Infineon Technologies EVAL-C101T-IM231 User manual

User manual Please read the Important Notice and Warnings at the end of this document <Revision 1.0>
www.infineon.com <2019-07-30>
AN2019_09 EVAL
-C101T-IM231 User manual
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T-T038 and IM231-L6S1B
About this document
Scope and purpose
This user manual provides an overview of the evaluation board EVAL-C101T-IM231 including its main features,
key data, pin assignments and mechanical dimensions.
EVAL-C101T-IM231 is an evaluation-board as part of the evaluation design platform for motor drive based on
iMOTION™2.0 IMC100 Series. This board features and demonstrates Infineon’s advanced Motion Control Engine
(MCE) technology for permanent magnet motors drive over the full speed range. In the same time it features
and demonstrates Infineon’s CIPOSTM Micro IPM technology for motor drive.
The evaluation board EVAL-C101T-IM231 was developed to support customers during their first steps designing
applications with running any permanent magnet motor via sensor-less sinusoidal control.
Intended audience
This user manual is intended for all technical specialists working with the EVAL-C101T-IM231 board under
laboratory conditions.
Table of Contents
About this document ....................................................................................................................... 1
Table of Contents ........................................................................................................................... 1
1 Safety precautions ......................................................................................................... 2
2 Introduction .................................................................................................................. 3
3 Main features ................................................................................................................ 4
3.1 Key data ................................................................................................................................................... 5
3.2 The relationship between IO and FPWM for EVAL-C101T-IM231................................................................ 8
3.3 Setting up the system.............................................................................................................................. 8
3.4 System debug process ............................................................................................................................ 9
3.5 MCEWizard setup overview ................................................................................................................... 10
3.6 MCEDesigner setup overview ................................................................................................................ 13
4 Pin assignments ........................................................................................................... 15
5 Schematics and Layout .................................................................................................. 16
5.1 EMI filter circuit ...................................................................................................................................... 16
5.2 Inverter section using CIPOSTM Micro IPM............................................................................................. 17
5.3 IMC101T-T038 Schematic Overview ..................................................................................................... 18
5.4 Auxiliary power supply .......................................................................................................................... 19
5.5 Inverter over current protection circuit................................................................................................ 19
5.6 PCB Layout ............................................................................................................................................ 20
6 Bill of Materials of EVAL-C101T-IM231 ............................................................................. 22
7 Reference .................................................................................................................... 25
Revision History ............................................................................................................................ 26

User manual 2 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Safety precautions
1 Safety precautions
In addition to the precautions listed throughout this manual, please read and understand the following
statements regarding hazards associated with development systems.
Table 1 Precautions
Caution: The ground potential of the EVAL-C101T-IM231 system is biased to a negative DC
bus voltage potential. When measuring voltage waveform by oscilloscope, the scope’s
ground needs to be isolated. Failure to do so may result in personal injury or death, and
equipment damage. Darkened display LEDs are not an indication that capacitors have
discharged to safe voltage levels.
Caution: EVAL-C101T-IM231 system contains DC bus capacitors which take time to
discharge after removal of the main supply. Before working on the drive system, wait
three minutes for capacitors to discharge to safe voltage levels. Failure to do so may
result in personal injury or death. Darkened display LEDs are not an indication that
capacitors have discharged to safe voltage levels.
Caution: Only personnel familiar with the drive and associated machinery should plan or
implement the installation, start-up and subsequent maintenance of the system. Failure
to comply may result in personal injury and/or equipment damage.
Caution: The surfaces of the drive may become hot, which may cause injury.
Caution: The EVAL-C101T-IM231 board contains parts and assemblies sensitive to
electrostatic discharge (ESD). Electrostatic control precautions are required when
installing, testing, servicing or repairing this assembly. Component damage may result if
ESD control procedures are not followed. If you are not familiar with electrostatic control
procedures, refer to applicable ESD protection handbooks and guidelines.
Caution: An incorrectly applied or installed drive can result in component damage or
reduction in product lifetime. Wiring or application errors such as undersized motor,
incorrect or inadequate DC supply, or excessive ambient temperatures may result in
system malfunction.
Caution: Remove AC input cable or turn off AC power supply. Wait three minutes after
removing power from the power drive to discharge the bus capacitors. Do not attempt to
service the drive until the bus capacitors have discharged to zero. Failure to do so may
result in personal injury or death.
Caution: The EVAL-C101T-IM231 board is shipped with packing materials that need to be
removed prior to installation. Failure to remove all packing materials which are
unnecessary for system installation may result in overheating or abnormal operating
condition.

