INDRA Smart Series User manual

Indra Smart Range
Installation Guide
Be at the forefront of EV charging with
Indra’s pioneering technology

2 Indra Smart Range Installation Guide
Contents
Products in the Range 4
Smart PRO Tethered 4
Smart PRO Untethered 4
Smart LUX™ Tethered 5
General Description 5
General Warnings and Safety 6
Overview and Intended Use Environment 7
Smart Features 8
Boost 8
O-PEN Fault Detection 8
House Fuse Protection (Load Curtailment) 8
DC Leakage Protection 8
TariIntelligence9
SolarMode9
SmartScheduling9
Over-The-AirUpdates9
ChargeAnalytics9
Protective Earth, Simultaneous Touch (PESTs) Protection 10
General Installation Notes 12
Charger Layout 13
Smart LUX™ 13
Smart PRO 14
Pre-Installation Survey 15
Installation Procedure 16
Procedure 16
Switchgear 16
Choosing the charger location 17
Wall Mounting 17
Hanging the charger 18
Smart LUX™ storage hook 18

3
Cable Entry19
SmartLUX™19
Smart PRO 20
Connect Mains Cables 21
Smart LUX™ 21
Smart PRO 22
Installing a Reference Pin 23
Connectivity 24
Wi-Fi 24
Wi-Fi Pairing 25
Hardwired 26
4G 27
4G Pairing 27
External CT Clamp 28
Testing29
 ContinuityofProtectiveConductors     29
InsulationResistance(IR)29
Polarity29
 EarthElectrodeResistanceTesting     29
 EarthFaultLoopImpedance(EFLI)Verication   29
RCD Testing 30
Sealing the Unit 31
Commissioning 32
Customer Handover 33
Charger Familiarisation 33
Customer Support 33
Wire Cut Lengths 34
Troubleshooting 34
Meaning of 4G Dongle LEDs 32
Turbine Lights 33
What the LEDs on the charger mean 37

4 Indra Smart Range Installation Guide
Smart PRO Tethered
SmartPROType2(SPRFGTWG102)hasanIEC62196(Type2)6Mtetheredcharging
connectortobeusedwithType2socketttedEVs.
Products in the Range
Smart PRO Untethered
SmartPROType2Untethered(SPRFGSKWG103)hasan62196(Type2)socketaspartofthe
frontbody.

5
Smart LUX™
SmartLUX™TetheredhasanIEC62196(Type2)tetheredchargingconnectortobeusedwith
Type2socketttedEVs.
Itcomeswitheithera6mor10mtetheredleadandavarietyofcolouredfascias.
Symphony
Black
Elgar
Grey
Malvern
Stone
Indra
White
General Description
This manual describes the method of installation and hardware operation of the Indra Smart
Range, where the charger is a permanently installed electric vehicle charging solution for
resistivedomesticandcommercialloadsofatleast6Aandupto32Aat230V,50Hz.
Smart LUX™ Product Codes:
SMNFGT2WH401 Indra White, 6m
SMNFGT2WH402 Indra White, 10m
SMNFGT2BL401 Symphony Black, 6m
SMNFGT2BL402 Symphony Black , 10m
SMNFGT2GY401 Malvern Stone, 6m
SMNFGT2GY403 Malvern Stone, 10m
SMNFGT2GY402 Elgar Grey, 6m
SMNFGT2GY404 Elgar Grey, 10m

6 Indra Smart Range Installation Guide
General Warnings and Safety
• The Smart Range should only be installed and maintained by a suitably competent
 electricianwhohassuccessfullycompletedIndraproducttraining.Failuretocomply 
 willVOIDtheproductwarranty.
• The Smart Range is designed for permanent installation and should only be used
 withintheparameterssetoutinthetechnicalspecicationandontheproductlabel.
• The Smart Range should be installed in accordance with the extant wiring regulations
 (BS7671).
• Use of an upstream O-PEN protection device is NOT permitted with Indra Smart
 Range.UseofsuchdeviceswillVOIDthewarranty.
• Before commencing installation or maintenance, the electrical power supply MUST be
 safelyisolated.
• The Smart Range should be installed in a location that is structurally sound and free
 fromexcessivevibration,dust,orothermaterialbuildupthatcouldaect  
 normaloperation.

