Ikelite PowerShot A610-A620 User manual

Digital Housing
instruction manual
for
Canon
PowerShot A610-A620
Housing
#6140.62

Congratulations on your purchase of an Ikelite Digital Camera
Housing. Ikelite has over 40 years of experience in the underwater
photographic and lighting market. Our products are designed and
built in the USA by Ikelite for both the professional and amateur
photographer.
The clear housing permits instant visual inspection of the camera
and all sealing surfaces as well as complete monitoring of controls
and camera LCD screens.
Ikelite Digital Housings are slightly negative in salt water for
stability. This housing has been water pressure tested at the
factory. Housing is pressure tested to 200’ (60m).
Ikelite Digital Housing
instruction manual
#6140.62 for Canon PowerShot A 610, A 620
2
P
Pl le ea as se eR Re ea ad d
We suggest that you read this instruction booklet thoroughly
before use. If you are new to underwater photography be sure
to read the General and Photo Tips.
We also suggest that you read the camera manual thoroughly
to have a full understanding of where each camera control is
located and what function each control provides.
3
Front View
Shutter
Release
Lid
Snap
Exposure
Display
Print/Share
Mode
Flash
Menu Macro
Function
Lid
Snap
Lens
Port
Back View
Ô
Ô
Lanyard
Thumb
Rest
On/Off
Shooting Mode
Zoom
4
O
Op pe en ni in ng gt th he eH Ho ou us si in ng g
1. Lid Snaps have a L
Lo oc ck k.
To open, push Lid Snap Lock
forward and lift as shown.
Keep pressure on the Lid
Snap so it does not fly open
quickly.
Some lid snaps have a lot of
spring tension once they go over center, have a firm grip on the
lid snap. Lid Snaps may be opened one at a time.
I
In ns st ta al ll li in ng gt th he eC Ca am me er ra a
Remove the back from the housing. The mounting tray for the
camera is secured
to the housing
back. Position the
camera on the tray
and secure it with
the mounting bolt
which threads into
the camera’s tripod
socket. U
Us se ea ac co oi in n
o
or rf fl la at tb bl la ad de ed d
s
sc cr re ew wd dr ri iv ve er rt to o
t
ti ig gh ht te en nt th he e
m
mo ou un nt ti in ng gb bo ol lt ts so o
t
th he ec ca am me er ra ai is sf fl la at t
a
ag ga ai in ns st tt th he et tr ra ay y. .
C
CA AU UT TI IO ON N: :
Some camera tripod socket threads are plastic. The mounting
tray bolt is metal. Do not cross thread or over tighten as you
may damage the camera tripod socket threads.
Lift
Push Forward
Lid Snap Lock
CAMERA / MOUNT
Lid
Hook
O' Ring
Mounting Bolt
Mounting
Tray

6
C
Ch he ec ck ki in ng gC Co on nt tr ro ol ls s
Once the housing has been closed, push the controls back into
place. Make sure they line up with the camera’s controls.
T
Tu ur rn nC Ca am me er ra aO On n
Turn the camera on and operate each of the housing controls to
get a feel for using the camera in the housing. Take a few
pictures above water with the camera in the housing.
Z
Zo oo om mC Co on nt tr ro ol l
(NOTE:) After you have used the
housing’s zoom control it must be
returned to the center position to
disengage. If the housing zoom
control is pushing the zoom lever
in either direction the camera
may not take a picture or access
any other function as the camera
is receiving a signal from the
engaged zoom control.
+- +-
Zoom control
engaged
Zoom control
disengaged
(centered)
5
C
Cl lo os si in ng gt th he eH Ho ou us si in ng g
1. Place housing face down in your
lap or on flat surface.
2. Check to see that there is an
o’ring on the housing back and
that it is clean and in its proper
location.
3. Guide the back onto the housing.
The o’ring should touch the
housing all the way around. There
should be an even gap all the way
around between the housing and
the housing back.
4. Lift the lid snaps so they are
extended and place the lid snap
into the hook on the housing
back.
