Iluv Morning Call 4Q User manual

Morning Call® 4Q
User Manual (Ver 1.0)
Wooden Large LED Display
Dual Alarm Clock with Wireless
Charging Station and FM Radio
English

WARNING AND SAFETY INSTRUCTIONS
1. All the safety and operating instructions should be read before the product is operated
2. The safety and operating instructions should be retained for future reference.
3. All warnings on the product and in the operating instructions should be adhered to.
4. All operating and use instructions should be followed.
5. Use of controls or adjustments or performance other than those specied may result in
hazardous radiation exposure.
6. Do not use this product near water or expose to rain to prevent re or shock hazard. i.e.
bathtub, washbowl, kitchen sink, laundry tub, wet basement, or swimming pool, etc.
7. Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Clean only with a dry cloth.
8.
Unplug Morning Call 4Q during lightning storms or when unused for long periods of time.
9. When main plug is connected, Morning Call 4Q is readily operatable. In order to
disconnect Morning Call 4Q completely, the main plug should be disconnected from the
main socket outlet.
10. Battery shall not be exposed to excessive heat such as sunshine or re.
11. If battery is incorrectly replaced, it may cause explosion. Replace only with the same
or equivalent type.
The lightning ash with
arrowhead symbol,
within an equilateral
triangle, is intended to
alert the user to the
presence of
un-insulated
“dangerous voltage”
within the product’s
enclosure that may be
of sucient magnitude
to constitute a risk of
electric shock to
persons.
CAUTION TO REDUCE
THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER OR BACK. NO
USERSERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONEL.
The exclamation point
within an equilateral
triangle is intended to
alert the user to the
presence of important
operating and
maintenance
(servicing) instructions
in the literature
accompanying the
appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
2

PM
FM
Wireless Charge
Morning Call
iLuv
User Manual
Micro USB
Charging Cable
Power Adaptor
with USB Port
User Manual
WHAT’S INCLUDED
Morning Call® 4Q
3

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL 1
1 2 3 4 5 6 7
8
TIME/PRESET
HOUR/TUN-
MINUTE/TUN+
SLEEP/DIMMER/SNOOZE
ALARM 1/VOLUME DOWN
ALARM 2/VOLUME UP
POWER/RADIO/ALARM OFF
Wireless Charging Pad
Top View
1
2
3
4
5
6
7
8
OVERVIEW OF THE PRODUCT
4

PM
FM
Wireless Charge
Morning Call
iLuv
DC 5V/2A
Morning Call 4Q
Made in China
Alarm Clock Speaker with Wireless Charger
Model : MORCAL4Q
Power : DC 5V 2A
Backup Battery : 2 x AAA
iLuv Creative Technology
iLuv
9
10
14
11
12
13
15
16 17
Front View
Back View
Alarm 1 Indicator
Alarm 2 Indicator
PM Indicator
FM Radio Indicator
Wireless Charging Indicator
Speaker
Micro USB Input Port
Battery Compartment
Antenna
9
10
11
12
13
14
15
16
17
5

DC 5V/2A
Morning Call 4Q
Made in China
Alarm Clock Speaker with Wireless Charger
Model : MORCAL4Q
Power : DC 5V 2A
Backup Battery : 2 x AAA
iLuv Creative Technology
iLuv
14
15
16 17
POWERING ON
CONNECTING TO POWER
Connect the Micro USB cable
provided in the box to the
Micro USB Port located on
the back of the unit to the wall
adaptor. Plug in the wall adap-
tor into a wall outlet.
15
AC Adaptor
6

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
912
11
13
10
1 2 3 4 5 6 7
8
1
Press & HOLD [TIME/PRESET] to enter TIME SET-UP
mode.
2
Select 12H (12-hour) or 24H (24-hour) time display setting
by pressing
[HOUR/TUN-] or [MIN/TUN+] .
Press
[TIME/PRESET] to continue.
3
Press
[HOUR/TUN-]
to set the hour and
[MIN/TUN+]
to set the minute.
(Press &
HOLD
for faster adjustment)
4
When Finished, press [TIME/PRESET] to conrm and exit
from
TIME SET-UP mode.
1
1
1
2
2
3
3
TIME SETUP
7

