Imagine DA-ASI6802+ User manual

Delivering the Moment
Installaon and Operaon Manual
DA-ASI6802+: 1×8 ASI
Distribuon Ampliers
Edion A
175-100028-00

Publicaon Informaon
© 2014 Imagine Communicaons Corp. Proprietary and Condenal.
Imagine Communicaons considers this document and its contents to be proprietary and condenal. Except for
making a reasonable number of copies for your own internal use, you may not reproduce this publicaon, or any part
thereof, in any form, by any method, for any purpose, or in any language other than English without the wrien consent
of Imagine Communicaons. All others uses are illegal.
This publicaon is designed to assist in the use of the product as it exists on the date of publicaon of this manual, and
may not reect the product at the current me or an unknown me in the future. This publicaon does not in any way
warrant descripon accuracy or guarantee the use for the product to which it refers. Imagine Communicaons reserves
the right, without noce to make such changes in equipment, design, specicaons, components, or documentaon as
progress may warrant to improve the performance of the product.
Trademarks
6800+™, ADC™, CCS Navigator™, Channel ONE™, ChannelView™, ClipSync™, Delay™, D Series™, D Series DSX™, Deliver
the Moment™, Delivering the Moment™, FAME™, Farad™, G8™, G Scribe™, HView™, IconMaster™, IconLogo™, IconSta-
on™, IconKey™, InfoCaster™, InfoCaster Creator™, InfoCaster Manager™, InfoCaster Player™, InstantOnline™, Invenio®,
Live Update™, mCAPTURE™, Magellan™, Magellan CCS Navigator™, Magellan Q SEE™, MulService SDN™, NetPlus™,
NetVX™, NewsForce™, Nexio® G8™, Nexio AMP® ChannelView™, Nexio® Channel ONE™, Nexio® ClipSync™, Nexio®
Delay™, Nexio® Digital Turnaround Processor™, Nexio® Farad™, Nexio® G Scribe™, Nexio® IconKey™, Nexio® IconLogo™,
Nexio® IconMaster™, Nexio® IconStaon™, Nexio® InfoCaster™, Nexio® InfoCaster Creator™, Nexio® InfoCaster Manag-
er™, Nexio® InfoCaster Player™, Nexio® InfoCaster Trac™, Nexio® InstantOnline™, Nexio® mCAPTURE™, Nexio® News-
Force™, Nexio® NXIQ™, Nexio® Playlist™, Nexio® Remote™, Nexio®RTX Net™, Nexio® TitleMoon™, Nexio® TitleOne™,
Nexio® Velocity ESX™, Nexio® Velocity PRX™, Nexio® Velocity XNG™, Nexio® Volt™, OPTO+™, Panacea™, Planum™,
Playlist™, Predator II GRF™, Predator II GX™, Punctuate™, Remote™, RTX Net™, QuiC™, Q SEE™, SD STAR™, Selenio™,
Selenio 6800+™, SelenioNext™, Selenio X50™, Selenio X85™, Selenio X100™, TitleMoon™, TitleOne™, Velocity ESX™,
Velocity PRX™, Velocity XNG™, Versio™, Videotek® SD STAR™, X50™, and X85™ are trademarks of Imagine Communica-
ons or its subsidiaries.
Altude Express®, Connectus®, Enabling PersonalizedTV®, ICE® Broadcast System, ICE Illustrate®, ICE Q® algorithms, ICE-
PAC®, Imagine ICE®, Inscriber®, Inscriber® Connectus®, Invenio®, NEO®, Nexio®, Nexio AMP®, PersonalizedTV®, Router-
Works®, Videotek®, Videotek® ASI STAR®, Videotek® GEN STAR®, and Videotek® HD STAR® are registered trademarks of
Imagine Communicaons or its subsidiaries.
Microso® and Windows® are registered trademarks of Microso Corporaon. HD BNC is a trademark of Amphenol
Corporaon. Some products are manufactured under license from Dolby Laboratories. Dolby and the double D symbol
are registered trademarks of Dolby Laboratories. DTS Neural audio products are manufactured under license from DTS
Licensing Limited. DTS and the Symbol are registered trademarks & the DTS Logos are trademarks of DTS, Inc. © 2008
2010 DTS, Inc. All other trademarks and trade names are the property of their respecve companies.
Contact Informaon
Imagine Communicaons has oce locaons around the world. For locaons and contact informaon see:
hp://www.imaginecommunicaons.com/contact us/
Support Contact Informaon
For support contact informaon see:
▪Support Contacts: hp://www.imaginecommunicaons.com/services/technical support/
▪eCustomer Portal: hp://support.imaginecommunicaons.com
© 2014 Imagine Communicaons Corp. Proprietary and Condenal

DA-ASI802+
1×8 ASI Distribution Amplifiers
Installation and Operation Manual
Edition A
December 2008