5. To close the housing push
down on the lid snaps until
they snap into place . Lid
snaps on opposite sides of the
housing should be closed at the
same time. Be sure they are down
far enough to engage the lock.
D
Do ou ub bl le ec ch he ec ck k- Once the housing is closed, check the o’ring seal.
Check the gap between the housing back and the housing, it
should be even all the way around.
Look through the clear plastic back at the o’ring. You should see a
darkened area where the o’ring is compressed against the
housing back. If you do not see an even black compression seal
all the way around the back, open the lid snaps, reseat the
housing back and close the lid snaps. Visually check the seal again.
o’ring
housing back
housing back
housing
housing
o’ring
even gap
all 4 sides
7
L
Lu ub br ri ic ca an nt ts s
1. Ikelite provides silicone lubricant with the housing. We recommend
you use only Ikelite lubricant on Ikelite products as some other
brands may cause the o’ring to swell and not seal properly.
2. Use only enough lubricant to lightly cover control shafts and
o’rings. Wipe off any excess lubricant with a clean cloth.
Lubricant is not a sealant, it is used to reduce friction. Excessive
lubricant can collect sand and dirt which may interfere with
proper sealing.
C
CA AU UT TI IO ON N
N
Ne ev ve er ru us se es sp pr ra ay yl lu ub br ri ic ca an nt ts sa as st th he ep pr ro op pe el ll la an nt ti in ng gr re ed di ie en nt tc ca an n
c
ca au us se et th he ep pl la as st ti ic ch ho ou us si in ng gt to oc cr ra ac ck k. .
8
D
Di if ff fu us se er r& &D De ef fl le ec ct to or rI In ns st ta al ll la at ti io on n
Housing shown with
Diffuser installed.
Diffuser
U
Us si in ng gF Fl la as sh h
U
Us si in ng gt th he eC Ca am me er ra a’ ’s sB Bu ui il lt t- -i in nF Fl la as sh h. .
If you do not have an external flash the camera’s built-in flash
can be used. See Diffuser instructions.

9
D
Di if ff fu us se er ra an nd dD De ef fl le ec ct to or rc co on nt t. .
A diffuser and deflector are
included with the housing.
The diffuser is white
transparent plastic. The
deflector is also white but
is not transparent and has
adecal on the front.
To install the diffuser or
deflector spread the port
clamp at the spring end
and slide over the lens port.
The white plastic should be
placed in front of the
camera flash. The port
clamp should be pushed
back against the front of the housing.
D
Di if ff fu us se er r
The diffuser should be installed when using the camera’s built in
flash. When shooting with the camera’s built-in flash at
approximately 2 feet (0.6 m) or less, the lens port on the
housing may block a portion of the light from the camera’s
built-in flash, creating a shadow in the lower left of the photo.
If this occurs, zoom the lens slightly to eliminate the shadow.
(You can test this above water)
D
De ef fl le ec ct to or r
The deflector should be installed when using an external strobe
such as the DS51 or DS125 Substrobe and EV Controller. The
deflector will redirect the camera’s flash to the EV Controller
which controls the external strobes output.
Diffuser/Deflector material
Port Clamp
Spring
Spread to Install
10
L
Le en ns sP Po or rt t
The Lens Port is factory sealed, do not remove.
Treat the glass in the lens port as a camera lens. After use, rinse
and gently dry the lens port to avoid water spotting. To clean
use a mild soap solution or lens cleaner.
Do not use alcohol or window cleaner on the Lens Port.
The Lens Port is threaded so that accessory lenses can be
screwed onto the port. The threads are very fine, take care not
to cross thread the lens.
Wide angle lenses are available from Inon, Sea & Sea and
Epoque. These lenses can be screwed onto the lens port above
or below water. These lenses are designed to have water
between the front of the port and the accessory lens. Make sure
no air bubbles are trapped between the port and the accessory
lens. There may be slight vignetting when these wide angle
lenses are installed. Any vignetting that occurs can be
eliminated by zooming the camera lens slightly. To properly
light subjects when using
a wide angle lens an
external strobe should be
used. Due to the wide
angle of coverage of the
Inon,Sea & Sea and
Epoque lenses, the DS125
Substrobe is
recommended or two
DS51 Substrobes.
