Immergas VICTRIX ZEUS 26 2 ERP Operating instructions

VICTRIX ZEUS
26 2 ErP
Instruction and
recommendation booklet
IE
*1.037936ENG*

Immergas S.p.A. declines all liability due to printing or transcription errors, reserving the right to make any modications to its technical and commercial
documents without prior notice.
Dear Customer,
Our compliments for having chosen a top-quality Immergas product, able to assure well-being and safety for a long period of time. As an Immergas customer
you can also count on a qualied aer-sales service, prepared and updated to guarantee constant eciency of your boiler. Read the following pages carefully: you
will be able to draw useful suggestions regarding the correct use of the appliance, the respect of which, will conrm your satisfaction for the Immergas product.
Contact our area authorised aer-sales centre as soon as possible to request commissioning.
Our technician will verify the correct functioning conditions; he will perform the necessary calibrations and will demonstrate the correct use of the generator.
For assistance and scheduled maintenance contact Authorised Aer-Sales centres: they have original spare parts and are specically trained directly by the
manufacturer.
General recommendations
All Immergas products are protected with suitable transport packaging.
e material must be stored in dry environments protected against bad weather.
e instruction book is an integral and essential part of the product and must be consigned to the new user also in the case of transfer or succession of ownership.
It must be stored with care and consulted carefully, as all of the warnings provide important safety indications for installation, use and maintenance stages.
is instructions manual provides technical information for installing Immergas boilers. As for the other issues related to boiler installation (e.g. safety in the work
site, environment protection, injury prevention), it is necessary to comply with the provisions specied in the regulations in force and principles of good practice.
In compliance with legislation in force, the systems must be designed by qualied professionals, within the dimensional limits established by the Law. Installation
and maintenance must be performed in compliance with the regulations in force, according to the manufacturer's instructions and by professionally qualied
sta, intending sta with specic technical skills in the plant sector, as envisioned by the Law.
Improper installation or assembly of the Immergas appliance and/or components, accessories, kit and devices can cause unexpected problems to people, animals
and objects. Read the instructions provided with the product carefully to ensure a proper installation.
Maintenance must be carried out by skilled technical sta. e Authorised Aer-sales Service represents a guarantee of qualications and professionalism.
e appliance must only be destined for the use for which it has been expressly declared. Any other use will be considered improper and therefore potentially
dangerous.
If errors occur during installation, operation and maintenance, due to non compliance with technical laws in force, standards or instructions contained in this
book (or however supplied by the manufacturer), the manufacturer is excluded from any contractual and extra-contractual liability for any damages and the
appliance warranty is invalidated.
For further information regarding legislative and statutory provisions relative to the installation of gas heat generators, consult the Immergas site at the
following address: www.immergas.com
Mauro Guareschi
Research & Development Director
Signature:
CE DECLARATION OF CONFORMITY
(according to ISO/IEC 17050-1)
e company IMMERGAS S.p.A., with registered oce in via Cisa Ligure 95 42041 Brescello (RE) whose design, manufacturing, and aer sale assistance
processes comply with the requirements of standard UNI EN ISO 9001:2008,
DECLARES that:
e boiler model Victrix Zeus 26 2 ErP complies with European Directives and Delegated European Regulations listed below:
“Eco-design” Directive 2009/125/EC, “Energy labelling” Directive 2010/30/EC, EU Regulation 811/2013, EU Regulation 813/2013, “Gas Appliance” Direc-
tive 2009/142/EC, “Electromagnetic Compatibility” Directive 2004/108/EC, “Performance” Directive 92/42/EC and “Low Voltage” Directive 2006/95/EC.

4
1 Boiler installation .......................................5
1.1 Installation recommendations..................5
1.2 Main dimensions. ......................................6
1.3 Anti-freeze protection................................6
1.4 Gas connection. ..........................................7
1.5 Hydraulic connection.................................7
1.6 Electrical connection. ................................7
1.7 Remote controls and room
chrono-thermostats (Optional). ...............8
1.8 External temperature probe
(Optional)....................................................8
1.9 Immergas ue systems..............................9
1.10Tables of resistance factors
and equivalent lengths. ..............................9
1.11Outdoor installation
in a partially protected area.....................11
1.12Concentric horizontal kit installation....12
1.13Concentric vertical kit installation.........13
1.14Separator kit installation..........................14
1.15Adaptor C9 kit installation. ....................15
1.16Ducting of ues or technical slots. .........16
1.17 Conguration type B, open
chamber and fan assisted for indoors. ...16
1.18Flue gas exhaust to ue/chimney............16
1.19Flues, chimneys, chimney
pots and terminals....................................17
1.20System lling. ............................................17
1.21Condensate trap lling.............................17
1.22Gas system start-up. .................................17
1.23Boiler start up (ignition)..........................17
1.24Domestic hot water storage tank unit....17
1.25Kits available on request. .........................17
1.26Circulation pump......................................18
1.27Boiler components....................................20
INDEX
USER page
2 Use and maintenance instructions.........21
2.1 Cleaning and maintenance......................21
2.2 General warnings......................................21
2.3 Control panel.............................................21
2.4 Ignition of the boiler.................................22
2.5 Troubleshooting........................................22
2.6 Boiler shutdown........................................23
2.7 Restoring central heating
system pressure............................................. 23
2.8 System draining. ......................................23
2.9 Storage tank draining...............................23
2.10Anti-freeze protection..............................23
2.11Case cleaning.............................................23
2.12Decommissioning.....................................23
3 Boiler start-up (initial check)..................24
3.1 Plumbing diagram....................................24
3.2 Wiring diagram.........................................25
3.3 Troubleshooting........................................25
3.4 Converting the boiler
to other types of gas..................................26
3.5 Calibration phase......................................26
3.6 Nominal heat output calibration. ...........26
3.7 Adjustment of the air-gas ratio. ..............27
3.8 Checks following conversion
to another type of gas...............................27
3.9 Pump operating mode. ............................27
3.10 Domestic hot water mode
selector switch............................................. 27
3.11Solar panels
coupling function. ....................................27
3.12''Chimney sweep'' function......................27
3.13Pump anti-lock function. ........................27
3.14ree-way anti-block function. ..............27
3.15Permanent reduction of
timing function.........................................27
3.16Radiators antifreeze function..................27
3.17Flow temperature value
in central heating mode...........................27
3.18Yearly appliance check
and maintenance.......................................28
3.19Casing removal. ........................................29
3.20Variable heat output. ................................30
3.21 Combustion parameters.........................30
3.22Technical data. ..........................................31
3.23Key for data plate......................................32
3.24Technical parameters for mixed boilers
(in compliance with Regulation
813/2013)...................................................33
3.25Product data sheet (in compliance
with Regulation 811/2013)......................33
3.26Parameters for lling in
the assembly sheet. ...................................34
INSTALLER page MAINTENANCE TECHNICIAN page