7
Overview and Intended Use Environment
IndraSmartRangecanbeclassiedasa‘smart’electricvehiclechargingsolutionbecause
of the communications infrastructure which allows charging to be remotely optimised by
the Indra App; where charging can take place when electricity is cheapest; or if immediate
chargingisrequired,its‘Boost’functionalityoverridesanysmartgridcriteriaandprovides
instantaneouschargingcapability.
ChargingusingIndraSmartchargerscantakeplaceatupto7.4kW,butduetomodulation
capability(measuredbytheexternalCTclamp)thispoweroutputlevelcanalsobereduced.
The Smart Range are intended for both indoor and outdoor installation, securely mounted to
awallorappropriatelypedestal.
In its operating environment, the temperature must be between -20°C and 50°C, with
humiditybetween10%to85%non-condensing.
The supply to the charger should be 230V AC +10/-6%, 50HZ and rated >=32A for maximum
chargingcapacity.

8 Indra Smart Range Installation Guide
Indra Smart Features
Boost
Fundamental function of the charger that enables the user to charge the car when the
chargerisoine,ortooverrideanysetschedules.Thisfunctionismostoftenusedwhenthe
userneedsthecarchargedearlierthannormal.
House Fuse Protection (Load Curtailment)
Is a function that allows an EV charger to be installed at a property that may not have
enoughsparecapacitytoaccommodatethechargeralwaysrunningatfullpower.
It works by monitoring the amount of power the installation is using via an external CT
clampandcomparingthattotheratingofthemaincut-outsupplyingtheinstallation.Ifthe
dierenceisgreaterthan32Athenthechargerwilloerfullcharge.Ifthedierenceisless
than32Athenthechargerwillonlyoerasmuchpowerasthereissparecapacityonthe
maincut-out.
Note:G100.2deneshowloadcurtailmentismanaged.Ifthechargerisconguredtouse
load curtailment and it loses contact with the external CT clamp, then the charger will
de-rateitspoweroutputto6Atoprotectthemaincut-out,thus6Aisthegurethatshould
beconsideredwhencarryingoutthemaximumdemandsurvey.
DC Leakage Protection
AnRDC-DDisttedintoIndraSmartchargers,oering6mADCleakageprotection.This
meanstheyshouldbeinstalledwithaTypeAortypeFRCDupstream.
O-PEN Fault Detection
IndraSmartRangehavebuilt-inO-PENprotectionintheformofIndra’spatentedPESTs.This
oersmultipleoptionstocomplywiththePENfaultregulations,includingLinetoNeutral
Voltagemonitoring(PESTmodeB)andCPCtotrueearthvoltagemonitoring(PESTmodeA).
(FormoreinformationseethePESTssection).

9
Over-The-Air Updates
TheSmartRangecanbeupdatedviaaninternetconnectiontothecharger.Theseupdates
canoerimprovementstothefunctionofthecharger,pre-emptivexesforidentied
issues,orcanbeusedtorectifyfaultsiftheyoccur.
Tari Intelligence
This feature enables the customer to tell the charger what electricity costs them and when,
thechargerwillchargethecaratthecheapesttimes.Thisfeatureisalsocompatiblewithall
timeofusetarisincludingagile.
Solar Mode
This mode can be selected in the Indra App and can enable the customer to use any excess
solarenergy(oranyotherformofmicro-generation)tochargetheircar.
TheexternalCTmonitorshowmuchenergyisbeingexportedfromtheinstallation.Ifthe
installationisexportingmorethan1.4KW,thenthechargerwilloerthecaracharge.
(1.4KWistheminimumamountofpowerrequiredforanin-carchargertoacceptacharge).
Note: The external CT clamp can only measure what energy is being exported back to the
grid, therefore, if the micro-generation is generating 2KW, and the installation is using 1KW,
thechargerwillonlydetecttheremaining1KWbeingexportedtothegrid.Thismeansthe
chargerwillnotoerachargetothecarbecausethereisn’tenoughpowertotriggerthe
in-carcharger(1.4KW).Exporttothegridneedstobe1.4kWorgreaterbeforethecarwill
beoeredcharge.
Smart Scheduling
Smart scheduling allows the user to create a schedule window - this is when the charger will
start and stop charging - but also, how many miles to add, how many kWh to add or how
muchmoney’sworthofenergytoaddtothecar.
Charge Analytics
TheIndraAppoerstheuserdetailedinformationaboutthebehaviouroftheirchargerand
their charging history, including how much money they have spent, how many miles have
beenaddedtothecarandoverallusage.