Wide Angle Lens
Housing shown with
accessory wide angle lens.
11
O
Op pt ti io on na al lA Ac cc ce es ss so or ri ie es s
B
Ba ac ck kO O’ ’r ri in ng g##00110099
O’rings last for several years if properly maintained. (See
maintenance) Always carry a spare.
U
UR R/ /P Pr ro oF Fi il lt te er r##66444411..4411
The UR/Pro underwater color correcting filter is designed to
restore some of the warm colors filtered out by the water. For
available light use only, not recommended for use with flash.
T
Tr ra ay yw wi it th hR Re el le ea as se eH Ha an nd dl le e##99552233..3311
Tray and Release Handle is required to mount external
Substrobes.
12
Substrobe
DS51
EV Controller
Ball Socket
Arm
O
Op pt ti io on na al lA Ac cc ce es ss so or ri ie es s
S
Su ub bs st tr ro ob be eD DS S5 51 1P Pa ac ck ka ag ge e##33994444..5577
The Substrobe DS51 package includes
the Substrobe DS51, the EV
Controller and ball socket arms. The
EV Controller provides 10 manual
power settings in 1/2 stop
increments. An external strobe
offers several advantages over using
the camera’s built-in flash. External
strobes move the flash away from
the camera lens which helps reduce
backscatter. They also expand
lighting options to achieve the best
lighting for different subjects. A
second external digital strobe
package can be added to fill the
shadows and produce more realistic
photographs.
The Substrobe DS51 covers the
equivalent of a 28mm lens. It is the
ideal choice when using only the
camera lens or the camera lens with
a macro accessory lens.
If an accessory wide angle lens wider
than 28mm is used, the ideal
lighting choice is the Substrobe
DS125, which covers 100 degrees, or
two Substrobe DS51’s can be used.
N
NO OT TE E: :
Optional Tray and
Release Handle
required to mount
Substrobes.

13
Substrobe
DS125
EV Controller
Ball Socket
Arm
O
Op pt ti io on na al lA Ac cc ce es ss so or ri ie es s
S
Su ub bs st tr ro ob be eD DS S1 12 25 5P Pa ac ck ka ag ge e##33994444..7777
The Substrobe DS125 package
includes the Substrobe DS125, the EV
Controller, ball socket arm and
charger. The EV Controller provides
10 manual power settings in 1/2 stop
increments. An external strobe offers
several advantages over using the
camera’s built-in flash. External
strobes move the flash away from
the camera lens which helps reduce
backscatter. They also expand
lighting options to achieve the best
lighting for different subjects. A
second external digital strobe
package can be added to fill the
shadows and produce more realistic
photographs.
The Substrobe DS125 covers the
equivalent of a 18mm lens, 100
degrees. It is the ideal choice when
using accessory wide angle lenses
greater than 28mm.
N
NO OT TE E: :
Optional Tray and
Release Handle
required to mount
Substrobes.
15
C
Co on nt tr ro ol lM Ma ai in nt te en na an nc ce e
Ikelite controls are designed to provide years of reliable service
with minimal maintenance.
1. Push button controls require no maintenance other than rinsing
in fresh water after saltwater use. If a push button control
becomes difficult to push or if it sticks when depressed, soak the
housing in luke warm fresh water. After a few minutes operate
the push button. If this does not correct the problem, return the
housing to Ikelite for maintenance.
2. Some of the controls have long shafts. These controls can be
pulled out, exposing the shaft (see drawing).
