Imagine DA-HR6802+DL User manual

Delivering the Moment
Installaon and Operaon Manual
DA-S6802+DL / DA-SR6802+DL /
DA-H6802+DL / DA-HR6802+DL
1×8 Looping Input SD/ASI Distribuon
Ampliers / 1×8 Looping Input SD/ASI
Distribuon Ampliers with Reclocking /
1×8 Looping Input 3 Gb/s, HD-SDI, SD-SDI,
and ASI Distribuon Ampliers / 1×8 Loop-
ing Input 3 Gb/s, HD-SDI, SD-SDI, and ASI
Distribuon Ampliers with Reclocking
Edion A
175-100071-00

Publicaon Informaon
© 2014 Imagine Communicaons Corp. Proprietary and Condenal.
Imagine Communicaons considers this document and its contents to be proprietary and condenal. Except for
making a reasonable number of copies for your own internal use, you may not reproduce this publicaon, or any part
thereof, in any form, by any method, for any purpose, or in any language other than English without the wrien consent
of Imagine Communicaons. All others uses are illegal.
This publicaon is designed to assist in the use of the product as it exists on the date of publicaon of this manual, and
may not reect the product at the current me or an unknown me in the future. This publicaon does not in any way
warrant descripon accuracy or guarantee the use for the product to which it refers. Imagine Communicaons reserves
the right, without noce to make such changes in equipment, design, specicaons, components, or documentaon as
progress may warrant to improve the performance of the product.
Trademarks
6800+™, ADC™, CCS Navigator™, Channel ONE™, ChannelView™, ClipSync™, Delay™, D Series™, D Series DSX™, Deliver
the Moment™, Delivering the Moment™, FAME™, Farad™, G8™, G Scribe™, HView™, IconMaster™, IconLogo™, IconSta-
on™, IconKey™, InfoCaster™, InfoCaster Creator™, InfoCaster Manager™, InfoCaster Player™, InstantOnline™, Invenio®,
Live Update™, mCAPTURE™, Magellan™, Magellan CCS Navigator™, Magellan Q SEE™, MulService SDN™, NetPlus™,
NetVX™, NewsForce™, Nexio® G8™, Nexio AMP® ChannelView™, Nexio® Channel ONE™, Nexio® ClipSync™, Nexio®
Delay™, Nexio® Digital Turnaround Processor™, Nexio® Farad™, Nexio® G Scribe™, Nexio® IconKey™, Nexio® IconLogo™,
Nexio® IconMaster™, Nexio® IconStaon™, Nexio® InfoCaster™, Nexio® InfoCaster Creator™, Nexio® InfoCaster Manag-
er™, Nexio® InfoCaster Player™, Nexio® InfoCaster Trac™, Nexio® InstantOnline™, Nexio® mCAPTURE™, Nexio® News-
Force™, Nexio® NXIQ™, Nexio® Playlist™, Nexio® Remote™, Nexio®RTX Net™, Nexio® TitleMoon™, Nexio® TitleOne™,
Nexio® Velocity ESX™, Nexio® Velocity PRX™, Nexio® Velocity XNG™, Nexio® Volt™, OPTO+™, Panacea™, Planum™,
Playlist™, Predator II GRF™, Predator II GX™, Punctuate™, Remote™, RTX Net™, QuiC™, Q SEE™, SD STAR™, Selenio™,
Selenio 6800+™, SelenioNext™, Selenio X50™, Selenio X85™, Selenio X100™, TitleMoon™, TitleOne™, Velocity ESX™,
Velocity PRX™, Velocity XNG™, Versio™, Videotek® SD STAR™, X50™, and X85™ are trademarks of Imagine Communica-
ons or its subsidiaries.
Altude Express®, Connectus®, Enabling PersonalizedTV®, ICE® Broadcast System, ICE Illustrate®, ICE Q® algorithms, ICE-
PAC®, Imagine ICE®, Inscriber®, Inscriber® Connectus®, Invenio®, NEO®, Nexio®, Nexio AMP®, PersonalizedTV®, Router-
Works®, Videotek®, Videotek® ASI STAR®, Videotek® GEN STAR®, and Videotek® HD STAR® are registered trademarks of
Imagine Communicaons or its subsidiaries.
Microso® and Windows® are registered trademarks of Microso Corporaon. HD BNC is a trademark of Amphenol
Corporaon. Some products are manufactured under license from Dolby Laboratories. Dolby and the double D symbol
are registered trademarks of Dolby Laboratories. DTS Neural audio products are manufactured under license from DTS
Licensing Limited. DTS and the Symbol are registered trademarks & the DTS Logos are trademarks of DTS, Inc. © 2008
2010 DTS, Inc. All other trademarks and trade names are the property of their respecve companies.
Contact Informaon
Imagine Communicaons has oce locaons around the world. For locaons and contact informaon see:
hp://www.imaginecommunicaons.com/contact us/
Support Contact Informaon
For support contact informaon see:
▪Support Contacts: hp://www.imaginecommunicaons.com/services/technical support/
▪eCustomer Portal: hp://support.imaginecommunicaons.com
© 2014 Imagine Communicaons Corp. Proprietary and Condenal

