Indesit FID20 User manual

Electric built in Double oven
Instructions for installation and use
FID20
FIDM20

Contents
1
You must read these instructions prior to using the
appliance and retain them for future reference.
Introduction 2
Safety Information 3
Features 5
Temperature Conversion Chart 7
Controls 8
Multifunction Switch (FIDM20 only) 10
Oven Timer Operation 11
Grill Pan and Handle 17
Using the Top Oven Grilling (FID20 only) 18
Using the Top Oven Grilling (FIDM20 only) 19
Using the Top Oven as a Convection Oven 21
Operation when using the Top Oven as a Convection Oven 22
Top Oven Temperature Charts 23
Main Oven - Fan Grilling (FIDM20 only) 25
Main Oven - Fan Grilling Roasting Chart (FIDM20 only) 26
Using the Main Oven for other Functions 27
Main Oven - Convection Oven (FIDM20 only) 28
Main Oven - Fan Oven 28
Main Oven Cookery Notes 29
Main Oven Temperature Charts 31
Main Oven Grilling (FIDM20 only) 33
Care and Cleaning 34
Installation 37
Somethng Wrong? 41
If it Still won’t Work 42
Key Contacts Back Cover

Introduction
2
This appliance conforms to the following EEC Directives:
Electromagnetic Compatibility Low Voltage Equipment
89/336/EEC 73/23/EEC
92/31/EEC 93/68/EEC
93/68/EEC
To minimise the risk of injury to children please dispose of your product carefully and safely.
Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the
appliance and always ensure that no plug is left in a condition where it could be connected to
the electricity supply.
To help the environment, Local Authority instructions should be followed for the disposal of
you product.
Disposal of your product
Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable
if the appliance has been installed in accordance with the installation instructions detailed in
this booklet.
To help make best use of your cooking equipment, please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not be accepted for
use in any other installation.
To help remove the ‘new’ smell, heat up the empty ovens to maximum temperature for a
minimum of two or three hours, keeping the oven doors closed. Ensure that the room is well
ventilated (e.g. open a window or use an extractor fan) and that persons who may be sensitive
to the odour avoid any fumes.
It is suggested that any pets be removed from the room until the smell has ceased.
This odour is due to temporary finish on oven liners and elements and also any moisture
absorbed by the insulation.
When the cooker is first used an odour may be emitted,
this will cease after a period of use
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage as stated on the
rating plate attached to this equipment.
(c) Has not been subjected to misuse or accident or been modified or repaired by
any person other than the authorised employee or agent.
(d) Has been correctly installed.

Always
●Always make sure you remove all packaging and literature from inside the oven
and grill compartments before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces will
get extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking
and when not in use.
●Always stand back when opening an oven door to allow any build up of steam or
heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and
allow the appliance to cool.
●Always make sure the shelves are in the correct position before switching on the
oven.
●Always keep the oven and grill doors closed when the appliance is not in use.
●Always take care when removing utensils from the top oven when the main oven
is in use as the contents may be hot.
●Always keep the appliance clean as a build up of grease or fat from cooking can
cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent the
possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a qualified appliance service engineer.
●During use the oven becomes hot. Care should be taken to avoid touching
heating elements inside the oven,
SAFETY ADVICE
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the
flames and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE MOVING IT.
Injuries are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of
the extinguisher is likely to tip the pan over. Never use water to extinguish
oil or fat fires.
3
Safety Information
When used properly your appliance is completely safe but as with any electrical product
there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.

Never
●Never leave children unsupervised where a cooking appliance is installed as all
cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never operate the grill with the door closed as this will cause the appliance to
overheat.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never allow children to play with the appliance controls.
●Never use ‘steam cleaners’.
4
Safety Information

Features (FID20 only)
5
WARNING: Do not touch the glass doors when the oven is in use as these areas can
become hot.
❍❍❍
NEVER line the shelves, floor or sides of the oven or grill with aluminium foil as
overheating and damage may result.
TOP OVEN
TEMPERATURE & GRILL
SELECTION CONTROL
TIMER
GRILL PAN &
FOOD SUPPORT
TOP OVEN
DOOR
OVEN LIGHT
OVEN SHELF
RATING PLATE
GRILL
SETTING
CONTROL
GRILL
ELEMENT
FAN GRILL
ELEMENT
CATALYTIC
LINER
OVEN FAN
CATALYTIC
LINER
INNER DOOR
GLASS MAIN OVEN
DOOR
GRILL SHELF
INNER DOOR
GLASS
MAIN OVEN TEMPERATURE
& FUNCTION CONTROL

