 100 patterns of customized Wipe patterns can be stored
KEY Memory 4 patterns of Key Setup can be stored.
Source Memory Key setup for input sources and Color Corrector Setup can be stored.
Button Memorry 100 patterns of operating order can be stored.
Key Frame Key Frame Memory for 2ch DVE (50 Frames x 14 Register)
CG Wipe can be created with Key Frame and DFE
Customized Wipe Patterns can be stored in Assign Mode.
Preset
System Diagram (including options)
The HSS-200 is a compact 16x6 I/O, 2M/E switcher which is
optimized for live video production such as Flight Rack application
or small mobile van installation.
Optional Tally Ports, Intercom Module, and Sync Generator
support easy system integration.
400 preset/customized Wipe Patterns are available.
Linear Key, Luminance Key, Chroma Key, Pattern
Key or Full Key can be selectable.
Image Effects
Customized Preset Wipe Patterns
Customized

Operation Console and Mainframe
Monitor Selector
4 Sync Generators4-Wire Intercom System (Up to 11 Headsets available)
M/E Remote, VE Console and AUX Remote Configuration
Independent Monitor Tally Outputs and Machine Tally Outputs
Base Station
Base Station
Base Station
Machine Tally
Mainframe
Mainframe
Mainframe
Monitor Tally
PD VE
Speaker
Engineer
Switcher
Main Console
M/E2
Key1,2,3,4
Key Remote
PD
VE
Color Correction Keyer
4CAM 2CAM
SD Camera HD Camera HD Camera
1CAM
Sub Console
M/E1
NTSC-42H
BBS-42H 3Sync 0H
3Sync +1H
HD SDI +1H
HD SDI + 2H
NTSC + 42H
BBS + 42H
4 Sync outputs
Video
HD SDI 0H
DSK
DWC
Producer
TK
1CAM
4CAM
Tally + Intercom + PGM Audio
2 PGM Audio inputs
4CAM 2CAM 1CAM
8.4-inch Touch Panel
Intercom Jack Panel
USB Port
System Examples (with Options)
UPC
VTR Selector
Mainframe Rear Panel (with Options)
Operation Console
19-inch Rack Mountable
4RU
Operation Console
Supports PGM/PST transition
14 Cross Point Buttons
8.4-inch LCD Touch Panel
USB port for Setup Data Storage
19-inch Rack Mountable Width
and 4RU Height
Low Power Consumption, 150W or less
19-inch Rack Mountable Width and
3RU Height
Optional Tally, Intercom, GPI, Sync
Generator and Editor I/F available
Mainframe
3RU

Configurations
Rating / Performance
1. Standard Configuration
Description Feature
HSS-200 Mainframe 16 Input and 6 Output, 2M/E, 2ch DVS-084 2D DVE Sub Module installed, 3RU Height
DCC-037 Operation Console 2M/E, 19-inch rack witdth, Rackmountable, 4RU Height
2x AC Cable for Mainframe and Operation Console
Stanadard Accessory 1x 5m ARCNET Cable
1x 5m ETHERNET Cable
1x CD-R, PDF Operation Manual
2. Factory Option
Description Feature
DVS-070 3D DFE Sub Module 1ch 3D DFE Sub Module, Up to 2x DVS-070 can be installed.
DVS-084 2D DFE Sub Module 1ch 2D DFE Sub Module, Up to 2x DVS-084 can be installed.