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
912
11
13
10
1 2 3 4 5 6 7
8
Entering ALARM SET-UP Mode:
Press & HOLD [AL 1/VOL -] to enter the ALARM SET-UP
mode. When the display is blinking, you have successfully
entered the
ALARM SET-UP mode.
Press
[HOUR/TUN-] to set the hour and [MIN/TUN+]
to set the minute.
(Press &
HOLD for faster adjustment)
Press
[AL 1/Vol-] to conrm and proceed to your Alarm
Sound Source
.
ALARM SETUP
2
SETTING UP YOUR ALARM:
Alarm Time > Alarm Sound Source > Alarm Sound Volume.
1
5
5
2 3
Setting Your Alarm:
8

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
1 2 3 4 5
912
11
13
10
6 7
8
Press the [HOUR/TUN-] or [MIN/TUN+] button to set
wake up sound volume(from volume 5 to 15).
Press
[AL1/VOL-] to conrm.
Press the
[HOUR/TUN-] or [MIN/TUN+] button to
select the
bu (buzzer) or rd (FM radio) as the alarm sound
source.
bu or rd will be displayed accordingly.
Press
[AL1/VOL-] to conrm.
5
5
2
2
3
3
3 Selecting alarm sound source:
4Setting wake up sound volume:
5
Once the alarm setting is done, the alarm will be ready with
the corresponding alarm indicator on.
(When alarm goes o, the volume will gradually increase from low to high.)
(If rd is selected, the last radio station selected will be played.)
9

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
1 2 3 4 5
912
11
13
10
6 7
8
Press [AL 1/Vol-] or [AL2/Vol+] button to enable or
disable the respective alarm while the display shows clock time.
The corresponding Alarm 1 or Alarm 2 indicator will be
on or o.
To set Alarm 2 follow step 1-4, replacing [AL1/Vol-]
with [AL2/Vol+].
TO SET ALARM 2
If you disable the alarm temporarily for next day (such as
holiday or weekend), corresponding alarm indicator will be o
and the alarm will not go o until you enable it again.
ALARM ENABLE/DISABLE
5
5 6
910
6
10

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
912
11
13
10
1 2 3 4 5 6 7
8
When the alarm activates, the corresponding Alarm 1
or Alarm 2 indicator will ash on the display.
Press the [SLEEP/DIMMER/SNOOZE] button to temporarily
deactivate it. The snooze function will extend your alarm in
increments of 9 minutes.
The corresponding Alarm 1 or Alarm 2 indicator will
ash on the display during the snooze period.
4
9
9
10
10
1
To shut o the alarm completely,
press [ /RADIO /AL OFF] button.
This will deactivate the alarm until the next scheduled alarm.
3
2
SNOOZE ALARM
7
11

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
912
11
13
10
1 2 3 4 5 6 7
8
The Sleep Timer Function allows you to set-up a timer for the
radio to shut-o automatically.
2
After your selection, wait 3 seconds for the sleep timer
function to set.
1
To activate the SLEEP TIMER FUNCTION,
Press [ /RADIO /AL OFF] button to turn on the radio.
You can toggle the timer limit by pressing the
[SLEEP/DIMMER/SNOOZE] button.
Select the desired timer limit (in minutes) 90, 60, 30, 15, 10,
05 and OFF.
This feature is not supported when radio is o.
SLEEP TIMER FUNCTION
4
7
12

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
912
11
13
10
1 2 3 4 5 6 7
8
3
Upon set-up, the radio will shut o automatically depending
on your preferred time setting.
4To
check the remaining amount of time left, simply press
the
[SLEEP/DIMMER/SNOOZE] button.
5To
shut o the SLEEP TIMER FUNCTION, simply press the
[SLEEP/DIMMER/SNOOZE] button until the display
shows "OFF"
4
4
13

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
iLuv
912
11
13
10
1 2 3 4 5 6 7
8
To adjust the radio frequency,
press [HOUR/TUN-] or [MIN/TUN+].
FM RADIO ON/OFF
2 3
2 3
Unravel and extend the antenna to improve the FM radio
signal reception.
1
2
Press [ /RADIO /AL OFF] button to turn the radio on.
3
4
Press and HOLD [HOUR/TUN-] or [MIN/TUN+] to
automatically tune to the next available FM station.
7
5
To turn the FM radio o, press [ /RADIO /AL OFF].
7
FM RADIO
14

