Induction Dynamics SolidDrive SD1 Operating manual

INDUCTION DYNAMICS®
INSTALLATION & USE GUIDE
for SolidDrive SD1 into wood, laminate,
and composite surfaces
INDUCTION DYNAMICS®True Audio PerfectionTM
Experience True
Audio Perfection
Induction Dynamics extensive
line of audio products makes
it easy to create the ultimate
audio system, regardless of
installation requirements.
Induction Dynamics builds
these products with only the
most select components and
materials; and utilizes numerous
unique and proven technologies.
TM

The SolidDrive SD1 can be installed directly to
wooden surfaces to deliver high-quality sound. Even
if your existing offices or conference rooms aren’t
wired for audio, the SolidDrive SD1 provides a
convenient solution and installs underneath desks,
counter tops and conference room tables so the sound
source is not visible.
When using the SolidDrive SD1 for a wooden surface
be sure to order it without the mounting bracket
which is for in-wall and in-ceiling installations only.
The oversized mounting base on the SolidDrive SD1
allows it to be screwed directly to the underside of
furniture. For maximum output each SolidDrive
channel should have available at least 20 squarefeet
of surface area.
The SolidDrive SD1 should be surface mounted with
the oversized mounting base facing the mounting area.
The mounting base is the audio output side opposite the
label. For surfaces made of wood, laminates, and
composites the SolidDrive SD1 should be screwed
directly to the surface.
Once you have determined where to mount the
SolidDrive SD1 use the appropriate length wood
screws to attach it securely to the surface. The best
mounting location is typically out of sight on the
underside or back of desks, counter tops, conference
tables or other office/home furniture. The four
pre-drilled mounting holes on the SolidDrive SD1
oversized mounting base will hold wood screws as
large as #9.
Some installations may require that pilot holes be
drilled into the surface material due to it’s hardness
especially if larger, course thread screws are used.
Figure1. Mounting the SolidDriveSD1 to a table
INSTALLATION OF SOLIDDRIVE
SD1 ON WOOD, LAMINATE,
AND COMPOSITE SURFACES
By utilizing these three basic installation steps,
you can install the SolidDrive SD1 on wood,
laminate, and composites on desks, counter
tops, conference room tables and other porous
surfaces.
Getting Started with SolidDrive
What’s included with the SolidDriveSD1 for
installation on wooden surfaces
ASolidDrive SD1 consists of:
One (1) SolidDrive SD1 unit and attached wiring
harness with Eurostyle connector. *No additional
mounting materials areneeded.
For wooden surfaces: The SolidDrive SD1 is
designed with an oversized mounting base which is
pre-drilled for mounting to wood surfaces.
*Installation requires four (4) wood screws up to
#9 (supplied by the installer).
s
STEP 1. Mount the SolidDrive SD1 to wood,
laminate, and composite surfaces.

Make the electrical connection between the SolidDrive
SD1 and the speaker cable using the Eurostyle connector
attached to the end of the SolidDrive SD1 audio cable.
The polarity of the wiring is clearly indicated (Figure 2).
The surface material plays a key role in the system’s
sound performance. To ensure an optimal listening
experience the installer MUST equalize the SolidDrive
SD1 system. Equalization is accomplished by using the
SolidDrive Wood Passive Equalization Module or using
the auto equalization featureavailable on some
receivers. *Additional information about the
SolidDrive Drywall Passive Equalization Module can
be found on the back cover of this guide.
INSTALLATION IS NOW COMPLETE – ENJOY THE
SOLIDDRIVE SD1 SOUND SYSTEM
Now that you’ve completed the installation process
and equalization, you can enjoy the True Audio
Perfection of the Induction Dynamics SolidDrive
SD1 sound system.
HIGH OUTPUT INSTALLATIONS
For installations requiring high output, such as a large
conference table or other high output type applications,
two SolidDrive SD1’s should be used for each of the
high output channels. For example the left, right, and
center channel of a home theater or the left and right
channels of a high output stereo system. The two
SD1’s should be wired in series for each of the high
output channels (Figure 3). For maximum output each
SolidDrive channel should have available at least 20
square feet of surface area.
STEP 2. Make the electrical connections.
Figure 3. SolidDrive SD1’s wired in series for high output installations
STEP 3. Equalize the SolidDriveSD1 sound system
Figure 2. Eurostyle connector

www.inductiondynamics.com / www.soliddrive.com
8650 College Boulevard •Overland Park, KS 66210 •TEL: [phone] •FAX: [phone]
INDUCTION DYNAMICS®True Audio PerfectionTM
Type Full Range Transducer
Impedance 8 Ohm
Frequency Response (Hz) 70 Hz to 15 kHz
Recommended Amplifier Power 10 – 100 Watts
Dimensions 2.28" Diameter x 2.08" Height
Mounting Plate 3.5'' Diameter
Weight 1.2 lb. / .54 kg
SolidDrive SD1 Specifications
Connector Type Eurostyle
Wire Size 16 guage
Dimensions 1.0" H x 2.875" W x 2.0" D
Weight .27 lb. / .12 kg
SolidDrive Wood Passive
Equalization Module Specifications
SolidDrives, SolidDrive Subwoofers, and A4
Amplifier come with a 7-year warranty.
SOLIDDRIVE WOOD PASSIVE EQUALIZATION
MODULE
The SolidDrive Drywall Passive Equalization Module
increases the system’ssound performance for optimal
listening enjoyment by using notch filters to correct
peaks in the frequency response. Use one (1) module
with each SolidDrive SD1.
WARRANTY
The product is guaranteed for 7 years from date of purchase. Any misuses
or modifications to this equipment in any way will void the warranty.
WARNING
Read instructions prior to operating. To reduce the risk of fire or electric
shock, do not expose this product to rain or moisture. Unplug prior to
cleaning and clean with a damp cloth. There are no user-serviceable parts
in this product, please refer all servicing to qualified personnel.
TM
