JYTEK PXIe-62780 User manual

PXIe-62780
18-slot PXI Express Chassis
User’s Manual
Manual Rev.: 1.00
Revision Date: Jul.15,2016

I
Getting Service
Contact us should you require any service or assistance.
SHANGHAI JYTEK Co., Ltd.
Web site: hp://www.jytek.com
Address: (201203) 300 Fang Chun Rd., Zhangjiang Hi-Tech Park, Pudong New Area,
Shanghai, 201203 China
Tel: +86-21-5047-5899
Fax: +86-21-5047-5899
Email: [email protected]
Addional informaon, aids, and ps that help users perform tasks.
Informaon to prevent minor physical injury, component damage, data loss,
and/or program corrupon when trying to complete a task.
Informaon to prevent serious physical injury, component damage, data loss,and/
or program corrupon when trying to complete a specic task.

II
Table of Contents
Geng Service �������������������������������������������������������������������������������������������������� I
1 Introducon������������������������������������������������������������������������������������������������ 1
1�1 Features ��������������������������������������������������������������������������������������������� 1
1.2 Specicaons ������������������������������������������������������������������������������������� 2
1.3 Schemacs ����������������������������������������������������������������������������������������� 4
1�4 Connectors, I/O, and Controls������������������������������������������������������������� 6
1�4�1 Front Panel������������������������������������������������������������������������������ 6
1�4�2 Rear Panel������������������������������������������������������������������������������� 7
1�4�3 Backplane ������������������������������������������������������������������������������� 9
2 Geng Started�������������������������������������������������������������������������������������������15
2�1 Package Contents ������������������������������������������������������������������������������15
2.2 Cooling Consideraons ����������������������������������������������������������������������15
2.3 Hardware Installaon������������������������������������������������������������������������16
2�3�1 Installing the System Controller����������������������������������������������16
2�3�2 Installing Peripheral Modules�������������������������������������������������18
2.4 Rack Mounng ����������������������������������������������������������������������������������20
2�4�1 Powering Up the System ��������������������������������������������������������21
3 System Management & Conguraon ��������������������������������������������������������22
3.1 Installing the Monitor Ulity �������������������������������������������������������������22
3�2 Monitoring the PXIe-62780����������������������������������������������������������������23
3�2�1 Connect Control ���������������������������������������������������������������������23
3.2.2 Chassis Control and Alarm Threshold Seng��������������������������25
3�2�3 Chassis Status�������������������������������������������������������������������������27
Appendix A - Troubleshoong and Maintenance ���������������������������������������������28
A.1 Installaon Problems ������������������������������������������������������������������������28
A.2 Basic Troubleshoong �����������������������������������������������������������������������28
A�3 Maintenance�������������������������������������������������������������������������������������29
A�3�1 Handling the Chassis��������������������������������������������������������������29
A�3�2 Cleaning the Exterior �������������������������������������������������������������29
A�3�3 Power Requirements �������������������������������������������������������������29
Important Safety Instrucons ��������������������������������������������������������������������������30

III
List of Tables
Table 1-1: Front Panel Legend �������������������������������������������������������������������������� 6
Table 1-2: Front Panel Indicators ���������������������������������������������������������������������� 6
Table 1-3: Rear Panel Legend ��������������������������������������������������������������������������� 8
Table 1-4: PXI Star Trigger Line Assignment�����������������������������������������������������11
Table 1-5: PXIe-62780 Reference Clock Priority �����������������������������������������������14
Table 2-1: Rack Mount Assembly Legend ��������������������������������������������������������20
Table 3-1: Supported Funcon Comparison Between SMBus Interface and RS-
232 Serial Port ��������������������������������������������������������������������������������22
Table 3-2: Target Temperature Parameters Legend ������������������������������������������27

