About the IE-MediaChassis/2 (DC)
The IE-MediaChassis/2 (DC) is a stand-alone chassis for use with iMcV modules. As
an unmanaged chassis, the IE-MediaChassis/2 (DC) supports two single-wide or one
dual-wide iMcV module. All iMcV modules, with the exception of the SNMP
management card, will function properly in this chassis.
The IE-MediaChassis/2 (DC) contains an internal Telco compatible DC power supply.
The iMediaChassis/2 (DC) includes a temperature triggered fan. When the internal
temperature of the chassis reaches 86° F (30° C) the fan is activated. As the
temperature increases the fan drive duty cycle adjusts to increase the fan speed. You
can test the fan operation by depressing the fan test switch on the back of the chassis.
Installing the IE-MediaChassis/2 (DC)
Use the IE-MediaChassis/2 (DC) as a table-top chassis, mount in a rack mount shelf,
or mount it to a wall surface (brackets are not required).
1.
Install the IE-MediaChassis/2 (DC) by placing it on a flat surface.
2.
If mounting on a Rackmount shelf, align screw holes and secure with
screws.

2
The rack-mount shelf is sold separately. To purchase the rack-mount shelf (part
number 895-39949); visit the IMC Networks’ Product Accessories page:
https://www.imcnetworks.com/Products/acc.cfm
Rackmounting requires a rackmount shelf for mounting up to three units side by
side.
3.
If mounting the chassis on a wall, place two #10 panhead screws (not
supplied) on the wall the distance of the holes on the chassis, and then
hang the unit on the screws.
4.
Attach the cables between the chassis and the device that will be
interconnected, and then plug the unit into a reliable, filtered power
source.

3
Configuring and Installing Modules
IMC Networks recommends turning the chassis power off before proceeding.
1.
To install an iMcV module, slide the module into the chassis until the
module is firmly seated in the backplane.
2.
Secure the module to the chassis by tightening the captive thumb screw on
the iMcV module.
3.
Attach the network cables between the iMcV module and other devices that
will be interconnected.
4.
Connect the DC power source.
DC Power Supply Wiring Instructions
The following image shows the wiring configuration for a 48 VDC power supply in a
negative ground system application. For positive ground system applications remove
the chassis ground shorting jumper and connect it between the positive terminal and
the chassis ground terminal. Alternatively, the chassis grounding jumper can be
eliminated and the chassis ground connected at the power source.
NOTE
Incorrect wiring will result in chassis malfunction. The IE-MediaChassis/2 (DC) is
compliant with Isolated Grounding Plane practices. The POSITIVE and NEGATIVE
terminals are isolated from chassis ground and must have a ground reference at
the power-sourcing equipment.
This equipment is designed to permit the connection of the grounded conductor of
the DC supply circuit to the earthed conductor at the equipment. If this connection
is made, all of the following conditions must be met:

4
1. This equipment shall be connected directly to the DC supply system
earthed electrode conductor or to a bonding jumper from a grounded
terminal bar or bus to which the DC supply system grounding electrode
conductor is connected.
2.
This equipment shall be located in the same immediate area (such as,
adjacent cabinets) as any other equipment that has a connection between
the earthed conductor of the same DC supply circuit and the earthing
conductor, and also the point of earthing of the DC system. The DC system
shall not be earthed elsewhere.
3.
The DC supply source shall be located within the same premises as this
equipment.
4.
Switching or disconnecting devices shall not be in the earthed circuit
conductor between the DC source and the point of connection of the
earthing electrode conductor.
Rack Mount Precautions
1. Elevated Operating Ambient - If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may
be greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
2.
Reduced Air Flow - Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is
not compromised.
3.
Mechanical Loading - Mounting of the equipment in the rack should be
such that a hazardous condition is not achieved due to uneven mechanical
loading.
4.
Circuit Overloading - Consideration should be given to the connection of
the equipment to the supply circuit and the effect that overloading of the
circuits might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be used
when addressing this concern.
5.
Reliable Earthing - Reliable earthing of rack-mounted equipment should be
maintained. Particular attention should be given to supply connections
other than direct connections to the branch circuit (e.g. use of power
strips).

