Tesla RS0906H User manual

Product images are for illustrative purposes only and may differ from the actual product.
FRIDGE
RS0906H
User Manual
SLOHR SRBENG BiH/
CG

2
ENG
In the interest of your safety and to ensure the correct use,
before installing and first using the appliance, read this
user manual carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents, it is important
to ensure that all people using the appliance are
thoroughly familiar with its operation and safety features.
Save these instructions and make sure that they remain
with the appliance if it is moved or sold, so that everyone
using it through its life will be properly informed on
appliance use and safety.
For the safety of life and property keep to the precautions
of these user instructions as the manufacturer is not
responsible for damages caused by omission.
Children and vulnerable people safety
• This appliance can be used by children aged of 8
years and above and persons with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge if they have supervision or have been given
instructions concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children aged from 3 to 8 years are allowed to load and
unload this appliance.
• Children should be supervised to ensure that they do
not play with the appliance.
• Cleaning and user maintenance should not be done by
children unless they are aged from 8 years and above
and supervised.
• Keep all packaging well away from children. There is risk
of suffocation.
• If you are discarding the appliance pull the plug out
of the socket, cut the connection cable (as close to the
appliance as you can) and remove the door to prevent
SAFETY INFORMATION

3
ENG
playing children from suffering electric shock or closing
themselves in.
• If this appliance features a magnetic door seal to replace
an older appliance having a spring lock (latch) on the
door or lid, be sure to make that spring lack unusable
before you discard the old appliance. This will prevent it
from becoming a death trap for a child.
General safety
Keep ventilation openings, in the appliance enclosure or
in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use other electrical appliances (such as ice cream
makers) inside of refrigerating appliances, unless they are
approved for this purpose by the manufacture.
Do not touch the light bulb if it has been on for a long
period of time because it could be very hot.1
When positioning the appliance, ensure the supply cord
is not trapped or damaged.
Do not locate multiple portable socket-outlets or portable
power suppliers at the rear of the appliance.
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
• The refrigerant isobutene (R600a) is contained within
the refrigerant circuit of the appliance, a natural gas with
a high level of environmental compatibility, which is
nevertheless flammable.
• During transportation and installation of the appliance,
be certain that none of the components of the
refrigerant circuit become damaged.

4
ENG
- avoid open flames and sources of ignition
- thoroughly ventilate the room in which the appliance is
situated
• It is dangerous to alter the specifications or modify this
product in any way. Any damage to the cord may cause
a short circuit, fire and/or electric shock.
• This appliance is intended to be used in a household
and similar applications such as
- staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Any electrical components (plug, power cord,
compressor and etc.) must be replaced by a certified
service agent or qualified service personnel.
The light bulb supplied with this appliance is a “special
use light bulb” usable only with the appliance supplied.
This “special use lamp” is not usable for domestic
lighting.1
• Power cord must not be lengthened.
• Make sure that the power plug is not squashed or
damaged by the back of the appliance. A squashed or
damaged power plug may overheat and cause a fire.
• Make sure that you can come to the main plug of the
appliance.
• Do not pull the main cable.
• If the power plug socket is loose, do not insert the
power plug. There is a risk of electric shock or fire.
• You must not operate the appliance without the lamp.

5
ENG
• This appliance is heavy. Care should be taken when
moving it.
• Do not remove nor touch items from the freezer
compartment if your hands are damp/wet, as this could
cause skin abrasions or frost/freezer burns.
• Avoid prolonged exposure of the appliance to direct
sunlight.
Daily use
• Do not put hot things on the plastic parts in the
appliance.
• Do not place food products directly against the rear
wall.
• Frozen food must not be re-frozen once it has been
thawed out. 2
• Store pre-packed frozen food in accordance with the
frozen food manufacture, s instructions. 2
• Appliance, s manufactures storage recommendations
should be strictly adhered to. Refer to relevant
instructions.
• Do not place carbonated of fizzy drinks in the freezer
compartment as it creates pressure on the container,
which may cause it to explode, resulting in damage to
the appliance.2
• Ice lollies can cause frost burns if consumed straight
from the appliance.2
To avoid contamination of food, please respect the
following
instructions
• Opening the door for long periods can cause
a significant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in contact with

