Impecca HSB120 User manual

Bluetooth Stereo Headphones
with built-in MP3 Player
Model No: HSB120
Operating Instructions

2
Read the following notices and information carefully
to ensure proper operation of your Bluetooth® Stereo
Headphones.
This manual is solely provided for informational
purposes and in no way constitutes a legally binding
document between the manufacturer, distributor, and
consumer.
INTRODUCTION:
Congratulations on your purchase of the Impecca
Bluetooth® Stereo Headphones (HSB120). Before using
your speaker system, please read through this manual.
This manual will help you use many of the exciting and
useful features of your new unit.
WARNING
PLEASE READ THIS MANUAL CAREFULLY BEFORE
OPERATING AND RESERVE IT FOR FUTURE
REFERENCE. IT WILL BE HELPFUL TO YOU IF YOU
ENCOUNTER ANY OPERATING PROBLEMS.

3
WARNING: To reduce the risk of electric shock, do not
disassemble the unit. There are no user-serviceable
parts inside. Contact technical support for further
assistance.
WARNING: To prevent fire or electric shock hazard, do
not expose the unit to rain or moisture.
Do not expose the adapter and Bluetooth® Stereo
Headphones to any water (including drips or splashes).
Objects filled with liquids, such as vases and water
bottles, should not be placed on or near the unit.
Keep the Bluetooth® Stereo Headphones away from
direct sunlight and heat sources such as radiators or
stoves.
Do not place the Bluetooth® Stereo Headphones on an
unstable table, stand, tripod, bracket or cart. The unit
may fall, resulting in possible damage or injury.
Dispose of this unit properly respecting your local laws
for electronics and battery disposal.
CAUTION: Danger of explosion if battery is incorrectly
replaced. Internal battery is sealed and not intended to
be replaced by consumer.
WARNING: The battery shall not be exposed to
excessive heat such as sunlight, fire or any other heat
source.
WARNING: Only use attachments/accessories provided
by the manufacturer.

4
European Union Electronic Waste Disposal
Guidelines:
This symbol means that used electrical and electronic products should not
be mixed with general household waste. For proper treatment, recovery and
recycling, please take this product(s) to designated collection points where it
will be accepted free of charge. Alternatively, in some countries you may be
able to return your products to your local retailer upon purchase of an
equivalent new product. Disposing of this product correctly will help save
valuable resources and prevent any potential negative effects on human
health and the environment, which could otherwise arise from
inappropriate waste handling. Please contact your local authority for further
details of your nearest designated collection point. Penalties may be
applicable for incorrect disposal of this waste, in accordance with you
national legislation.
Package Contents
Bluetooth® Stereo Headphones
USB (Type-A) to mini-USB
3.5mm (1/8”) male-to-male audio
cable (1.2 meter length)
User’s manual

5
Buttons and Ports Description
Right-Side ear cup and unit control panel
Play/Pause
/Mode
Previous
Track
-
Volume
down
Next Track
+
Volume Up

6
Features
1) Uses Bluetooth® for music streaming from
your smartphone, tablet or other
Bluetooth® compatible music source.
2) Built-in MP3 player can play music directly
from a microSD card (supports SDHC
cards)
3) Standard 3.5mm (1/8”) connection cable
allows you to use these headphones as
wired headphones for devices that don’t
have Bluetooth® compatibility.
4) Built-in rechargeable Li-ion battery allows
for completely cord-free operation.
5) Ability to control source unit from the
speaker system –Play, Pause, Previous
track, Next track, etc. Note: This works when
using Bluetooth ® and microSD MP3 files, but
not when using the wired connection cord to an
analog music source.

7
Getting Started and Bluetooth® Pairing
1) Charge your unit by plugging the
(included) mini-USB end of the
connection cable into the back of the unit
and USB-A end of the cable into a
computer or powered USB wall adapter
(not included).
2) While charging, you will see a red LED
shining through the small hole beneath
the logo on the right-side ear cup.
When finished, the LED should go out.
3) To power on unit, slide rocker switch on
the rim of the right-side ear cup from
“OFF” to “ON.”
4) Your HSB120 supports two different
modes. Bluetooth mode and microSD
mode. When entering Bluetooth mode,
you will hear a three-tone sound. When
entering microSD mode, you will hear a
steady tone. To switch between Bluetooth