IV
List of Figures
Figure 1-1: Front View �������������������������������������������������������������������������������������� 4
Figure 1-2: Right Side View ������������������������������������������������������������������������������� 4
Figure 1-3: Le Side View ��������������������������������������������������������������������������������� 5
Figure 1-4: Rear View���������������������������������������������������������������������������������������� 5
Figure 1-5: PXIe-62780 Front Panel ������������������������������������������������������������������� 6
Figure 1-6: PXIe-62780 Rear Panel Connectors �������������������������������������������������� 7
Figure 1-7: Inhibit/ Voltage & Remote Monitoring Connectors�������������������������� 8
Figure 1-8: PXIe-62780 Backplane ��������������������������������������������������������������������� 9
Figure 1-9: Temperature Sensors on Backplane������������������������������������������������� 9
Figure 1-10: Star Trigger Roung����������������������������������������������������������������������10
Figure 1-11: 3U Hybrid Slot Compable PXI-1 Peripheral Module���������������������12
Figure 1-12: 3U PXI Express Peripheral Module������������������������������������������������12
Figure 1-13: Trigger Bus Bridge Capability ��������������������������������������������������������13
Figure 2-1: Rack Mount Assembly��������������������������������������������������������������������20
Figure 3-1: PXIe-62780 Chassis Remote Mon. Ulity ����������������������������������������23
Figure 3-2: Log Opons Dialog �������������������������������������������������������������������������24
Figure 3-3: PXI Trigger Roung Interface ����������������������������������������������������������25
Figure 3-4: Target Temperature Parameters �����������������������������������������������������26

1
1 Introduction
The JYTEK PXIe-62780 18-slot PXI Express chassis is compliant with PXI Express and
cPCI Express specicaons, and oers one system slot, one system ming slot, six PXIe
peripheral slots, and ten hybrid peripheral slots for versale tesng and measurement
applicaons requiring enhanced bandwidth. The hybrid-slot design accepts installaon
of CompactPCI, PXI, CompactPCI Express, and PXI Express modules into any peripheral
slot, maximizing exibility. The PXIe-62780 provides a congurable PCIe switch fabric
and is congurable in two-link and four-link PXI express deployments, with 8GB/s system
bandwidth and up to 4GB/s slot bandwidth for dedicated peripheral slots, thanks to second
generaon PCIe signaling technology.
The PXIe-62780 implements a smart system monitoring controller, reporng full chassis
status, including fan speed, system voltages, and internal temperature.
Equipped with an industrial grade AC power supply, the PXIe-62780 delivers 800W
of power in environments from 0°C to 55°C, and features an innovave cooling scheme
providing superior heat dissipaon. Three 185.9CFM fans in the rear secon of the
chassis draw cool air from apertures on the boom and front of the chassis, over the PXI/
PXIe modules, to be exhausted to the rear. This innovave cooling design provides, not
only exceponal eciency of heat dissipaon, but also superior uniformity for each PXI
slot. BNC connectors for 10 MHz clock input/output on the rear panel increase chassis
exibility, enabling synchronizaon with supplementary devices.
1�1 Features
• PXI™-5 PXI Express hardware specicaon Rev.1.0 compliant
• 18-slot PXI Express chassis with one system slot, one system ming slot, ten hybrid
peripheral slots, and six PXI Express peripheral slots.
• Congurable PCIe switch fabric, can be congured as four-link x4, two-link x8 PXI
Express chassis
• Up to 8 GB/s system bandwidth
• Up to 4 GB/s peripheral bandwidth for dedicated slots
• 0°C to 55°C operang temperature range
• Intelligent chassis management
• Automac fan speed control
• Chassis status monitoring and reporng
• Remote chassis power on/o control
• BNC connectors for 10 MHz clock input/output
• Maximum total usable power of 800W at 55°C or less
• Power, temperature, and fan monitoring LEDs

2
1�2 Specifications
The PXIe-62780 complies with the PXI™-5 Specicaon Rev.1.0 and accepts all modules
compliant with the PXI™-5, CompactPCI, and PICMG 2.0 specicaons.
Power Supply
AC Input (*guaranteed by power supply design)
Input voltage range 100 to 240 VAC
Operang voltage range* 85 to 264 VAC
Input voltage frequency 50 to 60 Hz
Operang voltage frequency* 47 to 63 Hz
Input current rang
115 VAC 13 A
230 VAC 10 A
DC Output
Maximum total usable power 800 W
VDC Maximum Load Regulaon Maximum Ripple & Noise
+5V 29.0 A ±3% 50 mV
+12V 45.0 A ±3% 50 mV
+3.3V 60.0 A ±3% 50 mV
-12V 2.5 A ±3% 50 mV
10 MHz System Reference Clock (10 MHz REF)
Maximum clock skew between slots 300 ps
Built-in 10 MHz clock Accuracy ±25 ppm
BNC Output amplitude 1 Vpk-pk ±20% square-wave into 50 Ω
2 Vpk-pk unloaded
BNC Output impedance 50 Ω ±5 Ω
External 10 MHz clock source input requirements
Frequency input 10 MHz ±100 PPM
Input signal (10MHz REF In BNC) 100 mVPP to 5 VPP(square or sine)
Input impedance (10MHz REF In BNC) 50 Ω ±5 Ω
Input signal (PXI_CLK10_IN on 10th slot) 5 V or 3.3 V TTL signal
100 MHz System Reference Clock: PXIe_CLK100
Maximum slot-to-slot skew 100 ps
Accuracy ±25 ppm

