Imagine DA-DSR6804+D User manual

Delivering the Moment
Installation and Operaon Manual
DA-6804+D
Single- and Dual-Channel
3G HD-SDI, 1.5 G HD-SDI, and
SD-SDI Distribuon Ampliers
Edion B
175-100192-00

Publicaon Informaon
© 2014 Imagine Communicaons Corp. Proprietary and Condenal.
Imagine Communicaons considers this document and its contents to be proprietary and condenal. Except for
making a reasonable number of copies for your own internal use, you may not reproduce this publicaon, or any part
thereof, in any form, by any method, for any purpose, or in any language other than English without the wrien consent
of Imagine Communicaons. All others uses are illegal.
This publicaon is designed to assist in the use of the product as it exists on the date of publicaon of this manual, and
may not reect the product at the current me or an unknown me in the future. This publicaon does not in any way
warrant descripon accuracy or guarantee the use for the product to which it refers. Imagine Communicaons reserves
the right, without noce to make such changes in equipment, design, specicaons, components, or documentaon as
progress may warrant to improve the performance of the product.
Trademarks
6800+™, ADC™, CCS Navigator™, Channel ONE™, ChannelView™, ClipSync™, Delay™, D Series™, D Series DSX™, Deliver
the Moment™, Delivering the Moment™, FAME™, Farad™, G8™, G Scribe™, HView™, IconMaster™, IconLogo™, IconSta-
on™, IconKey™, InfoCaster™, InfoCaster Creator™, InfoCaster Manager™, InfoCaster Player™, InstantOnline™, Invenio®,
Live Update™, mCAPTURE™, Magellan™, Magellan CCS Navigator™, Magellan Q SEE™, MulService SDN™, NetPlus™,
NetVX™, NewsForce™, Nexio® G8™, Nexio AMP® ChannelView™, Nexio® Channel ONE™, Nexio® ClipSync™, Nexio®
Delay™, Nexio® Digital Turnaround Processor™, Nexio® Farad™, Nexio® G Scribe™, Nexio® IconKey™, Nexio® IconLogo™,
Nexio® IconMaster™, Nexio® IconStaon™, Nexio® InfoCaster™, Nexio® InfoCaster Creator™, Nexio® InfoCaster Manag-
er™, Nexio® InfoCaster Player™, Nexio® InfoCaster Trac™, Nexio® InstantOnline™, Nexio® mCAPTURE™, Nexio® News-
Force™, Nexio® NXIQ™, Nexio® Playlist™, Nexio® Remote™, Nexio®RTX Net™, Nexio® TitleMoon™, Nexio® TitleOne™,
Nexio® Velocity ESX™, Nexio® Velocity PRX™, Nexio® Velocity XNG™, Nexio® Volt™, OPTO+™, Panacea™, Planum™,
Playlist™, Predator II GRF™, Predator II GX™, Punctuate™, Remote™, RTX Net™, QuiC™, Q SEE™, SD STAR™, Selenio™,
Selenio 6800+™, SelenioNext™, Selenio X50™, Selenio X85™, Selenio X100™, TitleMoon™, TitleOne™, Velocity ESX™,
Velocity PRX™, Velocity XNG™, Versio™, Videotek® SD STAR™, X50™, and X85™ are trademarks of Imagine Communica-
ons or its subsidiaries.
Altude Express®, Connectus®, Enabling PersonalizedTV®, ICE® Broadcast System, ICE Illustrate®, ICE Q® algorithms, ICE-
PAC®, Imagine ICE®, Inscriber®, Inscriber® Connectus®, Invenio®, NEO®, Nexio®, Nexio AMP®, PersonalizedTV®, Router-
Works®, Videotek®, Videotek® ASI STAR®, Videotek® GEN STAR®, and Videotek® HD STAR® are registered trademarks of
Imagine Communicaons or its subsidiaries.
Microso® and Windows® are registered trademarks of Microso Corporaon. HD BNC is a trademark of Amphenol
Corporaon. Some products are manufactured under license from Dolby Laboratories. Dolby and the double D symbol
are registered trademarks of Dolby Laboratories. DTS Neural audio products are manufactured under license from DTS
Licensing Limited. DTS and the Symbol are registered trademarks & the DTS Logos are trademarks of DTS, Inc. © 2008
2010 DTS, Inc. All other trademarks and trade names are the property of their respecve companies.
Contact Informaon
Imagine Communicaons has oce locaons around the world. For locaons and contact informaon see:
hp://www.imaginecommunicaons.com/contact us/
Support Contact Informaon
For support contact informaon see:
▪Support Contacts: hp://www.imaginecommunicaons.com/services/technical support/
▪eCustomer Portal: hp://support.imaginecommunicaons.com
© 2014 Imagine Communicaons Corp. Proprietary and Condenal

Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
DA-DH6804+D
Dual 1×4 3-Gb/s HD-SDI Distribution Amplifiers
DA-DHR6804+D
Dual 1×4 3-Gb/s HD-SDI Distribution Amplifiers with Reclocking
DA-DS6804+D
Dual 1×4 SD-SDI Distribution Amplifiers
DA-DSR6804+D
Dual 1×4 SD-SDI Distribution Amplifiers with Reclocking
Installation and Operation Manual
Edition B
May 2011

iii
Copyright © 2011, Harris Corporation
Contents
About This Manual
Intended Audience .............................................................................................v
Revision History ..................................................................................................v
Writing Conventions ..........................................................................................vi
Obtaining Documents ........................................................................................vi
Unpacking/Shipping Information.........................................................................vi
Unpacking a Product ...................................................................................vi
Product Servicing ........................................................................................ vii
Returning a Product ................................................................................... vii
Safety Standards and Compliances.................................................................... vii
Safety Terms and Symbols ......................................................................... viii
Restriction on Hazardous Substances (RoHS) Directive ................................ viii
Waste from Electrical and Electronic Equipment (WEEE) Directive .................ix
Introduction
Main Features .................................................................................................... 2
All Models.................................................................................................... 2
DA-DSR6804+D and DHR6804+D Models .................................................... 2
Front Module..................................................................................................... 3
Back Module ..................................................................................................... 3
Signal Flow ........................................................................................................ 4
Maximum 6800+Frame Power Ratings ........................................................ 6
Installation
Jumpers J1 and J2 (DA-DSR6804+D and DA-DHR6804+D) ................................ 8
Jumper J3 .......................................................................................................... 9
Installing and Removing Modules ....................................................................... 9
Installation ................................................................................................... 9
Removal ....................................................................................................... 9
Operation
Automatic Changeover .................................................................................... 11
Reclocking ....................................................................................................... 11
LED Displays .................................................................................................... 12

Contents
iv
Copyright © 2011, Harris Corporation
Status Indicator ......................................................................................... 12
Signal Condition Indicators ........................................................................ 12
Web Browser Control ...................................................................................... 13
CCS Navigator Control .................................................................................... 14
Operating Notes .............................................................................................. 14
Specifications
Inputs .............................................................................................................. 17
Outputs ........................................................................................................... 18
Temperature .................................................................................................... 19
Power Consumption ........................................................................................ 19
Start-Up Time .................................................................................................. 19
Index
Keywords ........................................................................................................ 21

v
Copyright © 2011, Harris Corporation
About This Manual
This manual details the features, installation procedures, operational procedures,
and specifications of the following DA-6804+series distribution amplifiers:
DA-DH6804+D: Dual 1×4 3-Gb/s HD-SDI distribution amplifiers
DA-DHR6804+D: Dual 1×4 3-Gb/s HD-SDI distribution amplifiers with
reclocking
DA-DS6804+D: Dual 1×4 SD-SDI distribution amplifiers
DA-DSR6804+D: Dual 1×4 SD-SDI distribution amplifiers with reclocking
Intended Audience
This manual is written for engineers, technicians, and operators responsible for the
installation, setup, and/or operation of the DA-6804+series of distribution
amplifiers.
Revision History
Table P-1 Manual Revision History
Edition Date Revision History
AFebruary 2010 Initial release
BMay 2011 Product changes

About This Manual
vi
Copyright © 2011, Harris Corporation
Writing Conventions
To enhance your understanding, the authors of this manual have adhered to the
following text conventions:
Obtaining Documents
Technical documents can be viewed or downloaded from our website.
Alternatively, contact your Customer Service representative to request a document.
Unpacking/Shipping Information
This product was carefully inspected, tested, and calibrated before shipment to
ensure years of stable and trouble free service.
Unpacking a
Product
1Check equipment for any visible damage that may have occurred during
transit.
2Confirm that you have received the front and back module for the correct
product.
Table P-2 Manual Style and Writing Conventions
Term or
Convention Description
Bold Indicates dialog boxes, property sheets, fields, buttons, check
boxes, list boxes, combo boxes, menus, submenus, windows,
lists, and selection names
Italics Indicates email addresses, the names of books or publications,
and the first instances of new terms and specialized words
that need emphasis
CAPS Indicates a specific key on the keyboard, such as ENTER, TAB,
CTRL, ALT, or DELETE
Code Indicates variables or command-line entries, such as a DOS
entry or something you type into a field
>Indicates the direction of navigation through a hierarchy of
menus and windows
hyperlink Indicates a jump to another location within the electronic
document or elsewhere
Internet address Indicates a jump to a website or URL
NOTE: Indicates important information that helps to avoid and
troubleshoot problems

