Ikon 3212 User manual

Waste Disposer
User Manual
3212/3213
IKON COMMERCIAL LTD
18 Charlies Way, Frankton, Hamilton, New Zealand, 3204
Phone [phone] Fax [phone]
Website www.ikoncommercial.co.nz

Please read the following before using the
food waste disposer:
1 Please read the manual before using the food waste disposer.
2 Please supervise children nearby when using the food waste
disposer to prevent potential hazards.
3 Please don’t insert fingers into the disposer when the disposer
is in use.
4 Please unplug the waste disposal, before attempting to clean
disposer or take out objects from inside disposer.
5 Please don’t put the following objects into the disposer to
dispose:
A: shells
B: Drain cleaner
C: Glass, wood, plastic or any hard materials
D: Large, whole bones
E: Metal, such as bottle caps, tin cans, or aluminum foil
F: Whole corn husks
6 When not operating the disposer, leave the plug in the sink
flange to prevent objects falling into disposer.

1 Parts installation drawings
B Series installation parts（Picture 1.1）
Code: 3212/3213
Food Waste Disposer Users’ Manual Food Waste Disposer Users’ Manual
1
9
10
11
12
13
2
3
4
5
6
7
8
（Picture 1.1）
1. plug
2. Sink flange
3. rubber gasket
4. sink gasket
5. Fiber lining
6. Flange nut/
tightening screw
7. Clamp ring
8. Splash guard
Installation parts Disposer Discharging parts
0201
9. Dishwasher water inlet 10. Rubber seal
11. Pipe flange
12. hexagon socket screw
13. Discharging bending pipe
2 Check the installation size
1. Disposer's height(1)
2. The bottom of sink to the middle of discharge outlet
3. Disposer's width(4)
4. Disposer's vertical center line to the vertical center
line of "U" pipe.(5)
3 Disconnect Sink Drain
1. Loosen nut at the top of trap with pipe wrench.
2. Loosen nut at the top of extension pipe. Remove extension pipe.
3. Loosen nut at base of sink flange.
4. Push sink flange up through sink hole and remove it.
5. Clean sink flange area of any putty or other debris.
4 Disassemble New Disposer Mounting Assembly
2-1. Unlock the lock catch of the snap ring, take off the snap ring.
2-2. Take off the sink flange.
1
45
（2.1）
3 2
（Picture 5.1）
5 Attach Upper Mounting Assembly to Sink
1-1. Use plumbers putty under sink flange. Ensure sink hold area
is clear of debris and place sink flange into sink hole.
1-2. Working from under the sink, slip rubber gasket, fiber lining over the
sink flange, and then mount the feeding mouth locking screw and lock up.
1-3. Tighten three mounting screws up to sink until mounting
assembly is seated tightly and evenly against sink.

0403
6.Dishwasher Attachment And Overflow Connection
Wastewater from a dishwasher can be plumbed into the disposer
through the inlet access on the upper part of the disposer. There is a
plug on the inside of the inlet tube
Food Waste Disposer Users’ Manual
1
（Picture 7.1）
Note: If the dishwasher connection is made without removing the plug, the
dishwasher may overflow.
Remove Knockout Plug （Picture 7.1）
1. Lay disposer on its side and insert screwdriver （1）
into the dishwasher inlet so tip rests on outer edge of
knockout plug.
2. Tap end of screwdriver handle with hammer until molded
plug breaks loose.
3. Remove loose knockout plug from inside disposer.
If you have a sink overflow, it should be connected to the overflow
inlet on the tailpipe. To connect the overflow, remove the plug in
the tailpipe by unscrewing the overflow connector cap.
7. Connect Disposer to Mounting Assembly
Note: To avoid personal injury, do not position your head or body under disposer, the
unit could fall during installation.
Clear any objects from inside the disposer grind chamber before mounting
the disposer to the sink.
1. This product must be installed so that the motor reset button
located on the bottom of the disposer is readily accessible.
Keep this space clear of all objects.
2. Lift the disposer, inset the top end into the mounting assembly and
turn. So the mounting assembly bottom end end can slide into the
splash guard slot.
3. Mount the Locking ring and lock it up
4. Run water into sink, then check for leaks. Insert sound baffle into
sink flange.
8.Attach Discharge Tube to Waste Drain Pipe
Do not use plumbers putty on any other disposer connection other than on sink
flange. Do not use thread sealants. These may harm disposer and cause property
damage.
Regularly inspect disposer and plumbing fittings for water leaks, as water leaks can
cause property damage. Manufacturer can not be held responsible for property
damage as a result of water leaks.
Discharge pipe installation （Picture 9.1）
1. Place metal flange over discharge tube.
Insert rubber gasket with gasket lip facing
the metal flange into discharge tube.
2. Secure metal flange and discharge tube
to disposer with bolts.
3. Rotate disposer so that discharge tube
is aligned with drain trap. ( To prevent
leaks, do not pull or bend discharge
tube to drain trap.) If discharge tube
is too short, you can purchase an
extension from hardware store.
4. Place nut, then ferrule on discharge tube and tighten on drain trap.
(If you have a double sink, use separate drain traps for both sides
of sink.)
Ensure lower mounting ring is still securely locked over ridges on
mounting flange.
（Picture9.1）
Food Waste Disposer Users’ Manual

