IMT IQL Helios User manual
IQL® Helios Area-/Streetlight
User Manual
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 2 Version 4.6 201302
Contents
1. Safety..................................................................................................................................... 3
2. Warranty................................................................................................................................ 3
2.1 General.................................................................................................................................... 3
2.2 Life span .................................................................................................................................. 3
3. Type plate .............................................................................................................................. 4
4. Product Description................................................................................................................ 5
5. Specifications......................................................................................................................... 6
5.1 General.................................................................................................................................... 6
5.2 Dimensions .............................................................................................................................. 6
6. Installation ............................................................................................................................ 7
6.1 Preparation .............................................................................................................................. 7
6.2 Assembly ................................................................................................................................. 7
6.3 Connections ............................................................................................................................12
7. Use....................................................................................................................................... 13
7.1 Commissioning ........................................................................................................................13
7.2 Insulation test .........................................................................................................................13
8. Maintenance......................................................................................................................... 13
9. Recycling.............................................................................................................................. 13
10. Contact details ..................................................................................................................... 13
11. EC Declaration of Conformity ............................................................................................... 14
Copyright © IMT B.V.
All rights reserved.
No part of this User Manual may be copied, redistributed, published or changed without the prior written
permission of IMT B.V.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 3 Version 4.6 201302
1. Safety
In order to use the product safely and optimise the life of the product, the following instructions must be
observed.
Only qualified personnel may install the product.
Work in accordance with locally applicable safety standards and regulations.
Ensure there is a reliable connection to the earthing system.
Do not clean the light fitting with a high pressure steam or water jet, to avoid damage not covered by
warranty.
2. Warranty
2.1 General
The guarantee on the IQL® Helios fittings is only applicable when the light fitting is used within the operational
limits.
Operational limits are:
The minimum and maximum ambient temperature for the IQL® Helios fittings are -20°C to +40°C.
The light fitting must be installed by a qualified person and in compliance with the installation
instructions.
Damage caused by incorrect installation, accidents or external influences such as lighting strike and
harmonic distortion not in accordance with EN 50055 are not covered by the guarantee.
The lighting level of the light fitting depends on the temperature and is therefore not covered by the guarantee.
If an IQL® Helios fitting fails within the warranty period, IMT B.V. will supply a new fitting with a comparable
specification free of charge. Before the guarantee can be confirmed, a defective light fitting must be sent to
IMT B.V. at the user’s expense for inspection. After this inspection the user will be informed of the result(s).
See invoice for individual guarantee agreements.
2.2 Life span
Switching the light fitting with a semiconductor photoelectric cell or a semiconductor relay has no known effect
on the life span of the light fitting.
It is expected that more than 70% of the original illumination power will be retained after 80,000 operating
hours.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 4 Version 4.6 201302
3. Type plate
3.1 Standard model
The standard model light fitting has a type plate attached:
TYPE PLATE
This contains the following information:
1. Type : Low temperature range IQL55-LT IQL85-LT
: Normal temperature range IQL55 IQL85
2. Ambient temp. : Low temperature range -40°C up to 40°C
: Normal temperature range -20°C up to 40°C
3. Serial number
4. Year of Manufacture
5. Frequency : AC 50/60
: DC none
6. Voltage : 200-277Vac/dc or 100-120Vac/dc
7. Current : 100-120 Vac/dc 200-277 Vac/dc
: 55W 460mA 260mA
: 85W 730mA 400mA
: 165W 1420mA 740mA
3.2 Explosion proof model
The explosion proof model light fitting has a type plate attached:
TYPE PLATE
This contains the following information:
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 5 Version 4.6 201302
1. Type : Low temperature range IQL55-LT IQL85-LT
: Normal temperature range IQL55 IQL85
2. Ambient temp. : Low temperature range -40°C up to 40°C
: Normal temperature range -20°C up to 40°C
3. Serial number
4. Year of Manufacture
5. Frequency : AC 50/60
: DC none
6. Voltage : 200-277Vac/dc or 100-120Vac/dc
7. Current : 100-120 Vac/dc 200-277 Vac/dc
: 55W 460mA 260mA
: 85W 730mA 400mA
:165W 1420mA 740mA
8. Marking : IQL 55 and IQL 85 : Ex II 3 GD EEx nA II T4 T135°C IP66
IQL165W : Ex II 3 GD EEx nA II T3 T160°C IP66
4. Product Description
All IQL® Helios light fittings have been designed for use in demanding conditions.