4-Wire Intercom Function Supports up to 11 Headsets, Including Machine Tally/Intercom Rear Panel
DCP-004 Intercom Module(2x) Intercom Terminal for Operation Console (*1)
Monitor Tally Connector Panel 18 Separate Tally Out Connectors, Red/Green Tally Open-Collector Output
Additional Still Store/Frame Symchronizer Still Store: Output 2ch
- > 8ch / 7 Frames - > 28 Frames, FS: 1ch - > 4ch (*2)
4ch Sync Generator 4ch Black Burst/Tri-level Sync Output
Output Matrix Function Additional Cross-points for 3 inputs to assign AUX1-4 Outputs
Monitor Tally Multi-Connector Red/Green Tally Open-Collector Output assigned to 68 pin Multi-Connector (*3)
4ch GPI Port 4x XLR-4 Connector
Redundant Power Supply for Mainframe One AC Input is used for 2 Power Supplies
RS-422 Interface For RS-422 Editor Interface
3. Other Option
Description Feature
Desk Mount Adaptor for Console Mount Adaptor for Console
Rack Mount Adaptor for Console Mount Adaptor for 19-inch Rack with Drawer Mechanism
Slide Rail Set for Mainframe To fix rear side of Electronic Frame onto Rack
Carrying Case for Console Open Top Type
Carrying Case for Mainframe Front/Rear Open Type
Operation Manual (Printed Book) CD Manual included as Standard Accessory
4. Remote Panel / Adaptors
Description Feature
DCC-040 M/E Remote Panel Able to assign 1M/E to DCC-040
DCP-230 CTRL-16 Panel 8 Buttons / 2 Rows, AUX Bus Control Panel, 19-inch Half Width / 1RU
Rack Mount Adaptor for DCP-230 19-inch Width with Blank Panel
DCP-142 CTRL-32 Panel 16 Buttons / 2 Rows, AUX Bus Control Panel, 19-inch Width / 1RU
DCX-122 CTRL-16 Box 8 Buttons / 2 Rows, AUX Bus Control Box
DCX-110 CTRL-32 Box 16 Buttons / 2 Rows, AUX Bus Control Box
DPX-002 AC Adaptor AC Adaptor for Remote Panel/Box
DCF-035 ARCNET HUB 8 Ports / 50W Power Supply, 19-inch Half Width / 1RU
DCF-032 ARCNET HUB 16 Ports / 100W Power Supply, 19-inch Width / 1RU
DCF-033 ARCNET HUB 16 Ports / 100W Power Supply, 19-inch Half Width / 1RU
Rack Mount Adaptor for DCF-033/035 19-inch Width with Blank Panel
DCX-160 KEY REMOTE BOX XLR-4 Connector Interface
DCB-493 SW-4DSK Unit 4 DSK Controller
DAX-003 Intercom Terminal Box Supports 4-Wire Intercom with Headset Amplifier (*1)
DCX-175 VE Console Box Color Corrector/Keyer Control Box (Table Top)
DCP-234 VE Console Panel Color Corrector/Keyer Control Panel (Rack Mount)
Rack Mount Adaptor for DCP-234 19-inch Width with Blank Panel
DCP-235 VE Console Panel Color Corrector/Keyer Control Panel (19-inch Drawer Mount)
DCX-173 Tally Distribution Box R/G Tally and M/E Tally Distribution for 16 Input Source
DCX-142 Tally Box R/G Tally and Source Name Indication
ARCNET IF Unit Adsub1549A-5000 (USB
< = > ARCNET Conversion) for SST (*4)
Note:
*1: Optional '4-Wire Intercom Function' required
*2: SS and FS share the internal memory with trade-off basis (2ch SS = 1ch FS)
*3: Either Multi-Connector or Separate Connectors can be installed
*4: Ikegami's original Setup Terminal Application
Video Input 16 Inputs / HD-SDI (SMPTE292M) or SD-SDI (SMPTE259M)
Video Output 6 Outputs / HD-SDI (SMPTE292M) or SD-SDI (SMPTE259M)
External Sync Input Tri-level Sync, ±0.3V High Impedance or Black Burst, 0.286Vp-p High Impedance
Video Delay 1.0H Typical, ±0.3H adjustable
AVDL Timing -1.3H
~ +0.7H against Reference Signal
Output Phase control Range +0.3H
~ +1.3H against Reference Signal
Control System Delay 3VD (50ms) or less
Ambient Temperature 0
~ 40 ˚C (+32 ~ +104 ˚F): Full Performance Assured
0
~ 45 ˚C (+32 ~ +112 ˚F): Operation Assured
Control Cable ETHERNET: 100Base-TX/RJ-45 Cable, Up to100m
ARCNET: @BNC 75 ohm Cable, Up to 200m
Power Requirement 117VAC (85V
~ 132V) / 220VAC (170V ~ 264V), 50/60Hz
Recovery after Power Down Within 24 hours: Automatic recovery as it was.
Over 24 hours: Back to initial user setup.
Dimensions Operation Console: W483 x H155 x D420 mm ( W19.02 x H6.10 x D16.54 inch) / 4RU
Mainframe: W483 x H132 x D500 mm ( W19.02 x H5.20 x D19.69 inch) / 3RU
Power Consumption Operation Console: 50VA or less
Mainframe: 150VA or less
Weight Operation Console: 11kg (24.25lbs)
Mainframe: 15kg (33.07lbs)
SH93A103-HI
Design and specifications are subject to change without notice.