User manual 3 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Introduction
2 Introduction
The EVAL-C101T-IM231 evaluation board is an evaluation design platform for complete inverter-controlled
motor drive applications based on iMOTIONTM2.0 chipset. As a form factor board for motor drive it contains
Controller (IMC101T-T038) and inverter (with CIPOSTM Micro IPM). The evaluation platform can easily be
debugged through the MCEDesigner and MCEWizard during customer first designing applications with
IMC101T-T038.
This evaluation board is designed to give comprehensible solutions of sensor-less control of permanent
magnet motors over the full speed range. It provides a single-phase AC-connector, rectifier, DC-link, controller
(with sensor less field oriented control), 3-phase output to motor. It is single shunt for current sensing and a
voltage divider for DC-link voltage measurement.
The EVAL-C101T-IM231 evaluation board is available from Infineon. The features of this board are described in
the design feature chapter of this document, whereas the remaining paragraphs provide information to enable
the customers to copy, modify and qualify the design for production according to their own specific
requirements.
Environmental conditions were considered in the design of the EVAL-C101T-IM231. The design was tested as
described in this document but not qualified regarding safety requirements or manufacturing and operation
over the whole operating temperature range or lifetime. The boards provided by Infineon are subject to
functional testing only.
Evaluation boards are not subject to the same procedures as regular products regarding Returned Material
Analysis (RMA), Process Change Notification (PCN) and Product Discontinuation (PD). Evaluation boards are
intended to be used under laboratory conditions by specialists only.
Figure 1 shows the evaluation board EVAL-C101T-IM231. This evaluation board includes an EMI filter and
IMC101T-T038 controller, Flyback power supply to provide 15V and 3.3V, and the CIPOSTM Micro IPM – IM231-
L6S1B.
Figure 1 Evaluation board of the EVAL-C101T-IM231

User manual 4 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
3 Main features
EVAL-C101T-IM231 is a complete evaluation board including IMC101T-T038 controller and a 3 phase Micro IPM
for motor control application. The kit demonstrates Infineon’s motion control IC and IPM technology for motor
drives.
The evaluation board characteristics are:
• Flat design
• All components are SMD and only placed on the top side
• Complete evaluation board for running any permanent magnet motor via sensor-less sinusoidal control
• Input voltage 160~265 VAC
• Maximum 180 W (with heatsink and FPWM=6kHZ) motor power output
• On board EMI filter
• Current sensing with single shunt
• Flyback power supply with 15 V, 3.3 V
• Over current protection
• Sensing of DC-link voltage
• Fault diagnostic output
• PCB is 130×110mm and has two layers with 35μm copper each
• RoHS complaint
Applications:
• fridge compressor
• Small home appliances
• Pumps
Main features of Motion Control IC (IMC101T-T038) are:
• MCE (Motion Control Engine) as ready-to-use solution for variable speed drives
• Field oriented control (FOC) for permanent magnet synchronous motor (PMSM)
• Space vector PWM with sinusoidal commutation and integrated protection features
• Current sensing via single or leg shunt
• Sensorless operation
• Various serial communication interfaces (UART, I2C, SPI)
• Multiple motor parameter support
• 3.3 V (default) or 5 V VDD power supply
• Flexible host interface options for speed commands: UART, I2C, SPI, PWM or analog signal
• Support for IEC 60335 (‘Class B’)
• Scalable package options

