InstallationandOperationManual
SelenioX100TM
IntelligentDual‐ChannelFrameSynchronizerandConverter
Version2.0

PublicationInformation
©2014ImagineCommunicationsCorp.ProprietaryandConfidential.
ImagineCommunicationsconsidersthisdocumentanditscontentstobeproprietaryand
confidential.Exceptformakingareasonablenumberofcopiesforyourowninternaluse,you
maynotreproducethispublication,oranypartthereof,inanyform,byanymethod,forany
purpose,orinanylanguageotherthanEnglishwithoutthewrittenconsentofImagine
Communications.Allothersusesareillegal.
Thispublicationisdesignedtoassistintheuseoftheproductasitexistsonthedateof
publicationofthismanual,andmaynotreflecttheproductatthecurrenttimeoranunknown
timeinthefuture.Thispublicationdoesnotinanywaywarrantdescriptionaccuracyor
guaranteetheusefortheproducttowhichitrefers.ImagineCommunicationsreservesthe
right,withoutnoticetomakesuchchangesinequipment,design,specifications,components,
ordocumentationasprogressmaywarranttoimprovetheperformanceoftheproduct.
Trademarks
SelenioTMandSelenioX100TMaretrademarksofImagineCommunicationsoritssubsidiaries.
Adobe®andAdobeAfterEffects®areregisteredtrademarksofAdobeSystemsIncorporatedin
theUnitedStatesand/orothercountries.Microsoft®andWindows®areregisteredtrademarks
ofMicrosoftCorporation.HD‐BNCisatrademarkofAmphenolCorporation.Manufactured
underlicensefromDolbyLaboratories.Dolbyandthedouble‐Dsymbolareregistered
trademarksofDolbyLaboratories.DTSNeuralaudioproductsaremanufacturedunderlicense
fromDTSLicensingLimited.DTSandtheSymbolareregisteredtrademarks&theDTSLogosare
trademarksofDTS,Inc.©2008‐2010DTS,Inc.Allothertrademarksandtradenamesarethe
propertyoftheirrespectivecompanies.
ContactInformation
ImagineCommunicationshasofficelocationsaroundtheworld.Forlocationsandcontact
informationsee:http://www.imaginecommunications.com/contact‐us/
SupportContactInformation
Forsupportcontactinformationsee:
SupportContacts:http://www.imaginecommunications.com/services/technical‐support/
eCustomerPortal:http://support.imaginecommunications.com

iii
Contents
Preface.........................................................................................................................ix
Manual Information ......................................................................................................ix
Purpose .....................................................................................................................ix
Audience ...................................................................................................................ix
Revision History .........................................................................................................ix
Writing Conventions ...................................................................................................x
Obtaining Documents .................................................................................................x
Unpacking/Shipping Information .................................................................................x
Unpacking a Product ..................................................................................................x
Returning a Product ................................................................................................... xi
Safety Standards and Compliances .............................................................................xi
Restriction on Hazardous Substances (RoHS) Compliance ...........................................xi
Waste from Electrical and Electronic Equipment (WEEE) Compliance ......................... xii
Safety Terms and Symbols in this Manual ................................................................. xii
Chapter 1 Introduction.............................................................................................................. 1
Overview ....................................................................................................................... 1
Main Features ................................................................................................................ 1
Environment .............................................................................................................. 4
Selenio X100 Options and Packages ............................................................................ 4
GPI Pinouts ................................................................................................................ 7
Analog Audio Pinouts ................................................................................................ 8
Linear Timecode Pinouts ............................................................................................ 8
Signal Flow .................................................................................................................... 8
Chapter 2 Installation ............................................................................................................. 11
Preparing for Installation ........................................................................................... 11
Electrical Requirements ............................................................................................ 11
Environmental Requirements ................................................................................... 11
Rack Mounting ............................................................................................................ 11
Selecting an External Balun ....................................................................................... 14
Changing Jumper Settings ......................................................................................... 15
Configuring Network Settings ................................................................................... 17