10 Indra Smart Range Installation Guide
PEN Fault, Earthing, Simultaneous Touch
(PESTs) Protection
The Smart Range PESTs solution can operate under three of the indents of BS7671:2018
A1:2020+A2:2022;section722.411.4.1.Forthepurposesofdesign/installationwehavetwo
modesofoperationwhichIndracallA&B.ModeAcanbeconguredwithorwithouta
referencepin.ThesafestinstallationcongurationismodeAwithreferenceelectrode.
Mode A with reference pin – (Compliant to BS7671:2018, regulation 722.411.4.1, Indent
iii)
ThismethodmonitorsthevoltagedierencebetweenCircuitProtectiveConductor(CPC)
andtrueearth,disconnectingthecarfromthechargerintheeventofthevoltagedierence
risingabove30Vrms.ItalsomeasuresthevoltagebetweenL,N&CPCbetween184v-257.6v
(230v+/-12%).
What it means:
•  Removestheriskofnuisancetrippingduetosupplyvoltageuctuations(e.g.voltage
spikes due to energy export to the grid),
• Compliant install on a 3-phase supply,
• Prevents potentially dangerous voltages from occurring on the car chassis under
any circumstances,
• Removes simultaneous touch risks between the charger/connected car and conductive
 partsconnectedviaTT(e.g.lamppost).
Mode B – (Compliant to BS7671:2018, regulation 722.411.4.1, Indent iv)
Monitors the L-N voltage and will disconnect from the car if the voltage goes out of range
(253V-207V).ProtectedMultipleEarth(PME)isusedastheCPC,andnoearthrodor
referencepinisrequirediftherearenosimultaneouscontactortouchvoltageriskspresent.
Consideration should be given to nuisance trips where the line to neutral voltage may exceed
253V,especiallywherelocalrenewablesarepresent.
Mode A without reference electrode
Usedforinstallationsthatdonotfallundertherequirementsof722.411.4.1E.g.TT
installations; installations where the charger and car will be indoors when charging;
installations where PME is bonded to Earth in accordance with BS7671:2018; regulation
722.411.4.1,Indentii.

11

12 Indra Smart Range Installation Guide
General Installation Notes
WARNING: FAILURE TO COMPLY WITH THESE INSTRUCTIONS COULD PRESENT A HAZARD
A. TheIndraSmartRangemustbeinstalledbyaqualiedelectricianwhohascompleted
 IndraAcademyTraining.Anyservicingortamperingbyanon-qualied
 professionalelectricianWILLvoidthewarranty.
B. ReadtheseinstructionsfullybeforeinstallinganIndrasmartcharger.
C. ThepowersupplyMUSTbeisolatedandcheckedfordeadbeforeinstallation  
 ormaintenance.
D. TheIndraSmartRangechargersaredesignedforpermanentinstallationandis 
suitable for operation on an AC electricity supply having the same voltage and current
 ratingasshownontheproductlabel.
E. Thechargersshouldbeinstalledinaccordancewithextantwiringregulations.
F. ThechargerMUSTNOTbettedalongsideanupstreamprotectiondevicewhich 
 claimstomeetident(iv)ofBS7671:2018+A1:2020+A2:2022;section722.411.4.1.
Voltage upstream PEN Fault protection and curtailment devices may damage the
 devicethroughfrequentremovalofthegridsupplyunderload.
WARNING:Protectionagainstelectricshockshallnotbeautomaticallyreset.
G. ThechargerMUSTbeconnectedtoCPC(eithersuppliedfromaPMEorTTearth).
H. TheinstallationlocationMUSTbestructurallysoundandMUSTNOTbesubjectto 
 excessivedust,vibration,lint,orothermaterialbuild-upwhichcouldaect
 thecharger’sproperoperation.
I. Thecustomershouldhaveagreedtothepositionofthechargerandanyadditional 
 enclosures,andcablerouting.

1
2
3
4
5
CT Connections
Wireless Dongle
USB & RJ45
Live Neutral REF CPC
PESTs Mode Switch
1
2
35
4
13
Charger Layout - Smart LUX™

1
2
3
4
5
CT Connections
Wireless Dongle
USB & RJ45
Live Neutral REF CPC
PESTs Mode Switch
1
2
4
5
3
14 Indra Smart Range Installation Guide
Charger Layout - Smart PRO

Pre-Installation Survey
Before installing an Indra smart charger, we recommend surveying the installation to
ensure that an install can go ahead and that the charger is appropriate for the customers’
requirements.
This survey should include:
• IdentifytheearthingarrangementofthepropertyandtherequiredPESTmode.
•  Ifareferenceelectrodewillberequired,identifyasuitablelocationforit.
• Establish the maximum demand of the existing installation and compare this with the
 ratingofthemaincutoutsupplyingtheproperty.Ifthereislessthan32Acapacity 
 remaining,thentheLoadCurtailmentfeatureonthechargerwillberequired.  
you should account for a load of 6A for the charger when load curtailment is
 beingused.
• If Load Curtailment or Solar Mode is required by the customer, establish where the
 externalCTwouldbeplaced.
• Identifywhichconnectivitymethodwouldbemostappropriate.
•  EnsureWi-FiandCellularnetworksignalstrengthissucientforthefunctionofthe 
 charger.Required4Mb.
• Identifyasuitablelocationforthecharger,withagreementfromthecustomer.
15