Food Waste Disposer Users’ Manual
0605
Food Waste Disposer Users’ Manual
9. Connect Disposer to Electrical Supply（10.1）
Warning Electrical shock
· To avoid electrical shock, disconnect power
before installation or servicing disposer.
· If you are not thoroughly familiar with electrical
power, contact a qualified electrician to connect
disposer to electrical circuit.
· If three-prong, earth plug is used, plug must be
inserted into three hole, earth receptacle.
· All wiring must comply with local electrical codes.
· Do not attach earth wire to gas supply pipe.
· If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similar qualified
persons in order to avoid hazard.
Note：You must have access to an earth wall socket. Any additional socket should
befitted by a qualified electrician and properly earthed. The disposer is fitted with a
molded plug and cable.
On/off Control
Connect to a 10 amp earth wall socket using a 10 amp cable.
◎Air Switch：
Air switch is included with each disposer. An air switch activates/turns
off the unit by sending a pulse of air to the control box.
◎Air Switch Installation
1. Drill a 33mm wide hole into the kitchen work top, or the corner of the
sink unit, at the most convenient point for use. Some sink units may
already have a suitable hole in them which can be exposed by
removing the cap.
2. Remove the nut from the push button below, while keeping the
rubber gasket in place. Push one end of the PVC tubing onto the
spout of the push button bellows, feed the other end of the tube
through the hole in the work top and through the nut underneath
the work top. （Picture 10.3）
（Picture10.1）
3. Fit the Push button bellows in the hole and then screw up the nut
underneath the work top until it is hand tight.
（ Do not use a wrench to tighten the nut. ）（ Picture10.3）
4. Take the other end of the air tube and firmly push it over the spout
of the air switch, which is located on the underside of the waste
disposer.
◎Disable Air Switch
The air switch can be disabled if wall switch is preferred.
The disposer is shipped with the switch in the “off” position.
1. Push one end of the PVC tubing provided onto the spout of the
push button bellows.
2. Take the other end of the air tube and push it over the spout of air
switch, which is located at the bottom of the disposer unit.
3. Depress the air switch one time until you hear the switch “click.”
Remove and discard the push button and PVC tubing. The
disposer may now be activated by a wall switch.
The disposer installation is complete. Read all operation and safety
instructions in section 11 before operating the disposer. Lastly, place
stopper in sink to close position. Fill sink with water, remove the stopper,
turn the disposer on and check for leaks.
Please allow 24 hours before using product to let the plumbers putty seal.
（10.3）（10.4）

