Exhausting cooker hood
The equipment is constructed in accordance with
European Standards and with the requirements
included in the following Directives: 2006/95EC
(Low Voltage Directive), 2004/108 (Electromagnetic
Compatibility).
1. INSTALLATION
Read the instruction manual before installing and/or
using the hood.
Range hoods and other cooking fume extractors
may adversely affect the safe operation of appliances
burning gas or other fuels (including those in other
rooms) due to the back flow of combustion gases.
These gases can potentially result in carbon monoxide
poisoning. After installation of a range hood or other
cooking fume extractor, the operation of flued gas
should be tested by a competent person to ensure that
back flow of combustion gases does not occur.
In order that the minimum distance between the
supporting surface for the cooking pots on gas hob
and low-voltage components present in the hood is at
least 65cm as required by the regulations in force, it is
necessary that the lower part of the hood is at least 65-
70cm away from the work top.
If the mounting instructions of the gas cooker indicate
a wider distance, respect it. The unit must not be
mounted above cookers fitted with top radiant plate.
Respect all the air discharge regulations.
The air must not be discharged in a pipe used to
discharge exhaust fumes produced by gas- fed
equipment or fuel-fed equipment (this does not apply to
filtering hoods).
The room must be adequately ventilated when the
hoods is used together with other gas-fed or
fuel-fed equipment.
The hood is equipped with all the necessary fastenings
for its installation, which are suitable for most surfaces.
Anyway, ask to a professional to verify that the
installation surface is strong enough. Installation must
be carried out by qualified installers according to
present regulations.
For an easy access, it is advisable to move possible
furniture under the installation area.
• For mounting the hood follow the illustrations in
Fig. 1.
• To remove the bottom panel follow the illustrations
on Fig. 2
• To install the cover follow illustrations on Fig. 3
2. ELECTRICAL CONNECTIONS
This appliance must be connected to an earthed power
supply. Two types of electrical connection can be used:
1. Using a standard plug to be connected to the power
cable and inserted in a mains socket which must be
accessible (so that the plug can be disconnected when
servicing is carried out). Make sure that the plug is
accessible also after the complete installation of the
equipment.
2. By means of a fixed mains connection, fitting a
bipolar switch, which ensures the disconnection, with an
opening distance of the contacts allowing a complete
disconnection on the conditions of the over voltage
III category, according to installation regulations. The
ground connection (yellow-green wire) must not be
interrupted. For stationary appliances permanently
connected to the fixed wiring, compliance with this
requirement is considered to be met if the instruction
concerning disconnection incorporated in the fixed wiring
is in accordance with AS/NZS 3000
Refer to the plate inside the hood for the mains voltage
and frequency ratings.
3. USE
This cooker hood can be employed as exhausting or
filtering. Exhausting (Fig. 4). The carbon filters should not
be installed on the hood in exhausting version.
Kitchen smokes are driven outside through a flue joined
to the exhaust pipe flue connector.
Pipes must be communicating with the exterior of the
house. The diameter of the outlet of the hood is 150mm.
A 150-125 reduction is provided with the hood.
This pipe must not under any circumstances be
connected to cooker, boiler or burner exhaust pipes, etc.
Filtering (Fig. 5). The fumes pass through the carbon
filters to be purified and recycled into the kitchen through
a pipe connected to the outlet of the hood up to the
hole in the top of the cabinet. This hole must be free and
communicating with the kitchen.
In the filtering version you must install the two carbon
filters on the sides of the aspirator. To install the carbon
filters you must first remove the metal grease filters
(Fig. 6) and then install carbon filters by turning them
counterclockwise (Fig. 7).
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS FOR
RANGE HOODS DESIGNED FOR WALL FITTING 230 Vac • 50 Hz

INSTALLATION
2
4. OPERATION
The hood is supplied with a multi speed motor.
The hood should be run at low speed under normal
conditions and at higher speeds only when there is a
heavy build-up of fumes or odour.
Ideally, the hood should be switched on as soon as
cooking is started and then kept on until all odour have
been eliminated. The controls consist of these commands.
Press TL to turn on the light, press T1 to switch on the
hood at first speed and to switch off the aspirator, press
T2-T3-T4 to select functioning speeds.
By pressing of the command T1 the motor starts running
at the 1st speed. The commands T2-T3-T4 switch the
motor on respectively at the 2nd, 3rd and 4th speed. In
order to switch the motor off press T1 once if set at the
1st speed, twice if set at the 2nd, 3rd and 4th speed. With
the button T4, select the maximum speed of the extraction
fan for 5 minutes (LED blinking), after which the extraction
fan will automatically switch to the 3rd speed.