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
912
11
13
10
1 2 3 4 5 6 7
8
You can store up to 10 preset stations.
RADIO PRESET
2
Toggle through the preset number by pressing
[HOUR/TUN-] or [MIN/TUN+] from P01 to P10.
Tune to your desired FM Station by pressing or holding
the [HOUR/TUN-] or [MIN/TUN+] button.
3
Press and HOLD [TIME/PRESET] button until the
Preset Mode appears.
4
To program the station to the preset, press
[TIME/PRESET] to complete the process.
1
2 3
2 3
1
1
15

Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
PM
FM
Wireless Charge
Morning Call
912
11
13
10
1 2 3 4 5 6 7
8
FIND PRESET RADIO STATION
Preset option is only available when the Radio is on.
Press [TIME/PRESET] button repeatedly until
your desired preset station appears.
(P01> P02 > P03.... P10)
1
16

PM
FM
Wireless Charge
Morning Call
iLuv
Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
912
11
13
10
1 2 3 4 5 6 7
8
Press [SLEEP/DIMMER/SNOOZE] button to change the
brightness level of the display: (Low > O > High)
1
Default setting of the dimmer level is “Low”
2
To adjust the brightness, Alarm clock must be on
Standby Mode.
DISPLAY DIMMER
4
17

PM
FM
Wireless Charge
Morning Call
iLuv
Wireless Charge
SNOOZE
SLEEP/DIMMER
TIME HOUR MIN
PRESET RADIO
AL OFF
TUN TUN VOLVOL
AL 2AL1
912
11
13
10
1 2 3 4 5 6 7
8
1
Place your Qi enabled smartphone on the center of the Wireless
Charging Pad.
- For best connectivity, align your phone with the alarm clock.
CAUTION: Remove any protective cases containing magnets, metal, or
materials thicker than 0.12” (3mm)
USING QI WIRELESS CHARGING
8
IT IS SUGGESTED TO CHARGE YOUR PHONE WITH A WIRED CABLE INSTEAD OF A WIRELESS CHARGER DURING
PHONE SOFTWARE UPDATE. OTHERWISE, CHARGE YOUR PHONE FULLY BEFORE THE PHONE SOFTWARE UPDATE.
2
When the phone is being charged, the blue Wireless Indicator
will appear.
- Solid Blue Indicator: Device is charging properly
- Blinking Blue Indicator: Device is not charging properly.
Take the device o and re-position back onto the charging pad.
- Blue Indicator O: Device is charged (some devices do not support this feature)
13
18

3
If you have any question or need
support, please contact us by
visiting http://support.iLuv.com or
call customer service department
at 1-866-807-5946.
SPECIFICATIONS CUSTOMER SUPPORT
Tuner Range
Number of preset radio stations
Amplifier Rated Output Power
USB Wall Charger
FM: 87.5 – 108 MHz
10
400mW(RMS)
Input: AC 100-240V, 50/60HZ
Output: DC 5V, 2A
PMA wireless charging system is not supported.
Compatible Products for Wireless Charging:
iPhone X/Xs, iPhone Xs Max, iPhone XR, iPhone 8/8 Plus, Samsung Galaxy Note 8/5, Galaxy S9/S9+/S8/S8+, S7/S7
Edge, S6 Edge+, S6/S6 Edge, LG V30, Nexus 7/6/5, other Qi enabled smartphones/tablets and accessories.
19

1. Morning Call 4Q is
equipped with a timekeeping system that can be powered with two (2) AAA
batteies (not included). The power failure protection circuit will not operate unless battery is
installed.
2.
The back-up battery will save all previously programmed settings when normal household power is
interrupted. The back-up battery will not operate the clock's normal functions.
3.
Normal operation will resume after the power is restored. You will not need to set-up the
time/alarms/radio if back-up battery is installed correctly.
BATTERY BACKUP OPERATION
BACK-UP BATTERY WILL NOT OPERATE THE CLOCK
20