User manual 5 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Main features of CIPOSTM Micro IPM-IM231-L6S1B are:
• 600 V 3-phase inverter including gate drivers & bootstrap function
• Low VCE(sat) TRENCHSTOP™ IGBT6
• Temperature monitor
• Accurate overcurrent shutdown (±5%)
• Fault reporting and programmable fault clear
• Advanced input filter with shoot-through protection
• Optimized dv/dt for loss and EMI trade offs
• Open-emitter for single and leg-shunt current sensing
• 3.3 V logic compatible
• Isolation 2000 VRMS, 1min
3.1 Key data
Figure 2 provides a typical application Block Diagram using the IMC101T-T038 with single shunt current sensing.
The IMC101T-T038 provides a built-in closed loop sensorless control algorithm using the unique flexible Motion
Control Engine (MCE) for permanent magnet motors. The MCE™ consists of a collection of control elements,
motion peripherals, a dedicated motion control sequencer and internal memory to map internal signal nodes.
IMC101T-T038 also employs a unique single shunt current reconstruction circuit in addition to leg shunt current
sensing circuit to eliminate additional analog/digital circuitry.
M
EMI Filter
&
FUSE
HVIC
CoolSET For
AUX Power
Supply
CIPOS
TM
Micro IPM
Line
Neutral
IMC101T
-T038
Inverter PWM
15V
3.3V
UART interface to Front Panel
V
BUS
C
BUS
Shunt Sensor
Earth
U
V
W
V
BUS
Figure 2 Typical Application Block Diagram of Evaluation Board with Single Shunt Current Sensing

User manual 6 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Figure 3 provides pinout of the IMC101T-T038. The following drawings give the position of the functional pins
for the available packages.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
IMC101T
T038
(Top View)
HALL1/AIN4
VDC
IV/AHALL2-
REFV/AHALL2+/AIN7
REFU/AIN8
ISS/IU
VSS
VDD
PWMUL
PWMUH
PWMVL
PWMVH
PWMWL
PWMWH
17
18
19 20
21
22
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
TX0
RX0
GPIO9
DUTYFREQ
VDD
VSS
PAR2/GPIO4
PAR1/GPIO3
GPIO8
GPIO7
DIR/GPIO6
PAR3/GPIO6
HALL2/AIN3
IW/AHALL1-/AIN2
REFW/AHALL1+/AIN1
VSP/AIN0
NTC/AIN10
PARAM/HALL3/AIN11
LED
GK
TX1
PAR0/GPIO2
PGOUT
RX1
Figure 3 Pinout of IMC101T-T038
Note: Refer to the datasheet for more detailed specifications of the pin type. Those pins with generic
naming (GPIO) can be used via scripting.
Note: Figure 4 provides Internal Electrical Schematic of the IM231-L6S1B micro IPM. Refer to data sheet of
the IM231-L6S1B for more detail information.
Figure 4 Internal electrical schematic

User manual 7 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Table 2 depicts the important specifications of the evaluation board EVAL-C101T-IM231.
Table 2 EVAL-C101T-IM231 board specifications
Parameters Values Conditions / comments
Input
Voltage 220VAC Lower AC input, less motor power
output(with Heatsink)
Current 1.9ARM
At 220 VAC input, Ta=25°C,
1THS=80°C,FPWM=6kHz(with
Heatsink)
Output
Power(3 phases) 180W
At 220 VAC input, Ta=25°C,
THS=80°C，FPWM=6 kHz(with
Heatsink)
Phase Current 1.1ARMS
At 220 VAC input, Ta=25°C,
THS=80°C, FPWM=6 kHz(with
Heatsink)
Thermal Resistance
Rthca 10.7℃/W Heatsink Thermal Resistance
without Fan
DC Bus Voltage
DC Bus voltage 310 V Input 220VAC
DC Bus voltage Ripple 30 V CBUS=55uF @output power=180W
DC Bus Scaling 8.29 counts/v DC Bus sense Scaling
Current feedback
Inverter Current sensing resistors
RS1 100 mΩ Single shunt
Inverter Current Op-amp
Configuration Inverting
Inverter Current Op-amp Gain 2.65
IMC101T-T038 Resolution 12-bit
Latency 1 PWM cycle
Protections
3-phase output current trip level 2
3.9
A
peak
Configured by the resistors R41
Temperature trip level Tc=100 °C Only valid for CIPOSTM with built in
NTC
IMC101T-T038 internal current trip
level 0.875V Refer to MCEWizard Question 80
On board power supply
15V 15V+/-2% For CIPOSTM IPM driver
1 THS indicates the temperature of the heatsink’s base.
2 For iMOTION™ IC IMC1xx, there are three types of Gatekill Input Source (Refer to section 5.5 or control board user manual for detail).
Please note that, if select comparator for Gatakill Input Source, the external Gatakill signal will be not used. And the leg I_Shunt will
be compared by the internal comparator with the “Gatekill Comparator Reference” value set in MCEWizard only.