DA-ASI6802+Installation and Operation Manual iii
Copyright © 2008, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Contents
Preface
Manual Information .............................................................................................vii
Purpose .........................................................................................................vii
Audience .......................................................................................................vii
Revision History ...........................................................................................vii
Writing Conventions ...................................................................................viii
Obtaining Documents ..................................................................................viii
Unpacking/Shipping Information ......................................................................... ix
Unpacking a Product ..................................................................................... ix
Product Servicing .......................................................................................... ix
Returning a Product ....................................................................................... ix
Safety Standards and Compliances ....................................................................... x
Safety Terms and Symbols ............................................................................. x
Restriction on Hazardous Substances (RoHS) Directive ..............................xi
Waste from Electrical and Electronic Equipment
(WEEE) Directive ........................................................................................xii
Chapter 1: Introduction
Overview ................................................................................................................ 1
Product Description ............................................................................................... 2
Main Features ................................................................................................. 2
Typical Broadcast and Production Applications ............................................ 2
Module Descriptions ............................................................................................. 3
Front Module .................................................................................................. 3
Back Modules ................................................................................................. 3
Signal Flow ............................................................................................................ 4
Chapter 2: Installation
Overview ................................................................................................................ 5
Maximum 6800+Frame Power Ratings ............................................................... 6
Unpacking the Module .......................................................................................... 7
Preparing for Installation ................................................................................ 7
Checking the Packing List .............................................................................. 7
Setting Jumpers ...................................................................................................... 7
Setting J1 Jumpers .......................................................................................... 7

iv DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Contents
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Installing 6800+Modules ...................................................................................... 8
Required Frames and Back Module Connector Types ................................... 8
Installing Modules .......................................................................................... 8
Removing Modules ........................................................................................ 8
Making Connections............................................................................................... 8
Chapter 3: Operation
Overview ................................................................................................................ 9
Operating Notes ................................................................................................... 10
Understanding Jumper Controls ........................................................................... 10
Introducing Jumper Control Types .............................................................. 10
J1 Jumpers .................................................................................................... 10
Understanding Parameter Types........................................................................... 11
Adjustable Parameters .................................................................................. 11
Read-Only Parameters .................................................................................. 11
Setting Locally Controlled Parameters ................................................................ 12
Local Control Reclocking Mode .................................................................. 12
Setting Remotely Controlled Parameters ............................................................ 13
Changing Parameter Settings Using CCS Software ............................................ 14
Changing Parameters Using CCS Software ................................................. 14
Recalling Default Parameter Settings .......................................................... 14
Reading Software and Hardware Versions .................................................. 15
LEDs and Alarms ................................................................................................. 15
Module Status Indicator LED ...................................................................... 15
Module-Specific LEDs ................................................................................. 16
Alarms .......................................................................................................... 17
Chapter 4: Specifications
Overview .............................................................................................................. 19
Inputs ................................................................................................................... 20
Outputs ................................................................................................................. 20
Performance ......................................................................................................... 21
Power Consumption ............................................................................................. 21
Temperature ......................................................................................................... 21
Start-Up Time ...................................................................................................... 21
Appendix A: Troubleshooting
Overview ............................................................................................................. 23
General Troubleshooting Steps ........................................................................... 24
Control and Monitoring Using CCS Software .................................................... 25
Refreshing Your Module Using +Pilot Lite ............................................... 25
Discovering Your Module Using CCS Software ......................................... 25
Software Communication and Control Issues ..................................................... 26
+ Pilot Lite Fails to Communicate with Installed Modules ......................... 26
+ Pilot Lite Does Not Find All Modules in Frame ...................................... 27

DA-ASI6802+Installation and Operation Manual v
Copyright © 2008, Harris Corporation
Contents
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
+ Pilot Lite or CCS Software Application Not Responding ........................27
+ Pilot Lite Cannot Control a Module Showing
in the Control Window ................................................................................. 28
+ Pilot Lite Status Bar Reports ‘Not Ready’ Status .................................... 28
CCS Software Application or Remote Control Panel
Does Not Communicate with Module .......................................................... 28
Alarm Query Fails When a Device Reboots ................................................ 28
Hardware Communication and Control Issues .................................................... 29
Frame Fails to Communicate with the PC After a Power Failure ................ 29
Module Does Not Seem to Work ................................................................. 29
Contacting Customer Service ............................................................................... 29
Index
Keywords ............................................................................................................. 31

vi DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Contents
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.