6
ENG
food and accessible drainage systems.
• Clean water tanks if they have not been used for 48h;
flush the water system connected to a water supply if
water has not been drawn for 5 days.
• Store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
• Two-star frozen-food compartments (if they are
presented in the appliance) are suitable for storing pre-
frozen food, storing or making ice-cream and making
ice cubes.
• One-, two- and three -star compartments (if they are
presented in the appliance) are not suitable for the
freezing of fresh food.
• If the appliance is left empty for long periods, switch off,
defrost, clean, dry and leave the door open to prevent
mount developing within the appliance.
Care and cleaning
• Before maintenance, switch off the appliance and
disconnect the main plug from the power socket.
• Do not clean the appliance with metal objects.
• Do not use sharp objects to remove frost from the
appliance. Use a plastic scraper. 2
• Regularly examine the drain in the refrigerator for
defrosted water. If necessary, clean the drain. If the
drain is blocked, water will collect at the bottom of the
appliance. 3
Installation
• For electrical connection carefully follow the instructions
given in specific paragraphs.
• Unpack the appliance and check if there are damages

7
ENG
on it. Do not connect the appliance if it is damaged.
Report possible damages immediately to the place you
bought it. In that case retain packing.
• It is advisable to wait at least four hours before
connecting the appliance to allow the oil to flow back in
the compressor.
• Adequate air circulation should be provided around the
appliance, lacking this leads to overheating. To achieve
sufficient ventilation, follow the instructions relevant to
installation.
• Wherever possible the spacers of the product should
be against a wall to avoid touching or catching warm
parts (compressor, con- denser) to prevent possible
burn.
• The appliance must not be located close to radiators or
cookers.
• Make sure that the main plug is accessible after the
installation of the appliance.
Service
• Any electrical work required to do the servicing of
the appliance should be carried out by a qualified
electrician or competent person.
• This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
Energy saving
• Do not put hot food in the appliance;
• Do not pack food close together as this prevents air
circulating;
• Make sure food does not touch the back of the
compartment(s);
• If electricity goes off, do not open the door(s);

8
ENG
• Do not open the door(s) frequently;
• Do not keep the door(s) open for a long time;
• Do not set the thermostat on exceeding cold
temperatures;
• All accessories, such as drawers, shelves balconies,
should be kept there for lower energy consumption.
1If there is a light in the compartment.
2If there is a freezer compartment.
3If there is a fresh-food storage compartment.
OVERVIEW
Note: Picture is for reference only.
Thermostat and light
Glass Shelf
Crisper
Leveling Foot
Door Balconies

9
ENG
REVERSE DOOR
Tool required: Philips screwdriver, Flat bladed screwdriver, Hexagonal spanner.
• Ensure the unit is unplugged and empty.
• To take the door off, it is necessary to tilt the unit backwards. You should rest the unit on something solid
so that it will not slip during the door reversing process.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• It’s better that 2 people handle the unit during assembly.
Remove the top right hinge cover. Move the core cover from left side to right side.
And then lift the upper door and place it on a
padded surface to prevent it from scratching.
Undo the screws.Then remove the hinge bracket.
Remove the top left screw cover.
1 4
5
3
Unscrew bottom hinge.Then remove the
adjustable feet from another side.
Unscrew and remove the bottom hinge pin with flat screw
drivers, turn the bracket over and replacethe pin.
6
screw
unscrew
2
Unscrew

10
ENG
INSTALLATION
Space Requirement
• Keep enough space of door open.
F F
F
A480
B450
C850
Dmin=50
Emin=50
Fmin=50
G960
H930
Refit the bracket fitting the bottom hinge pin.
Replace the adjustable foot.
8. Place the door back on. Ensure the door is
aligned horizontally and vertically so that the
seals are closed on all sides before finally
tightening thetop hinge.
9. lnsertthe hinge bracket and screw itto the top
of the unit.
10. Use a spannerto tighten itif necessary.
Put the hinge cover and the screw cover back.
711
910 812
Detach the Fridge and the Freezer door gaskets
and then attach them after rotating.

