Indesit DOCTOR 2 Operating and installation instructions

Information
Indesit Company UK Ltd
© 2006 Reg. Office: Peterborough PE2 9JB. Registered in London: 106725
Service
WASHING
MACHINE
DOCTOR 2
A Guide
for use with
EMIT
Model Types Covered:
EVO 2 Laundry
5407182 Issue 3 June 2006

2
SAFETY NOTES & GENERAL SERVICING ADVICE
1. This manual is NOT intended as a comprehensive repair/maintenance guide to the appliance.
2. It should ONLY be used by suitably qualified persons having technical competence applicable
product knowledge and suitable tools and test equipment.
3. Servicing of electrical appliances must be undertaken with the appliance disconnected (unplugged)
from the electrical supply.
4. Servicing must be preceded by Earth Continuity and Insulation Resistance checks.
5. Personal safety precautions must be taken to protect against accidents caused by sharp edges on
metal and plastic parts.
6. After servicing the appliance must be rechecked for Electrical Safety. In the case of appliances which
are connected to a water supply (i.e.: Washing Machines, Dishwashers & Food Centres etc.) checks
must be made for leaks from seals gaskets and pipe work and rectification carried out where
necessary.
7. It can be dangerous to attempt 'DIY' repairs / maintenance on complex equipment and the Company
recommends that any problem with the appliance is referred to its own Service Organisation.
8. Whilst the Company has endeavoured to ensure the accuracy of the data within this publication they
cannot hold themselves responsible for any inconvenience or loss occasioned by any error within.
9. This appliance may be fitted with a '3 phase' motor which uses a different type of power
module.
This power board is fitted with a large aluminium heat sink which remains live after the power
is disconnected.
Under no circumstances should the board be removed under the time shown below in Fig 1.
Alternative 'quick methods' of discharging the board SHOULD NOT be used or attempted.
IMPORTANT SAFETY NOTE
Risk of Electric Shock
The metal heatsink fitted on the
Power Module may hold an
electrical charge for a short period
after switching off the machine.
Allow 5 minutes after
disconnecting the machine from
the electrical supply before
commencing ANY work.

3
INDEX
Safety Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Date Code, Serial Number & Industrial Code. . . . . . . . . . . . . . . . . . . . . . . . . .4
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Requirements / Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
Connection to EMIT & the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Starting the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Main Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 13
Using the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 - 29
Example Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 - 37
Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

4
MANUFACTURING DATE CODE CHART
This example shows that the machine was manufactured in MAY 2004:
SERIAL NUMBER / INDUSTRIAL CODE EXPLANATION
Serial Number Example
3 10 02 0895 Four remaining digits = Build number that day 895th built that day
Third two digits = Day of manufacture 2nd of month
Second two digits = Month of manufacture October
First digit = Year of manufacture 2003
Industrial Code Example
37 24455 0010 Last four digits = 0000 original production. Other numbers denote major
production changes
Second five digits = COMMERCIAL CODE *
* Vital for correct model information and system identification
First two digits = Factory of origin
1986
1994
2002
1987
1995
2003
1988
1996
2004
1989
1997
2005
1990
1998
2006
1991
1999
2007
1992
2000
2008
1993
2001
2009
Jan 01 13 25 37 49 61 73 85
Feb 02 14 26 38 50 62 74 86
March 03 15 27 39 51 63 75 87
April 04 16 28 40 52 64 76 88
May 05 17 29 41 53 65 77 89
June 06 18 30 42 54 66 78 90
July 07 19 31 43 55 67 79 91
Aug 08 20 32 44 56 68 80 92
Sept 09 21 33 45 57 69 81 93
Oct 10 22 34 46 58 70 82 94
Nov 11 23 35 47 59 71 83 95
Dec 12 24 36 48 60 72 84 96
First 2 digits of the serial number indicate production date
Date Code 29 120054

INTRODUCTION
Programme Uses
WM Doctor has been introduced to enable Merloni Engineers to run a diagnostic test from their
Emit terminal.
It can also be used via normal PCs or laptop computers fitted with appropriate software and
connecting leads.
The programme can be used to establish the current File Version loaded, check the loaded
Eeprom and power board is ok, and test components of the appliance.
Wash Doctor Evo 2 will work with laundry appliances manufactured with EVO 2 software.
It is important to read this guide fully and view the illustrations carefully before attempting to
use the Wash Doctor programmes.
Ensure that the Evo 2 appliances are switched on at the mains.
All appliances should be empty of water and clothes before beginning tests.
After programming or re-programming an Eeprom using the Eeprom Writer programme, Wash
Doctor should be used to run a functional diagnostic test to establish that the appliance works.
Do not run Wash Doctor at the same time as the Eeprom Writer programme.
5