DA-6804+D Series
Installation and Operation Manual vii
Copyright © 2011, Harris Corporation
3Contact your dealer if any item on the packing list is missing.
4Contact the carrier if any item is damaged.
5Remove all packaging material from the product and its associated
components before you install the unit.
Product Servicing DA-6804+series modules are not designed for field servicing. All hardware and
firmware upgrades, modifications, or repairs require you to return the modules to
the Customer Service center.
Returning a
Product
In the unlikely event that your product fails to operate properly, please contact
Customer Service to obtain a Return Authorization (RA) number, and then send
the unit back for servicing.
Keep at least one set of original packaging, in the event that you need to return a
product for servicing. If the original packaging is not available, you can purchase
replacement packaging at a modest cost or supply your own packaging as long as
it meets the following criteria:
Withstands the weight of the product
Holds the product rigid within the packaging
Leaves at least two inches of space between the product and the container
Protects the corners of the product
Ship products back to us for servicing prepaid and, if possible, in the original
packaging material. If the product is still within the warranty period, we will return
the product prepaid after servicing.
Safety Standards and Compliances
You can find the 6800+Safety Instructions and Standards Manual on the Harris
Infrastructure and Networking Documentation and Product Resources DVD, or
download it from our website.

About This Manual
viii
Copyright © 2011, Harris Corporation
Safety Terms and
Symbols
This product manual uses the following safety terms and symbols to identify
certain conditions or practices. See the 6800+Safety Instructions and
Standards Manual for more information.
Restriction on Hazardous Substances (RoHS) Directive
Directive 2002/95/EC — commonly known as the European Union (EU) Restriction on
Hazardous Substances (RoHS) — sets limits on the use of certain substances found in
electrical and electronic equipment. The intent of this legislation is to reduce the
amount of hazardous chemicals that may leach out of landfill sites or otherwise
contaminate the environment during end-of-life recycling. The Directive, which took
effect on July 1, 2006, refers to the following hazardous substances:
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (Cr-V1)
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
In accordance with this EU Directive, products sold in the European Union will be fully
RoHS-compliant and “lead-free.” Spare parts supplied for the repair and upgrade of
equipment sold before July 1, 2006 are exempt from the legislation. Equipment that
complies with the EU directive will be marked with a RoHS-compliant symbol, as shown
in Figure P-1.
Figure P-1 RoHS Compliance Symbol
Table P-3 Safety Terms and Symbols
Symbol Description
WARNING: Identifies conditions or practices that can result in
personal injury or loss of life — high voltage is present. Uninsulated
dangerous voltage within the product’s enclosure may be sufficient to
constitute a risk of electric shock to persons.
CAUTION: Identifies conditions or practices that can result in damage
to the equipment or other property. Important operating and
maintenance (servicing) instructions are included in the literature
accompanying the product.

DA-6804+D Series
Installation and Operation Manual ix
Copyright © 2011, Harris Corporation
Waste from Electrical and Electronic Equipment (WEEE) Directive
The European Union (EU) Directive 2002/96/EC on Waste from Electrical and Electronic
Equipment (WEEE) deals with the collection, treatment, recovery, and recycling of
electrical and electronic waste products. The objective of the WEEE Directive is to assign
the responsibility for the disposal of associated hazardous waste to either the producers
or users of these products. As of August 13, 2005, producers or users are required to
recycle electrical and electronic equipment at end of its useful life, and must not
dispose of the equipment in landfills or by using other unapproved methods. (Some EU
member states may have different deadlines.)
In accordance with this EU Directive, companies selling electric or electronic devices in
the EU will affix labels indicating that such products must be properly recycled. Contact
your local sales representative for information on returning these products for
recycling. Equipment that complies with the EU directive will be marked with a
WEEE-compliant symbol, as shown in Figure P-2.
Figure P-2 WEEE Compliance Symbol