5
SI NO
1-1
INSTALLERUSER
MAINTENANCE TECHNICIAN
1BOILER INSTALLATION
1.1 INSTALLATION
RECOMMENDATIONS.
e Victrix Zeus 26 2 ErP boiler has been de-
signed for wall mounted installation only; for
heating and production of domestic hot water
for domestic use and similar purposes.
e place of installation of the appliance and
relative Immergas accessories must have suitable
features (technical and structural) such to allow
(always in safety, efficiency and comfortable
conditions):
- installation (according to the provisions of the
technical legislation and technical regulations);
- maintenance operations (including scheduled,
periodic, routine and special maintenance);
- removal (to outdoors in the place for loading
and transporting the appliances and compo-
nents) as well as their eventual replacement
with appliances and/or equivalent components.
e wall surface must be smooth, without any
protrusions or recesses enabling access to the
rear part. ey are not designed to be installed
on plinths or oors (Fig. 1-1).
By varying the type of installation the classica-
tion of the boiler also varies, precisely:
- Type B23 or B53 boiler if installed using the
relevant terminal for air intake directly from
the room in which the boiler has been installed.
- Type C boiler if installed using concentric
pipes or other types of pipes envisioned for
sealed chamber boilers for air intake and expul-
sion of ue gas.
Note: appliance classication is provided in the
depictions of the various installation solutions
shown on the following pages.
Only professionally enabled companies are
authorised to install Immergas gas appliances.
Installation must be carried out according to
regulation standards, current legislation and in
compliance with local technical regulations and
the required technical procedures.
Before installing the appliance, ensure that it is
delivered in perfect condition; if in doubt, contact
the supplier immediately. Packing materials (sta-
ples, nails, plastic bags, polystyrene foam, etc.)
constitute a hazard and must be kept out of the
reach of children. If the appliance is installed in-
side or between cabinets, ensure sucient space
for normal servicing; therefore it is advisable to
leave clearance of at least 3 cm between the boiler
casing and the vertical sides of the cabinet. Leave
adequate space above the boiler for possible water
and ue removal connections. Keep all amma-
ble objects away from the appliance (paper, rags,
plastic, polystyrene, etc.).
Do not place household appliances underneath
the boiler as they could be damaged if the safety
valve intervenes, if the drain trap is blocked, or
if there are leaks from the hydraulic connec-
tions; otherwise, the manufacturer cannot be
held responsible for any damage caused to the
household appliances.
For the aforementioned reasons, we recommend
not placing furnishings, furniture, etc. under
the boiler.
In the event of malfunctions, faults or incorrect
operation, turn the appliance o and contact an
authorised company (e.g. the Authorised Tech-
nical Assistance centre, which has specically
trained sta and original spare parts). Do not
attempt to modify or repair the appliance alone.
Failure to comply with the above implies personal
responsibility and invalidates the warranty.
• Installation regulations:
- this boiler can be installed outdoors in a
partially protected area. A partially protected
area is one in which the appliance is not
exposed to the direct action of the weather
(rain, snow, hail, etc..).
- Installation in places with a re risk is pro-
hibited (for example: garages, closed parking
stalls), gas appliances and relative ue ducts,
ue exhaust pipes and combustion air intake
pipes.
- Installation is prohibited on the vertical
projection of cooking hobs.
- Installation is also prohibited in places/en-
vironments that constitute common parts of
oce condominiums such as stairs, cellars,
entrance halls, attics, los, escape routes,
etc. if they are not located inside technical
compartments under the responsibility of
each individual building and only accessible
to the user (for the features of the technical
compartments, see the technical standards in
force).
Attention: wall mounting of the boiler must
guarantee stable and ecient support for the
generator
e plugs (standard supply) are only to be used
to x the appliance to the wall; they only ensure
adequate support if inserted correctly (according
to technical standards) in walls made of solid or
semi-hollow brick or block. In the case of walls
made from hollow brick or block, partitions with
limited static properties, or in any case walls
other than those indicated, a static test must be
carried out to ensure adequate support.
N.B.: the hex head screws supplied in the blister
pack are to be used exclusively to x the relative
mounting bracket to the wall.
ese boilers are used to heat water to below
boiling temperature in atmospheric pressure.
ey must be connected to a central heating
system and hot water circuit suited to their
performance and capacity.
"Anti-legionella" heat treatment of the Immergas
storage tank (activated by the specic function
present on the predisposed thermoregulatory
systems): during this stage, the temperature of
the water inside the storage tank exceeds 60°C
with a relative risk of burns. Keep this domestic
water treatment under control (and inform
the users) to prevent unforeseeable damage
to people, animals, things. If required install a
thermostatic valve on the domestic hot water
outlet to prevent scalding.
YES NO

6
1-2
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.2 MAIN DIMENSIONS.
Key:
V - Electrical connection
G - Gas supply
SC - Condensate drain (minimum internal
diameter 13 mm Ø)
R - System return
M - System ow
RC - Domestic hot water recirculation
(optional)
AC - Domestic hot water outlet
AF - Domestic cold water inlet
N.B.: Connection group (Optional)
Height
(mm) Width (mm) Depth (mm)
863 580 380
CONNECTIONS
GAS SYSTEM
DOMES-
TIC HOT
WATER
G R M AC AF
1/2” 3/4” 3/4” 1/2” 1/2”
1.3 ANTIFREEZE PROTECTION.
Minimum temperature -5°C. e boiler comes
standard with an anti-freeze function that ac-
tivates the pump and burner when the system
water temperature in the boiler falls below 4°C.
In these conditions the boiler is protected against
freezing to an ambient temperature of -5°C.
Minimum temperature -15°C. In the event the
boiler is installed in a place where the tempera-
ture falls below -5°C, the appliance can freeze.
To prevent the risk of freezing follow the instruc-
tions below:
- protect the central heating circuit from freezing
by inserting a good-quality antifreeze liquid
into this circuit, which is specially suited for
central heating systems and which is manu-
facturer guaranteed not to cause damage to
the heat exchanger or other components of
the boiler. e antifreeze liquid must not be
harmful to one's health. e instructions of the
manufacturer of this liquid must be followed
scrupulously regarding the percentage neces-
sary with respect to the minimum temperature
at which the system must be kept. An aqueous
solution must be made with potential pollution
class of water 2 (EN 1717:2002).
e materials used for the central heating circuit
of Immergas boilers withstand ethylene and
propylene glycol based antifreeze liquids (if the
mixtures are prepared perfectly).
For life and possible disposal, follow the sup-
plier's instructions.
- Protect the domestic hot water circuit against
freezing by using an accessory that is supplied
on request (anti-freeze kit) comprising two
electric heating elements, the relevant cables
and a control thermostat (carefully read the
installation instructions contained in the ac-
cessory kit pack).
In these conditions the boiler is protected against
freezing to temperature of -15°C.
Boiler antifreeze protection (both -5°C and -15°C)
is thus ensured only if:
- the boiler is correctly connected to gas and elec-
tricity power supply circuits;
- the boiler is powered constantly;
- the boiler is not in stand-by ( ).
- the boiler is not in anomaly conditions (parag.
2.5);
- the essential components of the boiler and/or
antifreeze kit are not faulty.
e warranty does not cover damage due to inter-
ruption of the electrical power supply and failure
to comply with that stated on the previous page.
NOTE: if the boiler is installed in places where
the temperature falls below 0°C the domestic
hot water and central heating attachment pipes
must be insulated.