0807
Food Waste Disposer Users’ Manual Food Waste Disposer Users’ Manual
10. Important Safety Instructions
Warning！
When using electrical appliances, basic precautions are always to be
followed, including：
1. If the air switch or wall switch fails to shut off or turn on disposer,
unplug the power cord and contact your qualified trade person.
2. This product is designed to dispose of normal household food
waste, inserting materials other than food waste into the disposer
could cause personal injury and/or property damage. To reduce the
risk of injury, do not use the sink containing the disposer for
purposes other than food preparation (such as baby bathing or
wash hair)
3. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of appliance by a person
responsible for their safety. Children should be supervised to ensure
that they do not play with disposer. To reduce the risk of injury, close
supervision is required when an appliance is used near children.
4. When attempting to loosen a jam in the food waste disposer, switch
off or unplug the appliance before attempting to free a jammed
rotor. USE A SELF SERVICE WRENCHETTE AS DESCRIBED IN THE
RELEASING DISPOSER JAM SECTION
5. Use long-handle tongs or pliers to remove objects from disposer.
6. To reduce the risk of injury by materials that are expellable by a
waste disposer, do not operate disposer without the sound baffle in
place. (See picture) Place stopper in sink opening. Do not put the
following into a disposer: clam or oyster shells, large bones, metal
(such as bottle caps, steel shot, tin cans, or utensils), hot grease or
other hot liquids.
7. Replace sound baffle/mounting gasket/splash guard when worn to
help prevent entry or ejection of material and water.
8. When not using disposer, leave stopper in place to reduce risk of
objects falling into disposer. Make sure disposer power switch is
turned off.
9. Before pressing reset button, attempting to clear jam, or removing
objects falling into disposer. Make sure disposer power switch is
turned off.
10. Do not insert hands or fingers into disposer.
11. Fire Hazard: Do not store flammable items such as rags, paper, or
aerosol cans near disposer. Do not store or use gasoline or other
flammable vapors and liquids in vicinity of disposer.
12. Do not dispose of the following in the disposer: paints, solvents,
household cleaners and chemicals, automotive fluids, plastic wrap.
13. All IKON series of disposers are designed to national standard for
intermittent usage and shall not be used continuously per time.
Operation Instructions
1. Remove strainer basket and plug from sink opening and run cold
water.
2. Turn on wall switch or press air switch (See picture) to start disposer.
3. Slowly insert food waste into disposer and position strainer basket in
right place to minimize noise and possible ejection of material while
grinding. (See picture)
4. After grinding is complete, turn disposer off and run water for at least
15 seconds to flush drain line.
Do……
· Grind food waste with minimum cold water flow of 6 liters per
minute (1.5G.P.M).
· Grind hard material such as small bones and fruit pits to clean inside of
grind chamber.
· Grind citrus, melon rinds, vegetables, and coffee grounds.
· After grinding, run water for at least 15 seconds to flush drain line.

1009
（11.1）（11.2）
Food Waste Disposer Users’ Manual Food Waste Disposer Users’ Manual
· Switch off or unplug the appliance before attempting to free a jammed
rotor with implement.
· Maintain the area underneath the disposer of any objects to be sure
you have access to the disposer reset button.
Don’t……
· Don’t turn off water or disposer until grinding is complete and only
sound of motor and water running is heard.
· Don’t grind large amount of egg shells, fibrous materials like corn
husks, artichokes, etc., to avoid possible pipe blockage
· Don’t grind non-food waste of any kind.
· Don’t use this appliance to dispose of hard materials such as glass
and metal.
· Don’t ever pour fats, oils or grease down the sink- it will block your
drains and sewage system.
· Don’t fill disposer with lots of vegetable peels all at once. Instead, turn
the water and disposer on first and then feed the peels in gradually.
Over time, grease/food particles may accumulate in the grind chamber
and baffle, causing an unpleasant odor. To clean the disposer:
Cleaning Disposer:
1. Turn off disposer and disconnect power supply.
2. Reach through sink opening and clean underside of the splash baffle
and inside upper lip of grind chamber with scouring pad.
3. Place stopper in sink opening and fill sink halfway with warm water.
4. Mix 60ml baking soda with water. Turn disposer on and remove
stopper from sink at the same time to wash away loose particles.
Releasing Disposer Jam
If the motor stops while the disposer is operating, the disposer may be
jammed. To release jam:
1. Turn disposer power and water off.
2. Insert one end of the self-service wrenchette into the center hole on
the bottom of the disposer （See picture 11.1）. Work the wrenchette
back and forth until it turns one full revolution. Remove the
wrenchette.
3. Reach into the disposer with tongs and remove objects. Allow the
disposer motor to cool for 3-5 minutes and lightly push red reset
button on the disposer bottom （See picture 11.2）
Service
If service is required, contact authorized service center or your dealer.
Guarantees are void if you attempt to repair, or if the disposer is used for
commercial usage.

11