8
and microSD modes, hold down the mode
( ) button for 2-3 seconds.
Pairing Bluetooth®
1. When in “Bluetooth® Mode”there should
be a blue LED flashing quickly. This shows
that the unit is in pairing mode.
2. On your source device (phone, MP3
player, tablet), start a “search for devices”
in your “Bluetooth” menu. The exact
method varies from device to device.
3. After a few moments, you should see a
device labeled “HSB120” in the list of
found devices. This is the device you
should select.
4. You should hear a two-tone sound from
the headphones (if you’re wearing them)
if the connection is successful. At this
point the blue LED should be steadily lit
(not blinking) as long as your device is
connected.
5. If your device moves sufficiently out of
range, or Bluetooth® is turned off, the

9
headphones will emit a different three-
tone sound and the blue LED will begin to
flash rapidly. Moving back into range
should yield a two-tone sound again and
reconnect to your source device
automatically.
6. Note: Once you have paired to a
particular device, you should not have to
pair again, unless the device lost the
settings. Upon powering on in the future
(or switching back to Bluetooth® from
“microSD card mode,” you will hear the
three tone sound. However, after about
five seconds, you should hear a two-tone
sound, informing you that the devices are
connected. If you do not hear this sound,
simply select the HSB120 from the
Bluetooth menu of your device.
Playing Music
1) To play music using a Bluetooth® device,
first make sure you have paired your

10
Bluetooth® compatible device with the
HSB120 Bluetooth® headphones (see
directions above). If not already in
Bluetooth® Mode, choose it by holding
down the mode ( ) button for a few
seconds until you hear the three-tone
sound. Then, on your device, begin
playing whatever song you like as if you
were listeing to it direclty on your device
(or via wired headphones). The music
should play through the HSB120
headphones.
2) To play music from microSD card, simply
insert a card containing MP3 music into
the slot embedded into the right ear cup
(see picture on page 3). You will hear a
breif tone. (See Controlling Music
Playback below for more details.)
3) To play music from a wired connection
(known as “line-in mode”), simply connect
the included 3.5mm cord from the jack on
the bottom of your right ear cup to the

11
output jack of your source music device.
You do not need to switch any mode.
Controlling Music Playback
For the line-in mode, you must control the
music playback from your device. You can hold
down buttons buttons (-)or (+) to adjust the
volume.
For all other modes, you can also control the
song selection and volume from the buttons on
the right side of the headphones. Use buttons
and to jump to previous and next
songs, respectively. Hold down buttons (-)or
(+) to adjust the volume. Use the Play/Pause
button ( ) to temporarily pause the song
being played. Note: The volume control on
your device will also impact the volume coming
out of the speaker. For the highest quality
sound, set the volume on your source device to
a moderate level (not as loud as it gets).

12
Phone calls
This pair of headphones contains a built-in
microphone and also operates as a Bluetooth ®
headset for your smartphone when in
Bluetooth® mode. If a call comes in while
listening to music, you will hear a ring through
the headphones. Press the Play/Pause button (
) button to pick up the call. You can also pick
up the call as usual on your phone. Speak
normally. To end the call, end the call as usual
on your phone or press the Play/Pause button (
) button again.
Technical Specifications
Output Power:
2.5mW
Battery: built-in
Li-ion (400mAh
3.7V)
Audio: monaural
SNR: 117±3
External Audio
Frequency
Response: 20Hz-
20KHz
Charging: Via DC
5V 500mA –1A
input
Speaker: 32Ω
Bluetooth®

13
input: standard
3.5mm stereo
plug to mini-USB
range: up to
15M (barrier-
free)
Troubleshooting
Q: Why won’t my HSB120 power on?
A: Ensure that the unit has been fully charged,
by hooking up the provided mini-USB to USB-A
connector to a computer or USB wall power
adapter (not included).
Q: Why does it take so long for my device to
charge fully?
A: It should not take more than a few hours.
The red LED should extinguish after the unit is
fully charged. Note that the length of time to
fully charge depends on the power amperage
of your USB charging adapter. Most computers
output 500mA. Some adapters range from as
low as 200mA to as high as 2500mA. Charging
time will vary greatly depending on what

14
adapter is used. For best results, purchase an
Impecca USB210 wall adapter.
Q: How come I can’t get my music device to
play through Bluetooth®?
A: Follow instructions in the “Getting Started
and Bluetooth® Pairing” section above. If you
cannot pair, make sure that the blue light is
flashing rapidly. If it is steady, you may be in a
different mode. Hold down the Play/Pause
button ( ) button for 2-3 seconds until you
hear a three-tone sound.
Q: How come my HSB120 won’t keep a charge
for long anymore? It has worked fine for a
long time.
A: All rechargeable batteries eventually get
weaker with many charges. Your battery is
built-in and not user-replaceable.