Selenio X100
Installation and Operation Manual
iv
Changing the PC Network Settings ........................................................................... 19
Remote Control of the Selenio X100 .......................................................................... 21
Preparing for Remote Control via Control Panel ....................................................... 22
Selecting a Remote Unit to Control .......................................................................... 22
Configuring for Web Browser Control ......................................................................23
System Requirements for Device Monitoring ............................................................ 23
Initial Configuration ................................................................................................. 23
Logging In To the Selenio X100 Control Interface ....................................................24
Exiting the Control Interface .................................................................................... 24
Accessing MIBs and Configuring SNMP Support ....................................................... 25
Default IP Address .................................................................................................... 25
Chapter 3 Operation.................................................................................................................. 27
Overview ......................................................................................................................27
Front Panel Controls ....................................................................................................27
Push Buttons ............................................................................................................ 27
LED Functions .......................................................................................................... 28
Video Output and Routing ......................................................................................... 28
Output Format .........................................................................................................28
Output Routing ........................................................................................................ 30
Operation Mode ...................................................................................................... 30
Video Sync and Delay ................................................................................................. 35
Input Standard Select ............................................................................................... 35
Frame Sync Frozen, Force Black, Force Freeze, and Freeze Mode ..............................35
Frame Delay ............................................................................................................. 35
Actual Video Delay Used .......................................................................................... 36
Frame Sync Fast Switch ............................................................................................ 36
Audio/Video Align ....................................................................................................36
Analog Input Control (Video) .....................................................................................36
Analog Output Control (Video) ..................................................................................37
Video ProcAmp and Color Corrector .......................................................................... 37
Proc Amp .................................................................................................................37
Clip Control .............................................................................................................37
Color Corrector ..............................................................................................38
Gamma Correction ..................................................................................................40
Conversion and Advanced Video Processing ............................................................ 41
Status ...................................................................................................................... 41
AFD Presence and Output ........................................................................................ 41
ARC Control ............................................................................................................41
AFD-VI-WSS Insertion ............................................................................................... 42
AFD-VI-WSS Custom Mapping ................................................................................. 43
Custom ARC ............................................................................................................ 43
General Information on ARC and AFD ....................................................................... 46
AFD (Active Format Description) ............................................................................... 46
AFD Patterns ............................................................................................................ 48
Scalar Configuration ................................................................................................ 55
Logo Generation and Insertion .................................................................................. 56

Selenio X100
Installation and Operation Manual
v
Installing and Displaying Logo Files .......................................................................... 57
Basic Steps to Create Animated Logo Files ............................................................... 57
Basic Steps to Create Static Logo Files ...................................................................... 58
Step 1: Install LogoCreator Software ........................................................................ 58
Step 2: Convert Files to the .mg2 Format ................................................................. 59
Video TSG-OSD 1 and 2 .............................................................................................. 60
Test Signal Generator .............................................................................................. 60
On Screen Display (OSD) .......................................................................................... 61
Thumbnail Streaming .............................................................................................. 61
Data Embedding and De-Embedding ........................................................................ 61
Data Processing ....................................................................................................... 61
Data Input ............................................................................................................... 61
Data Output and Data Bridging ............................................................................... 62
VBI Line Delete ........................................................................................................ 62
Generic VANC Data Passing ..................................................................................... 62
VBI Transfer ............................................................................................................. 62
Dual Link Support .................................................................................................... 62
SCTE-104 ................................................................................................................ 63
SCTE-104 Insertion and Extraction Setup Examples .................................................. 66
BT-1685 .................................................................................................................. 69
AFD, VI and WSS ..................................................................................................... 71
ARIB ........................................................................................................................ 72
Closed Captioning/Teletext ...................................................................................... 72
Timecode ................................................................................................................ 73
Audio Embedding ....................................................................................................... 74
Handling of Non-PCM/Compressed Audio Signals ................................................... 74
Passing Embedded Non-PCM Audio through the Frame Sync ................................... 75
Audio Embedding Control ....................................................................................... 75
Audio Embedding Modes ........................................................................................ 75
Embedding Errors .................................................................................................... 79
Preventing Embedding Errors ................................................................................... 80
Audio I/O (Input/Output) Assignment ...................................................................... 81
Audio Inputs and Outputs ....................................................................................... 82
Audio Input Delay and Sync ....................................................................................... 83
Synchronization Parameters ..................................................................................... 83
Audio Proc Amp .......................................................................................................... 83
Audio Output Routing and Delay .............................................................................. 84
Audio Bit Manipulation .............................................................................................. 86
Channel Status Bits .................................................................................................. 86
Audio Metadata .......................................................................................................... 88
GPI and Rules Engine .................................................................................................. 88
GPI .......................................................................................................................... 88
Rules Engine ............................................................................................................ 89
Custom GPI Input Script .......................................................................................... 89
Custom GPI Output Script ....................................................................................... 90
Parameter Control Script ......................................................................................... 91
Green-Power Save ................................................................................................... 92
Genlock ........................................................................................................................ 93
Line Sync ................................................................................................................. 93