Installation Procedure
Indrasmartchargersaresuppliedwiththegeneralscrewsandwallxingsthatarerequired
topermanentlyxtheminposition.However,itremainstheresponsibilityoftheinstallerto
evaluatethesuitabilityoftheinstallationsurfaceandusetheappropriatexing.
Procedure
• All parts of the existing installation that will comprise part of the EVSE charging
circuit, must be inspected for damage, be suitably rated and compliant with
 theappropriateregulations.
• Ensure the installation earthing conductors are tested and compliant with BS
 7671:2018A1:2020+A2:2022.
WARNING: ANY DAMAGED OR UNSUITABLE CABLES OR EQUIPMENT MUST BE REPLACED
• Inspect the charger to ensure it has not been damaged in transit and is safe
 toconnect.
16 Indra Smart Range Installation Guide
Switchgear
IndrasmartchargersrequireanupstreamtypeAorFRCDtobetted.
Indra recommend installing the following equipment upstream to minimise potential
nuisancetrippingandtoensurecompliancewithBS7671:2018A1:2020+A2:2022section722.
(Theserequirementscanbemetinwhatevercongurationsuitsyourdesign).
a) Type A 30ma Double Pole RCD protection
b) C Curve 40A Overcurrent protection
InaccordancewithBS7671:2018A1:2020+A2:2022Regulation443.4.1asurgeprotection
device will need to be installed to protect the charger unless the customer has signed a
waiveracknowledgingtheyaccepttheriskofanypotentialdamagecaused.

Wall Mounting
Note: Thexingholesinthebracketarespacedtomeetstandardbricksizessotheycanall
fallwithinabrickcentre.
• Oerthemountingbracketagainstthesurfaceyouintendtoxtoandlevelusinga 
 spiritlevel.
• Markanddrillfourholeswitha6mmdrillbit(Masonry/5mmPlasterboard).
• Securetothewallwithfourxings.
17
Choosing the Charger Location
• Select an installation location that ensures future servicing of the Indra Smart
 charger,wherethebackplatecanbemountedushtoaatwallandscrewscanbe 
 usedtopermanentlysecurethechargerinposition.
• Makesuretheinstalllocationwillnotallowanyammablematerialtocomewithin 
 100mmoftheunit.
• Thecontrolpaneloftheunitshouldbeinstalledbetween0.75m-1.20mfrom  
 theground.
• The charger should be placed such that the potential risk of tripping over trailing
 chargingleadsisminimisedasfarasreasonablypracticable.

Hanging the charger
• Holdthetopofthechargerjustabovethewallbrackettiltedupwardsawayfromthe 
 wall.
• Lower the charger onto the two prongs at the top then hinge the charger back
 ushwiththebracket.
• Secure the charger to the bracket with the 4x8mm button head T20 Torx screws into
 thebottomofthechargerwithaT20screwdriver.Torquesetting2.0-2.5N/m.  
Carefully remove the front of the charger and hinge it to the side to allow access, the
front body is secured to the main body to protect the ribbon cable to the
 frontpanelPCB.Donotremoveordetatch.
Figure 1: Smart LUX™ Wall Mounting Figure 2: Smart PRO Wall Mounting
Smart LUX™ Storage Hook
TheSmartLUX™StorageHookshouldbettedincloseproximitytothechargertoenable
thetetheredchargingcabletobestowedonit.
ThecablehookshouldbesecuredwiththesuppliedxingsasperFigure3
Figure 3: Cable Storage Hook
18 Indra Smart Range Installation Guide

Figure 4: Smart LUX™ Cable Entry
19
Cable Entry - Smart LUX™
The Smart LUX™ is designed with two cable entries in the bottom edge and one in the rear
(IdentiedinblueonFigure4).
• Allcableentrypointsaredesignedfora25mmhole.
• Installa25mmIP68ratedglandforthecableidentiedinthecircuitdesign.

Figure 5: Smart PRO Cable Entry
All swarf and shavings should be removed from the charger and the hole deburred.
Cable Entry 2
Cable Entry 1
20 Indra Smart Range Installation Guide
Cable Entry - Smart PRO
The Smart PRO is designed with four cable entry points, two in the bottom edge and two in
therear(IdentiedinblueonFigure5).
• Cableentrypoint1isdesignedfora25mmhole.
• Cableentrypoint2isdesignedfora20mmhole.
• Therearentrypointsaredesignedfora25mmhole.
• InstalltheappropriatelysizedIP68glandforthecableused.
