Indesit IS31 Installation guide

TUMBLE DRYER
Use and Care & Installation Instructions
IS31
This symbol reminds you to read this booklet.

Contents
Safety Advice
Electrical Requirements
Features - Get to know the main parts of your Dryer
Where to put and vent your Dryer
How to use your Dryer
Sorting your laundry
Items not suitable for drying
Items requiring special attention
The Controls
Guide to Drying Times
How to remove and clean the Fluff Filter
Caring for your Dryer
If something goes wrong
If it still won’t work
Product Data
Indesit Guarantee/After Sales Service
Essential Contact Information
3 - 4
5
6
6
7
8
9
10
11
12
13
13
14
15
16
18/19
20
Retention of this Instruction Book
This Instruction Book must be kept handy for reference as it contains important
details on the safe and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it
behind, make sure this Book is also provided so the new owner can become
familiar with the appliance and safety warnings.
2

3
For your safety
NEVER ● Allow children to play with or otherwise interfere with the dryer.
NEVER ● Allow the air inlet at the back of the dryer, the air outlet or vent hose
to be obstructed.
NEVER ● Direct the vent hose outlet towards the air intake at the back of the
machine.
NEVER ● Allow the tumble dryer to recycle exhaust air.
NEVER ● Switch the machine off leaving a hot load in the drum.
NEVER ●Tumble dry without the filter in position.
NEVER ● Exceed the maximum load capacity recommended or place
dripping wet items in the drum.
NEVER ● Use the dryer on a carpeted floor where the pile height would
prevent air from entering the dryer from the base.
NEVER ● Allow lint to collect around the dryer.
NEVER ● Add liquid or sheet fabric conditioner to the dryer, use liquid
conditioner in the final rinse of your wash.
NEVER ●Use the dryer for commercial drying, the dryer is only suitable for
domestic use.
NEVER ●Dry Acrylics on the high heat setting.
NEVER ●Tumble dry articles that have NOT been well washed in water and
detergent then well rinsed and spun.
NEVER ●Tumble dry articles that have had chemicals used for cleaning.
NEVER ●Tumble dry articles that are contaminated with flammable
substances (Cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes, wax removers and hair sprays), unless
washed in hot water with an extra amount of detergent.
NEVER ●Tumble dry rubber, rubber backed articles and clothes, pillows fitted
with foam rubber pads, foam (latex foam), rubber, plastic, shower
caps, waterproof textiles, nappy pants or liners, polythene or paper.
NEVER ●Tumble dry: Large, very bulky items including duvets and sleeping
bags.
NEVER ●Attempt to stand on top of your dryer, it is not designed for such use
and you could injure yourself or damage the dryer by such abuse.
NEVER ●Switch electricity On or Off with wet hands.
IMPORTANT
Using your Tumble Dryer is easy.
Nevertheless, for your own safety and to get the best results it is important to know your
Dryer by reading right through this handbook before using your dryer for the first time.
A CHILD COULD CLIMB INTO OR TAMPER WITH AN UNATTENDED
TUMBLE DRYER.
WHEN THE MACHINE IS NOT IN USE SWITCH OFF, REMOVE THE PLUG AND CLOSE
THE DOOR.
IMPORTANT

4
For your safety
ALWAYS ●Supervise children to ensure that they do not play with the dryer.
ALWAYS ●Supervise persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their
safety.
ALWAYS ●When the dryer is not in use, switch off at the wall, remove plug
and close the door.
ALWAYS ●Comply with the specified electrical requirements.
ALWAYS ●Ensure that your dryer is installed correctly and has adequate
ventilation. (see, "Where to put and vent your dryer.")
ALWAYS ●Use the vent hose for optimum drying performance.
ALWAYS ●Finish every programme with the cool tumble cycle provided on
the control.
ALWAYS ●Clean the filter, it is essential that the filter is kept clear of fluff
after EACH drying cycle.
ALWAYS ●Observe the rules for drying garments:
In particular woollen articles should not be dried in a
tumble dryer unless they are labelled ‘Superwash’,
‘Machine washable’ or have the ‘May be tumble dried’
symbol:
If in any doubt do not dry wool in the machine.
Unlike other materials, the mechanism of wool
shrinkage is irreversible, i.e. it will not stretch back to
the original size and shape.
ALWAYS ●Buy genuine accessories and spares.
CAUTION: WHEN THE DRYER IS IN USE AVOID
TOUCHING THE REAR OF THE DRYER AS IT MAY BE
HOT.
WARNING: Never stop the dryer before the end of the drying
cycle unless all items are quickly removed and spread out so
that the heat is dissipated!