Selenio X100
Installation and Operation Manual
vi
System Presets ............................................................................................................. 95
SFP+HDMI+OUT Operation ......................................................................................... 95
Chapter 4 Advanced Audio Processing ............................................................................97
Software Key License Credits Overview ....................................................................97
Enabling DTS Neural and Dolby Modes ....................................................................98
Dolby Products ....................................................................................................... 100
Dolby-E Alignment .................................................................................................101
AAP Internal Metadata ........................................................................................... 102
DTS Neural Surround Audio UpMix ........................................................................108
Audio Delay ........................................................................................................... 109
DTS Neural Surround Audio DownMix ...................................................................110
DTS Neural Surround Audio MultiMerge ................................................................112
DTS Neural Loudness Control .................................................................................116
Chapter 5 Specifications....................................................................................................... 121
Video Input ................................................................................................................121
3G/HD/SD-SDI Video Input .....................................................................................121
Component Video Input ........................................................................................ 122
Composite Video Input .......................................................................................... 122
Audio Input ................................................................................................................123
Analog Audio Input ............................................................................................... 123
Balanced AES Input (With External Balun) ...............................................................123
Unbalanced AES Input ...........................................................................................124
Video Output .............................................................................................................125
3G/HD/SD-SDI Output ............................................................................................125
Component Video Output ..................................................................................... 126
Composite Video Output ....................................................................................... 126
HDMI Output ......................................................................................................... 127
Audio Output .............................................................................................................128
Analog Audio Output Specifications ....................................................................... 128
Balanced AES Output (With External Balun) ............................................................128
Unbalanced AES Output ........................................................................................129
SFP Specifications, Input ........................................................................................... 130
SDI Electrical Dual Receiver .....................................................................................130
SDI Electrical Dual Receiver with Reclocker ............................................................. 130
SDI Optical Dual Receiver ....................................................................................... 131
SFP Specifications, Output ........................................................................................132
SDI Electrical Dual Transmitter ................................................................................ 132
SDI Electrical Dual Transmitter with Reclocker ........................................................133
SDI Electrical-to-DVI Converter ............................................................................... 133
SDI Electrical-to-HDMI Converter ............................................................................ 134
SDI Optical Dual Transmitters .................................................................................135
Miscellaneous ............................................................................................................137
DARS Input ............................................................................................................137
Dimensions ............................................................................................................137