7
CAVO
ALIMENTAZIONE 1-3
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.4 GAS CONNECTION.
Our boilers are designed to operate with methane
gas (G20) and LPG. Supply pipes must be the
same as or larger than the 1/2”G boiler tting.
Before connecting the gas line, carefully clean
inside all the fuel feed system pipes to remove
any residue that could impair boiler eciency.
Also make sure the gas corresponds to that for
which the boiler is prepared (see boiler data
name plate). If dierent, the appliance must be
converted for operation with the other type of
gas (see converting appliance for other gas types).
e dynamic gas supply (methane or LPG) pres-
sure must also be checked according to the type
used in the boiler, which must comply with the
technical standards in force and relevant annexes,
as insucient levels can reduce generator output
and cause malfunctions.
Ensure correct gas cock connection. e gas sup-
ply pipe must be suitably dimensioned according
to current regulations in order to guarantee cor-
rect gas ow rate to the burner even in conditions
of maximum generator output and to guarantee
appliance eciency (technical specications).
e coupling system must conform to technical
standards in force.
Fuel gas quality. e appliance was designed
to operate with combustible gas free of impuri-
ties; otherwise it is advisable to t special lters
upstream of the appliance to restore the purity
of the fuel.
Storage tanks (in case of supply from LPG
depot).
- New LPG storage tanks may contain residual
inert gases (nitrogen) that degrade the mixture
delivered to the appliance casing functioning
anomalies.
- Due to the composition of the LPG mixture,
layering of the mixture components may occur
during the period of storage in the tanks. is
can cause a variation in the heating power of
the mixture delivered to the appliance, with
subsequent change in its performance.
1.5 HYDRAULIC CONNECTION.
Attention: in order not to void the condensa-
tion module warranty, before making the boiler
connections, carefully wash the heating system
(pipes, radiators, etc.) with special pickling or
descaling products to remove any deposits that
could compromise correct boiler operation.
A chemical treatment of the thermal system wa-
ter is required, in compliance with the technical
standards in force, in order to protect the system
and the appliance from deposits (e.g., lime scale),
slurry or other hazardous deposits.
Water connections must be made in a rational
way using the couplings on the boiler template.
e boiler safety valves outlet must be connected
to a draining funnel. Otherwise, the manufactur-
er declines any responsibility in case of ooding
if the drain valve cuts in.
Attention: Immergas declines all liability in the
event of damage caused by the inclusion of auto-
matic lling that is not its own brand.
In order to meet the system requirements es-
tablished by the technical regulation in force in
relation to the pollution of drinking water, we
recommend installing the IMMERGAS anti-
backow kit to be used upstream of the cold
water inlet connection of the boiler. It is also
recommended that the heat transfer uid (e.g.
water + glycol) entered in the primary circuit
of the boiler (heating circuit), complies with the
local regulations in force.
Attention: to preserve the duration and the ef-
ciency features of the appliance, in the presence
of water whose features can lead to the deposit of
scale, installation of the “polyphosphate dispenser”
kit is recommended.
Condensate drain. To drain the condensate
produced by the appliance, it is necessary to
connect to the drainage system by means of acid
condensate resistant pipes, with an internal Ø of
at least 13 mm. e system connecting the appli-
ance to the drainage system must be carried out
in such a way as to prevent freezing of the liquid
contained in it. Before appliance ignition, ensure
that the condensate can be correctly removed.
Aer rst ignition, check that the drain trap is
lled with condensate (para. 1.21). Also, comply
with national and local regulations on discharg-
ing waste waters.
1.6 ELECTRICAL CONNECTION.
e boiler has an IPX4D protection rating for the
entire appliance. Electrical safety of the appliance
is reached only when it is correctly connected to
an ecient earthing system as specied by cur-
rent safety standards.
Attention: Immergas S.p.A. declines any respon-
sibility for damage or physical injury caused by
failure to connect the boiler to an ecient earth
system or failure to comply with the reference
standards.
Also ensure that the electrical installation cor-
responds to maximum absorbed power specica-
tions as shown on the boiler data-plate. Boilers
are supplied complete with an “X” type power
cable without plug. e power supply cable must
be connected to a 230V ±10% / 50Hz mains sup-
ply respecting L-N polarity and earth connection;
, this network must also have a multi-pole cir-
cuit breaker with class III over-voltage category.
When replacing the power supply cable, contact
a qualied rm (e.g. the Authorised Aer-Sales
Technical Assistance Service). e power cable
must be laid as shown (Fig. 1-3).
In the event of mains fuse replacement on the
P.C.B., use a 3.15A quick-blow fuse. For the main
power supply to the appliance, never use adapt-
ers, multiple sockets or extension leads.
If during connection the L-N polarities are not
respected, the boiler does not detect ame pres-
ence and goes into ignition block.
Warning: even where L-N polarity is not com-
plied with, if there is temporary residual voltage
exceeding 30V on the neutral the boiler might
still operate (but only temporarily). Measure the
voltage using appropriate instruments, without
trusting the voltage tester screwdriver.
Installation with system operating at direct
low temperature. e boiler can directly feed a
low temperature system by acting on the jumper
(8 Fig. 3-4) and by setting the ow temperature
adjustment range from 50 ÷ 20°C (Para. 3.17). In
this situation it is good practice to insert a safety
device in series with the power supply and boiler.
is device is made up from a thermostat with
a temperature limit of 60°C. e thermostat
must be positioned on the system delivery pipe
at a distance of at least 2 metres from the boiler.
SUPPLY
VOLTAGE CABLE

8
1-5 1-6
45
31
58
1-4
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.7 REMOTE CONTROLS AND ROOM
CHRONOTHERMOSTATS
OPTIONAL.
e boiler is prepared for the application of room
chrono-thermostats or remote controls, which
are available as optional kits (Fig. 1-4).
All Immergas chrono-thermostats are connected
with 2 wires only. Carefully read the user and
assembly instructions contained in the acces-
sory kit.
• On/O Immergas digital chrono-thermostat.
e chrono-thermostat allows:
- set two room temperature value: one for
daytime (comfort temperature) and one for
night-time (reduced temperature);
- set a weekly program with four daily switch
on and switch o times;
- select the required operating mode from the
various possible alternatives:
• manual operation (with adjustable tempera-
ture).
• automatic operation (with set programme).
• forced automatic operation (momentarily
changing the temperature of the automatic
programme).
e chrono-thermostat is powered by two 1.5V
LR 6 type alkaline batteries.
• Comando Amico Remoto Remote Control De-
vice V2 (CARV2) with climate chrono-thermostat
function. In addition to the functions described
in the previous point, the CARV2 panel enables
the user to control all the important informa-
tion regarding operation of the appliance and
the heating system with the opportunity to eas-
ily intervene on the previously set parameters,
without having to go to where the appliance
is installed. e panel is provided with self-
diagnosis to display any boiler functioning
anomalies. The climate chrono-thermostat
incorporated into the remote panel enables
the system ow temperature to be adjusted to
the actual needs of the room being heated, in
order to obtain the desired room temperature
with extreme precision and therefore with
evident saving in running costs. e CARV2 is
fed directly by the boiler by means of the same 2
wires used for the transmission of data between
the boiler and device.
Important: If the system is divided into zones
using the relevant kit, the CARV2 must be used
with its climate thermostat function disabled, i.e.
it must be set to On/O mode.
Comando Amico Remoto Remote Control V2
or On/O chrono-thermostat electrical con-
nections (Optional). e operations described
below must be performed aer having removed
the voltage from the appliance. Any thermostat
or On/O environment chrono-thermostat must
be connected to clamps 40 and 41 eliminating
jumper X40 (Fig. 3-2). Make sure that the On/
O thermostat contact is of the “clean” type, i.e.
independent of the mains voltage, otherwise the
P.C.B. would be damaged. Any Comando Amico
Remoto Remote Control V2 must be connected to
clamps 42 and 43 eliminating jumper X40 on the
P.C:B., paying attention not to invert the polarity
in the connections (Fig. 3-2).
e boiler can only be connected to one remote
control. e boiler works with the parameters
set on the CARV2 only if the boiler main selector
is turned to DHW/Comando Amico Remoto(
).
Important: if the Comando Amico Remoto
Remote Control V2 or any other On/O chrono-
thermostat is used, arrange two separate lines in
compliance with current regulations regarding
electrical systems. No boiler pipes must ever be
used to earth the electric system or telephone
lines. Ensure elimination of this risk before mak-
ing the boiler electrical connections.
1.8 EXTERNAL TEMPERATURE PROBE
OPTIONAL.
e boiler is designed for the application of the
Room ermostat (Fig. 1-5) which is available
as an optional kit. Refer to the relative instruc-
tion sheet for positioning of the external probe.
e probe can be connected directly to the boiler
electrical system and allows the max. system
ow temperature to be automatically decreased
when the external temperature increases, in
order to adjust the heat supplied to the system
according to the change in external temperature.
e external probe always operates when con-
nected, regardless of the presence or type of room
chrono-thermostat used and can work in combi-
nation with Immergas chrono-thermostats. e
correlation between system ow temperature
and external temperature is determined by the
position of the central heating selector switch on
the boiler control panel (or on the CARV2 control
panel if connected to the boiler) according to
the curves shown in the diagram (Fig. 1-6). e
electric connection of the external probe must be
made on clamps 38 and 39 on the boiler P.C.B.
(Fig. 3-2).
Position of the central heating tempera-
ture user adjustment
In brackets, temperature value with 25°/50° range