User manual 8 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Parameters Values Conditions / comments
3.3V 3.3V+/-2% For IMC101T-T038 power supply,
Protection circuits
PCB characteristics
Material FR4, 1.6mm thickness
Copper thickness = 1oz (35um)
Dimension 130mmx110mm PCB Size
System environment
Ambient temperature 25°C
3.2 The relationship between IO and FPWM for EVAL-C101T-IM231
Figure 5 the picture is showing the relationship between IO (3 phase output current) and PWM Frequency, The
curves can be used as a reference to output current capability of the evaluation board when you use it.
Figure 5 The relationship between Output Current and PWM Frequency
Note: Tc measurement point refer to datasheet (section 11.1) of the IM231-L6S1B
3.3 Setting up the system
In order to run this evaluation board, the iMOTION™ Software Tools MCEDesigner and MCEWizard are also
required initially setup the system, as well as to control and fine-tune the system performance to match users
exact needs. Refer to 3.4 as well as MCEWizard and MCEDesigner documentation for more information.
6, 1.5
10, 1.17
15, 0.97 20, 0.92
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
0 5 10 15 20 25
Io Amp
fs kHZ
I
o
& F
PWM
@Tc=100
℃,Rthca=10.7℃/W For EVAL-C101T-IM231

User manual 9 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Figure 6 points out the functional groups on the top side of the EVAL-C101T-IM231 evaluation board.
Figure 6 Functional groups of the EVAL-C101T-IM231 evaluation board’s top side
3.4 System debug process
The user needs to assemble all the external hardware and ensures that all the connections are intact (includes
AC-Line connector, iMOTIONTM Link Tool and motor 3-phase output connector) When users get this EVAL-
C101T-IM231 evaluation board, then they can start trying to run the motor system. By default the user’s
evaluation board has been burned in the software to IMC101T, please execute the step2 directly. Otherwise,
take the step1 and step2.
The iMOTION™ Development Tool installers for MCEDesigner and MCEWizard are available for download via
Infineon iMOTIONTM website http://www.infineon.com/iMOTION. All supported tools and software variants are
listed there. Please visit this page periodically to check for tool/software updates.
1.
J1
-
AC Line connector
2. EMI filter
3. Rectifier
4. J3 - Motor phase connector
5. Fly back power supply
6. IMC101T-T038 controller
7. CIPOSTM Micro IPM IM231-
L6S1B
8. J2 - iMOTIONTM Link
connector
9. Inverter shunt resistor
1
2
3
4
5
6
7
8
9

User manual 10 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Figure 7 the picture is showing the application system connection.
Figure 7 System connection indication
STEP1: Download Firmware to IMC101T
(1) Connect iMOTIONTM Link to J2.
(2) Power on system.
(3) Use MCEDesigner program firmware to IMC101T’s internal SRAM.
(4) Power off system.
Note: The firmware version for IMC101T is from the Infineon website. http://www.infineon.com/iMOTION
STEP2: Tuning Motor
(1) Keep the iMOTIONTM Link Tool connect to J2.
(2) Use MCEWizard calculates motor hardware parameters and generate the parameters file (.txt).
(3) Power on system.
(4) Use MCEDesigner to program the parameters file (.txt) to the iMOTIONTM controller.
(5) Start running motor system.
3.5 MCEWizard setup overview
After installing the MCEWizard, the shortcut for MCEWizard appears on the Windows desktop. Double click the
shortcut to open the MCEWizard and configure the parameters for evaluation boards or motor. Figure 8 shows
the “Welcome Page” for MCEWizard, where the MADK control board or power board can be selected through
the pull-down list. Infineon keeps releasing new MADK controller and power boards. Therefore, it could happen
that some of the newest power boards are not pre-configured in the MCEWizard tool and cannot be selected
through the pull-down menu. In that case, the user should select any other power board (as similar as possible)
and follow the MCEWizard setup steps by entering the parameter values which are specific to the chosen board.
Make sure both “I have modified the circuit board” and “Enable advanced question” checkmarks are selected.
Please refer to the User Manual of the corresponding power board for additional information.
Motor Phase
Output
s