Selenio X100
Installation and Operation Manual
vii
General Purpose Interface ...................................................................................... 137
Genlock ................................................................................................................. 138
LAN ....................................................................................................................... 138
LTC Input .............................................................................................................. 138
LTC Output ........................................................................................................... 139
Power Consumption .............................................................................................. 139
RS-232/422/485 Specifications .............................................................................. 140
Serial Data ............................................................................................................. 140
Temperature .......................................................................................................... 140
Appendix A Laser Safety Guidelines.................................................................................. 141
Laser Safety for Fiber Optic Back Modules ............................................................. 141
Precautions for Enclosed Systems ........................................................................... 141
Precautions for Unenclosed Systems ...................................................................... 142
Label ........................................................................................................................... 142
Inspecting and Cleaning Fiber Optic Connections .................................................. 142
Important Points .................................................................................................... 143
Inspection and Cleaning Procedure ........................................................................ 144
Appendix B Servicing................................................................................................................. 147
Overview ................................................................................................................... 147
Cover Removal and Replacement ............................................................................ 148
Top Cover ............................................................................................................. 148
Front Panel Control Assembly ................................................................................ 149
Fan Module Replacement (131-100021000) ............................................................ 151
Power Supply Replacement (X100-PSU-200W) ....................................................... 152
Installation of Advanced Audio Processing Submodule (X100OPT-ADVAUD) ...... 153
OLED Display/Button Board Replacement (170-100689Q00) ................................. 154
Rotary Control Shaft Encoder Replacement (X50SPR-SE) ...................................... 156
Analog Video Input/Output Module (X100OPT-AVIO) ........................................... 159
Animated Logo Generator/Inserter and Program Delay Submodule .................... 162
Index......................................................................................................................... 163

Selenio X100
Installation and Operation Manual
viii

ix
Preface
Manual Information
Purpose This manual details the features, installation, operation, maintenance, and specifications for
the SelenioTM X100 Intelligent Dual-Channel Frame Synchronizer and Converter.
Audience This manual is written for engineers, technicians, and operators responsible for installation,
setup, maintenance, and/or operation of the Selenio X100 Intelligent Dual-Channel Frame
Synchronizer and Converter.
Revision History
Table 1-1 Revision History of Manual
Edition Date Comments
A May 2014 First release
B August 2014 Addition of jumper settings and servicing instructions
2.0 May 2015 Addition of animated logo generation/insertion, program/profanity delay,
thumbnail streaming, new advanced audio options
2.0 Revision June 2015 Changes to memory module part numbering

Selenio X100
Installation and Operation Manual
x
Writing Conventions
To enhance your understanding, the authors of this manual have adhered to the following
text conventions:
Obtaining Documents
Product support documents can be viewed or downloaded from our website. Alternatively,
contact your Customer Service representative to request a document.
Unpacking/Shipping Information
Unpacking a Product
This product was carefully inspected, tested, and calibrated before shipment to ensure years
of stable and trouble-free service.
1Check equipment for any visible damage that may have occurred during transit.
2Confirm that you have received all items listed on the packing list.
3Contact your dealer if any item on the packing list is missing.
4Contact the carrier if any item is damaged.
5Remove all packaging material from the product and its associated components before you
install the unit.
Keep at least one set of original packaging, in the event that you need to return a product
for servicing.
Table 1-2 Writing Conventions
Term or Convention Description
Bold Indicates dialog boxes, property sheets, fields, buttons, check
boxes, list boxes, combo boxes, menus, submenus, windows,
lists, and selection names
Italics Indicates E-mail addresses, the names of books or publications,
and the first instances of new terms and specialized words that
need emphasis
CAPS Indicates a specific key on the keyboard, such as ENTER, TAB,
CTRL, ALT, or DELETE
Code Indicates variables or command-line entries, such as a DOS entry
or something you type into a field
> Indicates the direction of navigation through a hierarchy of
menus and windows
hyperlink Indicates a jump to another location within the electronic
document or elsewhere
Internet address Indicates a jump to a website or URL
Note Indicates important information that helps to avoid and
troubleshoot problems

