HAMPTON BAY HB7028-05 User manual

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. –6 p.m., EST, Monday –Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
USE AND CARE GUIDE
____________________________________
EXTERIOR WALL LANTERN
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this exterior wall
lantern. We strive to continually create quality products designed to enhance your home. Visit us online to see our full
line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
Item:
Model:
Finish:
883902
HB7028-06
White
Item:
Model:
Finish:
882582
HB7028-05
Black

Before starting installation of this fixture or
removal of a previous fixture, disconnect
the power by turning off the circuit breaker
or by removing the fuse at the fuse box.
Consult a qualified electrician if you have
any electrical questions or need to replace
the driver.
If you have any non-electrical questions
about this fixture, please contact our
Customer Service Team at 1-
855‐HD‐HAMPTON or
HAMPTONBAY.COM.
WARNING: Disconnect the power prior to
removing or installing a light fixture.
Table of Contents
Safety Information
Warranty
WHAT IS COVERED
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship
for a period of three (3) years from date of purchase. This warranty applies only to the original
consumer purchaser and only to products used in normal use and service. If this product is found to
be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or
replacement of the product at the manufacturer’s discretion, provided that the product has not been
damaged through misuse, abuse, accident, modifications, alterations, neglect or mishandling.
WHAT IS NOT COVERED
This warranty shall not apply to any product that is found to have been improperly installed, set-up,
or used in any way not in accordance with the instructions supplied with the product. This warranty
shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence,
alteration, or faulty installation, or any other failure not relating to faulty material or workmanship.
This warranty shall not apply to the finish on any portion of the product, such as surface and/or
weathering, as this is considered normal wear and tear.
The manufacturer does not warrant and specially disclaims any warranty, whether expressed or
implied, of fitness for a particular purpose, other than the warranty contained herein. The
manufacturer specifically disclaims any liability and shall not be liable for any consequential or
incidental loss or damage, including but not limited to any labor/expense costs involved in the
replacement or repair of said product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.
Installation 5
Operation 7
Care and Cleaning 7
Exterior Maintenance 7
Interior Maintenance 7
Troubleshooting 7
Table of Contents 2
Safety Information 2
Warranty 2
Pre-Installation 3
Planning the Installation 3
Tools 3
Hardware 3
Package Contents 4
2

Pre-Installation
PLANNING THE INSTALLATION
Read all instructions before assembly and installation. Before starting installation of the fixture or
removal of a previous fixture, disconnect the power by turning off the circuit breaker or by removing
the fuse at the fuse box. To avoid damaging this product, assemble it on a soft, non-abrasive
surface such as carpet or cardboard.
NOTE: Keep your receipt and these instructions
for Proof of Purchase.
TOOLS REQUIRED
HARDWARE REQUIRED
NOTE: Hardware not shown to actual size.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
3
Phillips
Screwdriver
Wire
Cutter
Wire
Stripper
Flathead
Screwdriver
Ladder Safety
Goggles
Electrical
Tape
Silicone Rubber Sealant
for exterior use
Part
Description
Quantity
EE
Bracket Mounting Screw
2
FF
Fixture Mounting Screw
2
GG
Mounting Bracket
1
Part
Description
Quantity
AA
Lock Nut
2
BB
Hex Nut
2
CC
Hood Screw
2
DD
Wire Nut
3
3 Incandescent
60 W Bulbs
EEDD FF GG
BB
AA CC

Pre-Installation (continued)
PACKAGE CONTENTS
4
Part
Description
Quantity
A
Hood
1
B
Fixture Body
1
C
Finial
1
D
Hex Nut
1
A
D
C
B

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
1Mounting the hardware
Thread the fixture mounting screws (FF)
into the provided holes of the mounting
bracket (GG).
Thread the hex nuts (BB) onto the fixture
mounting screws (FF). Do not tighten the
hex nuts (BB) at this time.
Pull the supply wires out from the outlet
box and mount the mounting bracket (GG)
to the outlet box using the bracket
mounting screws (EE).
Place the back plate of the fixture body (B)
over the outlet box and onto the fixture
mounting screws (FF).
Adjust the fixture mounting screws (FF)
until they protrude out from the back plate
1/4 in.
Remove the fixture body (B) and secure
the position of the fixture mounting screws
(FF) by tightening the hex nuts (BB)
against the mounting bracket (GG).
2Connecting the wires
Connect the black supply wire to the black
fixture wire using a wire nut (DD).
Connect the white supply wire to the white
fixture wire using a wire nut (DD).
Connect the fixture ground wire to the
supply ground wire using a wire nut (DD).
Wrap all wire connections with electrical
tape for a more secure connection.
Installation
5
EE GG
FF
BB
DD
GG
B
NOTE: If you have electrical questions consult
your local electrical code for approved
grounding methods.