9
(A)
(B)
1-7
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.10 TABLES OF RESISTANCE FACTORS
AND EQUIVALENT LENGTHS.
TYPE OF DUCT
Resistance
Factor
(R)
Equivalent length
in m of concentric
pipe Ø 80/125
Concentric pipe Ø 80/125 m 1 2.1 1
Concentric bend 90° Ø 80/125 3.0 1.4
Concentric bend 45° Ø 80/125 2.1 1
Terminal complete with concentric
horizontal intake-exhaust Ø 80/125 2.8 1.3
Terminal complete with concentric
vertical intake-exhaust Ø 80/125 3.6 1.7
Concentric bend 90° Ø 80/125 with
inspection 3.4 1.6
Stub pipe with inspection Ø 80/125 3.4 1.6
1.9 IMMERGAS FLUE SYSTEMS.
Immergas supplies various solutions separately
from the boilers regarding the installation of
air intake terminals and ue exhaust, which are
fundamental for boiler operation.
Attention: the boiler must be installed ex-
clusively with an original Immergas “Green
Range” inspectionable air intake device and
fumes extraction system made of plastic, as
required by the regulations in force.
e plastic pipes cannot be installed outdoors,
for tracts longer than 40 cm, without suitable
protection from UV rays and other atmos-
pheric agents.
is system can be identied by an identica-
tion mark and special distinctive marking
bearing the note: “only for condensing boilers”.
• Resistance factors and equivalent lengths. Each
ue component has a Resistance Factor based
on experimental tests and specied in the table
below. e Resistance Factor for individual
components is independent from the type of
boiler on which it is installed and has a dimen-
sionless size. It is however, conditioned by the
temperature of the uids that pass through the
pipe and therefore, varies according to applica-
tions for air intake or ue exhaust. Each single
component has a resistance corresponding to
a certain length in metres of pipe of the same
diameter; the so-called equivalent length,
can be obtained from the ratio between the
relative Resistance Factors. All boilers have an
experimentally obtainable maximum Resistance
Factor equal to 100. e maximum Resistance
Factor allowed corresponds to the resistance
encountered with the maximum allowed pipe
length for each type of Terminal Kit. This
information allows calculations to be made to
verify the possibility of setting up various ue
congurations.
• Positioning the gaskets (black) for “green
range” ue systems. Position the gasket cor-
rectly (for bends and extensions) (Fig. 1-7):
- gasket (A) with notches, to use for bends;
- gasket (B) without notches, to use for exten-
sions;
N.B.: if necessary, to ease the push-fitting,
spread the elements with commonly-used talc.
• Coupling extension pipes and concentric
elbows. To install push-tting extensions with
other elements of the ue, proceed as follows:
Install the concentric pipe or elbow with the
male side (smooth) on the female side (with lip
seal) to the end stop on the previously installed
element in order to ensure sealing eciency of
the coupling.
Attention: if the exhaust terminal and/or
concentric extension pipe needs shortening,
consider that the internal duct must always
protrude by 5 mm with respect to the external
duct.
• N.B.: for safety purposes, do not obstruct the
boiler intake/exhaust terminal, even temporar-
ily.
• N.B.: when installing horizontal pipes, a mini-
mum inclination of 3% must be maintained and
a section clip with pin must be installed every
3 metres.

10
INSTALLERUSER
MAINTENANCE TECHNICIAN
TYPE OF DUCT
Resistance
Factor
(R)
Equivalent length
in m of concentric
pipe Ø 60/100
Equivalent
length in metres
of pipe Ø 80
Equivalent length
in metres of pipe
Ø 60
Equivalent length
in m of concentric
pipe Ø 80/125
Concentric pipe Ø 60/100
m 1
Intake and
Exhaust 6.4 m 1 Intake m 7.3 Exhaust m 1.9 m 3.0
Exhaust m 5.3
Concentric bend 90° Ø
60/100
Intake and
Exhaust 8.2 m 1.3 Intake m 9.4 Exhaust m 2.5 m 3.9
Exhaust m 6.8
Concentric bend 45° Ø
60/100
Intake and
Exhaust 6.4 m 1 Intake m 7.3 Exhaust m 1.9 m 3.0
Exhaust m 5.3
Terminal complete with
concentric horizontal
intake-exhaust Ø 60/100
Intake and
Exhaust 15 m 2.3
Intake m 17.2
Exhaust m 4.5 m 7.1
Exhaust m 12.5
Concentric horizontal
intake- exhaust terminal
Ø 60/100
Intake and
Exhaust 10 m 1.5 Intake m 11.5 Exhaust m 3.0 m 4.7
Exhaust m 8.3
Terminal complete with
concentric vertical intake-
exhaust Ø 60/100
Intake and
Exhaust 16.3 m 2.5
Intake m 18.7
Exhaust m 4.9 m 7.7
Exhaust m 13.6
Concentric vertical intake-
exhaust terminal Ø 60/100
Intake and
Exhaust 9 m 1.4
Intake m 10.3
Exhaust m 2.7 m 4.3
Exhaust m 7.5
Pipe Ø 80 m 1 Intake 0.87 m 0.1 Intake m 1.0 Exhaust m 0.4
m 0.4
m 0.5
Exhaust 1.2 m 0.2 Exhaust m 1.0
Complete intake terminal
Ø 80 m 1 Intake 3 m 0.5 Intake m 3.4 Exhaust m 0.9 m 1.4
Intake terminal Ø 80
Exhaust terminal Ø 80
Intake 2.2 m 0.35 Intake m 2.5 Exhaust m 0.6
m 1
m 0.9
Exhaust 1.9 m 0.3 Exhaust m 1.6
Bend 90° Ø 80 Intake 1.9 m 0.3 Intake m 2.2 Exhaust m 0.8
m 0.9
m 1.2
Exhaust 2.6 m 0.4 Exhaust m 2.1
Bend 45° Ø 80 Intake 1.2 m 0.2 Intake m 1.4 Exhaust m 0.5
m 0.5
0.7
Exhaust 1.6 m 0.25 Exhaust m 1.3
Pipe Ø 60 m 1 for ducting Exhaust 3.3 m 0.5 Intake 3.8 Exhaust m 1.0 m 1.5
Exhaust 2.7
Bend 90° Ø 60 for ducting Exhaust 3.5 m 0.55 Intake 4.0 Exhaust m 1.1 m 1.6
Exhaust 2.9
Reduction Ø 80/60 Intake and
Exhaust 2.6 m 0.4 Intake m 3.0 Exhaust m 0.8 m 1.2
Exhaust m 2.1
Terminal complete with
exhaust
vertical Ø 60 for ducting
Exhaust 12.2 m 1.9
Intake m 14
Exhaust m 3.7 m 5.8
Exhaust m 10.1