Selenio X100
Installation and Operation Manual
xi
Returning a Product
In the unlikely event that your product fails to operate properly, please contact Customer
Service to obtain a Return Authorization (RA) number, and then send the unit back for
servicing.
Keep at least one set of original packaging in the event that a product needs to be returned
for service. If the original package is not available, you can supply your own packaging as
long as it meets the following criteria:
The packaging must be able to withstand the product’s weight.
The product must be held rigid within the packaging.
There must be at least 2 in. (5 cm) of space between the product and the container.
The corners of the product must be protected.
Ship products back to us for servicing prepaid and, if possible, in the original packaging
material. If the product is still within the warranty period, we will return the product prepaid
after servicing.
Safety Standards and Compliances
The Selenio series safety manual is shipped in the Imagine Communications Manuals and
Product Resources DVD, and can be downloaded from our website.
Restriction on Hazardous Substances (RoHS) Compliance
Directive 2011/65/EU (ROHS 2)—commonly known as the European Union (EU) Restriction
on Hazardous Substances (RoHS)—sets limits on the use of certain substances found in
electrical and electronic equipment. The intent of this legislation is to reduce the amount of
hazardous chemicals that may leach out of landfill sites or otherwise contaminate the
environment during end-of-life recycling. The Directive, which took effect on July 1, 2006,
refers to the following hazardous substances:
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (Cr-V1)
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
According to this EU Directive, all products sold in the European Union will be fully
RoHS-compliant and “lead-free.” (See our website for more information on dates and
deadlines for compliance.) Spare parts supplied for the repair and upgrade of equipment
sold before July 1, 2006 are exempt from the legislation. Equipment that complies with the
EU directive will be marked with a RoHS-compliant emblem, as shown in Figure P-1.
Figure P-1 RoHS Compliance Emblem

Selenio X100
Installation and Operation Manual
xii
Waste from Electrical and Electronic Equipment (WEEE) Compliance
The European Union (EU) Directive 2002/96/EC on Waste from Electrical and Electronic
Equipment (WEEE) deals with the collection, treatment, recovery, and recycling of electrical
and electronic waste products. The objective of the WEEE Directive is to assign the
responsibility for the disposal of associated hazardous waste to either the producers or users
of these products. As of August 13, 2005, the producers or users of these products were
required to recycle electrical and electronic equipment at end of its useful life, and may not
dispose of the equipment in landfills or by using other unapproved methods. (Some EU
member states may have different deadlines.)
In accordance with this EU Directive, companies selling electric or electronic devices in the
EU will affix labels indicating that such products must be properly recycled. (See our website
for more information on dates and deadlines for compliance.) Contact your local Sales
representative for information on returning these products for recycling. Equipment that
complies with the EU directive will be marked with a WEEE-compliant emblem, as shown in
Figure P-2.
Figure P-2 WEEE Compliance Emblem
Safety Terms and Symbols in this Manual
This product manual uses the following safety terms and symbols to identify certain
conditions or practices. See the Safety Instructions and Standards Manual for more
information.
WARNING
Statements identifying conditions or practices that may result in personal injury or loss of
life. High voltage is present.
CAUTION
Statements identifying conditions or practices that can result in damage to the equipment
or other property.

1
1Introduction
Overview The Selenio X100 is an intelligent dual-channel frame synchronizer and converter. The X100
can operate in a dual- channel mode, or with a single input to two processed outputs, or in
a single-channel linear frame rate converter mode (when the X100OPT-SK-SC software
license key is installed).
The Selenio X100 provides two channels of video synchronization and delay, video up-,
down-, and cross-, aspect ratio conversion, basic frame rate conversion, optional linear
frame rate conversion (single channel), dual video processing amplifiers with color correction
and clipping, and dual logo generator inserters.
Audio processing features include dual channel capacity (total of eight groups with 32 mono
channels of internal processing), audio embedding and de-embedding to and from
Horizontal Ancillary Data (HANC) in the Serial Digital Interface (SD-SDI), 16 AES input /
output ports and eight channels of analog audio input and output with audio
synchronization and delay, gain, invert, and summing. Optional audio processing includes
audio decode and encode, audio up and down mix, and perceptual loudness control.
Input/output signal interfaces on the X100 include those for optional dual analog video,
composite and analog video component, analog audio, SD-SDI video and ancillary data, SFP
for optical and other interfaces, AES unbalanced digital audio, time code, General Purpose
Interface (GPI), and control and monitoring over Ethernet 100BaseT IP. An HDMI output is
provided for monitoring purposes
The X100’s data wrangler feature has the capability to process many metadata types in the
Vertical Ancillary and Vertical Blanking Interval (VANC/VBI). This includes timecode insert/
extract/pass through, closed captioning and teletext subtitling transcoding, processing for
AFD Active Format Description, Video Index (VI), and Wide Screen Signaling (WSS) for aspect
ratio conversion. In addition, the data wrangler processes GPI trigger insertion and
extraction (using SCTE-104 or BT-1685) and pass through for ABC BrandNet, Australian Cue
Data) for automation of remote devices, ARIB audio ID (Japan), SMPTE 352 Payload
Identifier, Dolby Audio Metadata and up to ten user DID/SDID.
Main Features
Intelligent dual-channel frame sync/delay, proc amp, noise reduction, clipping and color
correction
Rules engine for custom signal flow management
Fast frame sync, fast conversion, delay (lock to one input), and time base correction
(TBC) modes