Features (FIDM20 only)
6
TOP OVEN
TEMPERATURE CONTROL /
GRILL SELECT
TIMER MAIN OVEN
PILOT LIGHT
TOP OVEN
PILOT LIGHT
GRILL PAN &
FOOD SUPPORT
TOP OVEN
DOOR
OVEN LIGHT
OVEN SHELF
RATING PLATE
GRILL
SETTING
CONTROL
GRILL
ELEMENT
FAN GRILL
ELEMENT
CATALYTIC
LINER
OVEN FAN
CATALYTIC
LINER
INNER DOOR
GLASS
MAIN OVEN
DOOR
GRILL SHELF
INNER DOOR
GLASS
❍❍❍❍
MAIN OVEN
TEMPERATURE
CONTROL
MULTIFUNCTION
SELECTOR
WARNING: Do not touch the glass doors when the oven is in use as these areas can
become hot.
NEVER line the shelves, floor or sides of the oven or grill with aluminium foil as
overheating and damage may result.

Temperature Conversion Chart
7
The chart below gives details of comparisons of oven settings for gas
conventional ovens and fan oven in degrees ˚F and ˚C
CONVENTIONAL
OVEN
˚F ˚C
250 120
275 140
300 150
325 160
350 180
375 190
400 200
425 220
450 230
475 240
GAS
MARK
1/2
1
2
3
4
5
6
7
8
9
FAN
OVEN
˚C
100
120
130
140
160
170
180
200
210
220

Controls (FID20 only)
8
Cooling Fan: A gentle flow of air will be blown below the control panel when any
selector switch is used.
Note: Whenever the appliance has been used, the cooling fan may
run on or restart itself after all the controls have been turned off.
This indicates that the appliance is still warm.
Oven Interior The oven lights are operated when their respective oven control is
Lights used. (N.B. Not all models have a top oven interior light).
The main oven has a light only position.
Control Markings
Note: It is advisable to check that all oven controls have been switched off when you have
finished using the appliance.
Control Knob Description
Grill Setting Control
Top Oven Temperature &
Grill Selection Control
Main Oven Temperature &
Function Control
A
B
C
Function
Selects the heat at which the grill will cook the
food. 1 – max Grill Settings Control:
1 = Low, max = High
Note: To grill you must first select a grill function
using control (B).
- Selects the cooking temperature
(Degrees Centigrade) when using the top
oven as a conventional oven
.
- Switches the top oven to ‘Half Grill’
mode.
- Switches the top oven to ‘Full Grill’
mode.
Fan Only Setting
- This is used to decrease the amount
of time required to defrost food items.
Oven Light Only
- Switches on the Main Oven Interior
Light Only.
Main Oven Temperature Scale (In
Degrees Centigrade).
- When cooking select the required
cooking temperature.
100 -
220
90 -
230
AGRILL SETTING
CONTROL
BTOP OVEN TEMPERATURE
AND GRILL SELECTION
CONTROL
CMAIN OVEN TEMPERATURE
AND FUNCTION
CONTROL
TIMER

Controls (FIDM20 only)
9
IMPORTANT
Before using your oven in the ordinary way, ALWAYS make sure that the timer has been
set to MANUAL operation. Unless this is done, the main oven cannot heat up.
Before seeking assistance, make sure this is done (refer to oven timer operation).
MULTIFUNCTION SELECTOR
Rotate the control knob in either direction to the required function. Many of the
functions will also require the main oven thermostat to be set before the oven will heat
up.
MAIN OVEN TEMPERATURE CONTROL
This is used in addition to the multifunction selector. This is used for the functions: fan
oven, fan grill, half grill and full grill and convection oven.
Turn the control clockwise to set the oven thermostat to the required temperature.
If the timer is set correctly and the selector switch set to a suitable function an indicator
light will illuminate (Fan Oven, Convection Oven and Fan Grilling modes only). This will
remain on until the oven reaches the required temperature. This light will then cycle on
and off as the thermostat maintains control of the oven temperature.
TOP OVEN TEMPERATURE CONTROL
Turn the control clockwise to set the top oven thermostat to the required temperature.
An indicator light will illuminate. This will remain on until the oven reaches the required
temperature. This light will then cycle on and off as the thermostat maintains control of
the oven thermostat.
GRILL CONTROL
The grill control is designed to provide variable heat control of either both grill elements
on together or the single left-hand grill element only. Turn the top oven control
clockwise past the temperature settings to the half grill or full grill settings, depending
on which you require. To set the grill power, turn the grill control to any setting 1 - 6.
After use always set the oven control back to ‘O’ (Off).
COOLING FAN
A gentle flow of air will be blown below the control panel when any control is used. In
some instances this will continue after switching off. This helps to keep the control panel
and knobs cool.
TOP OVEN PILOT
AGRILL SETTING CONTROL
BTOP OVEN TEMPERATURE CONTROL
AND GRILL SELECT
DMULTIFUNCTION SELECTOR
CMAIN OVEN TEMPERATURE CONTROL
TIMER MAIN OVEN PILOT
