Image Projection iPro 150E Instruction Manual

1
iPro 150E/200E/300E LED
Outdoor Gobo Projector
Description
iPro “E” LED projectors are rated IP-65 for outdoor use. To project
an image, a high resolution glass or metal gobo is required. To
order a gobo, e-mail the artwork of the desired image to Info@
UseLight.com. Line-art or vector les are acceptable, as are pixel
les (e.g. .JPEG, .PNG, .TIFF, .PDF, etc.) 300 dpi or better.
Safety Information
• For indoor or outdoor use.
• Prevent direct eye exposure to the light source as it may lead
to injury or blindness.
• This projector uses a heat sink for cooling, which can heat up
the projector. Please use caution when handling or touching
the unit during and after operation.
• Only use power sources that comply with local electrical and
building codes and have proper grounding.
Gobo Specications
• Outer diameter (OD) - 66 mm
• Inner or image diameter (ID) - 46 mm
• Gobo thickness: Up to 3 mm
Package Contents
Projector, optical lens and cable with standard 110 Volt plug.
Instruction/User Manual and Specications

23
Model:
Power Output:
Lamp (LED):
Rated Frequency:
Expected LED Lamp Life:
Color Temperature (Kelvin):
Luminous ux:
Weight:
iPro-150E
110 to 277 V*
150 W
50/60 Hz
30 - 40,000 Hrs
6,000 - 6,500 K
13,500 lm
16 lbs.
iPro-200E
110 to 277 V*
200 W
50/60 Hz
30 - 40,000 Hrs
6,000 - 6,500 K
18,000 lm
16 lbs.
iPro-300E
110 to 277 V*
300 W
50/60 Hz
30 - 40,000 Hrs
6,000 - 6,500 K
27,000 lm
16 lbs.
Warranty
This projector comes with a 1-year warranty that begins on the
date of purchase and includes labor and parts.
Step 1
Remove the front plate of the projector
by unscrewing the thumb screws.
Step 2
Remove the metal pressure clip by
squeezing together the two bent ends.
WARNING: PLEASE USE CAUTION WHEN REMOVING
OR INSTALLING THE PRESSURE CLIP, AS IT MAY SPRING
OR JUMP OUT UNEXPECTEDLY.
Step 3
Place the gobo with image facing
down (reversed) in the gobo slot.
Step 4
Place the metal pressure clip on top of
the gobo and make sure it is pressing
against the gobo evenly.
Gobo Installation
and Exchange
Projector Specications
13“ / 325 mm
12 3/8“ / 315 mm
5 5/8 “ / 143 mm
5 .5 “ / 140 mm
Mounting bracket
5 1/2 “ / 139 mm
6 3/8 “ / 162 mm
5 1/2 “ / 139 mm
9 7/8
“ / 251 mm
7.5 “ / 190 mm
Lock ring
Optical lens
Thumb
Screws
3 “ / 76 mm
Top ViewBottom View
Side ViewFront View
* US only - 240 V outside of US

Image Projection • 1109 Ponce de Leon Blvd. • Coral Gables, FL 33134
305-444-0218 • [email protected] • www.UseLight.com
Once the gobo is succesfully installed and the front plate cover is
reattached, rotate the lens clockwise or counter-clockwise until
the image is in focus.
Adjusting the Image Focus
Press the button located on the side of the projector to turn the
rotator ON or OFF.
Turning Rotating Eect ON/OFF
ON
Once the image is in focus, turn the lock ring clockwise until the
rubber gasket is slightly compressed.
