PGS10H Series Grippers
Engineering
GREAT Solutions
User instructions
for PGS10H Series
Grippers
14469UI

Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC
Revisions ECN. NO. BY DATE
REL 26219 CR 09/21/12
001 26257 CR 01/28/13
002 26568 NRK 06/03/15
DRAWN DATE
CR 09/21/12
CHECKED DATE
AT 06/03/15
DES ENG DATE
CR 11/02/12
APPR, DATE
NRK 06/03/15
Revisions record
Table of contents
Section Page
Reference........................................................................................................... I.......................3
Purpose ............................................................................................................ II .......................3
Scope .............................................................................................................. III .......................3
Safety...............................................................................................................IV .......................3
Applicable Documents ......................................................................................V.......................3
Equipment Required ........................................................................................VI .......................3
Procedures...................................................................................................... VII .......................3
Cleaning and Maintenance............................................................................. VIII .....................10
Quality Assurance Requirements......................................................................IX .....................10
Specifications....................................................................................................X.....................10
02 11/16
14469UI REL: 002
User Instruction for PGS10H Series Gripper

Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC
I. Seference:
001POL Quality Policy
II. Purpose:
This document instructs the operator how to use the PGS10H Grippers
III. Scope:
This work instruction covers Port Size and Operation, Unlocking of Jaws & Setting Open Jaw Angle.
IV. Safety:
Safety glasses or approved eye protection must be worn at all times. Steps involving chemical bonding require the use of
proper ventilation and skin protection in accordance with manufacturer’s MSDS.
V. Purpose:
14418SP – Sales Page – PGS10HRXXXXXXXXX (Regular Jaw)
14419SP – Sales Page – PGS10HFXXXXXXXXX (Flange Jaw)
14417SP – Spare Parts List for PGS10H Gripper Series
VI. Equipment Required:
Standard Bench Tools
VII. Procedures:
A. Port Size and Operation
1. For Top, Right, Bottom and Left Air Port Orientation:
A) Ports are available in 1/8" NPS or 1/8" Rc.
03
11/16
14469UI REL: 002
User Instruction for PGS10H Series Gripper
Gripper open
Gripper close

Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC
2. For Rear Air Port Orientation:
A) Ports are available in 1/8” NPS, with hexagon socket head straight fittings supplied with telescope
PGS10TELXXP.
04 11/16
14469UI REL: 002
User Instruction for PGS10H Series Gripper
B) Gripper Unlock
1. Release jaw by using a hex key or flat screwdriver and pushing on drive pin through slot in side plate
C) Jaw Removal
1) Unlock gripper as shown in step B and remove pad(s) from existing jaws. Set a side for reassembly.
2) Top jaw should always be removed first. Remove SHCS and Schnorr washer from side plate. Rotate side
plate up to about 45° and remove side plate from gripper. Set SHCS and side plate aside for re-assembly.
Gripper open
Gripper open

4. Remove SHCS and Schnorr washer from side plate. Rotate side plate up to about 45° angle and remove from
gripper. Set SHCS and side plate aside for re-assembly.
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC 05
11/16
14469UI REL: 002
User Instruction for PGS20/42 Series Gripper
3. Remove jaw from gripper and flip gripper over to remove other jaw
5. For lower jaws (11103 and 10151): Remove bushing from lower jaw using a small flat screwdriver or hex key and
set aside for re-assembly. Lower jaw should be rotated completely down before removal. Lift up on front of jaw by
pad so there is an angle between jaw and frame. Remove lower jaw from gripper.
6. For lower jaws (11102): Remove lower jaw from gripper.

Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC
06
User Instruction for PGS10H Series Gripper
D. Jaw Replacement
1. For lower jaws (10151, 11102 and 11103): Apply high-temperature grease to cam and inside of jaw. Angle new
jaw so that tail of jaw goes in pocket of frame. Align pivot hole with boss and drive pin with the bottom side of the
cam slot. Carefully slide jaw over boss and onto gripper. Replace bushing over pin and into cam. Apply high
temperature grease to outside of jaw.
11/16
14469UI REL: 002
2. Refer to step E for installing a Side Plate.
3. Flip gripper over for top jaw installation.
4. For upper jaws (10150 and 11102): Apply high-temperature grease to cam and inside of jaw. Replace bushing
over drive pin and onto gripper. Align hole in jaw with boss on frame and cam with bushing. Slide jaw over boss and
drive pin so that jaw rests on gripper. Apply high- temperature grease to outside of jaw.
5. Refer to step E for installing a Side Plate.

Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC 07
User Instruction for PGS10H Series Gripper
E. Installing a Side Plate
1. With the Side Plate at 45°, align pins of side plate with slots of frame. Slide pins into slot. When pins are fully seated,
rotate side plate and slide down onto frame.
11/16
14469UI REL: 002
2. Add Schnorr washer to M5 X 12mm SHCS. Insert through side plate and into frame. Tighten M5 SHCS to 72in-lb.
F. Installing an Indirect Sensor
1. To install an Indirect Sensor, apply a liberal amount of high temperature grease to brass bushing prongs inside
sensor. Next, move the brass bushing in the sensor to align with drive rod slot in gripper. This must be done to
correctly install sensor. Make sure the sensor is in the orientation where the cable is pointing to the rear of the gripper.
Bushing
prongs
Drive rod slot
2. Apply Loctite 262 or equivalent to the three blind M4 tapped holes.