11
ENG
Levelling the unit
To do this adjust the two levelling feet at front of the unit.
If the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
Lenghten Shorten
Positioning
Install this appliance at a location where the
ambient temperature corresponds to the climate
class indicated on the rating plate of the appliance:
For refrigerating appliances with climate class:
• extended temperate: this refrigerating
appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C (SN);
• temperate: this refrigerating appliance is
intended to be used at ambient temperatures
ranging from 16 °C to 32 °C (N);
• subtropical: this refrigerating appliance is
intended to be used at ambient temperatures
ranging from 16 °C to 38 °C (ST);
• tropical: this refrigerating appliance is intended
to be used at ambient temperatures ranging
from 16 °C to 43 °C (T);
Location
The appliance should be installed well away
from sources of heat such as radiators, boilers,
direct sunlight etc. Ensure that air can circulate
freely around the back of the cabinet to ensure
best performance. If the appliance is positioned
below an overhanging wall unit, the minimum
distance between the top of the cabinet and the
wall unit must be at least 50 mm. Ideally, however,
the appliance should not be positioned below
overhanging wall units. Accurate leveling is
ensured by one or more adjustable feet at the base
of the cabinet.
This refrigerating appliance is not intended to be
used as a built-in appliance.
WARNING!
It must be possible to disconnect the appliance
from the mains power supply; the plug must
therefore be easily accessible after installation.
Electrical connection
Before plugging in, ensure that the voltage and
frequency shown on the rating plate correspond
to your domestic power supply. The appliance
must be grounded. The power supply cable plug
is provided with a contact for this purpose. If the
domestic power supply socket is not grounded,
connect the appliance to a separate grounder in
compliance with current regulations, consulting a
qualified electrician.
The manufacturer declines all responsibility if the
above safety precautions are not observed. This
appliance complies with the E.E.C. Directives.

12
ENG
DAILY USE
First use
Cleaning the interior
Before using the appliance for the first time,
wash the interior and all internal accessories with
lukewarm water and some neutral soap so as to
remove the typical smell of a brand new product,
then dry thoroughly
IMPORTANT! Do not use detergents or abrasive
powders, as these will damage the finish.
Temperature Setting
• Plug on your appliance. The internal
temperature is controlled by a thermostat. There
are 8 settings. 1 is warmest setting, 7 is the
coldest setting and 0 is to turn off the appliance.
• The appliance may not operate at the correct
temperature if it is in a particularly hot or if you
open the door often.
Daily use
Movable shelf
The shelf is able to be moved to suitable positions.
Positioning the door
balconies
In order to storage food or beverage with different
size, the door balconies can be placed at different
height. Follow below process to adjust the shelves.
• Step 1. pull the balcony to be free.
• Step 2. Select suitable position and press the
balcony to two convex plates until it is totally
blocked.
Vegetable Drawer
The draweris suitable for storing fruit and
vegetables. It can be pull out freely.
Thawing
Deep-frozen or frozen food, prior to be used, can
be thawed in a fridge compartment or at room
temperature. Place the frozen food in a dish or
bowl to avoid the flowing of condensate water
when thaw it in compartment.
Helpful hints and tips
Hints for fresh food refrigeration
To obtain the best performance:
• Do not store warm food or evaporating liquids
in the refrigerator
• Do cover or wrap the food, particularly if it has a
strong flavor
• Position food so that air can circulate freely
around it
Hints for refrigeration
Useful hints:
• Meat (all types): wrap in polythene bags and
place on the glass shelves above the vegetable
drawer.
• Cooked foods, cold dishes, etc...: these should
be covered and may be placed on any shelf.
• Fruit and vegetables: these should be
thoroughly cleaned and placed in the special
drawer(s) provided.
• Butter and cheese: these should be placed
in special airtight containers or wrapped in
aluminum foil or polythene bags to exclude as
much air as possible.
• Milk bottle: these should have a cap and should
be stored in the balconies on the door.
• Bananas, potatoes, onions and garlic, if not
packed, must not be kept in the fridge.
Cleaning
For hygienic reasons the appliance interior,
including interior accessories, should be cleaned
regularly.
CAUTION!
The appliance may not be connected to the mains
during cleaning. Danger of electrical shock! Before
cleaning switch the appliance off and remove the
plug from the mains, or switch off or turn out the