3
Cooling
Fans 3 sets of 185.9 CFM fans
Per-slot cooling capacity 38.2 W (veried by 55°C chamber test)
Physical
Slots 18 total, as follows:
• 1 x system
• 1 x system ming
• 10 x hybrid peripheral
• 6 x PXI Express peripheral
Dimensions 464.3 (W) x 191.4 (H) x 465.3 (D) mm
(18.1 x 7.46 x 18.14 in.)
Weight 11.9 kg (26.2 lb)
Environmental
Storage Ambient temperature: -20 to 70°C
Relave humidity: 10 to 90%, noncondensing
Operang Ambient temperature: 0 to 55°C
Relave humidity10 to 90%, noncondensing
Funconal shock 30 G, half-sine, 11 ms pulse duraon
Random Vibraon Operang: 5 to 500 Hz, 0.3 Grms, 3 axes
Nonoperang: 5 to 500 Hz, 2.46 Grms, 3 axes
Sound Pressure Level
(at operator posion) Tested in
accordance with ISO 7779
Auto fan (up to 25 °C ambient) 46.3 dBA
High fan 64.5dBA
Sound Power Auto fan (up to 25 °C ambient) 56.0 dBA High
fan 76.0 dBA
Cercaon
Safety EN 61010-1
Electromagnec
Compability
Emissions: EN 55011
Class A Immunity:EN 61326-1
CE Compliance Meets essenal requirements of applicable European
Direcves, as amended for CE Marking:
Low-Voltage Direcve (safety): 73/23/EEC
Electromagnec Compability Direcve (EMC): 9/336/EEC

4
1�3 Schematics
All dimensions are shown in mm (millimeters)
Figure 1-1: Front View
465.3
Figure 1-2: Right Side View

5
Figure 1-3: Left Side View
Figure 1-4: Rear View

6
1�4 Connectors, I/O, and Controls
1�4�1 Front Panel
Figure 1-5: PXIe-62780 Front Panel
Feature Details
APower Powers the chassis on/o (when INHIBIT on rear
panel (not shown) is set to “DEF”)
BChassis Status Temperature, Fan, and Power (L to R), funcons
as follows
Table 1-1: Front Panel Legend
Status Temperature (Amber) Fan (Green) Power (Blue)
On (Lit) N/A Fans operang
normally
DC voltage supply is
normal
O Temperature is normal Chassis is powered
down
Chassis is powered down
Blinking One or more temperature
sensors exceeds threshold
temperature (default
70°C)
One or more fans
falls below threshold
speed (default is
800RPM)
One or more power rails
exceeds threshold sengs
(defaults are ±5% for 5V,
3.3V, +12V, and -12V)
Table 1-2: Front Panel Indicators

7
1�4�2 Rear Panel
CDEFGH
IJ
Figure 1-6: PXIe-62780 Rear Panel Connectors
Feature Details
C10MHz Reference
Clock Input
The BNC connector acts as a 10MHz reference
clock input, whereby the backplane 10MHz clock is
overridden in the presence of an external 10MHz clock
D10MHz Reference
Clock Output
The BNC connector acts as 10MHz reference clock
output
ERemote Monitoring
Connector
The D-sub9 connector acts as a remote monitoring
connector, when connected to a remote computer
using a standard D-sub9 cable, with pin assignments
shown in Figure 1-7
Note: The remote monitor port is Rx-Tx/Tx-Rx crossed,
such that a RS-232 cable with Rx-Rx/
Tx-Tx connecon must be used
FInhibit/Voltage
Monitoring DB-9
Connector
The DB-9 connector monitors the four main
voltage rails via digital mulmeter
• voltage rail pin assignments shown in Figure 1-7
• 10 kΩ current liming resistors on each voltage
rail prevent accidental overload
• one Inhibit (acve low) pin is provided to power
the chassis on/o when the Inhibit Switch is in
the MAN (manual) posion, such that chassis
is powered on when Inhibit pin is logic high or
open, and o when Inhibit pin is grounded