DA-ASI6802+Installation and Operation Manual vii
Copyright © 2008, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Preface
Manual Information
Purpose
This manual details the features, installation procedures, operational
procedures, and specifications of the DA-ASI6802+1×8 ASI distribution
amplifier
Audience
This manual is written for engineers, technicians and operators responsible for
the installation, setup, and/or operation of the DA-ASI6802+1×8 ASI
distribution amplifier.
Revision History
Table 3-1. Manual Revision History
Edition Date Revision History
A December 2008 Initial release

viii DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Writing Conventions
To enhance your understanding, the authors of this manual have adhered to the
following text conventions:
Obtaining Documents
Product support documents can be viewed or downloaded from our website.
Alternatively, contact your Customer Service representative to request a
document.
Table 3-2. Manual Style and Writing Conventions
Term or
Convention Description
Bold Indicates dialog boxes, property sheets, fields, buttons,
check boxes, list boxes, combo boxes, menus, submenus,
windows, lists, and selection names.
Italics Indicates email addresses, the names of books or
publications, and the first instances of new terms and
specialized words that need emphasis.
CAPS Indicates a specific key on the keyboard, such as ENTER,
TAB, CTRL, ALT, or DELETE.
Code Indicates variables or command-line entries, such as a
DOS entry or something you type into a field.
> Indicates the direction of navigation through a hierarchy
of menus and windows.
hyperlink Indicates a jump to another location within the electronic
document or elsewhere
Internet address Indicates a jump to a website or URL
Indicates important information that helps to avoid and
troubleshoot problems.

DA-ASI6802+Installation and Operation Manual ix
Copyright © 2008, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Unpacking/Shipping Information
Unpacking a Product
This product was carefully inspected, tested, and calibrated before shipment to
ensure years of stable and trouble free service.
1. Check equipment for any visible damage that may have occurred during
transit.
2. Confirm that you have received all items listed on the packing list.
3. Contact your dealer if any item on the packing list is missing.
4. Contact the carrier if any item is damaged.
5. Remove all packaging material from the product and its associated
components before you install the unit.
Product Servicing
DA-ASI6802+modules are not designed for field servicing. All hardware and
firmware upgrades, modifications, or repairs require you to return the modules
to the Customer Service center.
Returning a Product
In the unlikely event that your product fails to operate properly, please contact
Customer Service to obtain a Return Authorization (RA) number, then send the
unit back for servicing.
Keep at least one set of original packaging, in the event that you need to return a
product for servicing. If the original packaging is not available, you can
purchase replacement packaging at a modest cost or supply your own packaging
as long as it meets the following criteria:
• Withstands the weight of the product
• Holds the product rigid within the packaging
• Leaves at least two inches of space between the product and the container
• Protects the corners of the product
Ship products back to us for servicing prepaid and, if possible, in the original
packaging material. If the product is still within the warranty period, we will
return the product prepaid after servicing.

x DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Safety Standards and Compliances
See the 6800+Safety Instructions and Standards Manual to find the safety
standards and compliances for this 6800+series product. A safety manual is
shipped with every FR6802+Frame Installation and Operation Manual and
can be downloaded from our website. Alternatively, contact your Customer
Service representative for a copy of this safety manual.
Safety Terms and Symbols
This product manual uses the following safety terms and symbols to identify
certain conditions or practices. See the 6800+Safety Instructions and Standards
Manual for more information.
Table 3-3. Safety Terms and Symbols
Symbol Description
WARNING
Identifies conditions or practices that can result in
personal injury or loss of life—high voltage is
present. Uninsulated dangerous voltage within the
product’s enclosure may be sufficient to constitute a
risk of electric shock to persons.
CAUTION
Identifies conditions or practices that can result in
damage to the equipment or other property.
Important operating and maintenance (servicing)
instructions are included in the literature
accompanying the product.

DA-ASI6802+Installation and Operation Manual xi
Copyright © 2008, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Restriction on Hazardous Substances (RoHS) Directive
Directive 2002/95/EC—commonly known as the European Union (EU)
Restriction on Hazardous Substances (RoHS)—sets limits on the use of certain
substances found in electrical and electronic equipment. The intent of this
legislation is to reduce the amount of hazardous chemicals that may leach out of
landfill sites or otherwise contaminate the environment during end-of-life
recycling. The Directive, which took effect on July 1, 2006, refers to the
following hazardous substances:
• Lead (Pb)
•Mercury(Hg)
• Cadmium (Cd)
• Hexavalent Chromium (Cr-V1)
• Polybrominated Biphenyls (PBB)
• Polybrominated Diphenyl Ethers (PBDE)
In accordance with this EU Directive, products sold in the European Union will
be fully RoHS-compliant and “lead-free.” (See our website for more
information.) Spare parts supplied for the repair and upgrade of equipment sold
before July 1, 2006 are exempt from the legislation. Equipment that complies
with the EU directive will be marked with a RoHS-compliant symbol, as shown
in Figure P-3-1.
Figure 3-1. RoHS Compliance Symbol