13
ENG
circuit breaker or fuse. Never clean the appliance
with a steam cleaner. Moisture could accumulate in
electrical components, danger of electrical shock!
Hot vapors can lead to the damage of plastic parts.
The appliance must be dry before it is placed back
into service.
IMPORTANT! Ethereal oils and organic solvents
can attack plastic parts, e.g. lemon juice or the
juice form orange peel, butyric acid, cleanser that
contain acetic acid.
• Do not allow such substances to come into
contact the appliance parts.
• Do not use any abrasive cleaners
• Remove the food from the freezer. Store them in
a cool place, well covered.
• Switch the appliance off and remove the plug
from the mains, or switch off the circuit breaker
or fuse.
• Clean the appliance and the interior accessories
with a cloth and lukewarm water. After cleaning
wipe with fresh water and rub dry.
• Accumulation of dust at the condenser
increases energy consumption. For this reason
carefully clean the condenserat the back of the
appliance once a year with a soft brush or a
vacuum cleaner1
• After everything is dry place appliance back into
service.
Replace the lamp
CAUTION!
Before replacing the lamp, shall disconnect the
appliance from mains power supply.
Lamp specification is listed in rating label.
Follow below process to replace the lamp:
1. Set the temperature regulation knob at number
“0” to switch off the appliance.
2. Unplug the appliance to make sure the
appliance is disconnected from main power
supply.
3. Remove the screw of the lamp cover.
4. Remove the lamp cover out by a flat screw
driver.
5. Unscrew the lamp by two fingers.
6. Fit new lamp according to the opposite
direction, then replace the lamp cover.
7. Plug in the appliance and regulate the knob to
right position.
Defrosting
The evaporator, however, will become
progressively covered with frost. This should be
removed. Never use sharp metal tools to scrape off
frost from the evaporator as you could damage it.
However, when the ice becomes very thick on the
evaporator, complete defrosting should be carried
out as follows:
• pull out the plug from the socket;
• remove all stored food, wrap it in several layers
of newspaper and put it in a cool place;
• keep the door open, and placing a basin
underneath the appliance to collect the defrost
water;
• when defrosting is completed, dry the interior
thoroughly replace the plug in the power socket
to run the appliance again.
1) If the condenser is at the back of appliance.

14
ENG
CAUTION!
Before troubleshooting, disconnect the power supply. Only a qualified electrician of competent person
must do the troubleshooting that is not in this manual.
IMPORTANT! There are some sounds during normal use (compressor, refrigerant circulation).
TROUBLESHOOTING
Problem Possible cause Solution
Appliance does not
work
Temperature regulation knob is set at
number “0”.
Set the knob at other number to
switch on the appliance.
Power plug is not plugged in or is loose Insert power plug.
Fuse has blown or is defective Check fuse, replace if necessary.
Socket is defective Socket malfunctions are to be
corrected by an electrician.
The food is too warm.
Temperature is not properly adjusted. Please look in the initial
Temperature Setting section.
Door was open for an extended period. Open the door only as long as
necessary.
A large quantity of warm food was placed
in the appliance within the last 24 hours.
Turn the temperature regulation
to a colder setting temporarily.
The appliance is near a heat source. Please look in the installation
location section.
Appliance cools too
much Temperature is set too cold.
Turn the temperature regulation
knob to a warmer setting
temporarily.
Unusual noises
Appliance is not level. Re-adjust the feet.
The appliance is touching the wall or
other objects. Move the appliance slightly.
A component, e.g. a pipe, on the rear of
the appliance is touching another part of
the appliance or the wall.
If necessary, carefully bend the
component out of the way.
If the malfunction shows again, contact the Service Center.