8
Feature Details
GInhibit Switch In the DEF (default) posion, the front panel power
buon turns the power supply on/o, and in the
MAN (manual) posion, the INHIBIT pin on the DB-9
connector turns the power supply on/o
HFan Switch In the HIGH posion, fans operate at maximum speed,
and in AUTO, the fans run based on the monitored
chassis temperature
IUniversal Power Inlet Accepts IEC 60320-1 C19 power outletequipped
connecon
J Chassis Ground Lug The ground wire can be crimped to the ground lug,
using a crimp tool of the appropriate size, with the
other end connected to ground
Table 1-3: Rear Panel Legend
Figure 1-7: Inhibit/ Voltage & Remote Monitoring Connectors

10
PCI Express Link Capability
The PXIe-62780 backplane provides a congurable PCIe switch fabric, allowing PCI express
link conguraon between system slot and PCIe switch fabric to change from 4-link x 4 lanes
(factory default) to 2-link x 8 lanes.
4-link x 4 lanes conguraon delivers the most balanced PCI express topology, with all the
peripheral slots sharing equally in system bandwidth.
2-link is installed into PCIe x8 peripheral slots, providing the module with the highest
throughput. For more details, please see “PXIe Link” on page 26.
Connector pin assignments of the PXI Express System Controller Slot, PXI Express
System Timing Slot, PXI Express Hybrid Peripheral Slots, and PXI Express Peripheral
Slots comply with the default pin assignments as dened in PXI-5 PXI Express
hardware specicaon Rev.1.0.
PXI Express System Controller Slot
The System Controller slot is Slot 1 of the chassis as dened by the PXI specicaon. The
PXIe-62780 chassis can accommodate a PXI Express system controller that occupies width
up to 4 slots. As dened in the PXI specicaon, three controller expansion slots allow the
controller to expand to the le to prevent the controller from using up peripheral slots.
PXI Express System Timing Slot
The System Timing (ST) slot is Slot 10, providing one dedicated single-ended star trigger and
3 pairs of dierenal star trigger lines to each peripheral slot. Roung of single ended star
trigger signals (PXI_STAR) and dierenal star trigger signals (PXIe_DSTAR) are as follows.
Figure 1-10: Star Trigger Routing

11
Slot PXI_Star PXIe_DStar
18N/A
276
365
457
544
633
722
811
900
10 N/A 8
11 9 9
12 10 10
13 11 11
14 12 12
15 13 16
16 14 13
17 15 14
18 16 15
Table 1-4: PXI Star Trigger Line Assignment
Star trigger funconality provides a precise trigger signal to the peripheral modules by
installaon of a specic star trigger controller module in the ST slot. The system ming
slot can also be used as a general PXI Express (x4 lanes) peripheral slot if star trigger
funconality is not required.
PXI Express Hybrid Peripheral Slots
10 PXI Express hybrid peripheral slots are provided in the PXIe-62780, all connected with
PCIe x4 lanes. Each can accommodate a 3U PXI Express/CompactPCI Express/ hybrid slot
compable PXI-1/CompactPCI peripheral module.
PXI Express Peripheral Slots
6 PXI Express peripheral slots are provided in the PXIe-62780, with 8th and 12th slots
connected with PCIe x8 lanes, and the other four peripheral slots connected with PCIe
x4 lanes. Each can only accommodate a 3U PXI Express/ CompactPCI Express peripheral
module.

12
Figure 1-11: 3U Hybrid Slot Compatible PXI-1 Peripheral Module
Figure 1-12: 3U PXI Express Peripheral Module
Local Bus
The local bus on a PXI backplane is a daisy-chained bus that connects each peripheral
slot with adjacent peripheral slots to the le and right. The quanty of local bus lines is

13
decreased from thirteen to one on a PXI Express backplane. The remaining local bus line can
transmit analog or digital signals between modules.
Trigger Bus
Three trigger bus segments on the PXIe-62780 consist of a rst segment from 1st to 6th
slots, a second from 7th to 12th slots, and a third from 13th to 18th slots, with each trigger
bus segment containing 8 trigger lines connecng all slots on the same segment, providing
inter-module synchronizaon. PXI and PXI Express modules can exchange trigger or
clock signals through the trigger bus, allowing precisely med response to asynchronous
external events. Two trigger bus buers can connect or disconnect the trigger lines of
adjacent segments.
As shown, eight combinaons of trigger bus segment connecons are possible between the
three bus segments, with any applicable to each of the eight trigger lines.
Figure 1-13: Trigger Bus Bridge Capability