Adjustable and delayed self switching off
While the hood is working, keep the TL command pressed
until all LEDs start blinking. By pressing one of the
commands (T1, T2, T3, T4) you can program the delayed
self switching off, as follows:
T1 corresponds to 5 minutes
T2 corresponds to 10 minutes
T3 corresponds to 15 minutes
T4 corresponds to 20 minutes
FILTER TIMER:
Aluminium anti-grease lters
Once the hood is switched off, after 30 hour functioning,
all the LEDs of the speed buttons switch on with a fixed
light for 30 seconds to remind that aluminium anti-
grease filter need cleaning. To set the timer to zero keep
the button T4 pressed with the aspirator switched off,
otherwise the timer will remain set on 30 hour functioning
and the reminder will occur again when the hood is
switched off again.
CHARCOAL FILTER (FOR FILTERING HOODS)
Once the hood is switched off, after 120 hour functioning,
all LEDs blink for 30 seconds to remind that the charcoal
filter need cleaning. To set the timer to zero keep the
button T4 pressed with the aspirator switched off,
otherwise the timer will remain set on 120 hour functioning
and the reminder will occur again when the hood is
switched off again.
5. MAINTENANCE AND REMINDERS
Always disconnect the hood from the mains before
carrying out any maintenance or cleaning operation
In order to remove the remaining glue or any impurity,
the cooker hood must be cleaned immediately after
installation and after having removed the protective film.
The cooker hood must be cleaned frequently both
internally and externally (at least once a month).
Do not let dirt gather on the inner and outer surfaces of
the hood. To clean the exterior of the hood do not use
either acid or basic products, or abrasive sponges.
Clean the hood with a sponge dampen in warm water
and a little quantity of neutral detergent (for example
dishwasher detergent), in order to remove possible
particles of grease. Rinse with a damp cloth, removing all
the detergent carefully, following the satin finish direction
on the steel surface.
Drying is very important, especially in areas where water is
particularly hard and leaves limestone.
Particular attention should be paid to the metallic anti-
grease filters that are designed to trap particles of fat
contained in the fumes. The metallic anti-grease filters
must be washed at least once a month with detergent in
hot water (or in the dish-washer).
ATTENTION:
• the grease collected in the filter can easily catch fire
and it is therefore extremely important to clean the metallic
filter on a regular basis as per instructions. Grease filters
are removed as illustrated (Fig. 5).
• Do not flambé under the range hood
• Caution; accessible parts may become hot when used
with cooking appliances.
• Never leave the hob unattended when frying, as oil or
fat can catch fire.
The function of the activated carbon filters is to prevent the
spread of odour present in the cooking fumes. Clean air is
returned to the kitchen. Carbon filters cannot be washed
and must be replaced 2 or 3 times a year according to the
amount of use.

33
The hood features a LED light that, in addition to offer
a good lighting and a significant energy savings, is
guaranteed to last about 10 times more than traditional
lights. For replacement, contact us at
customercar[email protected]
Spare filters can be purchased from dealers or direct
from the manufacturer.
Removal: detach the metal covers and rotate the
carbon filters clockwise (Fig. 6) until release from of the
motor.
Re-fit: position the new carbon filters and reverse the
procedure. The hood should be cleaned with a soft
damp cloth using neutral liquid detergents. Do not use
solvents, petroleum products or abrasives.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly qualified
persons in order to avoid a hazard.
THE MANUFACTURER DOES NOT ACCEPT LIABILITY
FOR ANY DAMAGE OR INJURY CAUSED IF THE
USER FAILS TO FOLLOW THE ABOVE INSTRUCTIONS
REGARDING INSTALLATION, MAINTENANCE AND
THE PROPER USE OF THE COOKER HOOD.
For service or a copy of this manual contact us at
customercar[email protected]
6. WARNINGS
The present instruction manual is an integral part of the
appliance itself, therefore it must be carefully kept and
ALWAYS accompany it, even in case of its assignment
to another owner or user or in case the cooker hood
is moved to another installation plant. Any eventual
adjustment to the electrical system, which may be
necessary to install the cooker hood, must be carried
out only by competent people. Any repair carried out
by no competent people may cause damages. For any
repair or needed technical action make reference to
a Technical Assistance Center, which is authorized to
carry out the replacement of the spare parts. Always
make sure that all the electrical parts (lights, exhaustion
unit) are disconnected when the appliance is not in use.