15
ENG
Environment Protection
This appliance does not contain gasses which could
damage the ozone layer, in either its refrigerant circuit or
insulation materials. The appliance shall not be discarded
together with the urban refuse and rubbish. The insulation
foam contains flammable gases: the appliance shall
be disposed according to the appliance regulations
which can be obtained from your local authorities. Avoid
damaging the cooling unit, especially the heat exchanger.
The materials used on this appliance marked by the
symbol are recyclable.
The symbol on the product or on its packaging
indicates that this product may not be treated as
household waste. Instead it should be taken to the
appropriate collection point for the recycling of electrical
and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences to the environment and human
health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed
information about recycling of this product, please
contact your local council, your household waste disposal
service or the shop where you purchased the product.
Packaging materials
The materials with the symbol are recyclable.
Dispose the packaging in a suitable collection container
to recycle it.
Disposal of the appliance
1. Disconnect the mains plug from the mains socket.
2. Cut off the mains cable and discard it.

16
ENG
WARNING!
During using, service and disposal the
appliance, please pay attention to symbol
similar as left side, which is located on rear of
appliance (rear panel or compressor) and with
yellow or orange color.
It’s risk of fire warning symbol. There are
flammable materials in refrigerant pipes and
compressor.
Please be far away fire source during using,
service and disposal.

17
ENG
PRODUCT INFORMATION SHEET
COMMISSION DELEGATED REGULATION (EU) 2019/2016
with regard to energy labelling of refrigerating appliances
Supplier's name or trademark: Tesla
Supplier's address: Tesla Electronics, Litijska 47, 1000 Ljubljana, SI
Model identifier: RS0906H
Type of refrigerating appliance:
Low-noise appliance: No Design type: freestanding
Wine storage appliance: No Other refrigerating appliance: No
General product parameters:
Parameter Value Parameter Value
Overall
dimensions
(millimetre)
Height 850
Total volume (dm³ or l) 90Width 480
Depth 450
EEI 125 Energy efficiency class F
Airborne acoustical noise
emissions (dB(A) re 1 pW) 39 Airborne acoustical noise emission class C
Annual energy consumption
(kWh/a) 107 Climate class: temperate, subtropical
Minimum ambient temperature
(ºC), for which the refrigerating
appliance is suitable
16
Maximum ambient temperature
(ºC), for which the refrigerating
appliance is suitable
38
Winter setting No
Compartment Parameters:
Compartment type
Compartment parameters and values
Compartment
volume
(dm³ or l)
Recommended
temperature
setting for
optimised food
storage (ºC)
These settings
shall not
contradict
the storage
conditions set
out in Annex IV,
Table 3
Freezing
capacity
(kg/24h)
Defrosting
type (auto-
defrost=A,
manual
defrost=M)
Pantry No - - - -
Wine storage No - - - -
Cellar No - - - -
Fresh food Yes 90,0 - - M
Chill No - - - -

18
ENG
0-star or icemaking No - - - -
1-star No - - - -
2-star No - - - -
3-star No - - - -
4-star No - - - -
2-star section No - - - -
Variable temperature
compartment - - - - -
For 4-star compartments
Fast freeze facility No
Light source parameters:
Type of light source LED
Energy efficiency class -
Minimum duration of the guarantee offered by the manufacturer: 24 months
Additional information:
Weblink to the manufacturer’s website, where the information in point4(a) Annex of Commission
Regulation (EU) 2019/2019 is found: tesla.info
Link to the EU EPREL database
The QR code on the energy label supplied with the appliance provides a web link to the registration
of this appliance in the EU EPREL database. Keep the energy label for reference together with the user
manual and all other documents provided with this appliance.
It is possible to find information related to the performance of the product in the EU EPREL database using
the link https://eprel.ec.europa.eu and the model name and product number that you can find on the
rating plate of the appliance.
For more detailed information about the energy label, visit www.theenergylabel.eu.

19
ENG

20
ENG