6800+
DA-S6802+DL: 1×8 Looping Input SD/ASI Distribution
Amplifiers
DA-SR6802+DL:1×8 Looping Input SD/ASI Distribution
Amplifiers with Reclocking
DA-H6802+DL: 1×8 Looping Input 3 Gb/s, HD-SDI,
SD-SDI, and ASI Distribution Amplifiers
DA-HR6802+DL: 1×8 Looping Input 3 Gb/s, HD-SDI,
SD-SDI, and ASI Distribution Amplifiers with Reclocking
Installation and Operation Manual
Edition A
March 2009

DA-S/SR/H/HR6802+DL Installation and Operation Manual iii
Copyright © 2009, Harris Corporation
Contents
Preface
Manual Information ................................................................................................. v
Purpose ............................................................................................................. v
Audience ........................................................................................................... v
Revision History ............................................................................................... v
Writing Conventions ....................................................................................... vi
Obtaining Documents ...................................................................................... vi
Unpacking/Shipping Information .......................................................................... vii
Unpacking a Product ...................................................................................... vii
Product Servicing ........................................................................................... vii
Returning a Product ........................................................................................ vii
Safety Standards and Compliances ......................................................................viii
Safety Terms and Symbols ............................................................................viii
Restriction on Hazardous Substances (RoHS) Directive ................................ ix
Waste from Electrical and Electronic Equipment
(WEEE) Directive ............................................................................................ x
Chapter 1: Introduction
Product Description .................................................................................................. 1
Main Features ........................................................................................................... 1
DA-S6802+DL ................................................................................................. 1
DA-SR6802+DL .............................................................................................. 2
DA-H6802+DL ................................................................................................ 2
DA-HR6802+DL ............................................................................................. 2
Back Modules .......................................................................................................... 3
Signal Flow............................................................................................................... 4
Chapter 2: Installation and Operation
Installation Procedures ............................................................................................. 5
Unpacking the Module ..................................................................................... 5
Setting Jumpers ................................................................................................ 5
Maximum 6800+Frame Power Ratings .......................................................... 6
Installing 6800+Modules ................................................................................ 7
Making Connections ........................................................................................ 7
Operation ................................................................................................................. 8
Operating Notes ................................................................................................ 8
Understanding Parameter Types ...................................................................... 8

iv DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Contents
Setting Locally Controlled Parameters ............................................................ 9
Setting Remotely Controlled Parameters ....................................................... 10
Recalling Default Parameter Settings ............................................................ 10
Reading Software and Hardware Versions .................................................... 11
LEDs and Alarms ................................................................................................... 11
Module Status Indicator LED ........................................................................ 11
Module-Specific LEDs ................................................................................... 12
Alarms ............................................................................................................ 13
Chapter 3: Specifications
Inputs ...................................................................................................................... 15
Outputs .................................................................................................................. 16
Performance ........................................................................................................... 17
Power Consumption ............................................................................................... 17
Temperature ........................................................................................................... 17
Start-Up Time ........................................................................................................ 17
Index
Keywords ............................................................................................................... 19