By storms take off the main switch of the house
electrical system. The using of the cooker hood
must not be other than the use of exhausting units
for cooking damps on domestic kitchens. The
manufacturer does not accept any liability for damages
caused by people, animals or things, by installation and
maintenance mistakes or by any illegitimate use.
Make sure that the voltage (V) and the frequency (Hz)
ratings indicated on the plate inside the cooker hood
correspond to the ones available in the installation
place.
We remind that the use of products functioning with
electrical energy implies the observance of some
essential security rules, as follows:
• This equipment is not intended for people (children
included) with reduced mental or motor capacities,
with lack of experience or knowledge, unless they are
supervised or unless a person responsible for their
security, gives them instructions regarding the use of the
equipment. Children must be supervised in order to be
sure that they do not play with the equipment.
• Any cleaning action is forbidden if the appliance hasn’t
been disconnected from the main power supply and if
the main switch of the house electrical system is not off. If
cleaning is not carried out according to these instructions,
a fire may break out.
• Do not pull, take off or twist the cable coming out from
the appliance, even though this has been disconnected
from the main power supply.
• Do not sprinkle or throw any water directly on the
appliance.
• Do not stick any sharp tool inside the exhausting holes
and into the air discharge.
• Do not take out the filters in order to reach the internal
sides of the appliance in case the main switch of the
house electrical system is not off.
• Do not singe or flambé directly underneath the cooker
hood. Take particular care when frying to ensure that the
oil does not catch fire.

NOTES

55
Eurolinx Pty Limited A.B.N. 50 001 473 347
trading as ILVE (“ILVE”)
Ofce:
48-50 Moore Street, Leichhardt N.S.W 2040
Post:
Locked Bag 3000, Annandale, N.S.W 2038
P: 1300 856 411
WARRANTY REGISTRATION
Your ongoing satisfaction with your ILVE product
is important to us. We ask that you complete the
enclosed Warranty Registration Card and return
it to us so that we have a record of the ILVE
product purchased by you, Alternitivley, you can
now register your warranty online at
http://support.eurolinx.com.au/
PRIVACY
ILVE respects your privacy and is committed
to handling your personal information in
accordance with the National Privacy Principles
and the Privacy Act 1988 (Cth). A copy of the
ILVE Privacy Policy is available at www.ilve.
com.au. ILVE will not disclose any personal
information set out in the Warranty Registration
Card (“Personal Information”) without your
consent unless required by:
1. law;
2. any ILVE related company;
3. any service provider which provide services
to ILVE or assist ILVE in providing services
(including repair and warranty services) to
customers. Our purpose in collecting the
Personal Information is to keep a record of
the ILVE product purchased by you, in order
to provide a better warranty service to you in
the unlikely event that there is a problem with
your ILVE product. ILVE may contact you at any
one or more of the addresses, email addresses
or telephone numbers set out in the Warranty
Registration Card. Please contact ILVE on 1300
694 583 should you not wish to be contacted by
ILVE.
WARRANTY
1. Warranty
ILVE warrants that each ILVE product will
remain, for a period of twenty four (24) months
computed from the date of purchase of the
ILVE product, free from defects arising in the
manufacture of the ILVE product (“Warranty”).
Except for consumer guarantees set
out in the Competition and Consumer Act 2010
(Cth) (“Act”), ILVE does not make any further
warranties or representations in relation to ILVE
products.
2. What is not Covered by the Warranty.
The Warranty does not apply if an ILVE product
is defective by a factor other than a defect
arising in the manufacture of the ILVE product,
including but not limited to:
(a) damage through misuse (including failure
to maintain, service or use with proper care),
neglect, accident or ordinary wear and tear
(including deterioration of parts and accessories
and glass breakage);
(b) use for purpose for which the ILVE product
was not sold or designed;
(c) use or installation which is not in accordance
with any specied instructions for use or
installation;
(d) use or operation after a defect has occurred or
been discovered;
(e) damage through freight, transportation or
handling in transit (other than when ILVE is
responsible);
(f) damage through exposure to chemicals, dusts,
residues, excessive voltage, heat, atmospheric
conditions or other forces or environmental
factors outside the control or ILVE;
(g) repair, modication or tampering by the
purchaser or any person other than ILVE, an
employee of ILVE or an authorised ILVE service
contractor*;
(h) use of parts, components or accessories
which have not been supplied or specically
approved by ILVE.
