5
Tighten the harness
Pull the shoulder straps upwards to
remove the slack from the lap sections
of the harness then pull the adjuster
strap until the harness is fully tightened.
Check the harness adjuster and tighten
each time the child is placed in the seat.
Loosen the harness
4.4 Adjust and use the harness
The harness is slackened by pressing
the adjuster (under the adjuster cover)
on the front of the seat.Press down the
adjuster as you grip the two shoulder
straps with your another hand. Pull the
shoulder straps towards you to loosen
the harness.
4.3 Usage of buckle
Step1 Step2 Step3
Firstly ,adjust the shoulder straps height ,please proceed as follows:
Step1.
Step2. Slot the two buckle connectors into the slot in the buckle until
you hear click .
Step3. Check the harness is correctly locked by pulling the shoulder
straps upwards.s
To release the harness ,you can press the red button of the buckle
downwards, the two metal sections will be pop up .
“ ”
Put the two metal sections of the buckle connector together.
4.5 Adjust the child seat to different incline positions
The child seat
f the seat upwards, and then pull or push the seat forwards or
backwards. Release the positioning handle in the desired position
and push it until you hear “click”.
Check to make sure the child seat is securely locked in the
desired position by pulling the positioning handle.
can be adjusted to 3 different positions: position 1,
position 2 and position 3. If installed rearward-facing(group 0+), only
the position 3 can be used. Pull the positioning handle under the front
o
Important:
As is shown in the picture,the
headrest can be adjusted to any
position in order to adapt to the
height of children. as is shown by
the picture, hold the headrest
handle up and down to adjust the
headrest, at the same time the
left and right flank will follow
it.,ensure that the headrest is
located in the position that is
suitable for the child's height.
4.6 Adjust the headrest
6
MODIFICADO 37320160314.pdf 1 05/07/16 16:31
20200228 REV3 LB373 Maya GUIDE.indd 620200228 REV3 LB373 Maya GUIDE.indd 6 11/05/2020 12:2611/05/2020 12:26

20200228 REV3 LB373 Maya GUIDE.indd 720200228 REV3 LB373 Maya GUIDE.indd 7 11/05/2020 12:2611/05/2020 12:26

20200228 REV3 LB373 Maya GUIDE.indd 820200228 REV3 LB373 Maya GUIDE.indd 8 11/05/2020 12:2611/05/2020 12:26

20200228 REV3 LB373 Maya GUIDE.indd 920200228 REV3 LB373 Maya GUIDE.indd 9 11/05/2020 12:2611/05/2020 12:26

20200228 REV3 LB373 Maya GUIDE.indd 1020200228 REV3 LB373 Maya GUIDE.indd 10 11/05/2020 12:2711/05/2020 12:27

9
Step3:
Thread
the lap belt through the two
belt guides of the child seat
base. Make sure the tip of the
belt guide hook points to the
blue label.
Clip the diagonal belt
into the same side belt guide
hooks of the child seat .
Step4: Insert the diagonal
belt together with lap belt into
car seat belt buckle, hear
“click”. Check the car seat
belt buckle is correctly locked
by pulli n g t h e s e a t b e l t
upwards.
1 0
Click
Step5: Place your child into the child
seat. Chec k the height of th e
shoulder straps on the correct
position and fasten the buckle.
lso check
that the cover is not impeding the
movement or fit of the harness in
any way .
Check that the harness has not
become twisted and a
5 2 This child seat can be used with the harness for children 9kg to 25kg in
weight (group ), installed forward facing using a three-point lap and
diagonal seat belt .
.
-
To disassemble the child seat, repeat the above prescribed
procedures in reverse order.
Step1: Place the child seat on
the car seat forward-facing
a n d m a k e s u r e t h a t the
backrest of the child seat is
firmly pressed against the car
seat backrest.
Step2:
Thread the lap belt through the
two belt guides of the child seat
base. Make sure the tip of the belt
guide hooks point to the red label.
Clip the diagonal belt into
the belt guidehook of the backrest.
Step3: Insert diagonal belt and
lap belt into car seat belt buckle,
hear “click”.Check the car seat
belt buckle is correctly locked
by pulling the seat belt upwards.
Step4: Place your child into the
child seat. Check the height of the
shoulder straps on the correct
position and fasten the buckle.
lso check
that the cover is not impeding the
movement or fit of the harness in
any way .
Check that the harness has not
become twisted and a
To disassemble the child seat, repeat the above prescribed
procedures in reverse order.
cilC k
