in2digi D-JV-2 User manual

Page 1
JLR Vehicle Power Distribution
Aftermarket DAB Module Installation
•it is recommended that the power feed for the in2digi D-JV-2 module
installation is individually fused y a series placed 5A fuse (not supplied)
•reference should e made to the in2digi we site (www.in2digi.com) for
additional installation guidelines
Power connection
•all of the infotainment elements are ultimately supplied from a “ attery”
connection (a typical Land Rover circuit configuration is shown and Jaguar
vehicles follow the same distri ution principle ut junction ox
nomenclatures may e different)
•it is important that the in2digi module receives its power from these
same infotainment distri uted circuit elements

Page 2
JLR Vehicle Power Distribution
High current feed to Audio Amplifier
Touch Screen
Audio Amplifier
IAM (Integrated Audio Module)
Tuners / Phone
RSE (Rear Seat Entertainment Module)

Page 3
JLR Vehicle Power Distribution
Aftermarket DAB Module Installation (vehicle front)
•take a spliced feed from the IAM
•Batt pin
•Gnd pin
•10A minimum fused supply in vehicle

Page 4
JLR Vehicle Power Distribution
Aftermarket DAB Module Installation (vehicle rear)
•take a spliced feed from the Tuners / Phone Module
•Batt pin
•Gnd pin
•10A fused supply in vehicle
•take a spliced feed from the Audio Amplifier
•RBD PWR pin
•Gnd pin
•5A fused supply in vehicle
OR ….