DA-S/SR/H/HR6802+DL Installation and Operation Manual v
Copyright © 2009, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Preface
Manual Information
Purpose
This manual details the features, installation procedures, operational
procedures, and specifications of the following distribution amplifiers:
• DA-S6802+DL: 1×8 looping input SD/ASI distribution amplifiers
• DA-SR6802+DL: 1×8 looping input SD/ASI distribution amplifiers with
reclocking
• DA-H6802+DL: 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and ASI
distribution amplifiers
• DA-HR6802+DL: 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and ASI
distribution amplifiers with reclocking
Audience
This manual is written for engineers, technicians, and operators responsible for
the installation, setup, and/or operation of the DA-S/SR/H/HR6802+DL
distribution amplifiers.
Revision History
Table P-1. Manual Revision History
Edition Date Revision History
A March 2009 Initial release

vi DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Writing Conventions
To enhance your understanding, the authors of this manual have adhered to the
following text conventions:
Obtaining Documents
Product support documents can be viewed or downloaded from our website.
Alternatively, contact your Customer Service representative to request a
document.
Table P-2. Manual Style and Writing Conventions
Term or
Convention Description
Bold Indicates dialog boxes, property sheets, fields, buttons,
check boxes, list boxes, combo boxes, menus, submenus,
windows, lists, and selection names.
Italics Indicates email addresses, the names of books or
publications, and the first instances of new terms and
specialized words that need emphasis.
CAPS Indicates a specific key on the keyboard, such as ENTER,
TAB, CTRL, ALT, or DELETE.
Code Indicates variables or command-line entries, such as a
DOS entry or something you type into a field.
> Indicates the direction of navigation through a hierarchy
of menus and windows.
hyperlink Indicates a jump to another location within the electronic
document or elsewhere
Internet address Indicates a jump to a website or URL
Indicates important information that helps to avoid and
troubleshoot problems.

DA-S/SR/H/HR6802+DL Installation and Operation Manual vii
Copyright © 2009, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Unpacking/Shipping Information
Unpacking a Product
This product was carefully inspected, tested, and calibrated before shipment to
ensure years of stable and trouble free service.
1. Check equipment for any visible damage that may have occurred during
transit.
2. Confirm that you have received all items listed on the packing list.
3. Contact your dealer if any item on the packing list is missing.
4. Contact the carrier if any item is damaged.
5. Remove all packaging material from the product and its associated
components before you install the unit.
Product Servicing
DA-S/SR/H/HR6802+DL modules are not designed for field servicing. All
hardware and firmware upgrades, modifications, or repairs require you to return
the modules to the Customer Service center.
Returning a Product
In the unlikely event that your product fails to operate properly, please contact
Customer Service to obtain a Return Authorization (RA) number, and then send
the unit back for servicing.
Keep at least one set of original packaging, in the event that you need to return a
product for servicing. If the original packaging is not available, you can
purchase replacement packaging at a modest cost or supply your own packaging
as long as it meets the following criteria:
• Withstands the weight of the product
• Holds the product rigid within the packaging
• Leaves at least two inches of space between the product and the container
• Protects the corners of the product
Ship products back to us for servicing prepaid and, if possible, in the original
packaging material. If the product is still within the warranty period, we will
return the product prepaid after servicing.

viii DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Safety Standards and Compliances
See the 6800+Safety Instructions and Standards Manual to find the safety
standards and compliances for this 6800+series product. A safety manual is
shipped with every host frame installation and operation manual and can be
downloaded from our website. Alternatively, contact your Customer Service
representative for a copy of this safety manual.
Safety Terms and Symbols
This product manual uses the following safety terms and symbols to identify
certain conditions or practices. See the 6800+Safety Instructions and Standards
Manual for more information.
Table P-3. Safety Terms and Symbols
Symbol Description
WARNING
Identifies conditions or practices that can result in personal
injury or loss of life—high voltage is present. Uninsulated
dangerous voltage within the product’s enclosure may be
sufficient to constitute a risk of electric shock to persons.
CAUTION
Identifies conditions or practices that can result in damage to
the equipment or other property. Important operating and
maintenance (servicing) instructions are included in the
literature accompanying the product.

DA-S/SR/H/HR6802+DL Installation and Operation Manual ix
Copyright © 2009, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Restriction on Hazardous Substances (RoHS) Directive
Directive 2002/95/EC—commonly known as the European Union (EU)
Restriction on Hazardous Substances (RoHS)—sets limits on the use of certain
substances found in electrical and electronic equipment. The intent of this
legislation is to reduce the amount of hazardous chemicals that may leach out of
landfill sites or otherwise contaminate the environment during end-of-life
recycling. The Directive, which took effect on July 1, 2006, refers to the
following hazardous substances:
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent Chromium (Cr-V1)
• Polybrominated Biphenyls (PBB)
• Polybrominated Diphenyl Ethers (PBDE)
In accordance with this EU Directive, products sold in the European Union will
be fully RoHS-compliant and “lead-free.” (See our website for more
information.) Spare parts supplied for the repair and upgrade of equipment sold
before July 1, 2006 are exempt from the legislation. Equipment that complies
with the EU directive will be marked with a RoHS-compliant symbol, as shown
in Figure P-1.
Figure P-1. RoHS Compliance Symbol

x DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Waste from Electrical and Electronic Equipment
(WEEE) Directive
The European Union (EU) Directive 2002/96/EC on Waste from Electrical and
Electronic Equipment (WEEE) deals with the collection, treatment, recovery,
and recycling of electrical and electronic waste products. The objective of the
WEEE Directive is to assign the responsibility for the disposal of associated
hazardous waste to either the producers or users of these products. As of August
13, 2005, producers or users are required to recycle electrical and electronic
equipment at end of its useful life, and must not dispose of the equipment in
landfills or by using other unapproved methods. (Some EU member states may
have different deadlines.)
In accordance with this EU Directive, companies selling electric or electronic
devices in the EU will affix labels indicating that such products must be
properly recycled. (See our website for more information.) Contact your local
Sales representative for information on returning these products for recycling.
Equipment that complies with the EU directive will be marked with a
WEEE-compliant symbol, as shown in Figure P-2.
Figure P-2. WEEE Compliance Symbol

DA-S/SR/H/HR6802+DL Installation and Operation Manual 1
Copyright © 2009, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 1
Introduction
Product Description
The DA-S/SR/H/HR6802+DL series of distribution amplifiers are designed to
process serial digital television signals according to SMPTE 257C, 292M,
424M, and DVI-ASI. They can also handle other bi-level data within amplitude
and date rate limitation, such as 19.39 Mb/s and 38.78 Mb/s SSI. These
distribution amplifiers feature high reliability, excellent video performance, and
low cost.
The individual modules are available as follows:
• The DA-S6802+DL is a 1×8 looping input SD/ASI distribution amplifier
•TheDA-SR6802+DL is a 1×8 looping input SD/ASI distribution amplifier
with reclocking
• The DA-H6802+DL is a 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and
ASI distribution amplifier
• The DA-HR6802+DL is a 1×8 looping input 3 Gb/s, HD-SDI, SD-SDI, and
ASI distribution amplifier with reclocking
You can control and monitor these distribution amplifier modules locally (via
jumpers and card-edge LEDs) or remotely (via optional ICE6800+or
6800+ETH Ethernet connection).
Main Features
DA-S6802+DL
• One input, eight non-reclocked outputs, one looping output
• Passive looping
• Handles data rates 540 Mb/s and below
• Input signal presence detect and report
• Automatic input cable equalization
• Card edge control by jumpers with LED display
• Remote control and monitoring via Ethernet

2 DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
DA-SR6802+DL
• One input, eight reclocked outputs, one looping output
• Passive looping
• Handles data rates 540 Mb/s and below
• Input signal presence detect and report
• Automatic input cable equalization
• Automatic reclocking 270 Mb/s SD or DVB-ASI
• Reclock status and rate report by LEDs
• Automatic bypass reclocking stage if not relockable
• Enforce bypass reclocker is available
• Card edge control by jumpers with LED display
• Remote control and monitoring via Ethernet
DA-H6802+DL
• One input, eight non-reclocked outputs, one looping output
• Passive looping
• Handles data rates 3.0 Gb/s and below
• Input signal presence detect and report
• Automatic input cable equalization
• Card edge control by jumpers with LED display
• Remote control and monitoring via Ethernet
DA-HR6802+DL
• One input, eight reclocked outputs, one looping output
• Passive looping
• Handles data rates 3.0 Gb/s and below
• Input signal presence detect and report
• Automatic input cable equalization
• Automatic and manual reclocking 270 Mb/s,1.485 Gb/s, 2.97 Gb/s, or
DVB-ASI
• Reclock status and rate report by LEDs
• Automatic bypass reclocking stage if not relockable
• Enforce bypass reclocker is available
• Card edge control by jumpers with LED display
• Remote control and monitoring via Ethernet