Electrical Requirements
Supply
Changing
the fuse
Moulded plug
Changing
the plug
Rewirable plug
Changing the
mains cable
WARNING: This appliance must be earthed!
REFER TO THE RATING PLATE FOR VOLTAGE AND CURRENT
REQUIREMENTS. (see diagram for location.)
The flexible mains lead is supplied fitted with a BS1363 plug and
with a 13 amp BS1362 fuse.
The plug should be connected to the mains supply via a suitable
switched socket which is accessible after installing your dryer.
If it is necessary to fit a replacement fuse, it must be a 13 amp
ASTA approved to BS1362 type.
If a replacement fuse holder/cover is required, it must be of the
same colour coding or wording as shown on the base of the plug.
Replacements are available from your Spares stockist.
The wires in the mains lead are coloured in accordance with the
following:
GREEN/YELLOW - EARTH
BLUE - NEUTRAL
BROWN - LIVE
If a replacement plug is to be fitted, the appropriate wire must be
connected to the correct terminal,as follows:
Connect:
Green/Yellow to terminal marked Earth or Green or
Blue to terminal marked Neutral or N or Black
Brown to terminal marked Live or L or Red.
If the plug being replaced is a non-rewirable type then the cut-off
plug must be disposed of safely. DO NOT leave where it can be
inserted into a socket and create a shock hazard.
Should the mains lead ever require replacing at any time please
contact your nearest Service Centre. A charge will be made for the
replacement of the mains lead or if you require a longer lead.
The mains lead must only be replaced by a specially prepared
cable obtainable from your Spares Stockist and fitted by a
qualified electrician.
WARNING: The plug must not be used without a fuse cover.
NOTE: IF IN DOUBT ABOUT ANY OF THE ABOVE CONSULT A
QUALIFIED ELECTRICIAN.
GREEN &
YELLOW TO
EARTH
13 AMP
FUSE
BROWN
TO LIVE
CORD
CLAMP
BLUE TO
NEUTRAL
5

6
Features - Get to know the main parts of your dryer
Where to put and vent your dryer
Your tumble dryer should NOT be located adjacent to a gas hob,
cooker, heater, or eye level grill as flames from the burners could
cause damage to your machine.
The dryer should be placed where air can freely circulate around
it, preferably near a window that can be opened to reduce the
possibility of condensation occuring while the dryer is in use.
When operating the dryer, there has to be adequate ventilation to
avoid the back flow of gases into the room from appliances
burning other fuels, including open fires.
A vent hose is recommended for optimum performance.
DO NOT operate the dryer in an enclosed environment,
ensure the dryer is adequately ventilated.
If the dryer is enclosed or fitted under a work surface, a gap
of at least 50mm (2") must be allowed above the top across
the full width of the dryer and at least 25mm (1") either side.
This allows air to enter into the rear air inlet. The dryer must
NEVER be run in a cupboard with a closed door.
We do not recommend that the dryer is installed in a cupboard
but the dryer must never be installed behind a lockable door,
a sliding door or a door with a hinge on the opposite side to
that of the dryer door.
DO NOT allow clothes, towels etc., to hang down the front of
the dryer into the airstream. This obstructs the airflow and
may damage the dryer.
Ensure that the end of the hose is not directed towards the
air intake grille at the rear of the dryer.
NOTE: The vent hose should not exceed 2.4 metres in length,
and should be kept free of any possible accumulation of fluff
lint (and water) by frequently shaking it out. Always ensure
that the hose is not squashed.
●
●
●
●
●
●
●
●
●
●
Filter Assembly
(on inside of the door)
Mains On/Off Indicator Light (if fitted)
Heat Selector Switch
Exhaust Air Grille
Door Release
Timer Knob
Wall Hanging Kit This allows the dryer to be mounted on a wall of suitable strength to
take the weight. Alternatively it should be used when the dryer is
mounted on top of a work surface to secure the dryer to the wall.
WARNING:
DO NOT DISCHARGE THE EXHAUST AIR INTO A FLUE WHICH
IS USED FOR EXHAUSTING FUMES FROM OTHER
APPLIANCES BURNING GAS OR OTHER FUELS.

7
How to use your dryer
1. Plug in, switch
on electricity.
2. Sort your laundry
(see section “Sorting
Your Laundry”)
3. Open the door.
Check that the fluff
filter is clean (see
section How to
remove and clean
the fluff filter).
4. Load the dryer
placing the
clothes carefully in
the drum, pushing
them well towards
the back and
away from the
door seal. Close
the door.
5. Select the
relevant heat setting
(see section “Sorting
your Laundry”).
Push IN for high heat, for cottons, linens
and synthetics.
Low setting - button OUT for acrylics and
acrylic mixtures.
6. Turn the Timer clock-
wise to select the
required drying time.
(See Section “The
Controls”.)
The dryer will start
7. When finished
open the door and
take out the laundry.
Clean and replace
the fluff filter.
WARNING: WHEN
SWITCHING ON
OR OFF, PLEASE
ENSURE THAT
YOUR HANDS
ARE DRY
WARNING: WHEN
SWITCHING ON
OR OFF, PLEASE
ENSURE THAT
YOUR HANDS
ARE DRY
Button IN
HIGH HEAT
Button OUT
LOW HEAT
Never switch the dryer off with a hot load in the drum.
You must terminate every programme with the Cool Tumble Phase.
8. Switch off electricity
and remove plug from
socket.