3. Apply Loctite Silver Grade Anti-Seize to M5 X 10mm SHCS. Make sure 5mm schnorr washer is used along with M5
X 10mm SHCS before inserting into one of the jaws. Take replacement pad and insert it into the opposite side of the
jaw with SHCS sticking out. Thread SHCS into pad and tighten to 72in-lb. Repeat step for other jaw.
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC
3. Rotate sensor down onto frame. As rotation begins make sure bushing and drive rod slot are still aligned.
08
User Instruction for PGS10H Series Gripper
11/16
14469UI REL: 002
Note: Whenever any part of the gripper is replaced including pads the sensor will need to be recalibrated, see step J.
4. To secure sensor to gripper, flip over while holding sensor to ensure that bushing and drive rod are still aligned.
Clean all three M4 X 30mm SHCS for sensor and insert through gripper body and into sensor. Tighten M4 SHCS
to 50in-lb.
G. Pad Replacement
1. Unlock jaws on gripper & open jaws to get access to pads. Side plates DO NOT need to be removed. Refer to
Gripper Unlock section B.
2. Remove M5X10 mm SHCS along with the 5 mm schnorr washer from jaw.

Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC 09
User Instruction for PGS10H Series Gripper
11/16
14469UI REL: 002
H. Calibrating Indirect Sensor
Sensor must be calibrated whenever any part of the gripper is replaced including pads.
1. Part Present
a) To program the sensor for a particular material thickness, apply air to the gripper and grip on the material thickness
which is to be used for the particular job. With an object such as a small Allen wrench, press the button until the
Red LED corresponding to the material range of the job lights as shown on the label.
0.5 – 0.9mm
1.0 – 1.9mm
2.0 mm - Up
Part Present– Grip 1 Sheet
Press Button for Material range
0.50 – 0.74 mm
0.75 – 0.99 mm
1.00 – 1.49 mm
Double Blank – Grip 1 Sheet
Press Button for Material range
1.50 – 1.99 mm
2.00 – 3.49 mm
3.50 mm - Up
b) Verify calibration:
(1) Close the gripper with no material between the pads. The LED should be o.
(2) Close the gripper on a single blank of material. The Red LED corresponding to your material range
should be on.
2. Double Blank
a) To program the sensor for a particular material thickness, apply air to the gripper and grip on the material thickness
which is to be used for the particular job. With an object such as a small Allen wrench, press the button until the
Red LED(s) corresponding to the material range of the job lights as shown on the label.
b) Verify calibration:
(1) Close the gripper with no material between the pads. The LED(s) should be o.
(2) Close the gripper on a single blank of material. The Red LED(s) corresponding to you material range
should be on.
0.5 – 0.9mm
1.0 – 1.9mm
2.0 mm - Up
Part Present– Grip 1 Sheet
Press Button for Material range
0.50 – 0.74 mm
0.75 – 0.99 mm
1.00 – 1.49 mm
Double Blank – Grip 1 Sheet
Press Button for Material range
1.50 – 1.99 mm
2.00 – 3.49 mm
3.50 mm - Up

VIII. Cleaning and Maintenance:
A) Remove excess grease from outer surfaces of gripper.
B) No required maintenance.
IX. Quality Assurance Requirements:
A) Verify that jaws shall open freely. Look for any irregular movement, binding, or interference.
Gripper Throat
Depth
Flange Height Working Pressure Double Sided Grip
Force Up To
Actuation Time
PGS10HF 0.91
(23.1 mm)
60psi (413kPa) Min. –
100psi (689 kPa) Max.
60psi (413kPa) Min. –
100psi (689 kPa) Max.
450lbs (200kgf) @
80psi (551kPa)
0.050±0.010 sec. close /
0.080±0.010 sec. open
PGS10HR 0.75
(19mm)
60psi (413kPa) Min. –
100psi (689 kPa) Max.
60psi (413kPa) Min. –
100psi (689 kPa) Max.
450lbs (200kgf) @
80psi (551kPa)
0.050±0.010 sec. close /
0.080±0.010 sec. open
IX. Specifications:
Regular/Flange Jaw
Single Blank Thickness Moveable Jaw
Pad Color
Opposing Jaw
Pad Color
0.50 mm to 2.0 mm Black Black
2.01 mm to 3.5 mm Silver Silver
3.51 mm to 5.0 mm Gold Silver
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2016 Norgren Automation Solutions, LLC
10
User Instruction for PGS10H Series Gripper
Warning
Improper selection, misuse, age or malfunction of components used in
systems can cause failure in various modes. The system designer is warned
to consider the failure modes of all component parts and to provide adequate
safeguards to prevent personal injury or damage to equipment or property
in the event of such failure modes. System designers and end users are
cautioned to consult instruction sheets and specifications available from the
factory. The system designer/end user is responsible for verifying that all
requirements for the application are met.