(i) damage to surface coatings caused by cleaning
or maintenance using products not recommended
in the ILVE product handbook provided to the
purchaser upon purchase of the ILVE product;
(j) damage to the base of an electric oven due to
items having been placed on the base of the oven
cavity or covering the base, such as aluminium
foil (this impedes the transfer of heat from the
element to the oven cavity and can result in
irreparable damage); or
(k) damages, dents or other cosmetic
imperfections not aecting the performance of the
ILVE in respect of an ILVE product purchased as a
“factory second” or from display
The Warranty does not extend to light globes
used in ILVE products.
3. Domestic Use
Each ILVE product is made for domestic use. This
Warranty may not extend to ILVE products used
for commercial purposes.
4. Time for Claim under the Warranty
You must make any claim under this Warranty
within twenty eight (28) days after the occurrence
of an event which gives rise to a claim pursuant
to the Warranty, by booking a service call on the
telephone number below.
Continued over...
WARRANTY

INSTALLATION
66
5. Proof of Purchase
Customers must retain proof of purchase in order
to be eligible to make a warranty claim in respect
of an ILVE product.
6. Claiming under the Warranty
Customers will bear the cost of claiming under this
Warranty unless ILVE determines the expenses
are reasonable, in which case the customer
must claim those expenses by providing written
evidence of each expense to ILVE at the address
on the Warranty Registration Card.
7. Statutory Rights
(a) These terms and conditions do not aect your
statutory rights.
(b) The limitations on the Warranty set out in this
document do not exclude or limit the application
of the consumer guarantees set out in the Act or
any other equivalent or corresponding legislation
in the relevant jurisdiction where to do so would:
(i) contravene the law of the relevant jurisdiction;
or
(ii) cause any part of the Warranty to be void.
(c) ILVE excludes indirect or consequential loss
of any kind (including, without limitation, loss of
use of the ILVE product) and (other than expressly
provided for in these terms and conditions)
subject to all terms,
conditions and warranties implied by custom, the
general law, the Act or other statute.
(d) The liability of ILVE to you for a breach of any
express or non-excludable implied term, condition
or warranty is limited at the option of ILVE to:
(i) replacing or repairing the defective part of the
ILVE product;
(ii) paying the cost of replacing or repairing the
defective part of the ILVE product;
(iii) replacing the ILVE product; or
(iv) paying the cost of replacing the ILVE product.
(e) Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.
8. Defects
Any part of an ILVE product deemed to be
defective and replaced by ILVE is the property of
ILVE. ILVE reserves the right to inspect and test
ILVE products in order to determine the extent of
any defect and the validity of a claim under the
Warranty.
*For your closest ILVE authorised service
agent go to
https://support.eurolinx.com.au/#/map/retailers
All warranty service calls must be booked
through ILVE’s Customer Care Centre on
[email protected] or
1300 85 64 11 option 1
01072021
6ILVE Operating Manual
Please complete and send to ILVE at: REPLY PAID 83617
LEICHHARDT NSW 2040
Last Name: First Name:
Address:
State: Postcode: Email:
Home Phone: Mobile:
Purchase Date: / / (Please attach proof of purchase to validate warranty)
MODEL NUMBER SERIAL NUMBER
(if you cannot locate the serial number please call ILVE on 1300 85 64 11)
1
2
3
4
WARRANTY REGISTRATION CARD
01072021
01072021
Warranty Card tear off
WARRANTY

P: 1300 694 583 E: [email protected] W: eurolinx.com.au
NATIONAL SERVICE CENTRE
Our high quality appliances are designed and manufactured to give you many years of cooking pleasure.
Should you have any questions or issues with your appliance please email our national service centre
[email protected] or phone us on 1300 85 64 11.
Our experienced staff are on hand to log your service request and ensure any matter is attended to promptly.
For after sales enquiries please contact us at [email protected] or 1.300 85 64 11 option 1
For spare parts contact us at [email protected] or 1.300 85 64 11 option 2
Technical support is available to authorised and licensed service providers only by contacting us at
[email protected] Allother technical enquiories should be directed to [email protected]
10/55 Howe St
Osborne Park, WA
1/42 Cavendish Rd
Coorparoo, QLD
48-50 Moore St
Leichhardt, NSW
LUXURY KITCHEN APPLIANCES