The characteristics of the IQL® Helios fittings are:
Maximum of 10 year guarantee on correct operation1
100,000 hours maintenance-free operation expected2
sealed for life
vibration proof
based on the principle of induction
explosion-safe model ATEX category 3 suitable for use in Zone 2 & 22
1For the Helios IQL®165 a different maximum guarantee period of 6 years applies. See invoice for individual guarantee
agreements.
2For the 165W version 60.000 hrs maintenance-free operation expected
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 6 Version 4.6 201302
5. Specifications
5.1 General
Housing : Copper free aluminium
Lens : Toughened glass
Colour recognition : Ra>80
Ingress protection : IP66
Burning position : Universal
(Re)ignition : Instant
Power factor : >0,92
Connection IP66 : Standard-3 pole Terminal Block
Connection EX Zone2 : Standard-12m flying lead Type RMcL H07RN-F 3x2.5mm²
Options:
The following options are available for the IQL® Helios light fittings:
Lamp Colour : Warm White (colour 827), Cool White (colour 840), Clear Sky
Wattage : 55 watt, 85 watt and 165 watt
5.2 Dimensions
IQL® Helios Area-/Streetlight 55/85W IQL® Helios Area-/Streetlight 165W
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 7 Version 4.6 201302
6. Installation
6.1 Preparation
1. Check that the light fitting will be installed in an environment that matches the ambient temperatures, gas
group and temperature class (for Zone 2 and 22). This data is shown on the light fitting type plate.
WARNING
The installation of the light fitting in an environment that does not match the
specified conditions can result in a dangerous situation.
WARNING
The installation of the light fitting in an environment that does not match the
specified ambient temperatures can have a strong negative effect on the life span
of the light fitting.
2. Choose the correct type of protection for the light fitting. The protection device needs to be a fuse or a
circuit breaker of at least 4 kA with a C characteristic.
3. Determine the number of light fittings that can be installed in each group. Consult the following table for
this.
Installation
protection
55 W
85 W
165 W
100-120
VAC/DC
200-277
VAC/DC
100-120
VAC/DC
200-277
VAC/DC
200-277
VAC/DC
B Type, 10 A
15
20
15
20
10
C type, 10 A
15
20
15
20
10
B Type, 16 A
22
30
22
30
16
C type, 16 A
26
35
26
35
16
55 W
85 W
165 W
100-120
VAC/DC
200-277
VAC/DC
100-120
VAC/DC
200-277
VAC/DC
200-277
VAC/DC
Inrush currents
16
12
16
12
24
Peak duration
170 μs
170 μs
170 μs
170 μs
140 μs
When using 30 mA earth leakage switches, provision must be made for a maximum of 30 light fittings on one
switch.
6.2 Assembly
Make sure there is a reliable connection to the earthing system.
WARNING
The installation of the light fitting in an environment that does not match the
specified conditions can result in a dangerous situation.
WARNING
The installation of the light fitting in an environment that does not match the
specified ambient temperatures can have a strong negative effect on the life span
of the light fitting.
WARNING
For Zone 2 and Zone 22 installation: the installation must be carried out in
accordance with (NEN-EN) IEC 60079-14.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 8 Version 4.6 201302
1. Take the light fitting out of the packaging.
2. Inspect the light fitting for mechanical damage.
3. Unscrew the metal screw to open the light fitting.
4. Check if the bag that comes with the product contains the following fixing materials:
2 plastic covers
2 long M8 socket-head bolts.
2 short M8 bolts (self drilling)
1 mast clamp.