15
Technical support
For questions not answered in this manual, or
for warranty service, please contact Impecca
Technical Support:
By phone: [phone] (9:00 AM to 6:00 PM
Eastern Time)
By e-mail: [e-mail]
Online: www.impecca.com
©2014 Impecca. Bluetooth® is a registered
trademark of Bluetooth® SIG, Inc.

16
Auriculares Estéreo Bluetooth
Con reproductor MP3 integrado
Modelo No: HSB120
Instrucciones de Operación

17
Lea cuidadosamente las siguientes instrucciones e
información para asegurar la adecuada operación de
sus Auriculares Estéreo Bluetooth®.
Este manual se proporciona únicamente con propósito
informativo y de ninguna manera constituye un
documento jurídicamente vinculante entre el
fabricante, distribuidor y consumidor.
INTRODUCCIÓN:
Felicidades por su compra de sus Auriculares Estéreo
Bluetooth® Impecca (HSB120). Antes de utilizar sus
auriculares por favor lea todo el manual. Este manual
le ayudará a usar las diferentes, útiles y emocionantes
funciones de su nueva unidad.
ADVERTENCIA
LEA CUIDADOSAMENTE ESTE MANUAL ANTES DE
PONER SU SISTEMA EN OPERACIÓN Y RESERVE PARA
FUTURAS REFERENCIAS. LE SERÁ DE GRAN AYUDA EN
CASO DE QUE LLEGARA A ENCONTRAR CUALQUIER
PROBLEMA DE FUNCIONAMIENTO.

18
ADVERTENCIA: Para reducir el riesgo de descarga
eléctrica, no retire la cubierta posterior de la unidad. No
hay partes que puedan ser reparadas por el usuario. Si
necesita ayuda, entre en contacto con soporte técnico.
ADVERTENCIA: Para prevenir el riesgo de incendio o
descarga eléctrica no exponga esta unidad a la lluvia o
humedad.
No exponga el adaptador o los Auriculares Estéreo
Bluetooth® a ninguna clase de líquidos (incluyendo
goteos o salpicaduras). Los objetos llenos de líquido
como vasos, o botellas de agua no deben de colocarse
encima de la unidad.
Mantenga los Auriculares Estéreo Bluetooth® lejos de la
luz directa del sol o superficies calientes como
radiadores o estufas.
No coloque los Auriculares Estéreo Bluetooth® en
mesas, trípode, estantes, soporte o carrito inestable. La
unidad puede caer dañándose o causando alguna lesión.
Deseche esta unidad adecuadamente respetando las
leyes locales de desecho de aparatos electrónicos y
baterías.
CUIDADO: hay peligro de explosión si la batería es
reemplazada de forma incorrecta. La batería interna
está sellada y no debe ser reemplazada por el
consumidor.

19
ADVERTENCIA: la batería no debe ser expuesta al calor
excesivo como la luz directa del sol, o cualquier otra
fuente de calor.
ADVERTENCIA: Utilice solo accesorios especificados
proporcionados por el fabricante.
Lineamientos de eliminación de desechos
electrónicos de la Unión Europea:
Este símbolo significa que los desechos eléctricos o electrónicos no deben
mezclarse con los desechos o basura de una casa. Para el tratamiento
adecuado, recuperación y reciclaje lleve este(os) producto(s) a los centros
designados de recolección donde serán aceptados sin costo. En forma
alternativa, en algunos países puede devolver sus productos a su proveedor
local al comprar un nuevo producto equivalente. La eliminación correcta de
este producto ayudará a resguardar recursos valiosos y a prevenir efectos
negativos potenciales en la salud y en el medio ambiente, lo cual de otro
modo sucedería al tener un manejo inapropiado de este tipo de desechos.
Para mayor información, contacte a sus autoridades locales para saber cuál
es el centro de recolección más cercano. Puede haber multas por la
eliminación inadecuada de este tipo de desechos de acuerdo a la legislación
de su país.
Contenido del Paquete
Auriculares Estéreo Bluetooth®
Cable USB (Tipo-A) a micro-USB
Cable de audio 3.5mm (1/8”)
macho-macho (1.2 metros de largo)
Manual de usuario

20
Descripción de Botones y Puertos
Copa derecha de los auriculares y unidad del
panel de control
Reproducir/P
ausa/Modo
Pista
Anterior
-
Bajar
Volumen
Pista
Siguiente
+
Subir
Volumen