About This Manual
x
Copyright © 2011, Harris Corporation

1
Copyright © 2011, Harris Corporation
1Introduction
The DA-6804+D series of distribution amplifiers distributes serial digital signals
according to SMPTE259C, 292M, 424M and DVB-ASI standards (compatibility
depends on the model selected).
The following modules are available:
DA-DH6804+D is a dual channel 3 Gb/s HD/SD-SDI distribution amplifier
DA-DHR6804+D is a dual channel 3 Gb/s HD/SD-SDI distribution amplifier
with reclocking capability
DA-DS6804+D is a dual channel SD-SDI distribution amplifier
DA-DSR6804+D is a dual channel SD-SDI distribution amplifier with reclocking
capability
Each distribution amplifier consists of a front and back module, and operates in
FR6802+series frames, occupying two slots. Ten distribution amplifiers can be
loaded into a frame.
Each distribution amplifier contains twoinputs and eight outputs, and can be
configured for either single channel use (1×8_ACO or 1×8) or independent
dual-channel use (2_1×4). Each FR6802+frame can provide up to 20 channels for
serial digital signal distribution.
DA-6804+D “green” power-saving distribution amplifiers shut down automatically
if no input signal is detected. Power consumption is partially reduced if the module
is receiving input, but is not connected to a 75Ωload.
DA-6804+D modules can be set up, controlled, and monitored either at the card
edge, or remotely, using an Ethernet connection. Web browser and CCS remote
control require either an ICE6800+ module, or a 6800+ETH module installed in the
frame. CCS remote control provides additional control functions not included in
local control mode.

Chapter 1
Introduction
2
Copyright © 2011, Harris Corporation
Main Features
All Models
The main features of the DA-6804+D series are listed below:
Passes signals at data rates from 5 Mb/s to 540 Mb/s (DA-DS6804+D and
DA-DSR6804+D) or from 5 Mb/s to 3 Gb/s (DA-DH6804+D and
DA-DHR6804+D)
Four selectable channel configurations:
1×8_ACO: 1 input to 8 outputs with auto changeover
1×8_ In_1: SDI In_1 is distributed to 8 outputs
1×8_ In_2: SDI In_2 is distributed to 8 outputs
2_1×4: 2 independent inputs, each distributed to four outputs as either
SDI In_1 to SDI Out_1 (1-4), or SDI In_2 to SDI Out_2 (1-4)
Input signal presence detection and report
Automatic input cable equalization
Selectable + 6dB gain to use external passive 75Ω2×1 splitter (via CCS only)
Selectable input EQ bypass
Automatic power saving mode if no input signal is detected, or if no output
load is detected
Local and remote control
Hot swapping capability
DA-DSR6804+D and DHR6804+D Models
DA-DSR6804+D and DHR6804+D modules also include the following features:
Reclocking capability for 270 Mb/s SMPTE signals (DA-DSR6804+D), or 270
Mb/s, 1.485 Gb/s, and 2.97 Gb/s SMPTE signals (DA-DHR6804+D)
Three selectable reclocking modes (automatic, manual, enforce bypass)
Automatic bypassing of the reclock stage if signal is not lockable
Reclock status and data rate report
Automatic slew rate control for output signal

DA-6804+D
Installation and Operation Manual
3
Copyright © 2011, Harris Corporation
Front Module
Figure 1-1 DA-6804+D Front Module
Back Module
DA-6804+D series modules cannot be installed in 6800/7000 series frames.
Figure 1-2 DA-6804+D Series Back Module
SDI
IN
SDI OUT 1
A
C
B
D
A
C
SDI OUT 2
D
21
B D A-DH / DA- DHR / DA- DS / DA-DSR 680 4+ D

Chapter 1
Introduction
4
Copyright © 2011, Harris Corporation
Signal Flow
Figure 1-3 DA-DH6804+D Signal Flow Diagram
Figure 1-4 DA-DHR6804+D Signal Flow Diagram
4 x 4
Driver 1
Driver 2
CPU
Monitoring
and Control
Driver 1
Driver 2
HD/SD-SDI In 1 Equalizer
1
HD/SD-SDI In 2 Equalizer
2
HD/SD-SDI Out 1A
HD/SD-SDI Out 1B
HD/SD-SDI Out 1C
HD/SD-SDI Out 1D
HD/SD-SDI Out 2A
HD/SD-SDI Out 2B
HD/SD-SDI Out 2C
HD/SD-SDI Out 2D
4 x 4
HD/SD-SDI In 1 Equalizer
1Reclock 1
Driver 1
Driver 2
CPU
Monitoring
and Control
HD/SD-SDI In 2 Equalizer
2Reclock 2
Driver 1
Driver 2
HD/SD-SDI Out 1A
HD/SD-SDI Out 1B
HD/SD-SDI Out 1C
HD/SD-SDI Out 1D
HD/SD-SDI Out 2A
HD/SD-SDI Out 2B
HD/SD-SDI Out 2C
HD/SD-SDI Out 2D