Selenio X100
Installation and Operation Manual
2
Advanced 3D adaptive 10-bit motion detection for up/down/cross/aspect ratio
conversion
Basic frame rate conversion built in, and optional single channel linear frame rate
conversion
Two switchable auto-sensing 3G/HD/SD inputs
Dual up/down/cross/aspect/basic ratio conversion
Noise reduction (mosquito and block), sharpness and texture controls
Two aspect ratio converters with full control over H/V size and position
Audio de-embed/embed, sync, gain, invert and delay with 16 channels (four groups) of
processing
PCM and non-PCM (Dolby® Digital, Dolby Digital Plus® and Dolby® E) passthrough
Options for Dolby Digital, Dolby Digital Plus, and Dolby E decode and encode (up to 2
Dolby decoders and encoders)
Options for DTS Neural Surround Upmix, Downmix, MultiMerge and DTS Neural
Loudness Control
Video Interfaces:
Optional dual channel analog composite and component input and output
Auto-sensing for SD-SDI, HD-SDI, 3G-SDI
HD-BNC™ and SFP interfaces
EDH/CRC error monitoring and insertion
HDMI output for video
Audio Interfaces
Eight-channel analog audio
Sixteen-channel embedded audio from each of the two video streams
16 AES (75 ohm) ports
Data and Metadata
CC (CEA608/708) and Teletext (OP47)
Audio metadata VANC embed/de-embed, generator
AFD/Wide Screen Signaling (WSS)/VI
Pass up to ten user DID/SDID when converting video
Time code
Control and Monitoring
10/100BT Ethernet connectivity
SNMP
Built-in web server interface
Local control panel
Compatible with Selenio X50 and X75/X85 control panels, Magellan™ network
control panels, Magellan CCS Navigator, Magellan NMS Network Management
System and NUCLEUS remote panels
Eight configurable GPI inputs and outputs
Built-in video test and audio tone generators
Redundant power supply
Dual logo generator/inserter
Optional independent dual channel animated logo generator/inserters
I-Wings side bar insertion during upconversion
Optional independent dual channel program delay, which can be configured for
profanity delay applications
Thumbnail streaming for the input and output of the two processing channels

Selenio X100
Installation and Operation Manual
3
Figure 1-1 Front and Rear Views of Selenio X100
Display Screen
Controls
Status
LEDs
Display Screen
Reference
Loop
Analog
Audio In
Analog
Audio Out
AES In/OutDARS
In
HDMI
Out
SFP
Out
SFP
In
SDI In/OutControl
Ethernet
Timecode
In/Out
GPI In
& Out/
Serial
AC In 1
Composite/Component
Video Option
AC In 2
Future
Options