1 strap clamp
5. Remove the plastic caps from the inserts.
For Horizontal Mounting (for vertical mounting see 13 onwards)
6. Place the corresponding plastic cover over the mounting hole that will not be used.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 9 Version 4.6 201302
7. Slide the long M8 socket-head bolts from underneath into the light fitting.
8. Fasten the mast clamp by turning the socket-head bolts a few times into the clamp.
9. Place the light fitting on the mast and tighten the socket-head bolts until the light fitting is completely
fastened to the mast.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 10 Version 4.6 201302
10. Connect the incoming cable to the connecting block.
11. Fasten the incoming cable by clamping it tight under the strain relief.
12. Close the light fitting. Fasten the metal screw securely to lock the light fitting.
For Vertical Mounting
13. Place the corresponding plastic cover over the mounting hole that will not be used.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 11 Version 4.6 201302
14. Slide the long M8 socket-head bolts from underneath into the light fitting.
15. Fasten the mast clamp by turning the socket-head bolts a few times into the clamp.
16. Place the light fitting on the mast and tighten the socket-head bolts until the light fitting is completely
fastened to the mast.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 12 Version 4.6 201302
17. Connect the incoming cable to the connecting block.
18. Fasten the incoming cable by clamping it tight under the strain relief.
19. Close the light fitting. Fasten the metal screw securely to lock the light fitting.
6.3 Connections
In the light fitting there is a standard connecting block, suitable for a single phase supply.
The following connection can be made:
L-N : Connection for the power supply.
In case of a flying lead instead of a standard connecting block, the neutral (code N - blue), the phase (code L –
brown) and earth (code PE, yellow-green) need to be connected.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 13 Version 4.6 201302
7. Use
7.1 Commissioning
The light fitting can be switched on immediately after installation.
7.2 Insulation test
Installations in which IQL light fittings are installed can be checked with an insulation test. For this test, apply a
maximum of 500 Vdc between earth and a phase or neutral connection.
WARNING
Never apply more than 500 Vdc between a phase and a neutral connection.
During production, all light fittings have been subjected to a dielectric test (2100 Vdc for 60 seconds). In
addition, the light fittings have also been subjected to an endurance test.
8. Maintenance
The light fitting’s critical components (the light compartment consisting of the reflector with glass and the
sealed off electronics compartment) are ‘sealed for life’ and cannot be opened. Consequently maintenance as
laid down in the IEC 60079-17 standard is not applicable; a visual inspection for correct operation will suffice.
WARNING
Opening the light compartment or electronics compartment voids the guarantee.
9. Recycling
For recycling the light fitting, agreements have been made with local bodies within the context of the WEEE
directive.
Contact your local partner (see the chapter ‘Contact details’). The local partner will be responsible for further
processing.
10. Contact details
IMT B.V.
Pascalweg 10a, 4104 BG Culemborg
P.O. Box 88, 4100 AB Culemborg
THE NETHERLANDS
Phone : +31 (0)88 –12 69 100
Fax : +31 (0)88 –12 69 101
For an up-to-date overview of all national and international contacts, visit our website: www.imt.eu.
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 14 Version 4.6 201302
11. EC Declaration of Conformity
The undersigned, representing the company
IMT B.V.
Pascalweg 10a
4104 BG Culemborg
The Netherlands
Phone :+31 (0) 88 - 12 69 100
hereby declares that the product: IQL® Helios marked with Ex II 3 GD EEx nA II T4 T135°C IP66 or Ex II 3
GD EEx nA II T3 T160°C IP66 complies with the terms of the EC directive(s) including all applicable
supplements.
94/9/EC
Equipment and protective systems intended for use in potentially explosive atmospheres
2004/108/EC
Electromagnetic Compatibility
and that all of the following standards and/or technically related specifications are met.
Standard
Issue
Title
EN 50021
1999
Electrical apparatus for potentially explosive atmospheres.
Type of protection “n”.
EN 50281-1-1
1998
Electrical apparatus for use in the presence of combustible dust part 1-1: Electrical
apparatus protected by enclosures –construction and testing.
EN 61547
2001
Equipment for general lighting purposes. EMC immunity requirements
EN 61000-3-2
2006
Limits for harmonic current emissions (equipment input current up to and including
16A per phase),
EC type certificate number PHX04ATEX1001X issued by
ph Xconsultancy
8 Ellingham Leas
Maidstone, Kent
UK
Culemborg, 1-04-2011
IMT B.V.
R.L.L.M.G. Mignot, Managing director
User Manual
IQL® Helios Area-/Streetlight
User Manual
IQL® Helios Area-/Streetlight 15 Version 4.6 201302
IMT B.V.
Pascalweg 10a, 4104 BG Culemborg
P.O. Box 88, 4100 AB Culemborg
Tel: +31 (0)88 –12 69 100, Fax +31 (0) 88 –12 69 101
www.imt.eu, sales@imt.eu
Table of contents