11
1-101-9
1-8
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.11 OUTDOOR INSTALLATION IN A
PARTIALLY PROTECTED AREA.
N.B.: a partially protected location is one in which
the appliance is not exposed to the direct action of
the weather (rain, snow, hail, etc..).
is type of installation is only possible when
permitted by the laws in force in the appliance's
country of destination.
• Conguration type B, open chamber and
forced draught.
Using the special coverage kit one can achieve
direct air intake (Fig. 1-8) and fumes exhaust in
a single ue or directly outside. In this congura-
tion it is possible to install the boiler in a partially
protected place. In this conguration the boiler
is classied as type B23.
With this conguration:
- air intake takes place directly from the envi-
ronment in which the appliance is installed
(outside);
- the fumes exhaust must be connected to its own
single ue (B23) or ducted directly outside via
a vertical terminal for direct exhaust (B53) or
via an Immergas ducting system (B53).
The technical regulations in force must be
respected.
• Coverage kit assembly (Fig. 1-9). Remove
the cap and gasket from the intake hole. Install
the Ø 80 outlet ange on the central hole of the
boiler, taking care to insert the gasket supplied
with the kit and tighten by means of the screws
provided. Place diaphragm Ø 41 on the intake
hole. Install the upper cover, xing it using
the 4 screws present in the kit, positioning the
relevant gaskets. Engage the 90° Ø 80 bend with
the male end (smooth) in the female end (with
lip seal) of the Ø 80 ange unit until it reaches
the end stop. Introduce the gasket, making it
run along the bend. Fix it using the metal-sheet
steel plate and tighten by means of the clip pre-
sent in the kit, making sure to block the 4 gasket
aps. Fit the male end (smooth) of the exhaust
terminal into the the female end of the bend 90°
Ø 80, making sure that the relevant wall sealing
plate is already tted; this will ensure hold and
joining of the elements making up the kit.
Max. length of exhaust duct. e ue pipe (both
vertical or horizontal) can be extended to a max.
length of 30 linear metres.
• Coupling of extension pipes. To install push-
tting extensions with other elements of the
ue, proceed as follows: Couple the pipe or
elbow with the male side (smooth) in the fe-
male side (with lip seal) to the end stop on the
previously installed element. is will ensure
sealing eciency of the coupling.
• Conguration without cover kit in a partially
protected location (type C boiler)
By leaving the side plugs tted it is possible
to install the appliance externally without the
cover kit. Installation takes place using the
Ø60/100 and Ø 80/125 concentric intake/
exhaust kits. Refer to the paragraph on indoor
installation. In this conguration the upper
cover kit assures additional protection for the
boiler. It is recommended but not compulsory.
e cover kit includes:
1 ermoformed cover
1 Ø 41 Intake diaphragm
N°1 Gasket clamping plate
N°1 Gasket
N°1 Gasket tightening strap
e terminal kit includes:
N° 1 Gasket
N° 1 Discharge ange Ø 80
N° 1 Bend 90° Ø 80
N° 1 Drain pipe Ø 80
N° 1 Wall sealing plate

12
1-11 1-12
1-13
C13
1-14
5
4
3
1
2
1
2
3
45
6
C13
C13
C13
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.12 CONCENTRIC HORIZONTAL KIT
INSTALLATION.
Type C configuration, sealed chamber and
fan assisted.
e position of the terminal (in terms of dis-
tances from openings, overlooking buildings,
floor, etc.) must be in compliance with the
regulations in force.
is terminal is connected directly to the outside
of the building for air intake and ue exhaust. e
horizontal kit can be installed with the rear, right
side, le side or front outlet. For installation with
frontal outlet, one must use the xing plate and
a concentric bend coupling in order to ensure
sucient space to carry out the tests required
by law upon commissioning.
• External grid. Both the Ø 60/100 and Ø 80/125
intake/exhaust terminal, if properly installed, is
pleasant to look at on the outside of the build-
ing. Make sure that the external silicone wall
sealing plate is properly inserted in the wall.
N.B.: for proper system operation the terminal
with grid must be installed correctly ensuring
that, the "high" indication on the terminal is
observed during installation.
Horizontal intake-exhaust kit Ø 60/100 Kit
assembly (Fig. 1-11): install the bend with ange
(2) on the central hole of the boiler, positioning
gasket (1) with the circular projections down-
wards in contact with the boiler flange, and
tighten using the screws present in the kit. Fit
the Ø 60/100 (3) concentric terminal pipe with
the male side (smooth) to the female side of the
bend (2) up to the end stop; making sure that the
internal and external wall sealing plate have been
tted, this will ensure sealing and joining of the
elements making up the kit.
• Extensions for Ø 60/100 horizontal kit (Fig.
1-12). e kit with this conguration can be
extended up to a max. 12.9 horizontal m in-
cluding the terminal with grid and excluding
the concentric bend leaving the boiler. is
conguration corresponds to a resistance factor
of 100. In this case the special extensions must
be requested.
Immergas also provides a Ø 60/100 simplied
terminal, which in combination with its exten-
sion kits allows you to reach a maximum exten-
sion of 11.9 metres.
Horizontal intake-exhaust kit Ø 80/125 Kit
assembly (Fig. 1-13): to install the kit Ø 80/125
one must use the anged adapter kit in order
to install the ue system Ø 80/125. Install the
anged adaptor (2) on the central hole of the
boiler, positioning gasket (1) with the circular
projections downwards in contact with the boiler
ange, and tighten using the screws contained in
the kit. Engage the bend (3) with the male side
(smooth) to the end stop on the adapter (1). Fit
the Ø 80/125 (5) concentric terminal pipe with
the male side (smooth) to the female side of the
bend (4) (with lip seals) up to the end top; making
sure that the internal (6) and external wall sealing
plate (7) have been tted, this will ensure sealing
and joining of the elements making up the kit.
• Extensions for horizontal kit Ø 80/125 (Fig.
1-14). e kit with this conguration can be
extended up to a max. length of 32 m, includ-
ing the terminal with grid and excluding the
concentric bend leaving the boiler. If addi-
tional components are assembled, the length
equivalent to the maximum allowed must be
subtracted. In this case the special extensions
must be requested.
e kit includes:
N° 1 - Gasket (1)
N° 1 - Concentric bend Ø 60/100 (2)
N° 1 - Int./exhaust concentric terminal Ø 60/100 (3)
N° 1 - Internal wall sealing plate (4)
N° 1 - External wall sealing plate (5)
e adaptor kit includes:
N° 1 - Gasket (1)
N° 1 - Adaptor Ø 80/125 (2)
e Kit Ø 80/125 includes:
N° 1 - Concentric bend Ø
80/125 a 87° (3)
N° 1 - Int./exhaust concentric
terminal Ø 80/125 (4)
N° 1 - Internal wall sealing
plate (5)
N° 1 - External wall sealing
plate (6)
e remaining kit components
must not be used
Max 12900 mm
Max 12790 mm
Max 32000 mm
Max 31956 mm

13
C33
C33
C33
C33
1-16
1-181-17
7
46
5
1
2
3
1
2
3
4
5
6
7
1-15
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.13 CONCENTRIC VERTICAL KIT
INSTALLATION.
Type C configuration, sealed chamber and
fan assisted.
Concentric vertical intake and exhaust kit. is
vertical terminal is connected directly to the out-
side of the building for air intake and ue exhaust.
N.B.: the vertical kit with aluminium tile enables
installation on terraces and roofs with a maxi-
mum slope of 45% (approx 25°) and the height
between the terminal cap and half-shell (374 mm
for Ø 60/100 and 260 mm for Ø 80/125) must
always be observed.
Vertical kit with aluminium tile Ø 60/100.
Kit assembly (Fig. 1-15): install the concentric
ange (2) on the central hole of the boiler, posi-
tioning gasket (1) with the circular projections
downwards in contact with the boiler ange, and
tighten using the screws contained in the kit.
Installation of the fake aluminium tile: replace
the tiles with the aluminium sheet (4), shaping
it to ensure that rainwater runs o. Position
the xed half-shell (6) on the aluminium tile
and insert the intake-exhaust pipe (5). Fit the
Ø 60/100 (3) concentric terminal pipe with the
male side (5) (smooth) into the ange (2) up to
the end stop; making sure that the wall sealing
plate has been tted (3), this will ensure sealing
and joining of the elements making up the kit.
Note: when the boiler is installed in areas where
very cold temperatures may be reached, a special
anti-icing kit is available that may be installed as
an alternative to the standard kit.
• Extensions for vertical kit Ø 60/100 (Fig. 1-16).
e kit with this conguration can be extended
to a max. straight vertical length of 14.4 m,
including the terminal. This configuration
corresponds to a resistance factor of 100. In
this case specic extensions must be requested.
Vertical kit with aluminium tile Ø 80/125.
Kit assembly (Fig. 1-17): to install the kit Ø
80/125 one must use the anged adapter kit in
order to install the ue system Ø 80/125. Install
the anged adaptor (2) on the central hole of the
boiler, positioning gasket (1) with the circular
projections downwards in contact with the boiler
ange and tighten using the screws contained
in the kit. Installation of the fake aluminium
tile: replace the tiles with the aluminium sheet
(4), shaping it to ensure that rainwater runs o.
Position the xed half-shell (5) on the aluminium
tile and insert the intake-exhaust pipe (7). Fit the
Ø 80/125 concentric terminal pipe with the male
side (smooth) to the female side of the adapter (1)
(with lip gaskets) up to the end stop; making sure
that the wall sealing plate (3) has been tted, this
will ensure sealing and joining of the elements
making up the kit.
• Extensions for vertical kit Ø 80/125 (Fig. 1-18).
e kit with this conguration can be extended
up to a max. length of 32 m including the ter-
minal. If additional components are assembled,
the length equivalent to the maximum allowed
must be subtracted. In this case specic exten-
sions must be requested.
e Kit includes:
N° 1 - Gasket (1)
N° 1 - Female concentric ange (2)
N° 1 - Wall sealing plate (3)
N° 1 - Aluminium tile (4)
N° 1 - Int./exhaust concentric pipe Ø
60/100 (5)
N° 1 - Fixed half-shell (6)
N° 1 - Mobile half-shell (7)
e adaptor kit includes:
N° 1 - Gasket (1)
N° 1 - Adaptor Ø 80/125 (2)
e Kit Ø 80/125 includes:
N° 1 - Wall sealing plate (3)
N° 1 - Aluminium tile (4)
N° 1 - Fixed half-shell (5)
N° 1 - Mobile half-shell (6)
N° 1 - Int./exhaust concentric
pipe Ø 80/125 (7)
e remaining kit components
must not be used
MAX LENGTH 14400 mmMax 32000 mm
Max 45%
Max 45%