User manual 11 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
After selecting the MADK control and the power board, start the MCEWizard system setup procedure by clicking
the “Next” button in the right bottom corner as shown in Figure 8.
Figure 8 Welcome Page of MCEWizard
iMOTION™ MADK system enables users to easily test different combination of control and power board with
their motors. User should be familiar with the system level parameters which are related to the motor used.
There are very limited numbers of parameters which are specific to the control board or power board hardware.
Table 3 provides the MCEWizard setup overview for hardware related parameters. Similar tables will be
available in each power board’s User Manual. Combination of this table and the corresponding table of the
power board provides enough information to setup the MADK-based motor drive system in shortest time.
Table 3 MCEWizard setup overview table
Page Parameter Value Comment
Welcome Page Power Board selecting MADK power board name If no, select EVAL-M1-
05-65D to modify
Options Page Motor 1 Shunt Configuration 100mΩ Single shunt
Hall Sense Configuration Refer to the Motor Parameters None Hall by default
Script Function Options Enable or Disable Disable by default
Question 3 Controller Supply Voltage 3.3V
Question 19 Max DC Bus Voltage 420V
Question 23 DC Bus Sensing High Resistor 2MΩ
Question 24 DC Bus Sensing Low Resistor Refer to control board user manual 13.3kΩ by default
Question 63 GateSense Low-Side Devices High is true High is true by default
Question 64 GateSense High-Side Devices High is true High is true by default
Script Edit
Page
Script Configuration ADC pin and GPIO pin Configuration Refer to the “Script
For MCE 2.0 User
Guide”

User manual 12 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
Page Parameter Value Comment
Script Coding Script File Operation and Script
Text Edit
Refer to the
“Reference Manual”
and the “Application
Guide”
Note: Please refer to the following link for more detailed information about Edit Script File.
1. Reference Manual: Page 44-58:2.5 Script Engine
-Infineon MCESW RM UM v01_01 EN.pdf
2. Application Guide
-Infineon AN2018 27_How_to_Use_iMOTION_Script_Language AN
After all the MCEWizard questions are answered, the “Verify & Save Page” will be shown as in Figure 9
Figure 9 Verify and Save page for MCEWizard
Click “Calculate” button and “Export to Designer File (.txt)” button to save the parameter file which will be used
by the MCEDesigner in the next steps.

User manual 13 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
3.6 MCEDesigner setup overview
After installing MCEDesigner installer, there is a shortcut for MCEDesigner on Windows desktop. Double click
the shortcut to open MCEDesigner and then open “IMC101T_xx.irc” file.
Figure 10 MCEDesigner’s Main Display for EVAL-M1-101T
To program system drive parameters into IMC101T-T038, please click “Tools” menu and select “Programmer”
in the pull down list. The pop-up window “Program IMC controller” will show up as in Figure 11. Click on the
“Program Parameters” radio button (this is the default option), and then select the Drive System Parameter file
created using MCEWizard by clicking on “Browse”. Finally, click on the “Start” button to program the parameter
file into the IMC101T-T038 IC.
Figure 11 “Program IMC Controller” pop-up window
After Drive System Parameter file has been programmed into IMC101T controller, and the motor drive system is
powered, the MCEDesigner can be used to start/stop the motor, display motor current traces, change the motor

User manual 14 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Main features
speeds, modify drive parameters and many other functions. Please refer to the MCEDesigner documentation
for more details.
To program new firmware and Drive System Parameter into IMC101T-T038, please click “Tools” menu and
select “Programmer” in the pull down list. The pop-up window “Program IMC controller” will show up as in
Figure 12. Click on the “Program Firmware and Parameter” radio button, and select the Drive System
Parameter file created using MCEWizard by clicking on the “Browse” button on the row of “Program Parameter
File”, and then select the firmware file by clicking on the “Browse” button on the row of “Program Firmware
File”. Finally, click on the “Start” button to program the parameter file into the IMC101T-T038 IC.
Figure 12 Program Firmware and Parameter in “Program IMC Controller” pop-up window
Note: All latest firmware file for different type of iMOTIONTM control ICs are available for download via
Infineon iMOTIONTM website http://www.infineon.com/iMOTION.