5
DC Power Supply Precautions
The following precautions must be observed when installing the chassis model with
an internal DC power supply.
1.
Check nameplate ratings to ensure there is no overloading of supply circuits that
could effect over current protection and supply wiring.
2.
In addition, the following must be observed:
a.
Connect the equipment to a 35 to 60 VDC power source that is electrically
isolated from the alternating current source.
b.
Route input wiring to terminal block and secure in such a manner that it is
protected from damage and stress. Do not route wiring past sharp edges or
moving parts.
c.
Incorporate a readily accessible disconnect device, with a 3mm minimum
contact gap in the fixed wiring.
d.
Install only in Restricted Access Areas (dedicated Equipment Rooms,
Equipment closets or the like) in accordance with Articles 110-18, 110-26,
and 110-27 of the National Electric Code, ANSI/NFPA 70.
e.
Provide a listed circuit breaker suitable for branch circuit protection of the
wiring and rated maximum 1A @ 48 VDC.
f.
For supply connections, use wires suitable for at least 75 ° C.

6
IMC Networks Technical Support
Tel: [phone] or [phone] (in the U.S. and Canada);
[phone] (Europe)
Fax: [phone]
E-Mail: [e-mail]
Web: www.imcnetworks.com
Specifications
Environmental:
Operating Temperature: -31° F to 156.2° F (-35° C to 69° C)
Storage Temperature: -4° F to 158° F (-20° C to 70° C)
Humidity: 5 to 95% (non-condensing)
DC Power Supply:
Input voltage: 35 to 60 VDC
Input Current: 2.7A maximum @35 VDC, Full Load
Output Current Capability: 15A @5 VDC
Dimensions:
2.23”H x 4.75”W x 7.30”D (5.7 cm H x 12.1 cm W x 18.6 cm D)
Heat Generation:
30 BTU/hr. maximum
Fan turns on if the internal temperature exceeds 86° F (30° C)

7
Electrostatic Discharge Precautions
Electrostatic discharge (ESD) can cause damage to your add-in modules. Always
observe the following precautions when installing or handling an add-in module or
any board assembly.
1.
Do not remove unit from its protective packaging until you’re ready to install it.
2.
Wear an ESD wrist grounding strap before handling any module or component.
If you do not have a wrist strap, maintain grounded contact with the system unit
throughout any procedure requiring ESD protection.
3.
Hold boards by the edges only; do not touch the electronic components or gold
connectors.
4.
After removal, always place the boards on a grounded, static-free surface, ESD
pad or in a proper ESD bag. Do not slide the board over any surface.
WARNING! Integrated circuits and fiber optic components are
extremely susceptible to electrostatic discharge damage. Do not
handle these components directly unless you are a qualified service
technician and use tools and techniques that conform to accepted
industry practices.

8
Safety Certifications
UL/CUL: Listed to Safety of Information Technology Equipment, including
Electrical Business Equipment.
CE: The products described herein comply with the Council Directive on
Electromagnetic Compatibility (89/336/EEC) and the Council Directive
on Electrical Equipment Designed for use within Certain Voltage Limits
(73/23/EEC). Certified to Safety of Information Technology Equipment,
Including Electrical Business Equipment. For further details, contact
IMC Networks.
European Directive 2002/96/EC (WEEE) requires that any equipment that bears this
symbol on product or packaging must not be disposed of with unsorted municipal
waste. This symbol indicates that the equipment should be disposed of separately
from regular household waste. It is the consumer’s responsibility to dispose of this
and all equipment so marked through designated collection facilities appointed by
government or local authorities. Following these steps through proper disposal and
recycling will help prevent potential negative consequences to the environment and
human health. For more detailed information about proper disposal, please contact
local authorities, waste disposal services, or the point of purchase for this equipment.

19772 Pauling • Foothill Ranch, CA 92610-2611 USA
TEL: [phone] • FAX: [phone]
www.imcnetworks.com
© 2008 IMC Networks. All rights reserved.
The information in this document is subject to change without notice. IMC Networks assumes no responsibility for any
errors that may appear in this document. IE-MediaChassis/2 is a trademark of IMC Networks. Other brands or product
names may be trademarks and are the property of their respective companies.
Document Number 50-80105-01 A1 April 2008
If the product’s part number begins with an “8”, it is compliant with the Restriction of Hazardous Substances (RoHS)
directive.