14
C83
1-21
C43
1-201-19
1
4
79
556
7
8
3
2
S
A
C53* - C83
INSTALLERUSER
MAINTENANCE TECHNICIAN
e kit includes:
N° 1 - Exhaust gasket (1)
N° 1 - Flange seal gasket (2)
N° 1 - Female intake ange (3)
N° 1 - Female drain ange (4)
N° 2 - Bend 90° Ø 80 (5)
N° 1 - Intake terminal Ø 80 (6)
N° 2 - Internal wall sealing plates (7)
N° 1 - External wall sealing plate (8)
N° 1 - Drain pipe Ø 80 (9)
* to er complete C53 conguration also provide for a roof discharge termi-
nal.
1.14 SEPARATOR KIT INSTALLATION.
Type C configuration, sealed chamber and
fan assisted.
Separator kit Ø 80/80. is kit allows air to come
in from outside the building and the fumes to exit
from the chimney or ue through divided ue
exhaust and air intake pipes. Combustion prod-
ucts are expelled from pipe (S) (in plastic, so as
to resist acid condensate). Air is taken in through
duct (A) for combustion (this is also in plastic).
e intake pipe (A) can be installed either on the
right or le hand side of the central exhaust pipe
(S). Both ducts can be routed in any direction.
• Kit assembly (Fig. 1-19): install ange (4) on
the central hole of the boiler, positioning gasket
(1) with the circular projections downwards
in contact with the boiler ange, and tighten
using the hex screws with at tip contained in
the kit. Remove the at ange present in the
lateral hole with respect to the central one (ac-
cording to needs) and replace it with the ange
(3), positioning the gasket (2) already present in
the boiler and tighten using the supplied self-
threading screws. Fit the male end (smooth) to
the bends (5) in the female end of the anges
(3 and 4). Fit the intake terminal (6) with the
male side (smooth) in the female side of the
bend (5) up to the end stop, ensuring that the
internal and external wall sealing plates are
tted. Fit the exhaust pipe (9) with the male
side (smooth) to the female side of the bend
(5) up to the end stop; making sure that the
internal wall sealing plate has been tted, this
will ensure sealing and joining of the elements
making up the kit.
• Installation clearances (Fig. 1-20). e mini-
mum installation clearance measurements of
the Ø 80/80 separator terminal kit have been
stated in some limit conditions.
• Extensions for separator kit Ø 80/80. The
maximum vertical straight length (without
bends) that can be used for Ø 80 intake and
exhaust pipes is 41 metres, regardless from
whether they are used for intake or exhaust.
e maximum horizontal straight length (with
bend in suction and in exhaust) that can be
used for Ø 80 intake and exhaust pipes is 36
metres, regardless from whether they are used
for intake or exhaust.
N.B.: to favour the removal of possible conden-
sate forming in the exhaust pipe, tilt the pipes
towards the boiler with a minimum slope of
1.5% (Fig. 1-21).
minimum slope 1.5%

15
12
3
3
3
4567
689
A
10
11
12
12
1-23
1-22
A
B
A
C
INSTALLERUSER
MAINTENANCE TECHNICIAN
Kit composition:
Ref. Qty Description
1 1 Door adaptor Ø 100 or Ø 125
2 1 Door gasket made of neoprene
3 4 Screws 4.2 x 9 AF
4 1 Hex headed screw M6 x 20
5 1 Flat nylon washer M6
6 2 Door hole closure metal-sheet plate
plug
7 1 Plug gasket made of neoprene
8 1 Toothed washer M6
9 1 Nut M6
10 1 (kit 80/125) Concentric gasket Ø 60-100
11 1 (kit 80/125) Flanged adapter Ø 80-125)
12 4 (kit 80/125) Hex headed screws M4 x 16 slotted
- 1 (kit 80/125) Bag of lubricating talc
Installation drawings key:
Unique identication of the component in
the kit
Identication of the component not supplied
in this kit
1
A
Supplied separately:
Ref. Qty Description
A 1 Ducting kit door
Rigid Ø 80
ducting (A)
mm
SHAFT
(B) mm
SHAFT
(C) mm
86 126 146
Flexible Ø 80
ducting (A)
mm
SHAFT
(B) mm
SHAFT
(C) mm
90 130 150
Rigid Ø 60
ducting (A)
mm
SHAFT
(B) mm
SHAFT
(C) mm
66 106 126
1.15 ADAPTOR C9 KIT INSTALLATION.
is kit allows an Immergas boiler to be installed
in "C93" conguration, with combustion air intake
directly from the sha where the ue gas exhaust is,
obtained by means of a ducting system.
System composition.
e system must be combined with the following
components (sold separately) to be functional and
complete:
- kit C93 Ø 100 or Ø125 version
- ducting kit Ø 60 or Ø 80
- fumes exhaust kit Ø 60/100 or Ø 80/125 congured
according to the installation and type of boiler.
Kit Assembly.
- Mount the components of kit "C9" on the door (A)
of the ducting system (Fig. 1-23).
- (Version Ø 125 only) mount the anged adaptor
(11) interposing the concentric gasket (10) on the
boiler, tting it with the screws (12).
- Mount the ducting system as described in the rela-
tive instructions sheet.
- Calculate the distances between the boiler drain and
the bend of the ducting system.
- Prepare the boiler ue system, making sure that the
internal pipe of the concentric kit is tted properly
in the bend of the ducting system (quota "X" g.
1-25), while the external pipe must be tted on the
adaptor until it stops (1).
N.B.: to encourage the removal of possible con-
densate forming in the exhaust pipe, tilt the pipes
towards the boiler with a minimum slope of 1.5%.
- Mount the cover (A) complete with adaptor (1) and
caps (6) on the wall and assemble the ue system to
the ducting system.
N.B.: (version Ø 125 only) before assembly
check the gaskets are in the right position. In
the event component lubrication (already car-
ried out by the manufacturer) is not sucient,
remove the residual lubricant using a dry cloth,
then to ease tting coat the parts with common
or industrial talc.
Once all components have been assembled prop-
erly, the exhaust fumes will be expelled via the
ducting system; the combustion air for normal
boiler operation will be aspirated directly by the
sha (Fig. 1-24).
Technical data.
- e dimensions of the shas must ensure a
minimum gap between the outer wall of the
smoke duct and the inner wall of the sha: 30
mm for circular section shas and 20 mm in
the event of a square section sha (Fig. 1-22).
- Maximum 2 changes of direction are allowed
on the vertical section of the ue system with
a maximum clearance angle of 30° with respect
to the vertical.
- e maximum vertical extension using a Ø 60
ducting system is 13 m, the maximum exten-
sion includes 1 bend Ø 60/10 at 90°, 1 m of
horizontal pipe 60/100, 1 90° ducted bend Ø
60 and the roof terminal for ducting.
To determine the C93 ue system in congura-
tions other than that described (Fig. 1-24)
one must consider that 1 metre of ducted pipe
according to the indications described has a
resistance factor equal to 4.9.
- e maximum vertical extension using a Ø 80
ducting system is 28 m, the maximum exten-
sion includes 1 adapter 60/100 to 80/125, 1 87°
bend Ø 80/125, 1 m of horizontal pipe 80/125,
1 90° ducted bend Ø 80 and the roof terminal
for ducting.
To determine the C93 ue system in congura-
tions other than that described (Fig. 1-24) one
must consider the following pressure drops:
- 1 m of concentric pipe Ø 80/125 = 1 m of
ducted pipe;
- 1 87° bend = 1.4 m of ducted pipe;
Consequently one must subtract the equivalent
length of the part added to the 28 m available.