To lubricate the control, gently pull on the knob until the
stainless steel shaft is exposed. Lightly lubricate the shaft, then
move the shaft in and out several times. This will lubricate the
x’ring in the Ikelite control gland. This should be done before
using the housing after a prolonged storage period, or once a
week when the housing is in use.
housing
lubricate shaft
pull out to
expose shaft
14
M
Ma ai in nt te en na an nc ce e
The Ikelite Digital Housing should be given the same care and
attention as your other photographic equipment. In addition to
normal maintenance we recommend that the housing be returned
to Ikelite periodically to be checked and pressure tested.
1.D
Do oN No ot tleave the camera and housing in direct sunlight for
prolonged periods. Heat may damage the camera.
2. D
Do oN No ot tship the camera in the housing.
3. Before using the housing, always check the tightness of the s
se et t
s
sc cr re ew win each control knob.
Check each c
co on nt tr ro ol lg gl la an nd dpenetrating the housing to make sure
they are tight. There is a slight chance that either could vibrate
loose during travel.
4. Keep the back o’ring clean and lightly lubricated. To lubricate
remove the o’ring from the back. Put a small amount of lkelite
lubricant on your fingers. Draw the o’ring through your fingers
to apply a light coating of lubricant. Only apply enough
lubricant to make the o’ring feel slick. D
Do oN No ot ts st tr re et tc ch ht th he eo o’ ’r ri in ng g.
This light coating of lubricant will help to keep the o’ring from
drying out and will help to show a dark sealing line when the
housing back is properly sealed.
5. Keep the area where the o’ring fits and the sealing surface of
the housing clean.
6. Rinse the housing exterior thoroughly in fresh water after each
salt water use. Dry with a soft cloth. Dry lens port to eliminate
water spotting.
After several uses in salt water soak the housing exterior in a
mild soap solution, rinse and dry before storage. When storing
the housing, remove the back o’ring, lightly lubricate and place
in a plastic bag. Place the plastic bag with o’ring inside the
housing for safe keeping.
C
CA AU UT TI IO ON N
N
Ne ev ve er ru us se es sp pr ra ay yl lu ub br ri ic ca an nt ts sa as st th he ep pr ro op pe el ll la an nt ti in ng gr re ed di ie en nt tc ca an n
c
ca au us se et th he ep pl la as st ti ic ch ho ou us si in ng gt to oc cr ra ac ck k. .
16
C
Co on nt tr ro ol lM Ma ai in nt te en na an nc ce eC Co on nt t. .
3. Some of the controls have a short shaft and cannot be pulled
out exposing the shaft for lubrication. In the unlikely event one
of these controls sticks or becomes difficult to operate you can
remove the control from the housing and lubricate it, or return
the housing to Ikelite for maintenance. To remove the control,
loosen the set screw in the knob (allen wrench required);
remove the knob. If there is salt or dirt build-up on the exposed
control shaft, clean the shaft. Open the housing and gently slide
the control shaft out of the control gland. Clean and lightly
lubricate the shaft, including the end of the shaft. Slide the
shaft back into the control gland and gently slide it back and
forth a few times without fully removing the shaft from the
gland. Replace the knob, NOTE the flat area on the shaft, the
set screw in the knob should tighten down against the flat area
on the control so the knob does not turn on the shaft.
Loosen set screw
(allen wrench required)
Flat
Tighten set screw down
against this area when
replacing the knob.
housing gland
control
shaft
Lubricate end of shaft
before reinserting into
gland

17
G
Ge en ne er ra al lT Ti ip ps s
1. Due to the power required to operate the camera, flash, and
LCD screen it is a good idea to start each dive with a fresh set of
batteries.
2. Some cameras reset their flash to AUTO when the camera is
turned on. If you prefer another setting be sure to select it.
3. As soon as you enter the water, take a moment and check the
housing to see that it is properly sealed.
4. Next, check to see if there are any bubbles on the face of the
lens port. If there are, take your finger and remove them. If
there are bubbles on the lens port they can produce soft focus
spots in your photographs.