14
The solid circle shown represents the source of the trigger and the transparent
circle the trigger desnaon.
For details regarding conguraon of trigger bus bridge roung please see “Trigger Bus”
on page 25.
Reference Clock
The PXIe-62780 backplane supplies a single-ended 10MHz reference clock (PXI_CLK10)
and dierenal 100MHz clock (PXIe_CLK100) to each peripheral slot for inter-module
synchronizaon. The independent buers drive the clock signal to each peripheral slot.
These common reference clock signals can synchronize mulple modules in a PXI Express
chassis. PXI modules with phase-lock loop circuits can lock reference clocks to generate
an in-phase mebase.
The PXI_CLK10 and PXIe_CLK100 clocks are in-phase according to the PXI-5™
specicaon. Since the external 10MHz clock input can override the onboard 10MHz
clock source, a phase-lock loop (PLL) circuit on the backplane synchronizes the PXIe_
CLK100 and external 10MHz clock.
The PXIe-62780 PXI chassis automacally selects the 10 MHz reference clock source from
among:
• Built-in accurate 10 MHz clock source
• External 10 MHz clock through a BNC connector
• PXI_CLK10_IN pin on the system ming slot Priority of the 10MHz reference clock
is as follows.
System Timing Slot
(10th slot)
BNC Connector on Rear
Panel
10mhz Clock Driven to Peripheral
Slots
No clock present No clock present 10MHz clock is generated by
backplane
No clock present 10MHz clock present Clock from BNC connector is
driven to all peripheral slots
10MHz clock present No clock present Clock from system ming slot is
driven to all peripheral slots
10MHz clock present 10MHz clock present Clock from system ming slot is
driven to all peripheral slots
Table 1-5: PXIe-62780 Reference Clock Priority

15
2 Getting Started
This chapter describes procedures for installing the PXIe-62780 and making preparaons
for its operaon. Please contact JYTEK or authorized dealer if there are any problems during
the installaon.
Diagrams and illustrated equipment are for reference only.
Actual system conguraon and specicaons may vary.
2�1 Package Contents
Before unpacking, check the shipping carton for any damage. If the shipping carton and/
or contents are damaged, inform your dealer immediately. Retain the shipping carton and
packing materials for inspecon. Obtain authorizaon from your dealer before returning
any product to JYTEK.
Please ensure that the following items are included in the package.
• PXIe-62780 Chassis
• Power cords
• Filler panel kit for unused/reserved slots including one 3-slot panel and eighteen
1-slot panels
If any of these items are missing or damaged, contact the dealer from whom you purchased
the product. Save the shipping materials and carton in case you want to ship or store the
product in the future.
Do not install or apply power to equipment that is damaged or missing
components. Retain the shipping carton and packing materials for inspecon.
Please contact your JYTEK immediately for assistance and obtain authorizaon
before returning any product.
2�2 Cooling Considerations
The PXIe-62780 features an innovave design for heat dissipaon, with cooling fans in the
rear secon of the chassis, drawing cool air through apertures on the boom for exhaust
through the back. This design provides uniform airow for each PXI slot and exceponal
cooling capability. When the chassis is installed in a rack, the cooling design minimizes
drawing of hot air from the rear area, where other devices exhaust, while maintaining a
steady temperature inside the chassis. For opmal cooling eciency, retain support feet.
When rack mounng the PXIe-62780, at least 1U (44.5 mm/1.75 in.) clearance below the
intake apertures is required. Also keep other objects or equipment at a minimum of 76.2
mm (3 in.) away from the outlet apertures in the rear region of the chassis.
Table of contents
Other JYTEK Chassis manuals
Popular Chassis manuals by other brands

EVOC
EVOC IPC-6805E manual

Hisense
Hisense MT5659AUHT Service manual

National Instruments
National Instruments NI PXIe-1078 user manual

National Instruments
National Instruments NI 9144 user manual

Supero
Supero SC503 Series user manual

National Instruments
National Instruments NI 9155 Operating instructions and specifications

Hewlett Packard Enterprise
Hewlett Packard Enterprise Apollo a6000 Product End-of-Life Disassembly Instructions

iStarUSA
iStarUSA BPU-124-SS user manual

IEI Technology
IEI Technology PAC-400AI Quick installation guide

Ariesys
Ariesys ARP 690 User's reference manual

Philips
Philips TES1.0E LA Service manual

Optical Systems Design
Optical Systems Design OSD350B Operation manual