8
Sorting your laundry
1. Always separate laundry into the correct fabric groups before
washing and drying.
2. See that all zips are closed, hooks and eyes are fastened and
belt, strings etc. are tied loosely in bows, you will normally have
done this for each item before the washing stage.
3. It is important to extract as much water as possible from each
item before drying. This saves you time and money.
4. Make sure that the items to be dried are suitable for tumble
drying, or are not of a type requiring ‘special attention’ (see“Wash
Care Labels” section).
Your dryer will hold a load of 3kg (6.6lb) dry weight of natural fabrics.
if you are drying items of man-made fibres (synthetic or acrylics), the
maximum load should not exceed 2kg (4.4lb) dry weight.
This difference is that man-made fibres require more space to
tumble-dry without creasing.
To help you estimate how many items it takes to make up a drying
load, the charts below show the approximate weights of some
everyday washing items.
If you group small cotton or terry-towelling items with a synthetic
fabric load they could be damp at the end of the drying cycle. If this
happens simply give them an additional short period of drying to
finish them off.
Maximum
load size
Typical load
WARNING:
CLOTHES SHOULD NEVER BE LOADED DRIPPING WET
WARNING:
DO NOT OVERLOAD YOUR DRYER AS THIS COULD RESULT
IN REDUCED DRYING PERFORMANCE.
Clothes
Blouse Cotton 150g 5oz
Other 100g 31/2oz
Dress Cotton 500g 1lb 2oz
Other 350g 12oz
Jeans 700g 1lb 6oz
10 Nappies 1000g 2lb 3oz
Shirt Cotton 300g 101/2oz
Other 200g 7oz
T-Shirt 125g 41/2oz
Household Items
Duvet cover Cotton 1500g 3lb 5oz
(Double) Other 1000g 2lb 3oz
Large Tablecloth 700g 1lb 6oz
Small Tablecloth 250g 9oz
Tea Towel 100g 31/2oz
Bath Towel 700g 1lb 8oz
Hand Towel 350g 12oz
Double Sheet 500g 1lb 2oz
Single Sheet 350g 12oz

9
Wash Care Labels
Most of today’s fabrics can be tumble dried in your Dryer with no
trouble at all, but there are certain fabric finishes which should be
dried away from direct heat.
The majority of garments now have wash-care labels on them, giving
full washing and drying instructions. These should always be followed
carefully especially when you are drying something for the first time.
Typical symbols are:
May be tumble dried
Do not tumble dry
Or:
Tumble dry at high heat setting
Tumble dry at low heat setting
• Those containing foam rubber or rubber-like materials or plastic
film (e.g. pillows, cushions, PVC rainwear), or any other articles
which are inflammable or contain inflammable substances (e.g.
towels contaminated with hair lacquer
• Fibreglass (e.g. some types of curtains)
• Items which have been dry cleaned
• Woollens. Woollen items need as much care in drying as they do
in washing. The movement of the tumble-drying action causes the
woollen fibre to shrink and distort.
• Garments with the ITCL Code (see ‘Items Requiring Special
Attention’).
Do not tumble dry.
• Large bulky items e.g. continental quilts, sleeping bags, pillows,
cushions, double blankets and large bedspreads. These expand
when drying and would prevent airflow through the Dryer.
WARNING: THE DRYER IS INTENDED FOR USE ONLY
WHERE WATER SOLUTION IS USED FOR THE CLEANING
PROCESS. MISUSE OF A TUMBLE DRYER MAY CREATE A
FIRE HAZARD.
Items not suitable for tumble drying

10
Items requiring special attention
The drying requirements of blankets and bedspreads will, of course,
vary tremendously according to size and weight. Some, however are
simply too big. if you have difficulty getting them into the Dryer, the
machine will have difficulty drying them properly. Blankets (and
Garments) made from Acrylic fibres (e.g. Acilan, Courtelle, Orion and
Dralon) must be dried with special care on Low heat setting.
Overdrying should be avoided to ensure heat creasing does not
occur.
Your dryer will cope with such clothes very well, but you should
always read the manufacturer’s drying instructions attached to the
garment before you begin.
Starched articles should be dried together in the same load to avoid
the distribution of starch to non-starched items. You should use a
slightly heavier starch solution than you would when drying the items
on the washing line. Make sure that as much of the solution is
removed from the load as possible before placing it in the Dryer.
Remove the items from the dryer as soon as they reach ironing
dampness. If they are overdried the starch will powder, leaving the
fabric limp - which rather defeats the purpose of the exercise!
To make sure all your tumble dried clothes come out really fresh and
soft we recommend you use a liquid fabric conditioner in the final
rinse of your wash. A liquid fabric conditioner restores bounce and
softness and helps eliminate static cling.
Garments with the ITCL Code may be cleaned using one of the
Home Dry Cleaning Kits available.
The instructions supplied with the Home Dry Cleaning Kit must be
strictly followed.
Blankets and
Bedspreads
Permanently
pleated or creased
garments
Starched articles
Fabric conditioner
Home Dry
Cleaning
WARNING: ON NO ACCOUNT SHOULD LIQUID FABRIC
CONDITIONER BE ADDED TO THE DRYER ITSELF.