DA-S/SR/H/HR6802+DL Installation and Operation Manual 3
Copyright © 2009, Harris Corporation
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Back Modules
DA-S/SR/H/HR6802+DL modules can be installed with double-width looping
back modules in their host frames. These modules cannot be installed in
6800/7000 series frames.
Figure 1-1 shows the double-width looping back connector module used by the
DA-S/SR/H/HR6802+DL.
Figure 1-1. DA-S/SR/H/HR6802+DL Double-Width Back Module

4 DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Signal Flow
Figure 1-2. Signal Flow Diagram

DA-S/SR/H/HR6802+DL Installation and Operation Manual 5
Copyright © 2009, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 2
Installation and Operation
Installation Procedures
Caution
Before installing this product, read the 6800+Series Safety Instructions
and Standards manual shipped with every host frame installation and
operation manual, or downloadable from our website. This safety
manual contains important information about the safe installation and
operation of 6800+series products.
Unpacking the Module
Review “Unpacking/Shipping Information” on page vii before you install
DA-S/SR/H/HR6802+DL modules.
Setting Jumpers
You need to configure modules for local or remote operation before power-up.
You can use the J1 jumper to select local control reclock setting or to select
remote control operation. See Figure 2-1 for a close-up view of the J1 jumper
set. Table 2-2 on page 9 shows the possible local reclocking mode parameters.
Follow this procedure to set the jumpers:
1. Locate the J1 jumper set on the module.
2. Place a shunt on the pin that corresponds to the mode that you want.

6 DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 2: Installation and Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Figure 2-1. J1 Jumper Set Location
Maximum 6800+Frame Power Ratings
Power consumption information is listed in Chapter 3: “Specifications” on
page 17.
Table 2-1 describes the maximum allowable power ratings for 6800+frames.
Note the given maximums before installing any 6800+modules in your frame.
DA-S/SR/H/HR6802+DL modules can be installed in FR6802+or FR6822+
frames. They cannot be installed in 6800/7000 series frames.
Table 2-1. Maximum Power Ratings for 6800+Frames
6800+Frame Type
Max. Frame
Power
Dissipation
No. Usable
Slots
Max. Power
Dissipation
Per Slot
FR6802+XF
(frame with AC power
supply)
120 W 20 6 W
FR6802+XF48
(frame with DC power
supply)
105 W 20 5.25 W
FR6802+QXF
(frame with AC or DC
power supply)
120 W 20 6 W
FR6822+
(frame with AC or DC
power supply)
120 W 20 6 W

DA-S/SR/H/HR6802+DL Installation and Operation Manual 7
Copyright © 2009, Harris Corporation
Chapter 2: Installation and Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Installing 6800+Modules
Back Module Types
The DA-S/SR/H/HR6802+DL modules have double-width back modules (see
Figure 1-1 on page 3). See the host frame installation and operation manual for
details on back module installation.
Installing Modules
These modules require no specialized installation or removal procedures. See
the host frame installation and operation manual for information about installing
and operating a frame and its components, or for removing components from a
frame.
These modules cannot be installed in 6800/7000 series frames.
Making Connections
Once you have installed the module, you can connect it to the appropriate input
and outputs.

8 DA-S/SR/H/HR6802+DL Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 2: Installation and Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Operation
Operating Notes
When you change a control parameter on a DA-S/SR/H/HR6802+DL module,
the effect is immediate. However, the module requires up to 20 seconds to save
the latest change. After 20 seconds, the new settings are saved and will be
restored if the module loses power and must be restarted.
Understanding Parameter Types
Most module parameters are adjustable, and can be set via a CCS software
application (see “Setting Remotely Controlled Parameters” on page 10 and
“Recalling Default Parameter Settings” on page 10). However, there are some
parameters that are considered “read-only” and cannot be changed. Indicated by
the abbreviation “[RO],” these parameters provide status and feedback
information only.
Harris recommends that you use the available 6800+software control options
(serial/local or Ethernet/remote) to aid in viewing, setting, and confirming
parameter values.
Adjustable Parameters
Two types of adjustable parameters can be changed. Numerical parameters
require you to select a value within a numerical range. Selectable parameters
require you to select a specific option. Both numerical and selectable parameter
changes are immediate. Use the available 6800+software controls (serial/local
or Ethernet/remote network) to view and monitor parameter selections.
Read-Only Parameters
These parameters provide status and feedback information only. They are
represented by LEDs on the front of the module’s card edge. See Figure 2-2 on
page 11 and Figure 2-3 on page 12 for the location of these LEDs.