16
1-25
C53
X
C93
1-24
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.16 DUCTING OF FLUES OR
TECHNICAL SLOTS.
Ducting is an operation through which, via
the introduction of one or more relevant pipes,
one achieves a system for the evacuation of the
combustion products of a gas appliance, made up
from the coupling of an existing or new ducting
pipe with a chimney, ue or technical slot (also
in new buildings) (Fig. 1-25). Ducting requires
ducts declared to be suitable for the purpose by
the manufacturer, following the installation and
user instructions, provided by the manufacturer
and the requirements of the standards in force.
Immergas ducting system. e Ø 60 rigid and Ø
80 exible “Green Range” ducting systems must
only be used for domestic use and with Immergas
condensing boilers.
In any case, ducting operations must respect
the provisions contained in the standard and in
current technical regulations; in particular, the
declaration of conformity must be compiled at
the end of work and on commissioning of the
ducted system. e instructions in the project
or technical report must likewise be followed, in
cases provided for by the standard and current
technical regulations. e system or components
of the system have a technical life complying with
current standards, provided that:
- it is used in average atmospheric and environ-
mental conditions, according to current regula-
tions (absence of fumes, dusts or gases that can
alter the normal thermophysical or chemical
conditions; existence of temperatures coming
within the standard range of daily variation,
etc.).
- Installation and maintenance must be per-
formed according to the indications supplied
by the manufacturer and in compliance with
the provisions in force.
- e max. possible length of the Ø 60 exible
ducting vertical section is equal to 22 m. is
length is obtained considering the complete
Ø 80 exhaust terminal, 1m of Ø 80 pipe in
exhaust, two 90° Ø 80 bends at boiler outlet.
- e max. possible length of the Ø 80 exible
ducting vertical section is equal to 30 m. is
length is obtained considering the complete
exhaust terminal, 1m of Ø 80 pipe in exhaust,
two 90° Ø 80 bends at boiler outlet for connect-
ing to the ducting system and two direction
changes of the exible hose inside the chimney/
technical slot.
- e maximum possible length of the Ø 80 rigid
ducting vertical section is equal to 30 m. is
length is obtained considering the complete
Ø 80 exhaust terminal, 1m of Ø 80 pipe in ex-
haust, two 90° Ø 80 bends on the boiler outlet.
1.17 CONFIGURATION TYPE B, OPEN
CHAMBER AND FAN ASSISTED FOR
INDOORS.
e appliance can be installed inside buildings
in 23 or B53 mode; in this case, all technical rules
and national and local regulations in force, must
be complied with.
- type B open chamber boilers must not be
installed in places where commercial, artisan
or industrial activities take place, which use
products that may develop volatile vapours
or substances (e.g. acid vapours, glues, paints,
solvents, combustibles, etc.), as well as dusts
(e.g. dust deriving from the working of wood,
coal nes, cement, etc.), which may be harm-
ful for the components of the appliance and
jeopardise operation.
- in B23 and B53 conguration, the boilers must
not be installed in bedrooms, bathrooms or in
studio ats.
- e installation of appliances in B23 and B53 con-
gurations are only recommended outdoors (in
a partially-protected place) or in places that
are not lived in and which are permanently
ventilated.
For installation the cover kit must be used, re-
ferred to in paragraph 1.11.
1.18 FLUE GAS EXHAUST TO FLUE/
CHIMNEY.
Flue exhaust does not necessarily have to be
connected to a branched type traditional ue.
e ue exhaust, for boiler clots installed in C
configuration, can be connected to a special
LAS type multiple ue. For B23 congurations,
exhaust is only allowed into individual chimney
or directly into the external atmosphere via a
relevant terminal. e multiple ues and the
combined ues must also only be connected to
type C appliances of the same type (condensing),
having nominal heat inputs that do not dier by
more than 30% less with respect to the maximum
that can be attached and powered by the same
fuel. e thermo-uid dynamic features (ue
ow rate, % of carbon dioxide, % humidity etc....)
of the appliances attached to the same multiple
ues or combined ues, must not dier by more
than 10% with respect to the average boiler at-
tached. Multiple and combined ues must be
specially designed according to the calculation
method and requirements of the standards, by
professionally qualied technical sta. Chimney
or ue sections for connection of the exhaust
pipe must comply with requisites of technical
standards in force.