DA-6804+D
Installation and Operation Manual
5
Copyright © 2011, Harris Corporation
Figure 1-5 DA-DS6804+D Signal Flow Diagram
Figure 1-6 DA-DSR6804+D Signal Flow Diagram
4 x 4
Driver 1
Driver 2
CPU
Monitoring
and Control
Driver 1
Driver 2
SD-SDI In 1 Equalizer
1
SD-SDI In 2 Equalizer
2
SD-SDI Out 1A
SD-SDI Out 1B
SD-SDI Out 1C
SD-SDI Out 1D
SD-SDI Out 2A
SD-SDI Out 2B
SD-SDI Out 2C
SD-SDI Out 2D
4 x 4
SD-SDI In 1 Equalizer
1Reclock 1
Driver 1
Driver 2
CPU
Monitoring
and Control
SD-SDI In 2 Equalizer
2Reclock 2
Driver 1
Driver 2
SD-SDI Out 1A
SD-SDI Out 1B
SD-SDI Out 1C
SD-SDI Out 1D
SD-SDI Out 2A
SD-SDI Out 2B
SD-SDI Out 2C
SD-SDI Out 2D

Chapter 1
Introduction
6
Copyright © 2011, Harris Corporation
Maximum 6800+Frame Power Ratings
Table 1-1 describes the maximum allowable power ratings for 6800+frames.
Note the given maximums before installing any 6800+modules in your frame.
DA-6804+D series modules cannot be installed in 6800/7000 series frames.
Table 1-1 Maximum Power Ratings for 6800+Frames
6800+Frame Type
Max. Frame
Power
Dissipation
Number of
Usable Slots
Max. Power
Dissipation
Per Slot
FR6802+XF
(AC power supply)
120 W 20 6 W
FR6802+XF48
(DC power supply)
105 W 20 5.25 W
FR6802+QXF
(AC or DC
power supply)
120 W 20 6 W
FR6822+
(AC or DC
power supply)
120 W 20 6 W

7
Copyright © 2011, Harris Corporation
2Installation
CAUTION: Before installing this product, read the 6800+Series
Safety Instructions and Standards manual shipped with the Harris
Infrastructure and Networking Documentation and Product
Resources DVD. The document is also downloadable from our
website and contains important information about the safe
installation and operation of 6800+series products.
Before you install DA-6804+D series modules, perform the following:
Remove the anti-static shipping pouch, if present, and all other packaging
material.
Retain the original packaging materials for possible re-use.
Check the equipment for any visible damage that may have occurred during
transit.
Your DA-6804+D package includes a front module, back module, and Harris
Infrastructure and Networking Documentation and Product Resources DVD.
Contact your Customer Service representative if parts are missing or damaged.
See Unpacking/Shipping Information on page vi for information about
returning a product for servicing.

Chapter 2
Installation
8
Copyright © 2011, Harris Corporation
Jumpers J1 and J2 (DA-DSR6804+D and DA-DHR6804+D)
To set the reclocker mode for the DA-DSR6804+D and DA-DHR6804+D at the
card-edge, use Jumper J1 (for channel 1) and Jumper J2 (for channel 2). The
reclocker remains in AUTO mode if no jumper is set.
Figure 2-1 Locations for Jumpers J1, J2, and J3
Table 2-1 J1 and J2 Jumper Settings
Jumper
Selection
Pin
Setting Label Description
J1/J2
(Channel 1/
Channel 2)
1/2 AUTO_1/2 Input signal locked at one of these data rates:
2.97 Gb/s*
1.485 Gb/s*
270 Mb/s
If not lockable, signal automatically bypasses reclocker
3/4 3.0G_1/2 Input signal locked at 2.97 Gb/s*; if not lockable, signal automatically
bypasses reclocker
5/6 HD_1/2 Input signal locked at 1.485 Gb/s*; if not lockable, signal
automatically bypasses reclocker
7/8 SD_1/2 Input locked at 270 Mb/s; if not lockable, signal automatically
bypasses reclocker
9/10 BYPASS_1/2 Enforces signal bypass reclocker
*Not applicable to the DA-DSR6804+
Jumper
J1
Jumper
J2
Jumper
J3