REQUIREMENTS / EQUIPMENT.
Washing Machine Doctor software.
EmitUnit.
Hardware Key Part Number C00115587 Low End Adapter C00116135
USB to Serial lead Part Number 5600261 Hardware Key Pin Kit C00114723
Hardware Key Part Number C00115587
USB to Serial Cable Part Number 5600261
Hardware Key Pin Kit C00114723
6

REQUIREMENTS / EQUIPMENT cont.
LOW END ADAPTOR
Some models have a combined Power and Display board mounted behind the console panel.
These products require an adaptor to connect the Emit to the appliance. The adaptor is
shown below Part Number C00116135.
Information on the use of this adapter can be found in leaflet 8200787.
Note: This procedure using the adaptor MUST NOT be carried out with the Mains supply
connected when the top cover is removed from the appliance.
7

CONNECTION
Connect the Hardware Key to the Emit via the USB cable and switch on the appliance. Connect the
Hardware Key to the appliance. A Green Led illuminates on the key. During communication with the
software Orange and Red Led’s on the Hardware Key will flash intermittently.
.
USB Cable - USB Connector
USB Cable
Serial Connector
Hardware Key
8

STARTING THE SOFTWARE
When you have the software loaded onto your Emit, using the dropdown task bar select Washing
Machine Doctor icon. This will launch the multi-button box shown. Next select the ‘WM Doctor
Evo 2’ button to launch the main screen.
9

WASH DOCTOR EVO 2 – MAIN SCREEN
This screen will launch when the programme opens after selecting Wash Doctor Evo 2 button
10

WASH DOCTOR EVO 2 – MAIN SCREEN
Press ‘Connection’ and after a brief delay, details of the current appliance will be displayed.
11

WASH DOCTOR EVO 2 MAIN SCREEN
Main Screen
APPLIANCE DETAILS TEST COMPONENTS
TEST BUTTONS CONNECTION
12

MAIN SCREEN
APPLIANCE DETAILS
This area displays appliance details, option buttons, knobs and features. If the information displays correctly it indicates the
Eeprom and power board are ok. If it is incorrect then the Eeprom or power board will need to be replaced before tests can
be carried out.
TEST COMPONENTS
This area shows the various components the Wash Doctor software checks during the test.
CONNECTION
This area shows Connection port, Connection button, Statistics and Customer Info buttons. The Statistics of the test and the
Customers information can be saved using these buttons.
TEST BUTTONS
These buttons select either an Automatic test or Single item test. There is also a Stop Test button and an ‘item OK’ button
if required. The ‘Ko’ button is not applicable. In almost all cases, the Single and Automatic buttons are the only ones required
for testing.
13

USING THE SOFTWARE – SINGLE TEST
After you have a connection and establish the Eeprom and power board are correct in ‘Hardware Configuration’ section,
there are two ways to test components, Single (as shown above) or Automatic (shown on page 19) In this case, select the
item from the dropdown list.
14

USING THE SOFTWARE – SINGLE TEST
Press the ‘Single’ button and the software will check the component selected.
15

USING THE SOFTWARE – SINGLE TEST
A successful test result will display as shown. This confirms the item is ok. The result can be printed if required, but at
present this function is disabled.
16

USING THE SOFTWARE – SINGLE TEST
An unsuccessful test result will display as shown.
17

USING THE SOFTWARE – SINGLE TEST
If test is unsuccessful a Help File is available by clicking in the white area where the failure is listed. A separate box
appears with suggestions of possible faults.
18

USING THE SOFTWARE – AUTOMATIC TEST
To test all the components shown, simply select ‘Automatic’ and the programme will progress through components 1 to 21 as
applicable to the appliance. Leave all the boxes with ticks checked.
19

USING THE SOFTWARE – AUTOMATIC TEST
A successful test result will display as shown. This confirms the item is ok. The result can be printed if required, but at
present this function is disabled.
20