User manual 15 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Pin assignments
4 Pin assignments
General information about the connectors of the EVAL-C101T-IM231 evaluation board is described below.
Table 4 provides the pin assignments of the J2.
Table 4 J2-iMOTION Link interface
S. No. Pin Details
1 TXD0 Output, Transmit data from IMC101T
2 RXD0 Input, Receive data to IRMCF188
3 +3.3V On board 3.3 V supply
4 GND Ground
5 GND Ground
6 +3.3V On board 3.3 V supply
7 RXD1 Input, Receive data to IMC101T
8 TXD1 Output, Transmit data from IMC101T
Table 5 provides the pin assignments of the AC line connector J1.
Table 5 J1- AC Line connector
S. No. Pin Details
1 L
AC line input(160 V
~
265 V)
2 N AC neutral input
3 EARTH Earth ground
Table 6 denotes the details of the motor side connector J3.
Table 6 J3-Motor side connector
S. No. Pin Details
1 U
Connected to motor phase U
2
V
Connected to motor
phase V
3 W
Connected to motor phase W

User manual 16 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Schematics and Layout
5 Schematics and Layout
To meet individual customer requirements and make the EVAL-C101T-IM231 evaluation board a basis for
development or modification, all necessary technical data like schematics, layout and components are
included in this chapter.
5.1 EMI filter circuit
Figure 13 depicts the schematic from the AC line input connector J1 to the rectified DC bus voltage. This
circuitry includes a passive EMI filter consisting of elements CX1, CX2, L1, CX3, CX4, CY1 and CY2. D1, D2, D3, D4
rectifier block, and reducing conduct loss in steady state.
Figure 13 The schematic for AC/DC section and EMI of the EVAL-C101T-IM231 evaluation board
CX1 4.7nF 250VAC SMD
R3
1Mohm 1/2W 1%
1
10
5 6
L1
WE744290321 3.25A 0.32mH-SMD
CX3 4.7nF 250VAC SMD
CY2
470pF 250VAC SMD
CY1
470pF 250VAC SMD
EARTH
EARTH
F1
3A 250V SMD
L
N
EARTH
J1
WE691709710303-SMT
CX2
4.7nF 250VAC SMD
CX4 4.7nF 250VAC SMD
CS3K 3A 800V-DO214AB
D4
D3
D2
D1

User manual 17 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Schematics and Layout
5.2 Inverter section using CIPOSTM Micro IPM
Inverter section are implemented using the CIPOSTM Micro IPM as sketched in Figure 14. The CIPOSTM module
includes 600 V 3-phase inverter including gate drivers & bootstrap function, and low VECTRENCHSTOPTM IGBT6.
The three capacitors C20, C27 and C32 are used as bootstrap capacitors to provide the necessary floating
supply voltages VBS1, VBS2 and VBS3 respectively.
Figure 14 The schematic of 3-phase inverter section using CIPOSTM Micro IPM on the EVAL-C101T-
IM231 evaluation board
VB1
2
VCC2
8
HIN1
4
HIN3
14
LIN3
15
LIN2
10
LIN1
5
COM
1
LO
HO
VB
VS
COM
VCC
HIN
LIN
VS2/V
21
V+
17
VCC1
3
VR1
19
VR2
20
VB3
12
HIN2
9
VS1/U
18
VS3/W
23
VTH
11
VB2
7
VR3
22
VCC3
13
LO
HO
VB
VS
COM
VCC
HIN
LIN
LO
HO
VB
VS
COM
VCC
HIN
LIN
RFE
6
ITRIP
16
U5 IM231-L6S1B
C11
10nF 630V
C12
10nF 630V
C20 2.2uF 25V
C27 2.2uF 25V
C32 2.2uF 25V
C28 1uF 25V
C34 1uF 25V
C23 1uF 25V
GND
GND
GND
GND
U
V
W
W
V
U
1
2
3
J3
WE691709710303-SMT
RS3 100mohm 2W 1%
GND
VCC
VCC
VCC
PWMUH
PWMUL
PWMVH
PWMVL
PWMWH
PWMWL
C38
1nF 16V
GND
ITRIP
VTH
GK
DCBUS
Isense+

User manual 18 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Schematics and Layout
5.3 IMC101T-T038 Schematic Overview
Figure 15 shows the schematic of EVAL-C101T-IM231 evaluation board with IMC101T-T038 controller.
Figure 15 The schematics for the EVAL-C101T-IM231 evaluation board