17
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.19 FLUES, CHIMNEYS, CHIMNEY POTS
AND TERMINALS.
e ues, chimneys and chimney pots for the
evacuation of combustion products must be in
compliance with applicable standards. Chimneys
and roof-installed exhaust terminals must com-
ply with the outlet height and with the distance
from technical volumes set forth by the technical
standards in force.
Positioning the wall ue exhaust terminals. e
wall ue exhaust terminals must:
- be installed on external perimeter walls of the
building;
- be positioned according to the minimum dis-
tances specied in current technical standards.
Combustion products exhaust of natural
draught or fan assisted appliances in open-top
closed environments. In spaces closed on all
sides with open tops (ventilation pits, court-
yards etc.), direct combustion product exhaust
is allowed for natural draught or fan assisted gas
appliances with a heat input range from 4 to 35
kW, provided the conditions as per the current
technical standards are respected.
1.20 SYSTEM FILLING.
Once the boiler is connected, proceed with sys-
tem lling via the lling valve (Fig. 2-2). Filling
is performed at low speed to ensure release of air
bubbles in the water via the boiler and central
heating system vents.
e pump may be noisy on start-up due to the
presence of air. is noise should stop aer a
few minutes of functioning and however aer
having correctly bled the air contained in the
hydraulic circuit.
e boiler has a built-in automatic venting valve
on the boiler circulator. Check if the cap is loose.
Open the radiator vent valves.
Close radiator vent valves when only water
escapes from them.
Close the lling cock when the boiler pressure
gauge indicates approx. 1.2 bar.
N.B.: during these operations, turn on the circu-
lating pump at intervals using the main switch
on the control panel. Vent the circulation pump
by loosening the front cap and keeping the motor
running and assuring that the liquid that escapes
cannot cause injury/damage to persons/objects.
Tighten the cap aer the operation.
1.21 CONDENSATE TRAP FILLING.
On rst lighting of the boiler, ue gas may come
out the condensate drain; aer a few minutes’
operation check that this no longer occurs. is
means that the drain trap is lled with conden-
sate to the correct level preventing the passage
of ue gas.
1.22 GAS SYSTEM STARTUP.
To start up the system, refer to the technical
standard in force: is divides the systems and
therefore the start-up operations into three
categories: new systems, modied systems, re-
activated systems.
In particular, for new gas systems:
- open windows and doors;
- avoid presence of sparks or open ames;
- bleed all air from the pipelines;
- check that the internal system is properly sealed
according to the specications set forth by
technical regulations in force.
1.23 BOILER START UP IGNITION.
In order to issue the Declaration of Conformity
required by the laws in force, one must full
the following requirements to commission the
boiler (the operations listed below must only
be performed by qualied personnel and in the
presence of professionals only):
- ensure the internal system is properly sealed
according to the specications set forth by
regulations in force;
- make sure that the type of gas used corresponds
to boiler settings;
- Check that there are external factors that may
cause the formation of fuel pockets;
- switch the boiler on and check correct ignition;
- make sure that the gas ow rate and relevant
pressure values comply with those given in the
manual (Par. 3.22);
- ensure that the safety device intervenes in the
event of gas supply failure and check the relative
intervention time;
- check the intervention of the main switch
located upstream from the boiler and in the
boiler;
- check that the intake/exhaust concentric
terminal (if tted) is not blocked.
e boiler must not be started up even if only
one of the checks should be negative.
N.B.: only upon completing commissioning by
an installer, may an authorised rm carry out an
initial inspection of the boiler, which is required to
activate the Immergas warranty. e test certicate
and warranty is issued to the user.
1.24 DOMESTIC HOT WATER STORAGE
TANK UNIT.
e Victrix Zeus 26 2 ErP storage tank unit has
a capacity of 45 litres. It contains a large coiled
stainless steel heat exchanger pipe, which allows
to notably reduce hot water production times.
ese storage tank units constructed with stain-
less steel casing and bottoms, guarantee long
duration through time. e assembly concepts
and welding (T.I.G.) are implemented to the
minimum detail to ensure maximum reliability.
e lower inspection ange ensures practical
control of the storage tank unit and the coiled
heat exchanger pipe and easy internal cleaning.
e domestic hot water connections are placed
on the ange cover (cold inlet and hot outlet)
along with the Magnesium Anode support cap
including the same, supplied as standard for
internal protection of the storage tank unit from
possible corrosion.
N.B.: have the eciency of the storage tank Mag-
nesium Anode checked annually by a qualied
rm. e storage tank unit is prepared for intro-
duction of the domestic hot water pump tting.
1.25 KITS AVAILABLE ON REQUEST.
• System shut-off valve kits with or without
inspection lter (on request). e boiler is
designed for installation of system interception
cocks to be placed on ow and return pipes
of the connection assembly. is kit is very
useful for maintenance because it allows to
empty just the boiler without having to empty
the entire system. Moreover, the version with
lter preserves the functioning characteristics
of the boiler thanks to its inspectionable lter.
• System zone control unit kit (on request). If
the heating system is to be divided into several
zones (max. three), in order to interlock them
with separate adjustments and to keep water
ow rate high for each zone, Immergas supplies
zone system kits by request.
• Polyphosphate dispenser kit (on request). e
polyphosphate dispenser reduces the forma-
tion of lime-scale and preserves the original
heat exchange and domestic hot water pro-
duction conditions. e boiler is prepared for
application of the polyphosphate dispenser kit.
• P.C.B. to a relay (on request) e boiler is pre-
pared for the installation of a P.C.B. to a relay,
which allows to control the main zone using
the CAR (optional).
• Cover kit (on request). If installed outdoors in a
partially protected place with direct air intake,it
is compulsory to mount the appropriate top
protection cover for the correct functioning
of the boiler and to protect it from adverse
weather conditions.
• Recirculation kit (on request). e boiler stor-
age tank unit is prepared for application of the
pump kit. Immergas supplies a set of ttings
and attachments to connect the storage tank to
the domestic hot water system. e pump kit
attachment is also envisioned on the template.
e above-mentioned kits are supplied complete
with instructions for assembly and use.

18
1-26
1-27
INSTALLERUSER
MAINTENANCE TECHNICIAN
1.26 CIRCULATION PUMP.
e boiler is supplied with circulator tted with
speed regulator.
ese settings are suitable for most systems.
In fact, the pump is equipped with electronic
control to set advanced functions. For proper op-
eration one must select the most suitable type of
operation for the system and select a speed in the
available range, with a focus on energy savings.
By-pass Regulation (part. 30 Fig. 1-29). e
boiler is supplied with by-pass closed by 1.5 turns
with respect to all open.
If necessary, the by-pass can be regulated to
system requirements from minimum (by-pass
closed) to maximum (by-pass open). Adjust
using a at head screwdriver, turn clockwise to
close the by-pass; turn anti-clockwise to open it.
Display of operation status. During normal
operation the status LED (2) is on green, the four
yellow LEDs (3) indicate circulator absorption
according to the following table:
Circulating pump LED Absorption
G Y Y Y Y
On On O O O
0 ÷ 25 %
G Y Y Y Y
On On On O O
25 ÷ 50 %
G Y Y Y Y
On On On On O
50 ÷ 75 %
G Y Y Y Y
On On On On On
75 ÷ 100 %
Selection of operating mode. To see the current
operation mode it is sucient to press button
(1) once.
To change operation mode press the button
for between 2 to 10 seconds until the current
conguration ashing, each time the button is
pressed all possible functions are scrolled cycli-
cally. Aer a few seconds without doing any
operation the circulator memorises the selected
mode and goes back to operation display.
Attention: e circulator has various built-in
operation modes, however the constant curve
operation mode must be selected according to
the following table.
Circulating pump LED Description
G Y Y Y Y
On On On O O
Do not use
G Y Y Y Y
On On On On O
Constant curve
speed 2
G Y Y Y Y
On On On On On
Constant curve
speed 3 (default)
G Y Y Y Y
On On On O On
Constant curve
speed 4
Constant curve: the circulator operates maintain-
ing constant speed.
Selection button lock. e button has a feature
that locks its operation to prevent accidental
modications, to lock the control panel it is
necessary to press button (1) longer than 10
seconds (during which the current conguration
ashes), the active lock is signalled by all LEDs of
the control panel ashing. To unlock the button
press again longer than 10 seconds.
Real time diagnostics: in the event of mal-
function the LEDs provide information on the
circulator operation status, see table (Fig. 1-27):
Circulating pump LED
(rst red LED) Description Diagnostics Remedy
R Y Y Y Y
On O O O On
Circulator pump blocked The circulator pump cannot restart
automatically due to an anomaly
Wait for the circulator to make auto-
matic release attempts or manually
release the motor sha acting on the
screw in the centre of the head.
If the anomaly persists replace the
circulator.
R Y Y Y Y
On O O On O
Abnormal situation (the circulator
continues operating).
low power supply voltage
Voltage o range Check power supply
R Y Y Y Y
On O On O O
Electrical fault
(Circulator pump blocked)
e circulator is locked due to power
supply too low or serious malfunction
Check the power supply, if the anomaly
persists replace the circulator
Key:
1 - Function selection button
2 - Green (G) / red (R) LED
3 - 4 yellow LEDs (Y)

19
1-28
V4
A4
A3
A2 V3
V2
INSTALLERUSER
MAINTENANCE TECHNICIAN
Head available to the system.
Key:
Vn = Available head
An = Circulating pump absorbed power
Circulator pump absorbed power (W)
Flow rate (l/h)
Head (kPa)

20
1-29
INSTALLERUSER
MAINTENANCE TECHNICIAN
Key:
1 - System lling valve
2 - Condensate drain trap
3 - Gas valve
4 - 3-way valve (motorised)
5 - 3 bar safety valve
6 - System pressure switch
7 - Boiler circulator pump
8 - Vent valve
9 - Fan
10 - Gas nozzle
11 - Venturi
12 - Detection electrode
13 - Condensation module
14 - Air intake pipe
15 - Flue safety thermofuse
16 - Sample points (air A) - (ue gas F)
17 - Negative signal pressure point
18 - Burner
19 - Positive signal pressure point
20 - Manual air vent valve
21 - Ignition electrode
22 - System expansion vessel
23 - Flow probe
24 - Safety thermostat
25 - Control panel.
26 - Domestic hot water probe
27 - Stainless steel storage tank
28 - 8 bar safety valve
29 - Adjustable by-pass
30 - orage tank unit draining valve
31 - System draining valve
N.B.: Connection group (Optional).
1.27 BOILER COMPONENTS.