Selenio X100
Installation and Operation Manual
4
Environment Selenio X100 frames are cooled by forced air drawn in from the front of the frame, and
exhausted through vents at the rear of the frame. There must be free passage for air flow
on to allow for adequate ventilation, and an ambient temperature of between 32°F to
104°F (0°C to 40°C) with relative humidity of 10% to 90% non-condensing.
You must provide adequate space behind the mounting ears, and clearance for the
connecting cables at the rear of the frame.
Selenio X100 Options and Packages
Table 1-1 X100 Options and Packages
Part Numbers Description
Base Model
X100-1RU-2PS 1RU dual-channel intelligent frame sync and converter with advanced audio
processing
Hardware Options
X100OPT-AVIO Plug-in dual-channel analog video input and output module option
X100OPT-ADVAUD Plug-in advanced audio module (required for Dolby and DTS options)
X100OPTCAB-HD-BNC-A HD-BNC-to-BNC adapter cable for audio (12 in/0.3m length)
X100OPTCAB-HD-BNC-V HD-BNC-to-BNC adapter cable for video (12 in/0.3m length)
X100OPT-TOOL-CABLE HD-BNC cable insertion and extraction tool
X100OPT-75-TERM 75precision HD-BNC terminator
X100-PSU-200W Spare/replacement power supply
See page 14 for external
supplier information
Baluns for unbalanced-to- balanced AES connections
X100OPT-MEMMOD8GB 8 GB memory module, required for program delay and/or animated logo generator/
inserter software key licenses
X100OPT-MEMMOD16GB 16 GB memory module, required for program delay and/or animated logo
generator/inserter software key licenses
X100OPT-MEM-8GB Spare or field upgrade 8 GB of storage for X100OPT-MEMMOD-xxx memory
module
SFP Modules
SFP+2ERX Dual channel SFP with HD-BNC inputs of 3G/HD/SD-SDI (re-clocked outputs)
SFP+2ERX+NR Dual channel SFP with HD-BNC inputs of 3G/HD/SD-SDI (non-re-clocked outputs)
SFP+2ETX Dual channel SFP with HD-BNC outputs of 3G/HD/SD-SDI (re-clocked outputs)
SFP+2ETX+NR Dual channel SFP with HD-BNC outputs of 3G/HD/SD-SDI (non-re-clocked outputs
SFP+DVI+OUT SD/HD-to-DVI SFP converter for monitoring purposes; includes 6.5 ft (2m) Type D
HDMI-to-DVI-D plug adapter cable
SFP+HDMI+OUT 3G/HD/SD-SDI-to-HDMI converter for monitoring purposes; includes 6.5 ft (2m)
Type D HDMI-to-Type A HDMI adapter cable
OP+SFP+RR Dual PIN receiver with pathological support for baseband video

Selenio X100
Installation and Operation Manual
5
OP+SFP+TT+13+13 1310 nm and 1310 nm wavelength dual transmitter SFP with pathological support
for baseband video
OP+SFP+TT+27+29 1270nm and 1290nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+31+33 1310nm and 1330nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+35+37 1350nm and 1370nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+43+45 1430nm and 1450nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+47+49 1470nm and 1490nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+51+53 1510nm and 1530nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+55+57 1550nm and 1570nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
OP+SFP+TT+59+61 1590nm and 1610nm CWDM wavelength dual transmitter SFP with pathological
support for baseband video
Software Keys
X100OPT-SK-SC One single-channel linear frame rate converter
X100OPT-SK-DDD One Dolby Digital decoder license; requires X100OPT-ADVAUD
X100OPT-SK-DED One Dolby E decoder license;requires X100OPT-ADVAUD
X100OPT-SK-DEE One Dolby E Encoder license; requires X100OPT-ADVAUD
X100OPT-SK-DDE One Dolby Digital Encoder license; requires X100OPT-ADVAUD
X100OPT-SK-DTS One DTS Neural Surround and Loudness Control license for the following:
One 2.0 Loudness Control (requires one DTS license)
Two 1.0 Loudness Controls (requires one DTS license)
One Upmix, one Downmix, or one 5.1 Loudness Control (requires three DTS
licenses)
One MultiMerge, four 2.0 Loudness Controls, or one 5.1 + 2 Loudness Controls
(each requires three DTS licenses and the X100OPT-ADVAUD audio module)
X100OPT-SK-ALG Single-channel animated logo generator/inserter software license key only
X100OPT-SK-PD Single-channel program delay software license key only
X100OPT-SK-DDPD Dolby Digital Plus Decoder (7.1, 5.1 + 2.0, 2.0 + 2.0) license key for Selenio X100;
X100OPT-ADVAUD is required
X100OPT-SK-DDPE Dolby Digital Plus Encoder (7.1, 5.1 + 2.0, 2.0 + 2.0) license key for Selenio X100;
X100OPT-ADVAUD is required
X100OPT-SK-RTLL Dolby Real Time Loudness Control for Dolby Digital Plus (5.1 + 2.0 or 2.0 + 2.0) or
Dolby Digital (5.1 or 2.0) encoder; X100OPT-ADVAUD is required
Table 1-1 X100 Options and Packages (Continued)
Part Numbers Description