User manual 19 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Schematics and Layout
5.4 Auxiliary power supply
Figure 16 depicts the schematic of the auxiliary power supply available on the EVAL-C101T-IM231 board. The
circuit includes the latest CoolSET 5 of Infineon and fly back topology, directly output 15V and 3.3V. VCC is
connected to the gate drivers inside the CIPOS™ IPM.
Figure 16 Power supply section of the EVAL-C101T-IM231 evaluation board
5.5 Inverter over current protection circuit
Figure 17 shows the Inverter over current protection circuitry. The open collector output of comparator U7 is
pulled up to 3.3V by resistor R42.
Figure 17 Inverter section over current protection circuit of the EVAL-C101T-IM231 evaluation board
The comparator threshold can be set through the voltage divider provided by resistors R41 and R43. By default
for single shunt application, R41 is 7.5kΩ and R43 is 1KΩ.
Itrip_Inverter=.∗ Ω
.ΩΩ
 Ω =3.9A
12
3 4
SFH617A-3X007
U3
Vin Vout
GND
U1
IFX1117-ME V33
E6
6.3V 100uF 5*5.5 SMD
E5
10V 220uF 6*7.7 SMD
E4
25V 220uF 8*10.5 SMD
E3
25V 220uF 8*10.5 SMD
E7 25V 100uF 8*6.5 SMD
C1 4700pF 100V
C4
10uF 10V
C7
1nF 16V
C5 10uF 10V
C2
1nF 630V 68k 1/4W
R9
15M 1/4W
R10
15M 1/4W
R14
15M 1/4W
R18 4R7 1/10W
R15
R19
0ohm 1/8W 1%
48.7K 1/10W 1%
R16
R20
1.5Kohm 1/8W 1%
R7 510kohm 1/4W 5%
SS2H10-E 2A/100V
D5
BYS10-45-E3/TR3-1.5A/45V
D7
US1M-E3/61T-1A/1000V
D6
C9
2.2nF 16V
GND
GND
9.76K 1/10W 1%
R23
VCC
+3.3V
SGND VCC
820R 1/10W 1%
R24
C8
220nF 16V
C6
1000pF 16V
SGND
+6V
Drain 6
VIN 1
Drain
7
NC
9
GATE
10
VCC
11
GND
12
Drain 5
VERR 2
FB 3
CS 4
Drain
8
U2
ICE5GR4780AG
R22
62Kohm 1/4W 1%
C10
0.1uF 25V
5.1R 1/4WRS1
GND
3M 1/4W
R11
3M 1/4W
R13
3M 1/4W
R17
22K 1/10WR21
+15V
SGND
1
2
3
4
5
6
7
10
9
T1
EPC13 5-5 SMT
DCBUS
ZD1
MMSZ5251B-7-F-22V 500mW
D8
DIO FRD 700mA 200V
L2
2.2uH 2.5A SMD
R25
510Kohm 1/8W 1%
U4
TL431DBZR
C42
10uF 25V
C43
10uF 25V
C39
4700pF 16V
C41
10uF 16V
R41 7.5Kohm 1/8W 1%
C40
4700pF 16V
R44 1Kohm 1/8W 1%
R42
1Kohm 1/8W 5%
+3.3V
GND
GND
R43 1Kohm 1/8W 1%
3
1
4
5 2
U7
LM397
VCC
GND
ITRIP: [(3.3V * 1/ 8.5)+0.005] / 0.1= 3.9A peak
ITRIP
Isense+

User manual 20 <Revision 1.0>
<2019-07-30>
EVAL-C101T-IM231 User manual
Motor Drive Evaluation Board Based On IMC101T
-
T
038 and IM231
-
L6S1B
Schematics and Layout
5.6 PCB Layout
The layout of this board can be used for different voltage or power classes of power board. The PCB has two
electrical layers with 35µm copper by default and its size is 130 mm × 110 mm. The PCB board thickness is
1.6mm. Get in contact with our technical support team to get more detailed information and the latest Gerber-
files.
Figure 18 illustrates the top assembly print of the evaluation board.
Figure 18 Top overlay print of the EVAL-C101T-IM231 evaluation board
Figure 19 depicts the bottom assembly print of the evaluation board.
Figure 19 Bottom overlay print of the EVAL-C101T-IM231 evaluation board