xii DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Preface
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Waste from Electrical and Electronic Equipment
(WEEE) Directive
The European Union (EU) Directive 2002/96/EC on Waste from Electrical and
Electronic Equipment (WEEE) deals with the collection, treatment, recovery,
and recycling of electrical and electronic waste products. The objective of the
WEEE Directive is to assign the responsibility for the disposal of associated
hazardous waste to either the producers or users of these products. As of August
13, 2005, producers or users are required to recycle electrical and electronic
equipment at end of its useful life, and must not dispose of the equipment in
landfills or by using other unapproved methods. (Some EU member states may
have different deadlines.)
In accordance with this EU Directive, companies selling electric or electronic
devices in the EU will affix labels indicating that such products must be
properly recycled. (See our website for more information.) Contact your local
Sales representative for information on returning these products for recycling.
Equipment that complies with the EU directive will be marked with a
WEEE-compliant symbol, as shown in Figure P-3-2.
Figure 3-2. WEEE Compliance Symbol

DA-ASI6802+Installation and Operation Manual 1
Copyright © 2008, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 1
Introduction
Overview
The following topics are described in this chapter:
•“Main Features” on page 2
•“Module Descriptions” on page 3
•“Product Description” on page 2
•“Signal Flow” on page 4

2 DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Product Description
The DA-ASI6802+distribution amplifiers are designed to distribute serial
digital video signals according to SMPTE 257C, DVB, and other related
standards. They feature high reliability, excellent video performance, and low
cost.
You can can control and monitor these distribution amplifier modules locally
(via jumpers and card-edge LEDs) or remotely (via RS-232 ports or optional
ICE6800+and 6800+ETH Ethernet connection).
Main Features
• One input, eight outputs
• Input signal presence detect and report
• Automatic input cable equalization
• Automatic reclocking 270 Mb/s DVB-ASI
• Reclock status and rate report by LEDs
• Automatic bypass reclocking stage if not relockable
• Card edge control by jumpers with LED display
• Remote monitoring via RS-232 or Ethernet
Typical Broadcast and Production Applications
DA-ASI6802+distribution amplifiers can be used in broadcast, cable,
production, educational, and auditorium applications where high performance
SD-SDI signal distribution is required.

DA-ASI6802+Installation and Operation Manual 3
Copyright © 2008, Harris Corporation
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Module Descriptions
Front Module
Figure 1-1 is a generic top-front view of a typical front module. See Figure 3-2
on page 20 and Figure 3-3 on page 21 for LED locations.
Figure 1-1. Typical Front Module
Back Modules
DA-ASI6802+modules can be installed with double-width (1×8) back modules
in FR6802+QX(F) and FR6802+DM frames. These modules cannot be
installed in 6800/7000 series frames.
FR6802+Frame Back Module
Figure 1-2 on page 3 shows the double-width back connector module used by
the DA-ASI6802+when installed in an FR6802+XF, FR6802+QXF, or
FR6802+DM frame.
Figure 1-2. Double-Width Back Module for FR6802+X(F) and
FR6802+DM Frames

4 DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Chapter 1: Introduction
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Signal Flow
Figure 1-3. Signal Flow Diagram

DA-ASI6802+Installation and Operation Manual 5
Copyright © 2008, Harris Corporation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 2
Installation
Overview
This chapter describes the DA-ASI6802+module’s installation process,
including the following topics:
•“Installing Modules” on page 8
•“Making Connections” on page 8
•“Maximum 6800+Frame Power Ratings” on page 6
•“Removing Modules” on page 8
•“Required Frames and Back Module Connector Types” on page 8
•“Setting Jumpers” on page 7
•“Unpacking the Module” on page 7
See the FR6802+Frame Installation and Operation Manual for information
about installing and operating an FR6802+frame and its components.
CAUTION
Before installing this product, read the 6800+Series
Safety Instructions and Standards manual shipped
with every FR6802+Frame Installation and Operation
Manual, or downloadable from our website. This
safety manual contains important information about
the safe installation and operation of 6800+series
products.

6 DA-ASI6802+Installation and Operation Manual
Copyright © 2008, Harris Corporation
Chapter 2: Installation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Maximum 6800+Frame Power Ratings
Power consumption information is listed in Chapter 4: “Specifications” on
page 26.
Table 2-1 describes the maximum allowable power ratings for 6800+frames.
Note the given maximums before installing any 6800+modules in your frame.
DA-ASI6802+modules can be installed in FR6802+frames. They cannot be
installed in 6800/7000 series frames.
Table 2-1. Maximum Power Ratings for 6800+Frames
6800+Frame Type
Max. Frame
Power
Dissipation
No. Usable
Slots
Max. Power
Dissipation
Per Slot
FR6802+XF
(frame with AC power
supply)
120 W 20 6 W
FR6802+XF48
(frame with DC power
supply)
105 W 20 5.25 W
FR6802+QXF
(frame with AC or DC
power supply)
120 W 20 6 W