Selenio X100
Installation and Operation Manual
6
Software and Hardware Combination Packages
X100OPT-ALG-PD-16 Single-channel animated logo generator/inserter and program delay; includes one
X100OPT-SK-ALG software key license, one X100OPT-SK-PD software key license
and one X100OPT-MEMMOD16GB Memory Module
X100OPT-1ALG-8GB Single-channel animated logo generator/inserter; includes one X100OPT-SK-ALG
software key license and one X100OPT-MEMMOD8GB memory module
X100OPT-2ALG-16GB Dual-channel animated logo generator/inserter; includes two X100OPT-SK-ALG
software key licenses, and one 100OPT-MEMMOD-16GB memory module
X100OPT-1PD-8GB Single-channel program delay; includes one X100OPT-SK-PD software key license,
and one X100OPT-MEMMOD8GB Memory Module
X100OPT-2PD-16GB Dual -channel program delay; includes two X100OPT-SK-PD software key licenses,
and one X100OPT-MEMMOD16GB Memory Module
Table 1-1 X100 Options and Packages (Continued)
Part Numbers Description

Selenio X100
Installation and Operation Manual
7
GPI Pinouts
Figure 1-2 Female GPI/Serial Connector Pinouts on Frame
Table 1-2 GPI/Serial Pinouts
Pin Function
1 GPI Input/Output 0
2 GPI Input/Output 1
3 GPI Input/Output 2
4 GPI Input/Output 3
5 GPI Input/Output 4
6 GPI Input/Output 5
7 GPI Input/Output 6
8 GPI Input/Output 7
9 D-Ground
10 D-Ground
11 RS-422 Port 2 Rx+
12 RS-422 Port 2 Rx- (RS-232 Port 2 Rx)
13 RS-422 Port 2 Tx+
14 RS-422 Port 2 TX- (RS-232 Port 2 Tx)
15 D-Ground
16 D-Ground
17 RS-422Port 1 Rx+
18 RS-422 Port 1 Rx- (RS-232 Port 1 Rx)
19 RS-422Port 1 Tx+
20 RS-422 Port 1 Tx- (RS-232 Port 1 Tx)
22012 14 16 1886410
1193579111315
17
Key and Slot

Selenio X100
Installation and Operation Manual
8
Analog Audio Pinouts
Figure 1-3 Female Back Panel Analog Audio Input and Output Pinouts on Frame
Linear Timecode Pinouts
Figure 1-4 Male Back Panel LTC Pinouts
Signal Flow
Figure 1-5 on page 9 illustrates the signal flow of the X100.
12
13 510 78 11 41296 3
14
25 17 22 1920 23 16 24 21 18 15
--
-
-
GGG
G
++++
Ch1a Ch4aCh3aCh2a Ch3bCh2bCh1b Ch4b
GGGG
++++
----
Table 1-3 Male Back Panel LTC Pinouts
Pin Function
1 LTC In+
2 LTC In-
3 Ground
4LTCOut+
5LTCOut-
6 Ground
165432
