Imtra C2-107 User manual

1
C2-107, C2-107HT, C2-139 & C2-139HT
PowerLED Floodlights
Installation and Operation Manual
C2-107
C2-107HT C2-139HT
C2-139

2
Overview
The Imtra C2 Series Floodlights are energy efficient solid-state marine-
grade LED floodlights. They are suitable for applications subject to high
vibration and intermittent shock loads and completely sealed against water
intrusion. They install easily with their included stainless steel mounting
brackets which allow for full tilt and 360° rotation.
Specifications
C2-107/C2-107HT C2-139/C2-139HT
Height 5.98” (153mm) 5.71” (145mm)
Width 4.72” (120mm) 5.90” (150mm)
Depth 2.55” (65mm) 3.39” (86mm)
Mounting Block 1.85” x 1.85” (47 x 47mm) 1.53” (39mm)
Input Voltage Range 9-56VDC 9-56VDC
Power Consumption 8.5W 13.0W
IP Rating IP66* IP66*
* IP66: “Protected from the ingress of dust and high pressure jets of water from all directions”
* These parts supplied with optional Thru-bolt kit (Part # ILP010045) only
Nut*
Tilt Ad
j
ust Nut
W
idth
De
p
th
Height
Split Washer*
Lock Nut*
Mounting Bolt*

3
Physical Installation
1. Determine the location where fixture will be mounted. Be sure you
have chosen the correct model for the application. The HT models are
specifically designed to be mounted upside down in a hanging
position. The non HT models should only be used for upright
mounting. If you do not have the correct model, please return it in
exchange for the appropriate type.
2. Remove the mounting bracket from the floodlight by loosening and
removing the tilt adjust nut and bolt.
Thru-bolt installation (optional)
3. Identify mounting location
and drill a ½” (12mm)
mounting hole.
4. Remove the lock nut, split
washer and nut from the
12mm mounting bolt (sold
separately) and pass the
12mm mounting bolt through
the mounting bracket and
mounting hole. Secure the
bracket with the nut, split
washer and lock nut.
Surface mount installation
3. Identify mounting location
and drill 4 pilot holes for #8
self-tapping fasteners. Use
the mounting bracket as a
template for these holes.
4. Secure the mounting bracket
with four #8 self-tapping
fasteners.
5. Attach the floodlight to the mounting bracket by passing the tilt adjust
bolt through the bracket, spring washer, light housing, spring washer,
bracket, split washer and nut.
6. Set the tilt height and tighten the Tilt Adjust Nut.
Wiring Instructions
1. Before making wiring connections, be sure the power is off!
2. Connect the white wire from your PowerLED Floodlight to DC (+).
3. Connect the black wire from your PowerLED Floodlight to DC (–).
4. Turn the power to the light on.
Wire Function
Red (or White)
+
Black –

4
Limited Warranty
Imtra warrants the LED electronic component of our PowerLED Floodlights
for a period of 2 years from the date of purchase. If the fixture should
cease to function within 2 years, return the unit to Imtra for repair or
replacement.
This warranty does not apply to damage resulting from actions of the user
such as misuse, improper wiring/installation, operation outside of
specification, improper maintenance or repair, unauthorized modification,
lightning strike or damage from a power surge.
Imtra specifically disclaims any implied warranties, merchantability or fitness
for a specific purpose and will not be liable for any direct, indirect,
incidental or consequential damages. Imtra's total liability is limited to
repair or replacement of the product.
The warranty set forth above is inclusive and no other warranty, whether
written or oral, is expressed or implied.
If it should become necessary to return a fixture for service during or
beyond the warranty period, please refer to Imtra's standard Return Policy
as detailed on Imtra's website (www.imtra.com) or call Imtra customer
service at [phone].
No returns are accepted without a Return Authorization (RA) number.
30 Barnet Boulevard, New Bedford, MA 02745
[phone] •www.imtra.com
