ring Solar Floodlight User manual

Solar Floodlight
Smart Lighting

Set up your Ring Bridge.
The Bridge is required to connect your Ring
Smart Lights to the Ring app and other
compatible Ring devices.
To set up your Bridge,
follow the instructions
in the Ring app or the
Bridge user manual.
Download the Ring app.
The Ring app walks you through setting up
and managing your Floodlight.
Search for “Ring” in one of these app
stores, or visit: ring.com/app.
Download from
Windows Store
32

Remove the back cover.
Twist your Floodlight counter-clockwise to
unlock and separate it from the back cover.
Remove the battery.
Push the metal tab and
remove the included
battery from the
battery compartment.
54

= Charged
= Charging
Charge the battery.
Fully charge the battery by plugging it
into a power source using the provided
orange cable. Once only one light is lit,
it’s fully charged.
Remove the battery strips.
Carefully remove and discard them.
76

Set up your Floodlight in the
Ring app.
In the app, tap Set Up a Device.
When prompted, select Smart Lighting
and follow the in-app instructions.
After setup, replace the back cover (be
sure to line up the arrows).
Insert the battery.
Insert the included battery and
push until it snaps in place.
If you like, you can purchase and
insert a 2nd battery to make
your Floodlight last
longer when bright
sunlight is rare.
98

Remove the mounting plate.
Press the tab on the side and slide the
mounting plate o of the back cover.
Mark pilot holes.
Mark your holes using
the mounting plate as a
guide, making sure the
“UP” arrow is pointing
upwards.
1110

Drive the screws.
Hold the mounting
plate firmly against the
surface and drive the
three mounting screws.
Install the mounting plate.
If installing on a masonry surface (such
as stucco or brick), first drill holes using
a 3/16” drill bit. Insert the wall anchors
before inserting the screws.
If installing on a wood surface, you can
screw the plate directly into your wall
using a Philips head screwdriver.
1312

Mount your Floodlight.
Align your Floodlight with the mounting
plate and slide it to the left to lock it in.
Next, let’s set up your Ring Solar Panel.
The motion sensor is adjustable. Try various
angles to find the best setting for your home.
1514

Mark pilot holes.
Select an install location
within 13 feet of your
Floodlight, where the
Solar Panel can get
direct sunlight.
Mark the holes using
the mounting arm as a
template, and refer to
page 12 to install wall
anchors (if needed).
Screw in the
Mounting Arm.
Drive the included
mounting screws into
your wall (or the wall
anchors, if installing
on a hard surface)
until the mounting
arm is secure.
1716

Attach the Solar Panel.
Position the slots in the rear of your
Solar Panel over the mounting arm
and slide it down to secure it.
1918

You can rotate and tilt your Solar Panel to get the best
orientation for your home.
Adjust the Angle.
Loosen the screw on the mounting
arm and adjust the panel to your
desired angle, then re-tighten the
screw to secure your setting.
2120

Connect the cable.
Once your Solar Panel is mounted,
insert the power plug into the
power input at the bottom of your
Floodlight.
2322

For additional help, visit: ring.com/help
Or give us a call…
US 1 800 656 1918
Canada 1 855 300 7289
Worldwide [phone]
© 2019 Ring LLC or its aliates.
Ring and all related logos are trademarks of Ring LLC or its aliates.
For a list of all our customer support numbers,
visit: ring.com/callus