N
NO OT TE E
5. If you are shooting with the camera’s built-in flash and the
cameras lens is set to the widest angle you may need to zoom
the lens slightly or a shadow may appear in the lower left
corner of close-up photographs. The lens port may block some
of the light. Installing the flash diffuser will help to eliminate
the shadow.
(You can test this above water)
To shoot photographs closer than 2 feet (0.6m), you need to
use an external strobe such as the DS51 or DS125. With an
external strobe you can position it so nothing blocks the light
path between the strobe and the subject.
18
P
Ph ho ot to oT Ti ip ps s
1. The number one rule in underwater photography is eliminate as
much water between camera and subject as possible. Get as
close as you can to the subject, then use the zoom. If you are
using flash, subjects beyond 6 feet (1.8m)will not have much
color.
2. The camera’s built-in flash is very close to the camera lens. The
flash can light up any suspended particles in the water and they
can be recorded in your picture. This effect is called backscatter.
To eliminate as much backscatter as possible, photograph close.
Photograph in clear water; do not stir up the sand or silty
bottom. If backscatter becomes a problem in the environment
you are photographing, an external flash will help eliminate
much of the backscatter.
3. Digital cameras have a slight lag time between when you press
the shutter release button and the camera actually takes the
picture. Hold the camera steady a second or two after pressing
the shutter release button.
4. Do not shoot down on subjects as they will quite often blend
into the background and be difficult to see in the photograph.
Shoot subjects straight on or shoot up at a slight angle using
the blue water as a contrasting background.
5. Underwater flash is used to restore the warmer colors filtered
out by the water as well as to illuminate the subject. When
photographing underwater, set the camera to use flash on
every shot. If the camera’s flash is set to AUTO and the sun is
behind your subject, the camera may see enough light that it
does not fire the flash. With the sun behind the subject the
subject is shaded (dark) and needs flash for a good exposure.
R
Re et tu ur rn ni in ng gP Pr ro od du uc ct ts sf fo or rS Se er rv vi ic ce e
Ikelite is most interested in preforming any service to assure that
all products perform as intended. For repair or service, return
the product to the address below with your name, address,
phone number and a brief description of the problem. Evidence
of purchase date must be provided to obtain warranty service.
I
Ik ke el li it te eU Un nd de er rw wa at te er rS Sy ys st te em ms s
5
50 0W W3 33 3r rd dS St tr re ee et t
I
In nd di ia an na ap po ol li is s, ,I IN N4 46 62 20 08 8U US SA A
3
31 17 7- -9 92 23 3- -4 45 52 23 3
e
em ma ai il l: :i ik ke el li it te e@ @i ik ke el li it te e. .c co om m
w
ww ww w. .i ik ke el li it te e. .c co om m
D
Di ig gi it ta al l6 61 14 40 0. .6 62 2- -0 01 1- -1 12 20 05 5
I
Ik ke el li it te eL Li im mi it te ed dW Wa ar rr ra an nt ty y
All Ikelite products are warranted against any manufacturing
defects for a period of one (1) year from the date of purchase.
Defective products should be returned prepaid to Ikelite. Ikelite
will, at its discretion, repair or replace such products, and will
return to customer prepaid. All other claims, of any nature,
including but not limited to bulb failure are not covered. Except as
mentioned above, no other warranty expressed or implied, applies
to this Ikelite product.
19
P
Ph ho ot to oT Ti ip ps sC Co on nt t. .
6. When using daylight or flash if your camera consistently over
or underexposes the image you may want to adjust your
camera’s exposure compensation settings. Many cameras allow
you to adjust both available light and flash exposure with an EV
control in the camera’s menu.
7. Many photographers transfer their images to the computer
where they can fine tune the appearance of the image. Many of
the image manipulation programs make you think you can
magically correct any image taken and make a good picture.
One thing to remember when using image manipulation
programs, if the image is overexposed much of the color is
missing. If the color is missing you cannot adjust it. If images
are slightly underexposed the color is there, it is just dark and
you can adjust it to some degree. So if you error in exposure it
is better to have the image slightly underexposed than over
exposed.
